Creek Company ODC 1220 User manual

ODC 1220
OUTDOOR DISCOVERY CRAFT
TWO MAN PONTOON BOAT
ASSEMBLY INSTRUCTIONS
Your ODC 1220 Two Man Pontoon Boat comes in two separate cartons consisting of the following parts:
FRONT FISHING FRAME
(1) Left Frame Member
(1) Right Frame Member
(1) Seat Support Frame Member
(1) Tall Seat Support Frame Member
(1) Plastic Padded Seat Back
(1) Plastic Padded Seat Bottom
(2) Seat Assembly Pins
(4) Seat Screws
(1) Leaning Bar
(1) Standing Platform
(1) Long U-Bar
(1) Under the Seat, Zippered Mesh Bag
(1) Behind the Seat, Zippered Mesh Bag
(1) Stripping Apron and Stripping Apron Waist Belt
(12) Short Snap Pins
(4) Long Snap Pins
OARS & OARLOCKS
(1) Pair 8 foot, 3 piece oars
(1) Pair bronze oarlocks, with split rings
(1) Pair Oar Stops
(2) Oarlock Bushings
WARRANTY CARD & PATCH KIT
REAR ROWING FRAME
(1) Left Frame Member
(1) Right Frame Member
(1) Seat Support Frame Member with Underseat Lift
and Lock Anchor System Attached
1) Plastic Padded Seat Back
(1) Plastic Padded Seat Bottom
(2) Seat Assembly Pins
(4) Seat Screws
(1) Foot Brace
(1) Short U-Bar
(1) Anchor Line Storage Bag
(1) Cargo Deck (with protective bar
for shipping attached)
(10) Short Snap Pins
(2) Side Storage Pockets
(1) Rod Holder
PONTOONS
(1) Pair pontoons: Each pontoon consists of
30 oz. thermal welded cover, 420 denier nylon liner and
30 gauge PVC bladder with valve insert
and valve plate all pre-assembled.
(16) Cam-lock straps
(1) PUMP
Complete with a set of adapters
TTMM
Please take a moment to lay out all frame parts as shown in figures 1 & 2 to familiarize
yourself with the frame parts of your new pontoon boat.

ODC 1220
OOUUTTDDOOOORRDDIISSCCOOVVEERRYYCCRRAAFFTT
ASSEMBLY INSTRUCTIONS
I. PADDED SEAT ASSEMBLY
1. Assemble Seat Back to Seat Bottom using Seat Assembly Pins (see figure 1a). Assemble both seats at this time.
II. FRAME ASSEMBLY
NOTE: Your frame assembles using (22) Short Snap Pins and (4) Long Snap Pins. Please follow instructions accordingly.
A. ASSEMBLE FRONT FISHING FRAME USING THE FOLLOWING STEPS:
1. Assemble Seat to Tall Seat Support Frame Member using (4) Seat Screws.(see figure 1b).
2. Assemble Seat Support Frame Member to Left and Right Frame Members using (4) of the Short Snap Pins. (see figure 1).
3. Assemble Tall Seat Support Frame Member to Seat Support Frame Member using (4) Short Pins. (see figure 1b).
4. Assemble Leaning Bar to Left and Right Frame Member. Do not insert (2) Short Snap Pins until following step 7 (see figure 1).
5. Assemble Standing Platform to Left and Right Frame Members using (4) Long Snap Pins. ( 2 ) of these pins also pin
together Leaning Bar and finish step 6. (see figure 1)
6. Assemble Long U-Bar to back of Left and Right Frame Member using (2) Short Snap Pins. (see figure1)
B. ASSEMBLE REAR ROWING FRAME USING THE FOLLOWING STEPS:
1. Assemble Seat to Seat Support Frame Member using (4) Seat Screws.(see figure 1a)
2. Assemble Seat Support Frame Member with Underseat Lift and Lock Anchor System attached
to Left and Right Frame Members using (4) Short Snap Pins (see figure 2).
3. Assemble Short U-Bar to back of Left and Right Frame Member using (2) Short Snap Pins (see figure 2).
4. Assemble Cargo Deck to back of Left and Right Frame Member using (2) Short Snap Pins (see figure 2).
5. Assemble Foot Brace to front of Left and Right Frame Member. Foot Brace can be assembled in longer position or shorter
position using (2) Short Snap Pins (see figure 2).
6. Attach Anchor Line Storage Bag to Seat Support Frame Member (see figure 1a).
7. See figure 5 and 6 for use of Underseat Lift and Lock Anchor System.
C. CONNECTING FRONT FISHING FRAME TO REAR ROWING FRAME. Attach back of Front Fishing
Frame Left and Right Frame Member to Foot Brace of Rear Rowing Frame using (2) Short Snap Pins (see figure 4).
III. PONTOON INFLATION
NOTE: Use the large cone adapter provided with your pump. See figure 3a for a detail of the valve assembly. Before
inflation, be sure to fully seat each valve assembly into the pontoon, screwing tightly by hand. When fully seating valve
assembly, be sure that the valve plate is in place around valve assembly and not restricting the valve assembly from a full
seal. After inflating, be sure to fully seat the top cap on to each valve assembly, screwing tightly by hand. Both are
required for an airtight seal.
1. Inflate each pontoon. The valve is located under the valve cover at the top and center of each Pontoon (see figure 3).
Inflate until firm (do not over inflate).
2. Again, be sure top valve cap and valve assembly are fully seated to achieve airtight seal.
PONTOON DEFLATION: Unscrew entire valve assembly from pontoon.

