Crest Audio Console Junior User manual

Operator Manual
Crest Healthcare Console Junior (CJ)
Series Ultrasonic Washer
Sales and Service:
Crest Ultrasonics Corp.
18 Graphics Dr, Ewing, NJ 08628, USA.
Phone: [phone].
www.crest-ultrasonics.com

Important Notifications
IMPORTANT: Read this entire manual before attempting to
install, operate or perform any maintenance on your Ultrasonic
Cleaning System. Ensure all appropriate personnel understand
the contents of this manual.
This operating manual contains important information on proper use
and maintenance of the ultrasonic cleaning system. All personnel
involved in the use and maintenance of this equipment must
carefully review and comply with the warnings, cautions and
instructions contains in this manual.
These instructions are important to protect the health and safety of
personnel operating the cleaner should be retained in a conveniently
accessible area for quick reference.
Complete instructions for uncrating have been furnished. If missing,
contact Crest Ultrasonics for a replacement copy, giving the serial,
equipment, and model numbers of the unit.
Crest carries a complete line of accessories for use with these units.
Crest representatives will gladly review these with you.
Advisory A listing of the SAFETY PRECAUTIONS to be observed when operating
and servicing this Ultrasonic Cleaning System is found in SECTION 1
of this manual. Do not operate or service the equipment until you
have become familiar with this information.
A
ny alteration of the cleaner not authorized or performed by Crest
will void the warranty, could adversely affect operator safety and
could violate national, state or local regulations.
Indications for Use The Ultrasonic Cleaning System is designed to thoroughly wash
(remove tissue, blood, and other contaminants) instruments prior to
final disinfection and sterilization as required. The Ultrasonic
Cleaning System’s compact design makes it suitable for use in the
Operating Room, Central Supply, or other high-volume areas to
process per-cleaned instruments.
IMPORTANT: Check the occupational health and safety act, as well
as local electric and plumbing codes, for any specific requirements
that may pertain to installation of this unit.
To help ensure operators are adequately trained in the safe use of
the equipment, Crest recommends:
All personnel operating or maintaining the Ultrasonic Cleaning
System are fully trained in equipment operation and safe use.
Personnel working with toxic chemicals and vapors (if applicable)
have comprehensive instructions in the washing process, relevant
health hazards and methods to detect the escape of toxic materials.
Crest Healthcare Console Junior R:1
Introduction

Service
Information
A thorough preventive maintenance program is essential for safe and
proper unit operation. This manual contains maintenance schedules
and procedures which should be followed for satisfactory equipment
performance. Comprehensive instructions for monthly, quarterly and
semi-annual preventive maintenance can also be found in this manual.
Only trained personnel should attempt to perform maintenance on the
Ultrasonic Cleaning System to avoid personal injury, improper
equipment performance, invalidation of the equipment warranty or
other costly damage.
Crest Healthcare Console Junior R:1
Operator Manual Introduction

