About This Document
Purpose
This document provides the positioning, features, networking schemes, and technical
specifications of the HUAWEI TE30 videoconferencing endpoint (TE30 or endpoint for
short).
Intended Audience
This document is intended for:
lEnd users
lAgents
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Description
Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.
NOTICE is used to address practices not related to
personal injury.
TE30 Videoconferencing Endpoint
Product Overview About This Document
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. ii

Symbol Description
Calls attention to important information, best practices
and tips.
NOTE is used to address information not related to
personal injury, equipment damage, and environment
deterioration.
Change History
Changes between document issues are cumulative. The latest document issue contains all the
changes made in earlier issues.
Issue 03 (2018-06-30)
This issue is the third official release.
Add 5.13 Custom Background Picture.
Issue 02 (2018-03-23)
This issue is the second official release.
Added 5.10 AirPresence Key.
Added 6.6 CHR Collection.
Issue 01 (2017-12-25)
This issue is the first official release.
TE30 Videoconferencing Endpoint
Product Overview About This Document
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. iii

Contents
About This Document.....................................................................................................................ii
1 Product Positioning.......................................................................................................................1
2 Product Highlights........................................................................................................................ 2
3 Application Scenarios...................................................................................................................5
3.1 On-Premises/IMS Hosted/SP Hosted Network.............................................................................................................. 5
3.2 Built-in MCU-based Network........................................................................................................................................ 5
3.3 Built-in MCU Networking with the RSE6500............................................................................................................... 7
3.4 Videxio Interconnection Network...................................................................................................................................8
3.5 Networking with the ACS.............................................................................................................................................. 8
4 Product Structure......................................................................................................................... 10
4.1 Appearance................................................................................................................................................................... 10
4.2 Front Panel and Rear Panel.......................................................................................................................................... 10
4.3 Checking Indicator Status.............................................................................................................................................12
5 Functions and Features...............................................................................................................14
5.1 Voice Dialing................................................................................................................................................................ 14
5.2 SiteCall......................................................................................................................................................................... 15
5.3 P2P to Multipoint..........................................................................................................................................................15
5.4 Conference Control.......................................................................................................................................................16
5.5 Screen Layout Adjustment........................................................................................................................................... 18
5.6 Multi-Language User Interface.....................................................................................................................................19
5.7 Conference Recording.................................................................................................................................................. 19
5.8 Wi-Fi Connectivity....................................................................................................................................................... 20
5.9 Wireless Data Sharing.................................................................................................................................................. 21
5.10 AirPresence Key......................................................................................................................................................... 21
5.11 Automatic Configuration Via a USB Device..............................................................................................................22
5.12 Startup Video Customization......................................................................................................................................22
5.13 Custom Background Picture.......................................................................................................................................22
5.14 Network Address Book.............................................................................................................................................. 22
5.15 Real-time Viewing of HD Images.............................................................................................................................. 23
5.16 Adaptation of and Conversion Between the 16:9 and 4:3 Display Modes.................................................................23
5.17 Seamless Convergence with IMS and USM...............................................................................................................24
TE30 Videoconferencing Endpoint
Product Overview Contents
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. iv

5.18 Registering with the SC Using the Same SIP Number as the TE Desktop&TE Mobile............................................24
5.19 Interworking with the Lync System............................................................................................................................24
5.20 Interconnection with the Videxio................................................................................................................................24
5.21 Interconnection with the ACS.................................................................................................................................... 24
5.22 Interconnection with the BroadSoft Platform.............................................................................................................25
5.23 Interconnection with the DDNS................................................................................................................................. 25
5.24 Third-Party APIs.........................................................................................................................................................25
5.25 Network Adaptability................................................................................................................................................. 25
5.26 Security.......................................................................................................................................................................25
6 Operation and Maintenance......................................................................................................29
6.1 Using the Touch Panel.................................................................................................................................................. 29
6.2 Using the Remote Control............................................................................................................................................ 30
6.3 Using the Web Interface............................................................................................................................................... 30
6.4 Log Management..........................................................................................................................................................31
6.5 Inspection......................................................................................................................................................................31
6.6 CHR Collection............................................................................................................................................................ 31
6.7 System Upgrade............................................................................................................................................................32
6.8 Disaster Recovery.........................................................................................................................................................32
7 Technical Specifications.............................................................................................................33
7.1 Physical Specifications................................................................................................................................................. 33
7.2 Performance and Capacity............................................................................................................................................35
7.3 Ports and Protocols....................................................................................................................................................... 37
7.4 Standards Compliance.................................................................................................................................................. 38
A Glossary........................................................................................................................................40
TE30 Videoconferencing Endpoint
Product Overview Contents
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. v

