Creative Lighting Solutions 114000 User manual

CLS Manuals
CLS Power Strip
www.cls-led.com
Version 1.0 August 2011
www.cls-led.com
- 1 - - 2 -
CLS Power Strip
INDEX
Index 2
Introduction 3
Available CLS Power Strips 3
Included items 3
Optional accessories 3
Safety information 3
Installation 4
How to connect the extension set 5
Wiring diagrams 6
Measurements 10
Specifications 10
List of symbols 11

www.cls-led.com
CLS manuals
CLS Power Strip
- 3 - - 4 -
Included items
The CLS Power Strip is shipped in one package containing the following items:
• 10 x CLS Power Strip
• 1 x user manual
Optional accessories
• 114200 CLS Power Strip connectioncable 100 cm
• 114210 CLS Power Strip extensioncable set 5-100 cm
• 707037 CLS LDV-45 DMX LED dimmer 4 channels 5Amp 12V-24V output
• 872012 CLS Dimmer Covelight 10-100% input 10-30V output 12V/140W 24V/280W
• 706995 CLS BT20.24 LED power supply 24VDC 20VA 85-264VAC
• 707011 CLS BT45.24 LED power supply 24VDC 45VA 85-264VAC
• 707012 CLS BT75.24 LED power supply 24VDC 75VA 85-264VAC
• 707013 CLS BT120.24 LED power supply 24VDC 120VA 85-264VAC
• 707014 CLS BT240.24 LED power supply 24VDC 240VA 85-264VAC
Note: It is important to read this manual before you install this product.
SAFETY INFORMATION
Warning! This product is for professional use only, not for domestic use.
Read this manual before powering up or installing the CLS Power Strip. Follow the instructions
listed below and observe all warnings in this manual.
INTRODUCTION
The CLS Power Strip is the perfect solution for shelf lighting, furniture, displays, high power cove lighting and
numerous other applications. The CLS Power Strip is dimmable and has an very high light output.
Available CLS Power Strips:
• 114000 CLS Power Strip 3000K, warm white standard version, 120º
• 114010 CLS Power Strip 2700K, extra warm white standard version, 120°
• 114020 CLS Power Strip 4000K, neutral white standard version, 120º
Protection from electric shock
• Disconnect the power supply from AC power before installing, dismounting or maintaining the product.
• Make sure all connectors are connected properly.
• Use only a source of AC power that complies with local building and electrical codes and has both
overload and ground-fault protection.
• Do not expose the unit to rain or moisture.
• Refer all service to a qualified technician.
INSTALLATION
Installing the CLS Power Strip has never been easier. The Power strip contains 3 mounting holes so no profile or
mounting clips are nessecary. Due the 'plug and play' connector only a single click is needed to connect 1 Power
Strip to another Power Strip.
Protection from burns and fire
• Provide a clearance of at least 50 mm around the unit.
• Do not install the product near a heat source.
• Do not install the product in a corrosive, flammable or explosive area.
• Do not modify the product, or install other than genuine parts.
• Do not operate the product if the ambient temperature exceeds 40 oC.
• Do not stare into the LED, this can cause damage to the eyes.
• Operate in a well-ventilated area.
Protection from injury due to falls
• Verify that all covers and mounting hardware are securely fastened.
• Block the access below the work area whenever installing or removing the product.
Mounting holes
100 cm cable
Note: Screw headsize max. ø 6 mm.
With extensioncable set (# 114210). Mounting hole

www.cls-led.com
CLS manuals
CLS Power Strip
- 5 - - 6 -
HOW TO CONNECT THE EXTENSIONCABLE SET
100 cm cable
# 114210 CLS Power Strip extensioncable set
5 mm
1 2
b
3
b
4
b
100 cm cable
# 114210 CLS Power Strip extensioncable set
5 mm
1 2
b
3
b
4
b
1. The CLS Power Strip extensioncable set.
Suitable for installing the Power Strip
around a corner.
2. Cut the wire to the desired length.
b. Strip the harnes for ± 5 mm.
3. Connect the - (black) wire in the - socket.
Connect the + (red) wire in the + socket.
b. Tighten the screws of both sockets.
4. Connect the assembled plug on the last
Power Strip before the corner.
b. Connect the plug on the first Power Strip
around the corner. Your installation with
the extensioncable set is now complete.
BT power supply, not dimmable
293 mm (w)
CLS Power Strip
connectioncable 100 cm
# 114200
CLS BT Power supply CLS Power Strip
# 114000 / 114010 / 114020
Max. 3 pcs. of Power Strip on a BT 20.24 LED power supply
Max. 7 pcs. of Power Strip on a BT 45.24 LED power supply
Max. 12 pcs. of Power Strip on a BT 75.24 LED power supply
Max. 20 pcs. of Power Strip on a BT 120.24 LED power supply
Max. 40 pcs. of Power Strip on a BT 240.24 LED power supply
Max. 14 pcs. of Power Strip in one line
WIRING DIAGRAMS

