Crest Audio CDVS-5432 Series User manual

-2-
CDVS-3032
1. Precautions
Cautions & Warnings
- Be sure to turn off the power before installation.
- Avoid rough handling or mechanical shock.
- Keep off 20 cm distance with other machines or electronic products.
- Keep away from direct rays of the sun or heater or similar devices.(it causes fire)
- Don’t put things such as vase, cup, cosmetics, bottle etc. on this product. (it causes fire, an electronic shock
hazard or an injury by falling)
- Don’t block the ventilating holes of this product with a kind of metal(ex : coins, hairpin, metal plate etc.) or
inflammable stuff(ex : match, paper etc.).(It causes malfunction of the product, fire and electronic shock hazard.)
- Don’t put a heavy-weight things on this product.(It causes an injury by falling)
- Fully insert power plug at outlet. (Uncertain connection causes fire.)
- Wipe smoothly with using dried cloth to clean the product. Don’t use any chemical products or detergent. This
may change the color of the product and spoil its surface .
- Stop using and turn off the power when odd smells or smokes comes out from the product. Then call your
nearest customer service. (continuous using may causes fire, an electronic shock hazard.)
- Don’t touch the power plug & cable with wet hand. (It causes electronic shock hazard.)
- Don’t pull power plug out by force. (Damaged power plug causes electronic shock hazard.)
- Keep away from the place of dust, humidity, soot when you install. These may cause malfunction of the product.
Be place dehumidifier near the product, remove dust from the fan of ventilate holes with compressed air every 3
months.(Dust & others may cause fire and electronic shock hazard.)
- Replace or clean front filter once of 3 months.
- Don’t drop or impact to the product.
- Keep this product away from strong magnetic fields or mechanical vibration.(It causes malfunction)
- Don’t install the product to extremely cold place.
- Install the product well-ventilated place.
- Don’t open the cover of product at your disposal. (It causes fire, an electronic shock hazard.)
- Don’t change the power supply switch at your disposal. (It causes malfunction and damage)
- Don’t press the product when front door open. (It causes transformation or damage of Front Door.)
- Put another supportable stuff not to damage BNC board. BNC board could be broken or damaged by the weight
of BNC cable.
- It causes danger of explosion if battery is incorrectly replaced.
- Replace only with the same or equivalent type recommended by the manufacturer.
- Dispose of used batteries according to the manufacturer’s instructions.
- Adjust power input switch correctly.(110V or 220V)
- Use stable transformer where expected unstable power supply.
- Ask your customer service when you add more devices on this product(ex: HDD, Back-up device)

-3-
CDVS-3032
2. Installation System
Open the box and make sure that the following accessories are supplied. (Some part and design could be
different according to model.)
2.1 Removing Package.
CDVS-5432
Door keys
Pan/Tilt Cable(RS-485)
Power Cable
Mouse
Keyboard
User’s Manual Install CD
User’s Manual

-4-
CDVS-3032
2.2 Rear panel of System
d
ef ghijklmnop qr s
a. Camera Input (CH1~CH32)
b. Camera 75Ohm Terminator
c. Control Output (Com:4port, Control:16port)
d. Sensor Input (Com:4port, Sensor:16port)
e. AC Power Input (AC 110 ~ 220V)
f. PS/2 Mouse Port
g. PS/2 Keyboard Port
h. USB Port
i. Com A Serial Port
j. LPT(Printer) Port
k. Com B Serial Port
l. Line Out 1
m. Line In / Line Out2
n. MIC In
o. Game Port
p. VGA Out
q. TV Out (Composite Out)
r. RS422/485 (RX Connection Port)
s. LAN Port

-5-
CDVS-3032
2.3 Connecting outer Devices
- Connect keyboard & mouse (included in the box)
Connect keyboard and mouse at the correct place like a picture.(picture shows keyboard
connection, upper port is for mouse connection)
- Connect Camera (cable is not included)
Connect camera cable to channel input port.
- Connect communication cable(cable is not included)
Connect LAN cable or public phone line(if installed) for using client program (such as
center & i-DVR).
- Connect Power supply cable
Connect power supply cable. Check again Voltage switch before connect cable.(110V or
220V)
- Connect RCA output(if available) jack & Pan/Tilt cable.
Connect RCA output jack line for outer monitor and Pan/Tilt camera control cable.

