KL INDUSTRIES INC.
Sun Dolphin Kayaks
All Models
OWNER’S MANUAL
1790 Sun Dolphin Drive
Muskegon, Michigan 49444
phone [phone]
fax [phone]
email [e-mail]
website www.sundolphin.com
Manufactured by:

1
Dear Customer,
Congratulations on the recent purchase of your new Sun Dolphin kayak manufactured by KL Outdoor! You have purchased a kayak
from one of the nation’s leading manufacturers of small boats. Your kayak represents years of commitment to product design,
excellence in engineering and quality in manufacturing. With proper care and maintenance, your kayak should last for many years
to come. If you have any questions, please call our helpful and knowledgeable Customer Support Department at 800-733-2727.
IMPORTANT INFORMATION TO CONSERVE
Keep your Owner’s Manual for future reference. In order to provide you with efficient and accurate service, please have the
following information available:
Model and Serial Number _______________________________________________
Date and Place of Purchase ______________________________________________
To order parts and accessories visit our website at www.sundolphin.com or contact us at 800-733-2727.
HOW TO LOCATE YOUR SERIAL NUMBER
The serial number is located on the rear right-hand side of the hull. The number starts with JOK and is
12 digits long. Photo #1
Serial Number Location

Never exceed the maximum weight capacity.
Never exceed your ability: Access your physical capability as to how long you can paddle and swim.
Make sure drain plug is secure.
Always familiarize yourself with the body of water where you will be boating: Learn what hours boating are permitted,
whether there are any known hazardous conditions, and where you can get help quickly in case of an emergency or accident.
Always abide by Coast Guard regulations and State and Local laws, regulations ordinances and rules concerning boating
and boating safety: Check with Coast Guard and local authorities concerning proper handling and the proper equipment to
be carried on board, such as lights and sound-producing devices.
Never use or consume alcohol, drugs or any other substance that may affect your coordination, judgment or ability to
safely operate the boat.
Sound Device: The Coast Guard requires boaters to have a means of signaling other boats of their presences. You should always
keep a device such as a whistle in the boat at all times. If possible, attach the sound device to your Personal Flotation Device.
Never stand up in the boat: Standing in the boat may cause it to capsize. If the boat should capsize, please note that, in most cases it is far more
dangerous to attempt to swim to shore than to stay with the boat.
Slippery when wet: The hull material may be slippery when wet. Always wear slip-resistant shoes.
Hypothermia: Boating accidents in cold water are very dangerous. Hypothermia (the loss of body heat due to immersion in cold waters) can be deadly. Survival
time can be as short as 15 minutes in 35 degree F (2 degree C) water. Dress appropriately for weather conditions, wearing a wet or dry suit if necessary.
Never allow minors to use this boat without adult supervision.
Always tell someone your boating plans. Inform others of your boating plans, including where you are going, how long you will be gone and when
you expect to return.
Never use this boat in severe weather conditions: Although stable, large waves could cause the boat to overturn.
Do not paddle in flood conditions. Never use this boat in rapids or fast moving currents: This boat is designed for leisure. The boat could be damaged
and (or) the occupants could be severely injured should they attempt to utilize it in any other way.
Never use this boat after sunset: This boat is not equipped with horns or lighting equipment required to ensure the safety of its occupants.
Always wear a helmet where appropriate.
Always wear a Coast Guard approved Personal Flotation Device (PFD) when using this boat: Before going boating, read the PFD manufacturer’s
information pamphlet regarding the PFD and thoroughly familiarize yourself with how the PFD is to be worn.
WARNING
Read the following information before using your kayak. Failure to follow the warning precautions below may lead to serious injury including
the possibility of death.
SECURITY MEASURES
Photo #2
Drain Plug Location
2

3
MATERIAL
Your kayak is manufactured from High Density Polyethylene (HDPE). It is a very durable material. Our specially formulated HDPE has
an ultra-violet inhibitor blended throughout the material to reduce color fade and maintain its strength. Polyethylene is a somewhat
flexible material with some memory. This means it has a tendency to return to its original molded shape if distorted.
BOAT SET-UP
Note: Models vary and may not come equipped with the features listed below.
Adjustable Foot Braces
Raise the foot brace handles and adjust foot braces to desired position. Lower handles to lock in position.
Adjustable Seat Back
Unhook strap fasteners from eyelets. Adjust straps to desired position. Lock fasteners back into eyelets.
Paddle Holder
Paddle can be secured in bungee paddle straps on side of hull.
Drain Plug
Make sure drain plug is secure.
Manufacturers Statement of Origin (MSO)
You should receive a MSO with your new boat. Some states may require a MSO for proper registration of your boat. Please check
with your local licensing bureau.
APPLYING REGISTRATION DECALS
Before applying boat registration decals (if required), clean the area with alcohol or any solvent that does not leave a residue. Make
sure the solvent is put aside and the decal area is dry. Using a propane torch, lightly pass the flame back and forth over the area
where the decals will be applied. Don’t try to heat the surface. This procedure will enhance the adhesion of the decals.
BEFORE LEAVING THE SHORE