1 Product Positioning
The TE30, an HD videoconferencing endpoint ideal for kinds of conference rooms, supports
H.264 Scalable Video Coding (SVC), H.264 HP, IPv4 and IPv6 as well as Wi-Fi.
Table 1-1 describes the appearance, features, and application scenarios of the TE30.
Table 1-1 Appearance, features, and application scenarios of the TE30
Appearance on Scenario Application Scenario
The TE30 is an integrated HD
videoconferencing endpoint as
well as a portable camera that
supports a resolution of up to
1080p 30 fps. It is compact and
easy to install.
The TE30 incorporates a
digital camera and a pair of
stereo microphones, and is
ready for visual
communication as soon as it is
connected to a network.
Small- and medium-sized
enterprises
Small-sized conference
rooms and executive offices
High-end home users
TE30 Videoconferencing Endpoint
Product Overview 1 Product Positioning
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 1

2 Product Highlights
Compact Design, Easy to Install
lDue to its compact design, which includes a built-in camera and a pair of microphones,
the endpoint is portable and easy to install.
lThe endpoint supports Wi-Fi access and is ready for use shortly after being connected to
a television and powered on. The entire process can be completed in five minutes.
lA mounting bracket is provided to allow positioning on a wall, above a TV set, or on a
ceiling.
Impressing Voice Services
lWith the voice dialing function, users can quickly initiate or join a conference by
speaking the name of a site in Chinese or English.
lNew participants can be directly added to an active P2P or multipoint call, facilitating
smooth communication.
Wireless Connections for Easy Sharing
lThe endpoint with a built-in Wi-Fi module can connect to a Wi-Fi network, serve as a
Wi-Fi hotspot, or both.
lThe wireless data sharing client is provided for connecting a PC to the endpoint over Wi-
Fi. Then you can use the client to easily share the PC desktop as well as files stored on
the PC.
lThe AirPresence mobile client can be installed on a mobile device and paired with the
endpoint through the projection code. Then you can use the AirPresence mobile client to
push content on the mobile device to the endpoint.
User Interface Easily Operated Using the Remote Control
lThe remote control has a compact design and integrates the most commonly used
buttons.
lA touch panel can be used if necessary.
lA wizard is provided to help you easily complete the installation.
TE30 Videoconferencing Endpoint
Product Overview 2 Product Highlights
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 2

lThe 3D user interface is available and different modules are visible to users of different
roles. You can use the remote control to initiate calls or join conferences from the user
interface.
lThe LCD screen on the endpoint shows the local site information (including the IP
address and number) in real time.
Next-Generation H.264 HP and VME Dual-Core Technologies
lThe H.264 HP technology, combined with Huawei's proprietary Video Motion
Enhancement (VME) technology, optimizes video images to be more pleasing to eyes
while reducing the bandwidth consumption by 50%.
lThrough intelligent face recognition and back-end video enhancement, the VME
technology improves light adaptability, reduces bandwidth consumption, improves image
definition, and enhances motion images.
lThe endpoint provides a built-in microphone that is able to pick up audio within 6 meters
to provide users with hi-fi audio using MPEG-4 Low Delay Audio Coder (AAC-LD),
acoustic echo cancellation (AEC), and automatic noise suppression (ANS) technologies.
High Network Adaptability and Security
lUsing H.264 SVC, the endpoint excellently adapts to different line bandwidths, device
capabilities, and network environments.
lThe endpoint utilizes Huawei's exclusive Super Error Concealment (SEC) and Intelligent
Rate Control (IRC) technologies.
lThe endpoint supports firewall traversal through the standard H.460 protocol or
Huawei's proprietary Super Network Passport (SNP) protocol.
lMedia and signaling streams are encrypted in multiple ways, ensuring secure and stable
running of the videoconferencing system.
Extensive System Integration
lThe endpoint can interwork with industry's mainstream standard endpoints,
infrastructures, the IP Multimedia Subsystem (IMS), the BroadSoft platform, and the
Videxio cloud videoconferencing platform (referred to as Videxio platform hereinafter),
delivering an intelligent, easy-to-use conference experience.
lThe endpoint can be seamlessly integrated into the IMS or SP hosted network.
lThe endpoint can interwork with Microsoft Skype for Business (next-generation Lync
client), Lync 2013/2010, and Lync Online (Office 365) through the Lync gateway or
PXP Integrated Media Server.
lThe endpoint is the industry's first videoconferencing endpoint that enables you to
schedule or start a multipoint video conference as easily as making a call.
lThe endpoint provides rich APIs for third parties to facilitate system integration and
customization.
lendpoints connected to the same third-party Dynamic Domain Name System (DDNS)
can call each other by domain name.
(Optional) Built-in MCU
The endpoint with the built-in MCU can hold multipoint conferences without any intervention
of the SMC or standalone MCU.
TE30 Videoconferencing Endpoint
Product Overview 2 Product Highlights
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 3

