Creator Electronics Digital Conference System User manual

i
CREATOR Electronics
Digital Conference System
Digital Conference System
User Manual
Please read this manual carefully before using this product

ii
CR-PDC08-0A-04
V1.4
2008, OTC
NOTICE
The Professional Digital Conference System User Manual provides reference
for the models of CR-M4101 / CR-ME4000/CR-M4102 / CR-M4104 / CR-M4103E3
/CR-TP4102/ CR-IR2000-12 / CR-IR1001-15/ CR-IR2001-12 / CR-IR2002-12 /
CR-V101﹡/ CR-T1000.It is only an instruction for operators, not for any
maintenance usage.
This manual is copyright CREATOR Corporation. All rights reserved. No part of this
publication may be copied or reproduced without the prior written consent of
CREATOR Corporation.
CR-PDC08-0A-04 V1.4
Please check CREATOR website or contact local supplier for updates.
http://www.creator.com.cn

iii
!
Safety Operation Guide

with the following items during installation and maintenance:
The system must be earthed properly. Please do not use two blades plugs and ensure
the alternating power supply ranged from 100v to 240v and from 50Hz to 60Hz.
Do not put the machine in a place of too hot or too cold.
To avoid any damage by over heat, please keep the working environment good in
ventilation to radiate the heat when running the machine.
The machine should be turned off when in rainy and humid days or nonuse for a long
time.
The AC power supply line should be disconnected with the power socket during the
following operation.
A. Take out or reinstall any component of the machine.
B. Disconnect or re-connect any connector of the machine.
Please do not attempt to maintain and uncover the machine for there is a high-voltage
component inside and the risk of the electric shock.
Do not splash any chemical product or liquid on or near the equipment.

iv
Index
1. Digital Conference System Introduction .................................................................1
About this system ................................................................................................................... 1
Features of DCS....................................................................................................................... 1
2. DCS controller............................................................................................................2
Product Instruction ................................................................................................................. 2
Front Panel ...............................................................................................................................................2
Volume Adjust the master volume from 1, the minimum, to 6, the maximum...................................2
Rear Panel................................................................................................................................................3
Features....................................................................................................................................................3
CR-ME4000............................................................................................................................... 5
Front Panel: ..............................................................................................................................................5
Rear panel: ...............................................................................................................................................5
Features................................................................................................................................... 5
Technical Parameter................................................................................................................ 6
Diagram.................................................................................................................................... 6
3. DCS Speaking Unit....................................................................................................7
Product Instruction ................................................................................................................. 7
CR-M4104A1 ............................................................................................................................ 8
Features....................................................................................................................................................8
Features：................................................................................................................................................8
Diagram ....................................................................................................................................................9
CR-M4102/4A2 ......................................................................................................................... 9
Features:...................................................................................................................................................9
Features..................................................................................................................................................10
Diagram ..................................................................................................................................................10
CR-M4102/4B ..........................................................................................................................11
Features..................................................................................................................................11
Features..................................................................................................................................................11
Diagram ..................................................................................................................................................12
CR-M4102/4E...........................................................................................................................12
Features..................................................................................................................................................12
Features..................................................................................................................................................13
Diagram ..................................................................................................................................................13
Embedded Unit.......................................................................................................................14
Features..................................................................................................................................................14
Diagram ..................................................................................................................................................15

v
Features..................................................................................................................................................15
CR-M4102/4F...........................................................................................................................16
Features..................................................................................................................................................16
Diagram ..................................................................................................................................................17
Features..................................................................................................................................................17
CR-M4102/4D2 ........................................................................................................................18
Features..................................................................................................................................................18
Diagram ..................................................................................................................................................19
Features..................................................................................................................................................19
CR-TP4102D............................................................................................................................20
Features..................................................................................................................................................20
Features..................................................................................................................................................23
Diagram...................................................................................................................................24
Technical Parameter...............................................................................................................25
4. DCS Simultaneous Interpretation...........................................................................27
CR-M4103E3...................................................................................................................27
Features..................................................................................................................................................27
Setting menu...........................................................................................................................................28
Monitor unit.............................................................................................................................................30
Features..................................................................................................................................................30
Techinical Parameter..............................................................................................................31
Diagram...................................................................................................................................31
5. DCS IR Language Distribution System..................................................................32
Product Description ...............................................................................................................32
CR-IR2000-12 IR Language Distribution System Transmitter Controller............................32
Destription:..............................................................................................................................................32
Features:.................................................................................................................................................32
CR-IR2001-12 IR Radiator board............................................................................................33
Function:.................................................................................................................................................33
Features:.................................................................................................................................................33
CR-IR2002-8/12 IR Receiver unit............................................................................................34
Function:.................................................................................................................................................34
Features:.................................................................................................................................................34
Parameters:.............................................................................................................................35
System Diagram .....................................................................................................................36
6. DCS Camera auto-tracking Controller ...................................................................37
Instruction...............................................................................................................................37