IV. ATTACH PONTOONS TO FRAME
NOTE: Always inflate the Pontoons first, before attaching to frame.
1. Position inflated Pontoons under the Left and Right Frame Members with ODC 1220 logo oriented to the outside.
The valve covers at top of Pontoon should fit between the Front Fishing Frame and the Rear Rowing Frame (see figure 3).
2. Attach each Pontoon to frame using (8) Cam Lock Straps. Slip each strap through D-Ring on Pontoon, around frame and pull
tight through Cam Lock Buckle. NOTE: Be sure the straps are pulled tight through the Cam Lock Buckles (see figure 3).
IIIa. ONE MAN CONVERSION: Your ODC 1220 can be converted to a one man craft by centering the Rear Rowing
Frame only on the Pontoons, leaving the Front Fishing Frame detached.
V. OAR & OARLOCK ASSEMBLY
1. Slide the Oar Stop over the handle end of the Oar Shaft.
2. Assemble 2 oar shaft pieces and blades.
3. Place Oarlock Bushing over Oarlock shaft and place Oarlock into frame. Frame has 3 Oarlock postions for a custom fit. Attach
split ring at end of Oarlock shaft to secure Oarlock in place. (see figure 7)
4. With Oarlocks installed on the Frame, slide Oars into Oarlocks starting at blade end of Oar. The Oars should be
adjusted equally left and right allowing at least two thumbs distance between the Oars to avoid pinching your thumbs when rowing.
Tighten the Oar Stops in place.
Figure 1
Front Fishing Frame
Assembly
A. Standing Platform
B. Leaning Bar
C. Right Frame Member
D. Left Frame Member
E Seat Support Frame Member
F. Long U-Bar B
C
D
EF
A
Detail Of
Snap Pin
Installation
FRONT FISHING FRAME
Figure 5
Underneath
View of
Underseat Lift
and Lock
Anchor System
To Front of Boat
Left Pontoon
Right Pontoon
to Anchor
(not Included)
Cargo
Deck
Anchor Rope
(not Included)
Anchor Line
Pulley
Designed to be
used while
sitting in rowers
seat.
To Back of Boat
Underneath View of Boat
Figure 4
Connecting
Frames

Figure 7
Oar Lock Detail
Oarlock
Oarlock Bushing
Split Ring
Figure 1a. Rowing Frame Seat Assembly
A. Seat Support Frame Member with Underseat Lift and
Lock Anchor Attached
B. Anchor Line Storage Bag
Locked
Figure 6
Anchor Drop Detail
Rope
(not included)
L
K
J
I
H
GM
HIN
HIN
Figure 2
Rear Rowing
Frame Assembly
G. Foot Brace
H. Right Frame Member
I. Left Frame Member
J. Seat Support Frame
Member
K. Short U-Bar
L. Cargo Deck
M. Underseat Lift and Lock
Anchor System
Figure 1b
Fishing Frame Seat
Assembly
A. Tall Seat Support Frame Member
B. Seat Support Frame Member
Front
View
Bottom
View
Seat
Back
Seat Bottom
Seat Screws
FORWARD
Lift and Lock
Anchor System
A
B
REAR ROWING FRAME
Unlocked
Seat
Screw
Holes
A
A
Seat
Assembly
Pins
Seat
Screws
B
A
Rod Holder Attached Here
or on Opposite Side of Frame