This enables users to call multiple sites one by one, or use a predefined conference template to
call multiple sites at a time. After a conference starts, sites can dial the number or IP address
of the endpoint that houses the built-in MCU to join in the conference.
lMaximum connected sites allowed by a non-encrypted conference: 4 576p 30 fps video
sites (local site included) + 3 audio sites
lMaximum connected sites allowed by an encrypted conference: 4 576p 30 fps video sites
(local site included)
lMaximum bandwidth required for a non-encrypted conference: 4.5 Mbit/s (1.5 Mbit/s for
each video site)
lMaximum bandwidth required for an encrypted conference: 3 Mbit/s (1 Mbit/s for each
video site)
lOne conference can be simultaneously joined by different types of endpoints, including
SD terminals, HD terminals, VoIP terminals, H.323 terminals, SIP terminals, and
terminals supporting different audio and video formats and bandwidths.
lContinuous presence per port: supports a maximum of 5 video panes.
lSupports rich functions, including voice activation, floor request, dual-stream
transmission through H.239, and Binary Floor Control Protocol (BFCP), and can
collaborate with the Huawei RSE6500 to support multipoint conference recording,
meeting the requirements of small- and medium-sized enterprises in terms of equipment
price and maintenance costs.
TE30 Videoconferencing Endpoint
Product Overview 2 Product Highlights
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 4

3 Application Scenarios
3.1 On-Premises/IMS Hosted/SP Hosted Network
The endpoint connects to on-premises, IMS hosted, or SP hosted CloudVC/CloudEC
networks, enabling video communication for enterprises and carriers. Figure 3-1 shows the
network diagram.
Figure 3-1 Networking diagram
The network is described as follows:
lThe endpoint connects to the on-premises network through the standard SIP or H.323
protocol.
lThe standard SIP protocol is used for connecting the endpoint to the IMS or SP hosted
network.
lVideo, data, and presentation sharing can be implemented between the endpoint and
various kinds of terminals and clients to deliver the optimal communications experience.
3.2 Built-in MCU-based Network
TE30 Videoconferencing Endpoint
Product Overview 3 Application Scenarios
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 5

In the CloudVC on-premises networking scheme, the endpoint TE30 can hold multipoint
conferences using its built-in MCU, without any intervention of the SMC2.0 or MCU. The
built-in MCU makes conference rooms of small- and medium-sized enterprises video-
enabled. Figure 3-2 shows the built-in MCU-based network of the endpoint.
Figure 3-2 Built-in MCU-based network
The network is described as follows:
lAfter having the built-in MCU enabled, the endpoint TE30 can hold both encrypted and
unencrypted conferences.
–An unencrypted conference can hold a maximum of three 576p 30 fps HD video
sites and three audio sites, besides the site that initiates the conference. Each video
site occupies 1.5 Mbit/s bandwidth. The total bandwidth occupied by the conference
cannot exceed 4.5 Mbit/s.
–An encrypted conference can hold a maximum of three 576p 30 fps HD video sites,
besides the site that initiates the conference. Each video site occupies 1 Mbit/s
bandwidth. The total bandwidth occupied by the conference cannot exceed 3
Mbit/s.
lSD and HD video sites and audio-only sites of the H.323 or SIP type can join
conferences on this network.
NOTE
Audio-only sites can join conferences using IP phones only when the SC is deployed on the
network.
lThis network supports presentation sharing through the H.239 protocol, as well as
simultaneous video and presentation sharing through the Binary Floor Control Protocol
(BFCP).
TE30 Videoconferencing Endpoint
Product Overview 3 Application Scenarios
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 6