4
Make sure your drain plug is secure.
Passengers should always wear a Personal Flotation Device.
Check for wind conditions, currents or wave conditions that would make it difficult to paddle back.
Always let someone know of your boating plans, your boating location, and when you expect to return.
CARE AND MAINTENANCE
Your kayak is designed to require minimal maintenance, and a little timely care will ensure a lifetime of enjoyment. Whenever you
wash your boat, use mild soap and water. Rinse your boat and hardware thoroughly after paddling in salt, brackish or polluted water.
A quick rinse of the moving parts of the foot braces keeps them clean and operating smoothly.
Occasional operational checkups will keep your boat in tip top condition. Check hatch covers, cables, buckles, straps and other
moving parts for wear, and replace them when necessary. Give your hull and deck a thorough review annually. Light nicks,
scratches and scrapes are part of the paddling experiences, but deep scratches should be repaired.
Polyethylene is a somewhat flexible material with some memory. This means it has a tendency to return to its original molded
shape if distorted. If this occurs, follow these steps:
1. Relieve the pressure that caused the dent or distortion by supporting the boat differently or removing the gear.
2. Place the boat in the warm sun. Usually the south side of the building is the warmest spot. As the boat warms up, usually
(but not always) the boat will return to its original molded shape. This may take a few hours or a couple of weeks depending
upon outside temperatures and the degree of distortion.

5
STORAGE
• Store your kayak on its side. Do not store your boat on its hull.
• To protect your kayak, provide shelter from sun using a tarp suspended above the boat. To prevent excessive heat build-up,
do not cover boat with tarp laying directly on its surface. Leave adequate air space to allow for air circulation.
• If possible, it is best to store your kayak inside for the winter.
• Don’t allow water to accumulate between the deck and hull and freeze.
• Don’t place the boat on 4x4’s or sawhorses. Dents will form in the hull.
FREQUENTLY ASKED QUESTIONS
• Where is the serial number located? The serial number is located on the rear right-hand side of the hull. The number starts with
JOK and is 12 digits long.
• What can I do if dents form in the hull from improper storage? Expose the dents to the warm sunlight, preferably on the south
side of a building. As the plastic warms, it will usually (but not always) return to its molded shape. This process may take one
day to two weeks.
OPTIONAL ACCESSORIES
• Order online at www.sundolphin.com

6
Please Choose Your Model
ALSO FEATURES:
•
Lightweight, easy
to carry
• Tracks and
paddles with
ease while offering
maximum stability
• Tough polyethylene
deck and hull
Comfortable, padded
seat back
(SS model only)
Self
bailing
Carrying
handles
Open cockpit
allows the easiest
of entry
Recessed
drink holders
Storage
compartment
(SS model only)
On-board storage
with shock-cord
deck rigging
(SS model only)
Graduated foot wells are
molded-in to accomodate
paddlers of any size or age
Bali 6 Sit-On Bali 8 Sit-On
(SS Model Shown)
Tough polyethylene
deck and hull
Graduated foot wells
Open cockpit allows
the easiest of entry
Large, comfortable
seating area
Convenient
paddle holder
ALSO FEATURES:
•
Lightweight, easy
to carry
• Tracks and paddles
with ease while
offering maximum
stability
Specifications
Length 6’ 183cm
Width 24” 61cm
Depth 8” 20cm
Weight 28 lbs. 13kg
Capacity 140 lbs. 64kg
Specifications
Length 8’ 244cm
Width 28” 71cm
Depth 15” 38cm
Weight 30 lbs. 14kg
Capacity 197 lbs. 89kg

