TANDBERG 6000 MXP Profile User manual

Tandberg 6000 MXP
CONNECTING THE 6000 MXP INPUTS AND OUTPUTS
1. Connect Line Output D of the Vortex Device to the 6000 MXP codec mixer Input 4 as
shown below using the attached RCA cable.
2. Connect Line Input C of the Vortex Device to the Main line level Output 1 of the 6000
MXP codec as shown below using the other attached RCA cable.
3. Connect Line Output 1 to the Audio or Speaker input of the amplifier or video display to
hear the far end audio using the final attached cable.
See next page for Tandberg settings.

To configure the Tandberg 6000 MVX system to use Revolabs DSP
Package microphones:
Go to Audio Settings.
Set Input 4 and Output 1 to ON.
Disable Echo Canceller.
Adjust the audio Input Type Level if necessary.
Speak into the Revolabs microphones that are connected to the audio line
inputs.
The audio meter should peak at about 5 dB for normal speech.