Pontoon
Nylon Strap
Frame
D-Ring
VI. ATTACH STRIPPING APRON TO FRAME
1. Position Stripping Apron at top of Leaning Bar (see figure 3).
2. Wrap hook & loop strap around Leaning Bar and snugly strap down.
3. Waist Belt for Stripping Apron is provided so fisherman can wear stripping apron if desired.
VII. ATTACH SIDE STORAGE POCKETS TO FRAME
1. Position Side Storage Pockets along Left Frame Member and Right Frame Member of Rear Rowing Frame (see figure 3).
2. Wrap lower hook & loop straps around bottom rail of frame and strap down.
3. Wrap hook & loop straps around upper rail frame and strap down.
VIII. ATTACH UNDER THE SEAT ZIPPERED MESH STORAGE
BAG & BEHIND THE SEAT ZIPPERED MESH STORAGE BAG.
1. Position Zippered Mesh Storage Bags on frame. Smaller bag under Tall Seat Support Frame Member, with zipper facing forward.
Larger bag behind Tall Seat Support Frame Member. (see figure 3)
2. Attach bags to frame using ladder lock buckles and straps to wrap around frame.
VIIII. ROD HOLDER TO FRAME
1. Rod Holder attaches to frame anywhere a Snap Pin assembly is found.
2. Recommended location is where Cargo Deck attaches to Left or Right Frame Member (see figure 2).
Figure 3a Valve Insert detail
Top valve cap
Valve assembly
Valve plate
Bladder
Figure 3
Assembled ODC 1220
A . Stripping Apron
B. Under the Seat, Zippered Mesh Bag
C. Behind the Seat, Zippered Mesh Bag
D. Side Storage Pocket
E. Side Storage Pocket
F Valve Cover
G. Oar Stop
H. Anchor Line Storage Bag
ODC 1220
Transom for
trolling motor
A
BC
D
G
E
Cam Lock
Buckle
H
F

ODC 1220™
OOUUTTDDOOOORRDDIISSCCOOVVEERRYYCCRRAAFFTTTTMM
Warning:
Please read and follow carefully.
1. Always wear a US Coast Guard approved personal flotation device when in your ODC 1220.
2. Never float alone.
3. Always check your ODC 1220 air bladders, frame, oar components, and pontoon covers for possible damage
before you use your craft.
4. Never use your craft if you suspect the air bladders, frame, oar components, or pontoon covers has been damaged.
5. Never over inflate your ODC 1220.
6. Never use your ODC 1220 without the air chambers fully inflated.
CARE AND MAINTENANCE:
1. If your pontoon bladder is losing air, please check that valve assembly and top valve cap are fully seated. Reseat valve
assembly and repeat pontoon inflation instructions.
2. Do not store your ODC1220 in direct sunlight.
3. If you are leaving your ODC 1220 out in the sun for any amount of time, be aware that the heat can increase the
pressure inside the pontoons to a dangerous level. Let some of the air out of the pontoons if the craft will be out of the water
in the sun for any length of time, or if it is stored in a vehicle, etc.
4. A gain in altitude will increase the pressure in the pontoons also. If you are taking your inflated ODC 1220 from
a low elevation to a high elevation, be sure to let some of the air out of it.
5. For short term storage, we recommend you let some air out of your pontoons.
6. For long term storage, we recommend you make sure your ODC 1220 is completely dry, deflated and stored out of
the sunlight in a cool dry area.
7. Repairing bladder, use enclosed patch kit. Fully deflate bladder. Remove safety split-ring from zipper pull and open
zipper in pontoon cover. Remove bladder from inner liner. Identify puncture. Clean and dry area around puncture.
Apply glue to puncture area and patch using applicator straw. Press patch over puncture area. Allow 24 hours to
dry before Inflation.
8. Note: Metal parts may rust and are not covered under warranty.
Your ODC Outdoor Discovery Craft is designed to give you many years of service.
Please follow inflation instructions and warnings carefully.
IF YOU EVER HAVE ANY QUESTIONS OR PROBLEMS WITH YOUR ODC 1220 PLEASE DO NOT
RETURN IT TO THE DEALER YOU BOUGHT IT FROM. PLEASE CONTACT THE CREEK COMPANY WE ARE
OPEN M-F 9AM-5PM MOUNTAIN TIME. OR CONTACT US VIA E-MAIL AT [email protected].
HIN IS LOCATED ON SQUARE TUBING OF SEAT SUPPORT FRAME MEMBER
AND ON RIGHT MAIN FRAME MEMBER (SEE FIGURE 4)
Accessories are available for your ODC 1220. Ask for them where you bought your ODC 1220,
or visit the Creek Company Store at www.creekcompany.com
The Creek Company Ltd. , PO Box 773892, Steamboat Springs, CO 80477
email: [email protected]
Specifications and other details subject to change without notice.
All Creek Company products are guaranteed against defects in material and workmanship for the life of the product to
the original owner. This does not cover damage due to misuse or normal wear and tear.