7
Please Choose Your Model
ALSO FEATURES:
•
Lightweight, easy
to carry
• Tracks and paddles
with ease while
offering maximum
stability
Specifications
Length 10’ 305cm
Width 30” 76cm
Depth 11” 28cm
Weight 44 lbs. 20kg
Capacity 250 lbs. 113kg
Bali 10 & Journey 10
Sit-On
(Journey 10 ss Model Shown)
Open cockpit
allows the easiest
of entry
Adjustable foot
braces
Convenient
paddle holder
Tough polyethylene
twin sheeted deck
and hull
Storage
compartment
Swivel fishing
rod holder
(Fishing model only)
Shock cord deck
rigging fore/aft
P.A.C.
Portable
Accessory
Carrier
Retractable
carrying
handles
Large comfortable
seating area
(seating may vary)
Flush mount fishing
rod holders
(Fishing model only)
Camino 8 Sit-On
(SS Model Shown)
ALSO FEATURES:
•
Lightweight, easy
to carry
• Tracks and paddles
with ease while
offering maximum
stability
Specifications
Length 8’ 244cm
Width 30” 76cm
Depth 12” 30cm
Weight 40 lbs. 18kg
Capacity 225 lbs. 102kg
Adjustable,
padded seat with
high backrest
Molded-in
carrying handles
Square stern offers
maximum stability
Large, open
cockpit for easiest
of entry
Storage
compartment
Graduated
foot wells
Self-bailing

Please Choose Your Model
8
ALSO FEATURES:
•
Lightweight, easy
to carry
• Tracks and paddles
with ease while
offering maximum
stability
Bali 12 & Journey 12
Sit-On
(Journey 12 ss Model Shown)
Specifications
Length 12’ 366cm
Width 29½” 75cm
Depth 13½” 34cm
Weight 48 lbs. 22kg
Capacity 395 lbs. 179kg
Large, comfortable
seating area (seating
may vary)
Retractable carrying
handles
Shock cord
deck rigging
fore/aft
Open cockpit
allows the easiest
of entry
Storage
compartment
Tough polyethylene
twin sheeted deck
and hull
Adjustable
foot braces
Swivel fishing
rod holder
(Fishing model only)
P.A.C.
Portable
Accessory
Carrier
Flush mount fishing
rod holders
(Fishing model only)
Specifications
Length 13½’ 412cm
Width 34” 86cm
Depth 17” 43cm
Weight 70 lbs. 32kg
Capacity 500 lbs. 227kg
Bali 13.5 Tandem
(ss Model Shown)
ALSO FEATURES:
•
One, two or three
person kayak
• Self-bailing
Adjustable
foot braces
Carrying
handles
Paddle
holders
Adjustable, padded
seats with high
backrests
Storage hatches
and compartments
(ss models only)
Middle seat location
for one person
operation

9
Please Choose Your Model
Aruba 8 Sit-In
(SS Model Shown)
ALSO FEATURES:
•
Lightweight, easy
to carry
• Tracks and paddles
with ease while
offering maximum
stability
Specifications
Length 8’ 244cm
Width 28” 71cm
Depth 16” 41cm
Weight 27 lbs. 12kg
Capacity 260 lbs. 118kg
Large open
cockpit
Carrying
handles
Convenient
paddle holder
Tough Polyethylene
deck and hull
Padded seat back
(ss model only)
Spray deflector/
collar
Storage
compartment
(ss model only)
On board storage
with shock cord
deck rigging
(ss model only)
ALSO FEATURES:
•
Adjustable foot
braces
• Hull design
is optimum
combination
of tracking
and turning
Large open
cockpit
UV-stabilized
High Density
Polyethylene
Carrying
handles
fore and aft
Thigh pads
Shock cord
deck rigging
Adjustable, padded seat
(Seating may vary) Storage
hatch
Water bottle
holder
Aruba 10 & Excursion 10
Sit-In
(Excursion 10 Model Shown)
Specifications
Length 10’ 305cm
Width 30” 76cm
Depth 13” 33cm
Weight 40 lbs. 18kg
Capacity 250 lbs. 113kg
Flush mount
fishing rod holders
(Fishing model only)
Swivel fishing
rod holder
(Fishing model only)