vi
MVC-4200 Camera auto-tracking Controller.........................................................................37
Features:.................................................................................................................................................37
Technical parameter................................................................................................................................38
CR-V1011/V1012 High-speed autodome................................................................................39
Features:.................................................................................................................................................39
Technical parameters:.............................................................................................................................39
System diagram......................................................................................................................40
7. DCS Telephone conference module.......................................................................41
Instruction...............................................................................................................................41
Features:.................................................................................................................................41
Panel diagram.........................................................................................................................41
Technical parameters:............................................................................................................42
System diagram......................................................................................................................42
8. Accessaries..............................................................................................................43
CR-P2 Headphone No Microphone........................................................................................43
Features:.................................................................................................................................................43
Technical parameters:.............................................................................................................................43
CR-P4 Headphone with Microphone .....................................................................................43
Features:.................................................................................................................................................43
Technical parameter:...............................................................................................................................43
Cable...............................................................................................................................44
CR-M4KL315...................................................................................................................44
CR-CT10 “T”connector..................................................................................................44
CR-CT20 socket .............................................................................................................45
CR-CT30 socket .............................................................................................................45
CR-CT50 8–pin aviation connector...............................................................................45
CR-HMP24 Expand power.............................................................................................45
CR-link20 ........................................................................................................................45
9. Annex........................................................................................................................45
Code specification:........................................................................................................45

1
1. Digital Conference System Introduction
About this system
DCS (Digital Conference System), central control system and matrix switcher system are 3 most
important product lines of CREATOR Electronics. It consists of the function modules as contribution,
simultaneous interpretation, IR language distribution, telephone conference, voting and video tracking.
CREATOR is always dedicated to integrated system solutions. Therefore, the DCS is not only a Hi-tech
electronical system, but also a powerful conference control solution while cooperating with the central
control system seamlessly.

real-is controllable by PC
software.
Features of DCS
Safety: The safety of every delegate is the most important thing to each conference.
The power of delegate unit and chairman unit are supplied by the central control unit with
24V safety current.
To improve the antistatic performance, the parts are selected carefully to avoid point
discharge current and the earth line is ensured to be enough thick. As a result, the
antistatic performance is up to 8000V.
Security and anti-jamming: Everything discussed in a conference must be important and sensitive.
To keep the signals and information securely and distortion-free is highly required.
The discussion system is shielded-cable linked, which can prevent the radio disturbance
and wiretapping effectively.
Perfect audio quality: 
The contribution equipment adopts condenser microphone with unidirectional response.
The contribution equipment adopts built-in hi-fi loudspeaker.
The lightweight earphone with a hanging design can reproduce the audio vividly and it is
comfortable to wear. It is very suitable for a long time use without any feeling of oppressive
or unhappy.
Maneuverability: Simple operation and control represent efficiency.
Easy installation: the communication method of daisy-chaining the units simplify the work
of installation and save the cost.
Easy operation: every one can easily control the unit by press a button to address and turn
the knob to adjust the volume of speaker or earphone.
Maintainability: An excellent system design leads to low maintenance cost, lesser upgrade
expense, long life-span and high efficiency.
The communication method of daisy-chain is easy to maintain and locate the problem unit.
Even the end user technician can maintain the system well with a short-term training.
All the equipments are produced and tested under ISO9001 strictly. They are international
qualified.