TABLE OF CONTENTS
Section
Number Description Page
1
2
Safety Precautions ..................................................................................................................................... 1-1
Important User Information ...................................................................................................................... 2-1
2.1
2.2
2.3
Installation Checklist ........................................................................................................................................... 2-1
General Description ........................................................................................................................................... 2-2
Technical Specifications ..................................................................................................................................... 2-3
2.3.1 Overall Size (W x L x H) ........................................................................................................................... 2-3
2.3.2 Electrical .................................................................................................................................................... 2-3
2.3.3 Other Facility Requirements: ................................................................................................................. 2-3
Weight ........................................................................................................................................................ 2-3
Seismic Anchorage .................................................................................................................................. 2-3
Environmental Conditions ...................................................................................................................... 2-4
2.3.4
2.3.5
2.3.6
2.4 Special Additives Specifications ....................................................................................................................... 2-4
3 Operating Instructions ............................................................................................................................... 3-1
3.1
3.2
Before Operating This Equipment ..................................................................................................................... 3-1
Controls and Indicators ....................................................................................................................................... 3-2
3.2.1 Operator Controls and Indicators ........................................................................................................... 3-2
3.2.2 Other Controls ........................................................................................................................................... 3-3
3.3 Operating Instructions ........................................................................................................................ 3-5
3.3.1
3.3.2
3.3.3
Initial Start-up .......................................................................................................................................... 3-5
Wash Cycle .............................................................................................................................................. 3-7
Draining Cleaning Chamber. .............................................................................................................. 3.8
3.4
3.5
Port Flushing System. ......................................................................................................................................... 3-8
.
D .. a .. i . l .y...S.. h .. u ..t. d .. o .. w ... n .................................................................................................................................................... 3-10
4 Routine Maintenance .................................................................................................................................. 4-1
4.1 Before Performing Routine Maintenance ......................................................................................................... 4-1
4.2 Preventive Maintenance Schedule.................................................................................................................... 4-2
4.3 Cleaning Procedures .......................................................................................................................................... 4-3
4.3.1 General ...................................................................................................................................................... 4-3
4.3.2 Monthly Cleaning Procedure ................................................................................................................... 4-4
Replacement Parts .............................................................................................................................................. 4-5
4.4
5 Troubleshooting .......................................................................................................................................... 5-1
Crest Healthcare Console Junior R:1
Table of Contents Operator Manual

LIST OF FIGURES
Description Page
Figure 2-1. Lid Counterweight Shipping Bracket and Hardware ................................................................................... 2-2
Figure 3-1. Sonic Cleaner Control Panel (Typical) .......................................................................................................... 3-2
Figure 3-2. Generator Power Switch .................................................................................................................................. 3-4
Figure 3-3. Cycle Start foot pedal ...................................................................................................................................... 3-4
Figure 3-4. Port Flushing kit connections ......................................................................................................................... 3-9
Figure 4-1. Generator Module ............................................................................................................................................ 4-4
Crest Healthcare Console Junior R:1
Table of Contents Operator Manual

LIST OF TABLES
Table Title Page
Table 1-1 Definition of Symbols on Crest Healthcare Ultrasonic Cleaning System ............................................. 1-3
Table 4-1
Table 4-2
Table 4-3
Preventive Maintenance Guide .................................................................................................................. 4-2
Recommended Cleaning Products* .......................................................................................................... 4-3
Replacement Parts ...................................................................................................................................... 4-5
Table 5-1 Troubleshooting Chart - Cleaning Phase of Wash Cycle ....................................................................... 5-2
Crest Healthcare Console Junior R:1
Table of Contents Operator Manual

1
SAFETY PRECAUTIONS
The following Safety Precautions must be observed when operating or servicing this Ultrasonic Cleaning System.
WARNING indicates the potential for personal injury and CAUTION indicates the potential for damage to
equipment. For emphasis, certain Safety Precautions are repeated throughout the manual. It is important to
review ALL Safety Precautions before operating or servicing the unit.
WARNING – PINCHING HAZARD:
Pinch point is created during lid articulation. Keep hands clear when opening or closing the lid.
WARNING – CHEMICAL BURN AND/OR EYE INJURY HAZARD:
Detergents are caustic and can cause adverse effects to exposed tissues. Do not get in eyes, on skin or
attempt to ingest by mouth.
• Read and follow precautions and instructions on detergent label and in Material Safety Data Sheet
(MSDS) prior to handling chemical, refilling chemical containers or servicing chemical injection
pumps and lines.
• Wear appropriate Personal Protective Equipment (PPE) whenever handling chemicals or servicing
chemical injection pumps and lines.
WARNING – ELECTRIC SHOCK HAZARD:
Allow instrument tray to fully drain prior to moving to next processing stage. Excess water spillage
may cause electrical shock and serious injury.
Disconnect all utilities to unit before servicing. Do not service unit unless all utilities have been properly
locked out. Always follow local occupational health and safety regulations, as well as electric and
plumbing codes.
Lock building electrical supply disconnect switch and console master power Switch to OFF before
checking or replacing any parts. Electrical shock can cause serious injury.
WARNING – EXPLOSION HAZARD:
Use only water or water-detergent mix in cleaning chamber. Never use flammable solvents. Fire or
explosion could result.
WARNING – SLIPPING HAZARD:
To avoid slippery floor conditions, immediately wipe up any spilled liquid or condensation. If spills or
drippage are detergents or other chemicals, follow safety precautions and handling procedures set forth
on detergent or chemical label and/or Material Safety Data Sheet (MSDS).
Crest Healthcare Console Junior R:1 1-1
Safety Precautions Operating Manual