10
Please Choose Your Model
Aruba 10 ss &
Excursion 10 ss Sit-In
(Excursion 10 SS Model Shown)
Specifications
Length 12’ 366cm
Width 29½” 75cm
Depth 13½” 34cm
Weight 47 lbs. 21kg
Capacity 395 lbs. 179kg
Tough
polyethylene twin
sheeted deck and hull
Retractable
carrying
handles
Thigh
pads
Swivel fishing
rod holder
(Fishing model only)
Shock cord
deck rigging
fore/aft
Large, comfortable
seating area
(seating may vary)
Flush mount fishing
rod holders
(Fishing model only)
Covered
console
P.A.C.
Portable
Accessory
Carrier
Storage
compartment
Excursion 12 Sit-In
(Excursion 12 Model Shown)
ALSO FEATURES:
•
Lightweight, easy to
carry
• Tracks and paddles
with ease while
offering maximum
stability
• Adjustable foot
braces
ALSO FEATURES:
•
Lightweight, easy to
carry
• Tracks and paddles
with ease while
offering maximum
stability
• Adjustable foot
braces
Specifications
Length 10’ 305cm
Width 30” 76cm
Depth 13” 33cm
Weight 44 lbs. 20kg
Capacity 280 lbs. 127kg
Large, open cockpit
with adjustable
padded seat
Carrying
handles
Shock cord
deck rigging
Protective
thigh pads
Hands-free
electronics console
(Bluetooth speaker
and dry bag optional)
Two flush mount
rod holders
(fishing model only)
Removable P.A.C.
can be used as
extra storage
One swivel
rod holder
(fishing model only)
Paddle
holder

Warranty
LIMITED LIFETIME WARRANTY
GENERAL INFORMATION
Your boat represents years of commitment to product design, excellence in engineering and quality in manufacturing. With proper care and maintenance, your boat should
last for many years to come. If you have any questions or need technical support please go to the “Contact Us” section of our website at www.sundolphin.com or contact our
Customer Service Department at 800-733-2727.
Do not return this boat to the retailer. If you have any questions regarding this product please contact us. In order to provide you with efficient and accurate service, please have
the following information available: model and serial number, date and proof of purchase.
KL Outdoor’s warranty is valid only if the product is used for its intended purposes and for which it was designed.
HOW TO REGISTER YOUR BOAT
Warranty is not valid unless registration is submitted within 30 days of retail purchase. Please register your boat via our website at www.sundolphin.com.
TERMS OF LIMITED LIFETIME WARRANTY
KL Outdoor warrants to the original owner of any KL Outdoor boat. Any part of the deck or hull which is defective in material or workmanship will be repaired or replaced,
without charge, at the purchasers’ local authorized dealer or at KL Outdoor. This warranty is non-transferable.
Component parts and accessories are warranted for a period of one (1) year from the date of purchase. Any warranties from suppliers of component parts supersede KL
Outdoor’s warranty.
CLAIMS PROCEDURE
The return of any KL Outdoor boat will not be accepted without a return authorization number. The retailer can obtain this number by contacting our Customer Service
Department.
Any claim under this warranty must be communicated via our website at www.sundolphin.com. Please have the following information available: model, serial number, proof of
purchase and photos of the defect. KL Outdoor will evaluate the information and determine if it is a valid manufacturing defect prior to issuing a return authorization number.
KL Outdoor reserves the right to discontinue and make changes in any of its products. In the event that products covered by this warranty are not available, KL Outdoor shall
have the right to substitute products at KL Outdoor’s sole discretion of comparable grade, quality or price.
EXCLUSIONS AND LIMITATIONS
The owner must follow the Care and Maintenance Instructions outlined in the owner’s manual. Failure to follow such instructions may void this warranty.
This warranty does not cover:
1. Damage caused by accidents, vandalism, abuse, misuse, neglect or carelessness
2. Any defect cause by alteration or modification
3. Boats used for rental or commercial purposes
4. Damage caused by Mother Nature, environmental conditions or other causes beyond the control of KL Outdoor
5. Deterioration from normal wear or exposure
6. Any defect which would not have occurred if instructions in the owner’s manual had been followed
7. Hull abrasion damages
8. Damages incurred in possession of freight company or any other third party
Freight to and from local dealer or manufacturing plant is at the owner’s expense. KL Outdoor is not responsible for any damages incurred in transport, for storing or for
inconvenience or loss of time or money while repairs are being made.
All incidental and/or consequential damages are excluded from this warranty. Implied warranties are limited to the life of this warranty. Some states do not allow limitations
on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages so the above limitations or exclusions may not apply to you. This
warranty gives you special legal rights and you may also have other legal rights which may vary from state to state.
This limited warranty only covers products within the continental United States, Canada and Mexico.