2
Expansibility:            
flexible and powerful.
To cope with the increasing number of delegates, the only thing to do is just adding in the
delegate units.
The modular system can be easily expanded by putting in the proper functional module.
When adding in a voting unit, it becomes a voting conference system; when adding in the
camera tracking module, it becomes a simultaneousA/V conference system.
2. DCS controller
Product Instruction
CR-M4101 controller
CR-ME4000 extender
CR-M4101 controlle
Front Panel
①POWER
②MODE
FIFO MODE: It is the first in first out mode with the configurable number of 1/2/4/6 speaking
units, except the chairman unit.
NORMALMODE: The mode with a maximum number of active delegate units. The number of
contribution units may be set to 1/2/4/6, except the chairman unit. When the active
microphones reach the limitation, one delegate unit must be closed to leave the place for the
other who wants to speak.
FREE MODE: 20 active units at one time.Without any limitation from Chairman Unit.
APPLYMODE，delegate needs permission from Chairman unit before speaking
③ACTIVE  configure the maximum number of active microphone to be used at a
same time. Users can choose from 1, 2, 4 and 6
④BASS Adjust bass up to eliminate the howling or squeal and adjust it down to get a more
clear audio reproduction
⑤TREBLE Adjust treble down to eliminate the howling or squeal and adjust it up to get a more
clear audio reproduction
⑥VOLUME Adjust the master volume from 1, the minimum, to 6, the maximum.

3
Rear Panel
78910
①IN It is the audio-in connector to input the audio signal like background music
②OUT 1It is the audio-out connector to output the audio signal to amplifier or audio recorder.
OUT 2It is the audio connector to output the audio signal to telephone conference.
③OUTPUTS There are 6 channels of audio-out connectors to output the audio signal to amplifier
or audio recorder etc.
④INTERPRET It is the interface to the interpreter unit. Up to 5 interpreter units can be connected in
the hand in hand daisy-chain
⑤ROUTE It is the expanded interface to the expanded control host. Up to 4096 contribution units
can access the system by daisy-chaining the expanded hosts hand in hand
⑥DELEGATES It is the interface to the contribution units. There are 3 channels to access the
system, and each can link to not more than 64 contribution units in hand in hand daisy-chain. There
is no limitation for the chairman unit. It can be located anywhere in the chain
⑦CONTROL SYSTEM It is the interface to the CR-PGMⅡcentral control system. Via this interface,
the CR-PGM II can cooperate with theACS seamlessly and control the conference remotely
⑧PC It is the serial control port to the console PC. With the application on the console pc, users
can control the conference system remotely
⑨SET ID 
Please refer to the chapter 2.10 Coding Description for the details of coding method.
Setting: After power on, switch the SET ID to “ON”, press the speaking button of delegate
units one by one, the light will be on after setting successful.
⑩POWER INPUT Power supply of 100V－240V AC
Features
1 The host itself can provide system accessing for up to 128 contribution units and can be
expanded to 4096 at the most.
2 It supports 5 interpreter units and achieves 6 languages simultaneously interpretation at a
same time including the original one
3 Communicating in the hand in hand daisy-chain, it is easy to install and maintain
4 Equipped with audio-in connector, it is able to have background music
5 Equipped with enough audio-out connectors, it is able to output the audio signal to different
audio devices
6 Limit function: Restrict present speaking units, when reach the max number, close opened
units then others can start speaking. The number can be 1, 2, 4, and 6.
7 Voice active function can automatically inspect the speaking status, and then control the video
to switch between speaker and main picture.

4
8 FIFO mode can automatically control the active microphones.
9 Working with the telephone coupler, it can open a telephone conference with remote user
10 Cooperating with the central control system, it becomes a powerful conference controller and
achieves the super function of camera auto-tracking.
11 Support voting and data managing。
12 Cover with metal material and earth well to ensure the 8000V antistatic performance
13 Rack-
NOTICE
1.8-pin aviation connector
8 P in M ALE
485A/1
485B/8
GND/2
A+ /3
A+ /5
B+ /6
B- /7
24V+/4
2. CONTROL SYSTEM COM
3. PC COM
PC
SIGNAL
INSTRUCTIO
N
1


2
TXD
TXD
3
RXD
RXD
4


5
GND
GND
6


7


8


Control
System
COM
SIGNAL
INSTRUCTIO
N
1


2


3
TXD
TXD
4


5
GND
GND
6


7


8



5
CR-ME4000
Front Panel:
①POWER and power indicator
②ACTIVE indicator
③NETWORK indicator
④COMMUNICATION indicator
Rear panel:
①ID ID Setting
②DELEGATESIt is the interface to the contribution units. There are 3 channels to access the
system, and each can link to not more than 64 contribution units in hand in hand daisy-chain.
There is no limitation for the chairman unit. It can be located anywhere in the chain.
③ROUTEA is the interface to the controller. B is the expanded interface to another
expanded controller. When in a multilevel expansion, A is the interface to the front level, and B
is the interface to the next level
④POWER INPUTPower supply of 100V－240V AC
Features
1.8-pin aviation connector
2. Working with CR-M3201 control host to expand the contribution units in system
3.Input voltage between 100－240V, it can endure 3500V high voltage
4. Cover with metal material and earth well to ensure the 8000V antistatic performance
5. Rack-