www.cls-led.com
CLS manuals
CLS Power Strip
- 7 - - 8 -
BT power supply, dimmable
293 mm (W)
CLS Power Strip
extensioncable set 5-100 cm
# 114210
CLS Power Strip
# 114000 / 114010 / 114020
CLS Dimmer Covelight
10-100% input 10-30V
output 12V/140W 24V/280W
# 872012
60 mm
60 mm
Max. 14 pcs.of Power Strip in one line
Max. 3 pcs.of Power Strip on a BT 20.24 LED power supply
Max. 7 pcs.of Power Strip on a BT 45.24 LED power supply
Max. 12 pcs.of Power Strip on a BT 75.24 LED power supply
Max. 20 pcs.of Power Strip on a BT 120.24 LED power supply
Max. 40 pcs.of Power Strip on a BT 240.24 LED power supply
CLS BT power supply 24V/48V

www.cls-led.com
CLS manuals
CLS Power Strip
- 9 - - 10 -
24 VDC
CLS Power Strip connectioncable 100 cm # 114200
CLS Power Strip # 114000 / 114010 / 114020
CLS LDV-45 DMX LED dimmer 4 chanels # 707037
Max. 3 pcs.of Power Strip on a BT 20.24 LED power supply Max. 7 pcs.of Power Strip on a BT 45.24 LED power supply Max. 12 pcs.of Power Strip on a BT 75.24 LED power supply Max. 20 pcs.of Power Strip on a BT 120.24 LED power supply Max. 40 pcs.of Power Strip on a BT 240.24 LED power supply
Max. 14 pcs.of Power Strip in one line
LDV-45 DMX LED dimmer 4 chanels, dimmable
MEASUREMENTS
293 mm
5,5 mm
16 mm
96,5 mm 96,5 mm 48 mm48 mm
ø 3,1 mm ø 3,1 mm ø 3,1 mm
TECHNICAL SPECIFICATIONS
LEDs: Cree MX-6
Available colours: Neutral white, 4000K, warm white 3000K, extra warm white 2700K
Beam angle: 120º
Power supply: 24 VDC
Power consumption: Max. 6 Watt
Housing: Aluminum strip
Measurements: 5,5 x 293 x 16 mm (hxwxd)
Weight: 34 gr
Ambient temperature: -10 ºC till +40 ºC
120º
Max.
6 Watt
3000K4000K
Aluminum
strip
Cree
6 x
24
VDC
34 gr 2700K

www.cls-led.com
CLS manuals
CLS Power Strip
- 11 - - 12 -
Multiple connection
Daisychain connectivity
Installation depth
In centimeters
Swivel
Fixture is horizontally rotatable,
indicated in degrees
Swivel
Fixture is vertically rotatable,
indicated in degrees
Mounting hole
In centimeters
Application area
Indoor or outdoor
Application area
Floor, wall or ceiling
Protection class
One, two or three
Cable length
Maximum cable attached
to the fixture in centimeters
Lifespan
Of the light source in hours
Driver
Inclusive or exclusive
Pressure
Maximum pressure on
the fixture in kg/cm2
Weight
In grams/kilograms
Curve
Minimal bending curve
in centimeters
LED pitch
Pitch between the
LEDs in millimeters
Power supply
In VAC, VDC or milliAmpere
Power consumption
In VA or Watt
IP value
Ingress Protection classifies the
degrees of protection provided
against the intrusion of the product
Housing
Housing material
Cutting length
Indicated by the
cutting marks
DMX channels
Numbers of DMX channels
on a product
LEDs
Kind of LED used in the
fixture
50 cm
Lenses
Availble lenses,
indicated in degrees
Plug & play
Easy connection using the
SmartConnect system
Colour temperature
White in different Kelvin values;
Cold white, neutral white, warm
white or extra warm white
Colour
Available colours;
Amber, blue, red or green
Colour changing
RGB, RGB-W or RGB-A
DMX input
Fixture works on DMX512
protocol
Combined product
Compose your own fixture
Warranty
3 years warranty on the product
Energy label
Conformité Européenne
CE marking for free marketability of
industrial goods within the EU
54º 8º 12 x 50º
Luxeon
1 x
3000K 2700K
6300K 4000K
DMX
512
A
Max.
700 mA
Max.
3 Watt
100~240
VAC
100~240
VDC
Max.
20 VA
IP40
Aluminum
Brushed
RGB-W
RGB RGB-A
LIST OF SYMBOLS
2007 CLS-LED BV. All rights reserved. Information subject to change without notice, CLS-LED BV and all affiliated companies disclaim liability for
injury, damage direct or indirect loss, consequential or economic loss or any other loss occasioned by the use of, inability to use or reliance on the
information contained in this manual. No part of this manual may be reproduced, in any form or by any means, without permission in writing from
CLS-LED BV. Other legal information can be found in our General conditions to be found on the back of your CLS-LED BV invoice or on our website
www.cls-led.com/conditions.pdf