lWhen a site joins a conference, the endpoint automatically adjusts the continuous
presence layout to display the video of that site. For example, when there are only two
video sites, the continuous presence layout is 2-pane . If a third video site joins in,
the continuous presence layout is automatically adjusted to 3-pane . The site that
generates the loudest volume is displayed in the largest pane. The local site is not
displayed by default.
lThe endpoint with a built-in MCU provides conference control functions, including
requesting or releasing chair control rights, allowing or forbidding the chair site, locking
or unlocking a conference, and selecting a screen layout.
3.3 Built-in MCU Networking with the RSE6500
In the CloudVC on-premises network, the endpoint TE30 that has a built-in MCU can be
separately interconnected with the Recording & Streaming Engine (RSE), without the
intervention of the SMC2.0 or MCU. Figure 3-3 shows how the endpoint TE30 with the
built-in MCU is networked with the RSE6500.
Figure 3-3 Built-in MCU networking with the RSE6500
The network is described as follows:
lThe MCU-embedded endpoint is deployed on the same IPv4 or IPv6 network as the
RSE6500. It can contact the RSE6500 using the IP address.
lThe MCU-embedded endpoint exchanges media streams with the RSE6500 to
implement simultaneous recording of conference voice, video, and presentation.
Recording control can be performed on either the endpoint or the RSE6500.
lUsers can view live broadcast or VoD either from the endpoint web interface or from the
RSE6500 web interface on their PCs, smartphones, or tablets.
NOTE
On this network, the endpoint with the built-in MCU works with the RSE6500 in the simplest way.
Without any intervention of the GK or SIP server, they are connected by their IP addresses.
TE30 Videoconferencing Endpoint
Product Overview 3 Application Scenarios
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 7

3.4 Videxio Interconnection Network
To interconnect your endpoint with the Videxio platform, click the activation button on the
Videxio web page and choose to automatically scan your endpoint or manually search for
your endpoint by IP address. Figure 3-4 shows the network where the endpoint is
interconnected with the Videxio platform.
Figure 3-4 Videxio interconnection network
The network is described as follows:
lBy interacting with the activation server, registrar server, and configuration server on the
Videxio platform, the endpoint gets activated, obtains SIP configuration data, acquires its
own site name, and automatically registers with the Videxio platform based on the
obtained data.
lThe endpoint communicates with the Videxio platform only through the SIP protocol to
get registered and convene conferences.
lFor video conferences that are held on the Videxio cloud videoconferencing platform,
only presentation sharing is supported.
3.5 Networking with the ACS
The endpoint can interconnect with the Auto-Configuration Server (ACS) to implement
management functions through the TR-069 service offered by the ACS.
Figure 3-5 shows the interconnection between the endpoint and the ACS.
TE30 Videoconferencing Endpoint
Product Overview 3 Application Scenarios
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 8

Figure 3-5 Interconnecting with the ACS
On this network:
lThe endpoint communicates with the TR-069 server through the TR-069 protocol.
lThe HTTP server is used to upload and download configuration files and download
upgrade files.
lThe Simple Traversal of UDP through NAT (STUN) server implements traversal
between private and public networks and delivers management over all devices on both
networks.
lThe endpoint can be deployed on a public or private network, while the ACS must be
deployed on a public network.
–If the endpoint is deployed on a public network, it can be managed by the ACS
through the TR-069 protocol.
–If the endpoint is deployed on a private network, the STUN server needs to be
deployed for traversal between private and public networks. After the deployment,
the TR-111 protocol, an extension of the TR-069 protocol, will be available for the
ACS to manage the endpoint.
TE30 Videoconferencing Endpoint
Product Overview 3 Application Scenarios
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 9

