Creative WCU90D User manual

MLK-I-05-0*-0001
User s Guide Rev.:1.0
热键科技（深圳）有限公司
MLK Industries (ShenZhen)Limited 第1页共1页
制作：曹新伟 日期： 20030531
User sGuide
Of
WCU90D WirelessOptical MouseAnd
Multimedia Keyboard COMBO Set
(Primary)
Note:
This device complies with Part15 of the FCC rules. Operation is subject tothe following two conditions:
(1) This devicemaynotcause harmfulinterference, and
(2) This devicemust acceptanyinterference received, including interferencethatmaycause undesired operation.
Caution:
Themanufacturerisnot responsiblefor anyradioor TVinterference causedbyunauthorizedmodifications to this
equipment. Such modifications couldvoid the user authority to operatetheequipment.
REV : 1.00
Prepared byMLK TechnologiesLimited
28. May.2003

MLK-I-05-0*-0001
User s Guide Rev.:1.0
热键科技（深圳）有限公司
MLK Industries (ShenZhen)Limited 第2页共2页
制作：曹新伟 日期： 20030531
Informationin this documentis subjecttochangewithoutnoticeanddoes net represent acommitment on thepartof
Creative Technology Ltd.Nopartof this manual maybereproducedor transmittedin anyformor byany
means,electronicor mecharical,including photocopying and recording,foranypurpose withoutthe written pemissionof
Creative TechnologyLtd.Thesoftwaredecribedin this document isfurmished under alicenseagreement and maybe
used or copiedonlyin accordance whitthetemsof thelicenseagreement.It is against the lawto copy the softwareon any
othermedium.except as specifically allowed inthelicense agreement,The licenseemay makeone copyofthe software
for backuppurposes.
Copyright 2002CreativeTechnologyLtd.All rights reserved.
Version 1.0
May2003
TheCreative logo is a registeredtrademark of Creative Technology Ltd.in United States and other courtries.
Microsoft MS-DOS,andWindowsare registeredtrademarks of Microsoft Corporation.Allrights reserved.All other
logos,brandor productnames are trademarksor registeredtrademarks oftheir respective holders andare hereby
recognized as such.All specifications aresubjecttochange.Actualcontents maydiffer slightlyfromthose pictured.
Contents
Introduction
PackageContents………………………………………………………………………………………….3
MinimumSystemRequirements..................................................................................................................3
1About WCU90D Wireless Keyboard and Optical Mouse
WCU90D Wireless Keyboard…………………………………………………………………………..1-1
WCU90D OpticalMouse……………………………………………………………………………….1-3
WCU90D RF Receiver………………………………………………………………………………….1-4
2Installing Hardware
Step1:Insertbatteries into the WCU90D Optical Mouse……………………………………………….2-1
Step2:Insertbatteries into the WCU90DWireless Keyboard…………………………………………..2-2
Step3:Connect the Creative RF receiver………………………………………………………………..2-3
Step4:Turning on the RF receiver……………………………………………………………………….2-4
Tips On Using Your Keyboard and Mouse………………………………………………………………2-5
3Installing DeviceDrivers
Device Drivers Installation……………………………………………………………………………….3-1

MLK-I-05-0*-0001
User s Guide Rev.:1.0
热键科技（深圳）有限公司
MLK Industries (ShenZhen)Limited 第3页共3页
制作：曹新伟 日期： 20030531
Appendixes
Technical Specifications
WCU90DOptical Mouse…………………………………………………………………………………A-1
WCU90DWireless Keyboard…………………………………………………………………………….A-2
WCU90DRF receiver…………………………………………………………………………………….A-3
Introduction
Thankyou purchasing theCreative Desktop Wireless,whichconsists of the Creative Wireless Keyboard,Creative
OpticalMouseandthe Creative RFReceiver.ITcombinesaninnovative ergonomicdesign withallthefeatures
and convenienceof wireless technology.
Thekeyboard hasadvanced multimedia featuresthat enable you todayplayaudioCDs,VCDs and DVDs
files.You canusethe keyboard’shotkeystoraise,lower or muteaudio.Otherhotkeysletsyou sende-mail,launch
the Windowscalculator and enablePower Saving mode.Themouse includesa Scroller thatcan be customized.You
can assign functions such as quick scrolling andautomatic launching to themouse.
Package Contents
The following items are included in yourpackage:
□WCU90DWireless Keyboard
□WCU90D Optical Mouse
□WCU90D RF Receiver
□4 ×AAbatteries(for the keyboard and mouse)
□Installation CD
□Quick Start leaflet
Minimum SystemRequirements
□Genuine Intel®Pentium®266MHz,AMD®K6 300MHz or faster processor
□Intel,AMD or 100% compatiblemotherboardchipset
□MicrosoftWindows98,Windows98 SecondEdition(SE),WindowsMillenniumEdition(Me),Windows2000or
Windows XP
□64MB RAM (128MB highly recommended)
□600MBof freehard disk space
□Available USB portorpowered USB hub
□CD-ROM drive installed

MLK-I-05-0*-0001
User s Guide Rev.:1.0
热键科技（深圳）有限公司
MLK Industries (ShenZhen)Limited 第4页共4页
制作：曹新伟 日期： 20030531
AboutWCU90D Wireless Keyboard and Optical Mouse
The keyboardand itshot keysareshownin Figure 1below:

MLK-I-05-0*-0001
User s Guide Rev.:1.0
热键科技（深圳）有限公司
MLK Industries (ShenZhen)Limited 第5页共5页
制作：曹新伟 日期： 20030531
ButtonFunction ButtonFunction
Play/PausePlays or pause aCD/VCD/DVD BackGoesto theprevious
MuteTurns off/on theaudio outputForwardGoes tothe next page inyour
Webpage
StopStops playing the CD/VCD/DVD Stop Loading Stops loading a Web page
Previous Tack Goestotheprevioustrackin a
CD/VCD/DVD
Refresh Reloads the current Web page
Volume Up Increases thevolume level World Wide Web Launchesthe defaultWeb
browser
Volume DownDecreases thevolume levelE-mailLaunchesthe defaulte-mail
application
Next TrackGoestothe next trackina
CD/VCD/DVD
MyFavourite LauncheseitherInternet
Explorer’sFavoritesfolder,or
Netscape Navigator’sBookmarks
folder
Search Opens aSearch box in thecurrent
Web browser
Suspend/Sleep Enables the power saving mode
Mycomputer Opens theMy computer CalculatorOpens the Calculator
The mouseanditspartsareshownin Figure below:

MLK-I-05-0*-0001
User s Guide Rev.:1.0
热键科技（深圳）有限公司
MLK Industries (ShenZhen)Limited 第6页共6页
制作：曹新伟 日期： 20030531
The RF receiver and its partsare shown inFigure below:

MLK-I-05-0*-0001
User s Guide Rev.:1.0
热键科技（深圳）有限公司
MLK Industries (ShenZhen)Limited 第7页共7页
制作：曹新伟 日期： 20030531
InstallingHardware
Step 1:Insert batteries into the WCU90DOptical Mouse
1. Holding the mousein one hand,push the batterycompartmentcover catch downwardswith the
other hand,and then remove the cover.
2. Insert twoAAbatteriesaccording to thedirections in the batterycompartment,
3. Close the batterycompartmentcover andthen pushthe catch upwardsto lock the compartment
cover.
Step 2:Insert batteries into the WCU90DWireless Keyboard
1.Turn the keyboard over.
2.Slide the batterycompartmentcover downwards.
3.Insert twoAAbatteries according to the directions in the batterycompartment.
4.Slide the batterycompartmentcover upwards to closeit.
Step 3:Connect the WCU90DRF receiver
1. Turn on your computer.
2. Connectthe USB connectoron the RF receiverto the USB porton your computer.
3. Place the RF receiver atleast 8 inches(20cm)fromyour computer or monitor.
Step 4:Turning on the RF receiver

MLK-I-05-0*-0001
User s Guide Rev.:1.0
热键科技（深圳）有限公司
MLK Industries (ShenZhen)Limited 第8页共8页
制作：曹新伟 日期： 20030531
1. Pressthe Connect button on your RF receiver.
2. Pressthe Connect button on themouse.The Communication LED indicator blinks green.
3. Use apentip orbent paper clip topress the Connect button onthe keyboard.The Communication
LED indicatorblinks green.
Tips On Using Your Keyboard and Mouse
The following area fewtips to help you workeffectivelywithouta lot of physical discomfort:
□When using the keyboard and mouse,keep your forearms,wristsand handsin a relaxed position,with
your elbows atyourside.
□Position the keyboard and mouseneabysothat you donot have to stretch.
□Do notstrike thekeyboard skeys toohard.Type with a soft touch.
□Keep your thighsparallel to theground,and your feet flat on the ground or on a footrest.
□Usea chair that offers you good backsupport.
□Takea breakeveryhalfan hour.
□Placeyour computer smonitor awayfromsunlight glare.
□Varyyour tasks throughout the day.
□Keep your wrists straightand ifnecessaryuse the wristrest provided.
InstallingDevice Drivers
Device Drivers Installation
Youneed to install device drivers to use Creative DesktopWireless. Thefollowing instructionsare
applicable to all supported Windows operation systems.
1.Insert the Installation CD into yourCD-ROMdrive.
The disc supportsWindows AutoPlaymode and startsrunningautomatically.Ifnot,you need to
enable your CD-ROM drive sauto-insertnotification feature.Formoredetails,see”Problems
Installing Device Drivers”.
2.Selectthe applications to install,and then clickthe OK button.
3.Follow the onscreeninstructions to complete the installation.
4.When prompted,restartyoursystem.Installation isnow complete.
Technical Specifications
WCU90DOptical Mouse
Dimensions125mm(L) x 64mm(W)x37mm(H)
Weight 140g
Operating temperature 0℃- 40℃
Radiofrequency27MHz,single channel with 256 changeable ID formouse
Humidity0%- 90% RH
Working distance Up to 1.8m

MLK-I-05-0*-0001
User s Guide Rev.:1.0
热键科技（深圳）有限公司
MLK Industries (ShenZhen)Limited 第9页共9页
制作：曹新伟 日期： 20030531
Power 2×AAbatteries
Transmitting angle 360 degree
WCU90DWirelessKeyboard
- Dimensions 465mm(L) x200mm(W)x 37mm(H)
Weight 760g
Operating temperature 0
℃
-40℃
Radiofrequency27MHz, single channel with 256 changeable ID forkeyboard
Humidity 10% - 85% RH
Working distance Upto 1.5m
Power 2 ×AAbatteries
Sleeping mode current <0.5mA
WCU90DRF receiver
- Dimensions 81.00mm(L) x 67.50mm x 23.00mm(H)
Weight 70g
Operating temperature 0℃-40℃
Humidity0% -95%RH
Working distance Up to1.8m
Power 2 ×AAbatteries
LED indicators
□Communication
□NumLock
□Caps Lock
□ Scroll Lock