WARNING – PERSONAL INJURY AND/OR EQUIPMENT DAMAGE HAZARD:
Repairs and adjustments to this equipment must be made only by trained service personnel.
Maintenance performed by unqualified personnel or installation of unauthorized parts could cause
personal injury, result in improper equipment performance, invalidate the warranty, or result in costly
damage. Contact Crest regarding service options.
Regularly scheduled preventive maintenance, in addition to the faithful performance of routine
maintenance described within this manual, is required for safe and reliable operation of this
equipment.
Failure to perform periodic inspections of the cleaner could result in serious personal injury or table
damage.
WARNING – DISPOSAL HAZARD:
This product contains materials which may require disposal through appropriately licensed and
permitted hazardous waste management firms.
CAUTION – POSSIBLE EQUIPMENT DAMAGE:
Never use CLEANING Chamber as a sink. Under no circumstances should waste water be poured into
cleaning chamber as water could overflow drain and damage delicate components.
Never drop or rest parts directly on chamber bottom top of transducers.
Never scratch chamber walls or transducers. This can increase cavitation erosion.
When choosing a detergent, select one with a low chloride content. Detergents with a high chloride
content can be harmful to stainless steel.
Repeated fuse burnouts indicate a short circuit or overload. Have a fully trained technician locate and
correct situation.
Use nonabrasive cleaners when cleaning unit. Follow directions on container and rub in a back-and-
forth motion, in same direction as surface grain. Abrasive cleaners damage stainless steel. Cleaner
rubbed in a circular motion or applied with a wire brush or steel wool will scratch and dull stainless
steel. Do not use these cleaners on painted surfaces.
Failure to remove shipping bracket and hardware from lid counterweights will result in lid and/or unit
cabinet damage.
REMEMBER – POSSIBLE TIME DELAY:
Insufficient clearance space will make repairs more difficult and time-consuming. Refer to the
equipment drawing for minimum clearance for service/maintenance access requirements.
Crest Healthcare Console Junior R:1
1-2
Operating Manual Safety Precautions

Symbols on Unit Table 1-1 is a key to the symbols appearing on
ultrasonic Cleaning System.
Table 1-1. Definition of Symbols on Ultrasonic Cleaning System
Crest Healthcare Console Junior R:1
1-3
Safety Precautions Operating Manual
Symbol Definition
Unit to be Serviced by Trained Personnel Only
Protective Earth Ground
Hot Surfaces
Electric Shock Hazard
Keep Hands Clear (Symbol for Lids)
- OR -
Attention, Consult Manual for Further Instructions
A Amperage Rating of the Unit
V Voltage Rating of Unit
~ Alternating Current
Hz Frequency Rating of Unit
W Power Rating
SN Serial Number of the Unit

