Kendall Howard 1918-3-004-F User manual

Page | 1
Save These Instructions for Future Reference
The Answer is Yes! What’s the Question?™
Installation Instructions
Part Number 1918-3-004-F
For Your Safety
Read and understand the entire manual before installing
48” POWER STRIP
®

Save These Instructions for Future Reference
Dimensional Drawing
Specifications
Dimensions
48.25” W X 1.86 D X 2” H
Weight
6 lb.
Outlets
16
Power cord length
14”
Surge protection
1,060 Joules
Circuit protection
15 amps
Color
Gray
Page | 2

Save These Instructions for Future Reference
Component Identification
What’s Included?
48” Power Strip (1) Accessory Bar Mount Bracket (2)
Part Number KH-3500 Part Number KH-2501
10-32 x 2” Pan Head Screw (2) 10-32 x 2.25” Pan Head Screw (2)
Part Number HW-PHS-005 Part Number HW-PHS-013
Power Strip Frame Bracket (2) 3/8-16 x 1.5” Button Head Screw (4)
Part Number KH-3502 Part Number HW-1017
3/8-16 x 1-5/8” Channel Nut (4)
Part Number HW-CN-001
Tools Needed:
Phillips screwdriver, standard hex wrench set, level
Page | 3

Save These Instructions for Future Reference
Installation Instructions
If mounting to an accessory bar (Figure 1):
Step 1:
Place the accessory bar mounting brackets onto each end of the accessory bar approximately
44” on center apart, secure bracket with the provided 10-32 x 2” screws.
Step 2:
Determine which directing the power cable need to be routed, place the power strip into the
brackets and install the provided 10-32 x 2.25” screws.
If mounting direct to 48” workbench uprights (Figure 2):
Step 1:
Loosely thread both provided button head screws through mounting bracket and into channel nuts.
Insert channel nuts into upright channel.
Step 2:
Determine which directing the power cable need to be routed and insert one end of the Power
Strip into the mounting bracket.
Step 3:
Install opposite end into clamp, check if mounts are level, fully tighten hardware.
Figure 1
Figure 2
