Crest Audio X-MATRIX X-VCA MATRIX EXPANDER User manual

features
● Can be used as a dual output Matrix expander for the Crest X-
VCA console, or as an independent 12X2 Line input mixer.
●Front panel rotary potentiometers for setting mix levels
● Input and Output multi-pin connectors for linking multiple units.
● 1/4" TRS balanced inputs and XLR balanced outputs
● Insert send and return on each output channel.
● LED Level meter and master level control for each output
● Five Year Crest Audio warranty.
When used as X-VCA Matrix Expander:
● 37-pin D-Sub connector brings in Groups 1 - 8, Left, Right &
Mono, and external line input
● Solo, Talkback, and Mute facilities on each output channel.
● Line input connectors can be used to bring in substitute signals
● Multiple units can be daisy chained for additional matrix mixes
● X-VCA console provides power for up to 4 X-Matrix units via
main link cable, resulting in a 12x12 matrix mix system. External
power supply available for powering additional units.
When used as a stand alone mixer:
● Functions as dual 12X2 mixer
● Accepts balanced or unbalanced line level signals via 1/4" TRS
inputs
● Multiple units can be daisy chained together to create multiple
mixes from the signals that are fed to the first unit.
● Powered by external power supply which includes headphone and
talk back facilities
40
20
10 0
6
•
3
30
+
–
PWR
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
12B11M10R9L87654321 OUT LEVEL
A
A&B
INPUTS
X
M
A
T
R
I
40
20
10 0
6
•
3
30
+
–
MUTE SOLO
TB
40
15 10 0
10
•
5
20
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
40
20
10 0
6
•
3
30
+
–
BB
MUTE
40
15 10 0
10
•
5
20
+
–
ASOLO
TB
12A11M10R9L87654321
–24 15 9 6 3 0 3 6 +
A – OUTPUT LEVEL – VU
–24 15 9 6 3 0 3 6 +
B – OUTPUT LEVEL – VU
MATRIX EXPANDER
LINE MIXER
X-Matrix is a 12 X 2 matrix mixer. It's primary application is
to add additional matrix mixes to the X-VCA console. It can
also be used as a stand-alone matrix mixer. As a companion
piece to the X-VCA console, it provides the facilities to create
additional mixes from the eight Sub groups and the Left, Right
and Mono mix buses. In both applications, multiple units can
be daisy-chained, offering almost unlimited expansion capabili-
ties.
Each X-Matrix can accept 12 line inputs (via multi-pin connec-
tor) from the X-VCA or from 1/4" TRS line input jacks, and
generates 2 outputs which include insets, level adjustment and
muting capabilities. The outputs appear on balanced XLR's
mounted on the rear panel.
Expansion, applications and quality X-Matrix may be
expanded both horizontally and vertically, turning X-Matrix on
its own into a very versatile mixing system for specialized
applications, or where additional matrixes or auxiliary mixes
need to be added to any console.
The X-Matrix has all the flexibility, sonic purity and rock solid
reliability common with all Crest Audio mixing console prod-
ucts. While it is intended to be used as an add-on accessory
to the X-VCA console, it's flexibility allows it to be used in a
wide variety of applications such as submixing, recording,
broadcast, and monitor mixing.
Powering for the X-Matrix Power is derived directly
from the console for up to 4 units. This configuration enables
a basic X-VCA to generate 12x12 matrix outputs. The X-
VCA console acts as the power supply, talkback, and solo and
headphone system for the added-on X-Matrix units. With
the addition of an optional power supply, virtually unlimited
matrixes may be added to the X-VCA. The external power
supply unit contains headphone and talkback facilities allowing
the X-Matrix to be used as a flexible, full featured stand-alone
unit.
description
Mixing
Consoles
X-Matrix
1
23456789101112A12B
B
Bal Out
A
Bal Out
From Console, PS, Or Previous X-Matrix
To Next X-Matrix Or Power Supply
Line Inputs: Nom Lev= -2dBu
(Normalled From Expansion-In Conn)
IN
OUT
EXPANSION CONNECTORS
B
Rtn•INSERT•Snd
BUS
B • IN • A
A
Rtn•INSERT•Snd
Nom Level= +4dBu
T = OUT +
R= G COMP
S= GND
T = IN +
R= IN –
S= GND
1/4” TRS Input 1/4” TRS Output Male XLR Output
12
3
1= GND
2= OUT +
3= OUT –
Bus Input
Line Input
Insert Return
Insert Send A & B Main Out
X
M
A
T
R
I
Professional Audio Products
Designed and Built in the USA
front panel
rear panel
X-VCA Matrix Expander
www.crestaudio.com v. 1.1 01/10/01