-6-
CDVS-3032
2.4 Connect Pan/Tilt control
- Connect to PAN/TILT Receiver (RS-485 Signal line)
- Caution : When connect, pay attention (+), (-) polarity
of signal line
485 Signal Line (+)
Signal Line (-)
a ground
RX LED (Green)
TX LED (Red)
Operation LED (Green)
- Only when Operation LED is
‘On’ state, image appears
normally.

-7-
CDVS-3032
2.5 Connecting PSTN, ISDN, Leased Line & LAN
Connecting to COM 2 port
( 9 PIN )
LAN port
Ethernet
D.S.U(Modem)
Printer
Client pc for Remote control
Leased Line (ISDN)
A/C ADAPTER
D.S.U(Modem)
A/C ADAPTER
RS-232(25Pin)
COM2
Following picture shows how you connect to a communication line. It shows about LAN connection and
PSTN (external modem). When you have modem in your system, you don’t need to use COM2 port for
connection.

-8-
CDVS-3032
2.6 Connecting Loopback output (Camera 75 Ohm Terminator)
When a sensor triggered or motion detected, warning or alarm signal is output through the each port of control
out.(need to setup before using. See P35). If devices connected correctly, it works by the output signal from control
out port. (See the picture for connection)
- Use 12V, below 300mA. For controlling lights or other devices, use another external relay.
Con.
COM Control Out ( 1 ~ 16)
(+)(-)
External Power Supply ( DC 12V)
Siren, Alarm, Outside Relays
2.8 Connecting External Sensor
Sen.
COM Sensor Input ( 1 ~ 16)
16 sensor connections are available. Usually sensor’s one of signal lines connect to com port and connect the
other signal line to a desired sensor input port(1-16).
- Set “NC”, “NO” Type at setup menu.(see p35)
- No power supply from the product. Use individual or provided power for each sensor.
ON ON
2.7 Connecting Control Output
1 ----------------------------------------------------16
Each channel’s current input image can directly out to monitor by ‘Ch out’ port. 16 ch outputs are available.
To use this function, connect cable then adjust dip switch.
- ‘On’ : not connected outer monitor.
- ‘Off’ : connected with outer monitor
- For a normal image output of each channel, adjust dip switch as ‘On’ status when there are no connection
with monitor.

-9-
CDVS-3032
3. Surveillance Mode
When every connection is made, turn the power on. After loading OS, it automatically starts DVR program.
Initial screen is surveillance mode(see the picture below). In surveillance mode, it shows real time images of
each channel from a connected camera. Also user can control other functions with using function buttons.
3.1 Surveillance screen.
a) Shows current user.
b) Shows Current date and time
c) Select image group : In 32ch DVR, because of its screen size, we add the function which able to select
image group ‘cam1-16’ and ‘cam17-32’. When you select ‘1-16’, Cam1-16 image group will be displayed and
you can control screen division with using buttons(1,4,6,7,8,9,10, 13, 16 divided screens). Same as when you
select ‘17-32’ mode.
d) Function Button : search, setup, backup, Pan/Tilt control, exit button.
e) Select Screen division : icons for selecting whole screen, 4, 6, 7, 8, 9, 10, 13, 16 division.
f) Shows status of current working HDD partition.
g) Shows connected control & sensor ‘s working status.(on/off)
h) Shows IP address of connected user’s.
* When program starts, it login as ‘default’ user. To add user or control all the function, you must re-
login as ‘Administrator’ (ID : Administrator, Password : none). See detail at 3.2.
- When system starts, it only shows 4 channels(4ch display is default value at initial time). When system
restarted by unexpected power failure or by force, it remembers last information of screen division then shows
last screen division.
a) b)
c)
d)
e)
f)
g)
h)

-10-
CDVS-3032
3.2 Login as Administrator
At the first time, program automatically login as default user. To use program with another user, user
information must be registered by Administrator. When DVR starts, login as ‘Administrator’ and add users and
allow permissions of each user. No password is set to Administrator. After login as Administrator, then
change the password and memorize it.
Click one of function
buttons.(except Auto
change button) If above message shows , press ‘Yes’
When ‘User Login’ shows up, type ‘Administrator’ in
user name and press ‘Ok’.(No password at first time)
After login as ‘Administrator’, Now user can use every
function of DVR.
* You can add user after login as ‘Administrator’. For more information about add
user see 5.14 e) on this manual.