4 Product Structure
4.1 Appearance
The TE30, as shown in Figure 4-1, is sleek, compact, and pleasing to the eye. Its all-metal
shell feels durable and shows the quality of the product. It is designed especially to be suitable
for all conference room environments.
Figure 4-1 Appearance
4.2 Front Panel and Rear Panel
Figure 4-2 shows the parts on the front and rear panels, and Table 4-1 describes these parts.
For details about the status of the indicators, see 4.3 Checking Indicator Status.
TE30 Videoconferencing Endpoint
Product Overview 4 Product Structure
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 10

Figure 4-2 Parts on the front and rear panels
Table 4-1 Parts description
No. Parts Description
1 Built-in
microphone
Provides 180-degree sound pickup with an optimal range of six
meters.
2 Lens Shoots video of the local site with 12x optical zoom.
3 MODE button lWhen the TE30 is running, press and hold the MODE
button for 10s to reset the TE30 to factory settings. You can
also press this button to make the TE30 sleep or wake up.
lWhen the TE30 is powering on, press and hold this button
for 3s to enter the mini system.
NOTE
If the endpoint is used in a conference or being upgraded, it will not go
to sleep after you press the MODE button. Instead, a message is
displayed on the remote control UI.
4 Infrared
receiver module
Receives infrared signals from the remote control that comes
with the endpoint.
5 OLED display Displays the IP address, site number, and indications for
startup, upgrade, sleep, and malfunction.
6 Status indicator Shows whether the TE30 is running, sleeping, upgrading, or
malfunctioning.
TE30 Videoconferencing Endpoint
Product Overview 4 Product Structure
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 11

No. Parts Description
7 SELECT button When the endpoint is running:
lPress this button to switch the VGA OUT port between
VGA and YPbPr modes.
lPress and hold this button for 10s to restore the TE30 to the
last backed up settings.
8 USB port Connects to a USB device, such as a removable hard disk,
USB flash drive, or data card, or connects to a USB-to-serial
adapter to convert the USB port into a serial port.
9 LINE OUT port 3.5 mm (0.14 in.) audio output port, which connects to the
audio input port on a display or an external speaker.
LINE IN port 3.5 mm (0.14 in.) audio input port, which connects to an audio
input source, such as a computer or a mobile phone.
10 MIC/TV/LAN/
POWER
Functions as an HDMI, Ethernet, microphone, or power port
using the provided HD-VI to composite adapter cable
provided.
11 VGA IN port Connects to a VGA input source, such as a computer or a
Digital Video Disc (DVD) player.
12 VGA OUT port Exports VGA/YPbPr signals only and connects to the VGA
port on a display, for example, a projector.
4.3 Checking Indicator Status
By checking the status of indicators on an endpoint, you can know its running status and
ensure that it works well with other videoconferencing devices.
When all cables are connected correctly, connect the TE30 to a power supply using the power
adapter. When the power adapter indicator turns on, the TE30 automatically powers on and
the Wizard screen is displayed. After the configuration is complete, the menu screen is
displayed.
Table 4-2 describes the TE30 indicator status.
Table 4-2 TE30 indicator status
The Indicator Is... The Endpoint Is...
Blinking green Powering on or upgrading.
Steady green Working properly.
Blinking green (on for 1s, off for 2s) Standby.
Steady red Powered off. (Press on the remote
control to power off the TE30.)
TE30 Videoconferencing Endpoint
Product Overview 4 Product Structure
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 12

The Indicator Is... The Endpoint Is...
Off Disconnected from the power supply.
Blinking red Confronted with a fault, such as a self-check
error, overheating, and software
malfunction.
TE30 Videoconferencing Endpoint
Product Overview 4 Product Structure
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 13

5 Functions and Features
5.1 Voice Dialing
The endpoint uses speech recognition technology to support point-to-point voice calls on the
remote control screen in both Chinese and English, and also allows users to initiate multipoint
conferences through templates. The endpoint can recognize site names, conference names,
and names of predefined conferences. It can automatically call sites to join conferences or
initiate SiteCalls to initiate conferences, simplifying user experience. Figure 5-1 shows the
Call window.
Figure 5-1 Voice dialing
If there is only one site shown in the list after voice dialing is made, then a call is initiated
automatically.
TE30 Videoconferencing Endpoint
Product Overview 5 Functions and Features
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 14