6
Technical Parameter
Technical Parameter
CR-M4101
CR-ME4000
Power supply
100-240V
100-240V
Static consumption
10W
10W
Nominal power
consumption
350W
350W
Output power


Audio output
 
mode:unbalanced
 
mode:unbalanced
MIC input
 
Electriclevel:-60dB
mode:unbalanced

Electriclevel:-60dB
mode:unbalanced
Frequency response
60－8kHz
60－8kHz
(S/N)
> 80dB
> 80dB
Harmonic distortion
< 0.5%
< 0.5%
Harmonic distortion at overload
<1%
<1%
Crosstalk attenuation at 1kHz
>50dB
>50dB
Weight
6.5KG
6KG
Dimension
483L *275W *88H (mm)
483L * 275W *88H (mm)
Colour
Grey
Grey
Diagram
Setting ID for conference units:
1. The ID setting for conference units means that, every conference unit in the system (including
interpretation & speech unit) was given the only address for being discerned by the host.
2. setting the conference units as following: after connection finished, turn on the host power, and set


system will work under the normal mode

7
3. DCS Speaking Unit
Product Instruction
Model
Name
Externality
MIC Key
Voting
Channels
Switch
LCD
CR-M4104A1
Delegate Unit
Fold-away

×
×
×
CR-M4102A2
Chairman Unit
Fold-away


×

CR-M4104A2
Delegate Unit
Fold-away


×
×
CR-M4102B
Chairman Unit
Table-Top

×
×
×
CR-M4104B
Delegate Unit
Table-Top

×
×
×
CR-M4102C1
ChairmanUnit
Embedded

×
×
×
CR-M4104C1
Delegate Unit
Embedded

×
×
×
CR-M4102C4
Chairman
Voting Unit
Embedded
×

×
×
CR-M4104C4
Delegate
Voting Unit
Embedded
×

×
×
CR-MC4032B
Chairman
twinaudio box
×
×
×
×
CR-MC4034B
Delegate
twinaudio box
×
×
×
×
CR-M4102D2
Chairman Unit
Slide


×

CR-M4104D2
Delegate Unit
Slide


×

CR-TP4102D
Chairman Unit
Slide


×

CR-M4102E
Chairman Unit
Table-Top

×
×
×
CR-M4104E
Delegate Unit
Table-Top

×
×
×
CR-M4102F
Chairman Unit
Embedded


×

CR-M4104F
Delegate Unit
Embedded


×


8
CR-M4104A1
Features
①Microphone: Pluggable, easy to transport and maintain
②MIC button: Press it to open the microphone and repress it to close the microphone.
③Build-in flat panel loudspeaker: It will automatically mute while the microphone opens.
④Earphone jack: Install and connect the earphone for DCS here.
⑤Volume adjustment:Adjust the volume of the contribution unit
Features：
1. Voting function integrated
2. 8-pin aviation connector
3. Pluggable unidirectional microphone with red ring indicator
4. Knob pin MIC pole
5. 2M cable for each unit
6. Build-in flat panel loudspeaker and earphone jack with excellent audio quality and adjustable
volume control.
7. The power of delegate unit and chairman unit are supplied by the central control unit with 24V
safety current.
8. Radio disturbance prevention
9. Communicating in the hand in hand daisy-

9
Diagram
CR-M4102/4A2
Features:
CR-M4102A2 Front View CR-M4104A2 Front View Side View
①Microphone: Pluggable, easy to transport and maintain
②Multi voting buttons
For/against: buttons 2/3/4 stand for For/Abstain/Against, respectively.
Multiple election: buttons 1/2/3/4/5 can stand for different candidates, respectively.
－/0/＋/＋＋, from low to high.
NOTICE
Button 4 on the chairman unit has a special function of intermission.
The chairman can press to temporarily close all the microphones on delegate units and
release it to resume the conference.
The conference holder can press the START button on the chairman unit to start voting. At this