-11-
CDVS-3032
3.3 Controlling Screen Division
When user clicks one of following buttons, screen display will change as selected division. In 32 ch system, it
displays only 16 channels at a time. If you want to see from ch17-32, press ’17-32ch’ button at display mode.
Select button works same as when you do in 1-16ch mode. (ex, Ch1 -> Ch 17, Ch2 -> Ch18 …Ch16 -> Ch32)
3.4 Instant Recording in Surveillance mode
If system schedule set as ‘No recording’ or ‘Motion mode’, no images are recorded without motion. Use this
function when user need to record a image regardless of system schedule.
Although in continuous recording mode, user can use this function to mark suspicious part.
-Howtouse
- Move mouse and click right mouse button.
- Then ‘Instant’ caption shows up on top of right screen.
- To release, double click right mouse button.
* You can’t use this function without setting the frame on ‘Recording Schedule’ at Setup.
4A : Display the screen cam1 ~ cam4 (cam17-cam20 in ’17-32’ mode).
4B : Display the screen cam5 ~ cam8 (cam21-cam24 in ’17-32’ mode).
4C : Display the screen cam9 ~ cam12 (cam25-cam28 in ’17-32’ mode).
4D : Display the screen cam13 ~ cam16(cam29-cam32 in ’17-32’ mode).
9A : Display the screen cam1 ~ cam9 (cam17-cam25 in ’17-32’ mode).
9B : Display the screen cam8 ~ cam16 (cam25-cam32 in’17-32’ mode).
13 : Display the screen cam1 ~ cam13 (cam17-cam29 in ’17-32’ mode).
16 : Display the screen cam1 ~ cam16 (cam17-cam32 in ’17-32’ mode).
6 : Display the screen cam1 ~ cam6 (cam17-cam22 in ’17-32’ mode).
7 : Display the screen cam1~ cam7 (cam17-cam23 in ’17-32’ mode).
8 : Display the screen cam1~cam8 (cam17-cam24 in ’17-32’ mode.)
10 : Display the screen cam1~cam10 (cam17-cam26 in ’17-32’ mode).
If you press this button, all button disappears and entire screen displays. To return
to a previous mode, click right mouse button again.

-12-
CDVS-3032
3.5 Screen Auto Switching
To use Auto Switching, click the button(left picture) in a surveillance mode. When you click
this button, the divided screen switches automatically. You can set switching time at the
setup.(Auto switching is available on 1, 4, 9 division)
-1chmode
1
Double click left mouse button Click
16
- 4 ch division mode
1 2
3 4
13 14
15 16
Choose Mode Click
123
456
789
10 11 12
13 14 15
16 8 9
- 9ch division mode
- How to use Auto Switching
1. Choose screen.(1, 4(a,b,c), 9 division)
2. Click auto switching button
3. To stop, click auto switching button again.
* For entire screen mode, click entire screen icon after clicking auto switching button
Choose Mode
Click
*

-13-
CDVS-3032
3.6. Backup
The icon left is backup button. If this button is pressed, following picture shows up. This function
uses for moving a stored image data from local HDD to other backup media. User can backup
image data to other portable media or other HDD. Available backup devices are DVD-RAM, CD-
RW and IEEE1394 devices.
a)
b)
c)
d)
a) Error Msg : Show error messages. If selected data is more than available space it shows error message.
b) Calendar : Red for current date, reversed for data stored date.
c) Select Backup Media : Shows available backup devices(when check ‘Fixed disk’, it shows installed local
HDD list.)
d) Time table for selected data. Each block contains 10 minutes’ data.
- How to backup
- Press backup button, following dialog shows up.
- Select date and 10 minute data block.(if selected it turns red)
- Select backup media. (Backup medial should be installed)
- Press ‘Start Backup’ button.
Format IEEE1394 connected external HDD.

-14-
CDVS-3032
3.7 Controlling PAN/TILT Camera
If the PAN/TILT camera installed, you can control camera with following remote control. To do
this press the PAN/TILT remote control button(picture in left) then you can control camera.
Available function may be varied according to camera.
To control camera direction, use arrow buttons. The number in the
middle of circle shows currently selected camera number. To change
this, click camera image from surveillance screen. If no PAN/TIL
camera installed this will not available.
Using arrows, user can Zoom in/out and adjust focus manually. If your
camera doesn’t support these, you can’t use these function.
User can turn on/off the power of WIPER, LIGHT with click button.
When you press ‘TOUR’ button, the camera moves to the preset
location(Location and other control should be set before use this
function), These function subject to the function of camera.
- Direction Control
- Zoom & Focus Control
- Control additional devices
- Preset Control
To use preset control, user should preset the position in “Pan/Tilt Detail settings’. This function enables
your camera automatically moves to the position where you set before. User can use this function when he
needs to watch more than one area with one camera.

-15-
CDVS-3032
3.8 Exit (Power Off/ Restart System)
The button like a picture is a logout(exit) button. To change current user, you should log off and
then log on with other user name.
When you need to change Windows setting, select ‘Restart in Window mode’.
- Log On : Log on with other user.
- Log Off : Log off current user and Log on with default user.
- Power Off : Shut down system.
- Restart System : Restart System.
- Restart in Window Mode : Finish DVR program and restart in windows mode.
Restart in Windows Mode

-16-
CDVS-3032
4. Search
With search function, user can find a recorded data more easily than VCR. Our search function
provides special features such as Index search & Object search.
a) Functions in Search mode
In search mode. Print, Saving file, Index search, removing after image, object search and Thumb nail
preview are available.
a) b) c)
b) Select Camera
Select camera number, date & time before start search. To select more than one camera, you can
use screen division button or choose each cameras you desired to watch.
d)
e)
f)
g)

-17-
CDVS-3032
d) Playback buttons
e) Date, skip & delay
Select a button like a picture then a calendar shows up on your screen. Red
color is current date and reversed date means that there are recorded images of
that day. Select a date and press ‘Ok’.
-Delay : set delay time for playback(higher value(50)).
-Skip : Set the number of frame to skip
User can adjust Time and minute of stored data with
using scroll bar like a picture.
f) Adjusting Time
g) Select Screen
1, 4, 16, 32 screen selection is available in
search mode.
Playback button(clockwise)
Counterclockwise
playback button
Frame by frame playback
button(Clockwise)
Move to the end of frame
Frame by frame playback
button (counterclockwise)
Move to the start
of frame
Stop button
c) Adjust Bright & Zoom
User can adjust brightness and screen size of current stopped image.
To adjust current image in the middle of searching, you should pause
the image and select a camera then you can adjust it.
To zoom in current image’ part, pause current screen and move
mouse pointer to a desired area then click ‘right’ mouse button, 5 steps
zoom in is possible for pointed area.
- User can adjust brightness of screen with using ‘Bright’ adjust bar.

-18-
CDVS-3032
4.1 Printing
User can print out current image. To print out a image, stop the desired image then press print
button.(If printer is not installed, you can’t print out.)
- Install printer
- Press ‘Exit’ button and select ‘Restart in Window mode’
- Press ‘Start’ then ‘setting’.
- Press ‘Add Printer’
- Press ‘Next’ in print installation Wizard
- Select ‘Local Printer’ then press ‘Next’.
- Choose correct printer driver in the list or use a driver when you purchase a printer.
4.2 Saving Image files
User can save current image as Jpeg or AVI format. To save image, press save button and
check export type and choose a director to save files. Press ‘Ok’ to save.
- Export Type : Choose file format.
- JPEG File : current stopped frame
- AVI File : moving pictures.
- AVI detail setup(available when ‘AVI file’ checked)
- AVI duration from current frame(sec) : choose a time to
export from current image.
- Quality : choose Quality of exporting images.
Choose directory to save files and
press ‘Ok’.

-19-
CDVS-3032
4.3 Index Search
User can search a recorded image by Index search. User can search a recorded image by
sensor, motion, instant recording with this function.
- Select Camera : Select camera number.
- Select sort option
- Sensor : shows image list recorded by sensor
- Motion detection : shows image list recorded by motion
- Instant Record : shows image list by Instant recording
- All event : Shows all list of index recording.
Select option above picture then, following picture shows up. Select a recorded image
in list then you can play it.

-20-
CDVS-3032
4.4 Search Backup data
User can search a recorded image from a backup media. When user select a backup device, it
shows contained data list like a following picture.Choose one of them to playback.
- Backup Media : Shows available backup media.
-Fixed HDD : Shows installed HDD list in the system. If not selected it
shows installed external backup devices.
- Choose Start hour : Show the recorded data list from selected device.
Press ‘Ok’ button to playback selected image.
4.5 Filtering Afterimage
This product records 3 kind of resolution. In 720x480 resolution, because of its high speed
recording occurs afterimages when there is a high speed movement. This function filters this
phenomenon and shows clear image.
Afterimage After filtering