10
Then, the delegates should press the button 1 to confirm and start voting.
Their last choice on the buttons will be considered as their final decision and will be indicated by
the button indicator. When the conference holder press the STOP button on the chairman unit,

button 4 for 2 seconds, to return the normal discussion status.
③LCD displayer
④MIC on/off
⑤Build-in flat panel loudspeaker
⑥Earphone jack
⑦Volume adjustment
Features
1, voting function integrated.
2, 8-pin aviation connector
3. Pluggable unidirectional microphone with red ring indicator.
4, 2M cable for each unit
5, Knob pin MIC pole
6, Build-in flat panel loudspeaker and earphone jack with excellent audio quality and adjustable
volume control.
7, Chairman Unit has the function to approve or deny the talking request from delegate units.
8, Chairman Unit is not limited by the active microphone limitation.
9, Chairman Unit can cut the microphone of delegate units at any time to manage and control the
whole conference conveniently
10, There is no limitation for the chairman unit. It can be located anywhere in the daisy chain. Power
supplied by the central control unit with 24V safety current.
11, the flat panel loudspeaker will automatically mute to avoid howling when the microphone turns
on.
12, communicating in the hand in hand daisy-
Diagram

11
CR-M4102/4B
Features
CR-M4102B Front View CR-M4104B Front View Rear View
①MIC jack
②PRIOVITYKey
③POWER
④MIC ON/OFF
⑤MIC indicator light
⑥Build-in loudspeaker
⑦Volume adjustment
⑧Earphone jack
⑨Link jack
⑩Cable
Features
1, voting function integrated.
2, 8-pin aviation connector
3. Pluggable unidirectional microphone with red ring indicator.
4, 2M cable for each unit
5, Knob pin MIC pole
6, Build-in flat panel loudspeaker and earphone jack with excellent audio quality and adjustable
volume control.
7, Chairman Unit has the function to approve or deny the talking request from delegate units.
8, Chairman Unit is not limited by the active microphone limitation.
9, Chairman Unit can cut the microphone of delegate units at any time to manage and control the
whole conference conveniently
10, There is no limitation for the chairman unit. It can be located anywhere in the daisy chain. Power
supplied by the central control unit with 24V safety current.

12
Diagram
CR-M4102/4E
Features
Side View Front View Side View
MI
C P
H O NE O N/ O
F F
DIG ITA L C ONF E REN CE S Y STE M
1
2
3
1
6
4
5
78
Rear View
①Earphone jack
②MIC jack
③Build-in loudspeaker
④MIC indicator light
⑤MIC on/off

13
⑥Volume adjustment
⑦Cable
⑧Link connector
Features
1, voting function integrated.
2, 8-pin aviation connector
3. Pluggable unidirectional microphone with red ring indicator.
4, 2M cable for each unit
5, Knob pin MIC pole
6, Build-in flat panel loudspeaker and earphone jack with excellent audio quality and adjustable
volume control.
7, Chairman Unit has the function to approve or deny the talking request from delegate units.
8, Chairman Unit is not limited by the active microphone limitation.
9, Chairman Unit can cut the microphone of delegate units at any time to manage and control the
whole conference conveniently
10, There is no limitation for the chairman unit. It can be located anywhere in the daisy chain. Power
supplied by the central control unit with 24V safety current.
11, the flat panel loudspeaker will automatically mute to avoid howling when the microphone turns
on.
Diagram

14
Embedded Unit
Features
CR-M4102C1Front View CR-M4104C1Front View
123
MIC/BREAK
CREATOR
4 0 . 00 m m
MIC
CREATOR
123
40m m
1 29 mm 12 9 mm
CR-M4102C4Front View CR-M4104C4Front View
CREATOR
4
CREATOR
129mm 12 9 m m
40 m m
40 m m
4
CR-MC4032B/CR-MC4034B
6
121.0 mm
24.5 mm
86.0mm
57
78
8
①MIC jack
②Earphone jack
③MICON/OFF,long press for 3 seconds of Chairmane unit can stop active delegate unit.
④Multi voting buttons
，2，3，4，
For/against: buttons 2/3/4 stand for For/Abstain/Against, respectively.
Multiple election: buttons 1/2/3/4/5 can stand for different candidates, respectively.
－/0/＋/＋＋, from low to high.