2
IMPORTANT USER INFORMATION
2.1 Installation
Checklist
A
fter installing cleaning system according to the previously supplied
Equipment Utility Requirements and Specifications and Equipment
Drawings, complete the following checklist to ensure complete and
correct installation.
Shutoff valves (not provided by Crest), for maintenance purposes
and capable of being locked in OFF position only. Install water
lines and in compliance with local occupational health and safety
regulations, as well as electric and plumbing codes.
❑
Disconnect switches (not provided by Crest), for maintenance
purposes and capable of being locked in OFF position only,
install electrical supply lines near unit and in compliance with local
occupational health and safety regulations, as well as electric and
plumbing codes. Disconnect switches must bear the identification
of the equipment to which they are connected.
❑
NOTE:If unit is installed next to other equipment, shutoff
valves and disconnect switches should be located so that
service can be shut off to one piece of equipment at a time.
Cleaning system is positioned on a hard, level surface as shown on
equipment drawing, with required clearance space and in relation
to building supply lines.
Cleaning system is level. Use levelling legs if necessary.
For cleaning system, verify lid counterweights shipping
bracket and hardware are removed from rear of cabinet (see
Figure 2-1).
Building cold water line supplies water to unit as specified on
equipment drawing.
Building hot water line supplies water to unit as specified
on equipment drawing.
Building waste line is provided to unit as specified on
equipment drawing.
Verify all quick disconnect clamps are tightened. Tighten if
necessary.
Ensure all switches are properly installed, adjusted
and connected.
Ensure facility power meets requirements listed on
nameplate located on front of unit (see SECTION 2.3.2,
ELECTRICAL).
2-1
Operator Manual
❑
❑
❑
❑
❑
❑
❑
❑
❑
Crest Healthcare Console Junior R:1
Important User Information
REMEMBER – POSSIBLE
TIME DELAY: Insufficient
clearance space will make
repairs more difficult and
time-consuming. Refer to the
equipment drawing for
minimum clearance for
service/maintenance access
requirements.
CAUTION – POSSIBLE
EQUIPMENT DAMAGE:
Failure to remove shipping
bracket and hardware from lid
counterweights will result in
lid and/or unit cabinet
damage.
IMPORTANT: A listing of the Safety Precautions to be observed when operatin
g
or servicin
g
this e
Ultrasonic Cleaning System can be found in SECTION 1. Do not operate or service equipment until
you have become familiar with this information.

Figure 2-1. Lid Counterweight Shipping Bracket and Hardware
NOTE: After a few weeks of operation, inspect unit for leaks.
Retighten all clamps and connections.
2.2 General When ultrasonic energy is introduced into a cleaning solution,
cavitation (the foundation of ultrasonic cleaning) occurs. Ultrasonic
energy causes alternating patterns of low- and high-pressure phases.
During the low-pressure phases, minute bubbles (or vacuum cavities)
are formed. During the alternate high-pressure phases, the bubbles
implode violently - this is called cavitation.
Cavitations provide scrubbing action leading to rapid cleaning
speeds and consistency when compared with simple soaking or
immersion with agitation. Additionally, the bubbles are small enough
to penetrate even microscopic crevices, cleaning them thoroughly
and consistently. As a result, ultrasonic cleaning is an effective and
efficient method of cleaning.
This cavitation or optimum ultrasonic cleaning power is ensured by
constant power output generators operating about 132kHz and
complemented with complex resonance frequencies to ensure lock-
box cleaning efficiency. The generators are mounted with individual
slide out modules for ease of service. Also, patented ceramically-
enhanced transducer modules are bonded to the wash tank providing
efficient energy transmission for instrument cleaning.
The Ultrasonic Cleaning System is a freestanding instrument washer,
supplied in a compact stainless-steel cabinet with automatic opening lids
and load elevators for easy and safe instrument loading. The System
contains all needed components to effectively clean (utilizing ultrasonic
cavitation passing through a detergent-balanced wash solution as
described in the previous paragraphs), thoroughly rinse surgical
instruments prior to disinfection and sterilization.
Description
2-2 Crest Healthcare Console Junior R:1
Operator Manual Important User Information
Shipping Bracket and Hardware
Console

2.3 Technical
Specifications
The following specifications are intended to describe the technical
information located on your unit nameplate and to state other relevant
information. Check the previously supplied equipment drawing and/or
identification nameplate for proper voltage and amperage.
NOTE: Electrical and plumbing services must be flexible or have a
quick disconnect so Ultrasonic Cleanin
g
S
y
stem ma
y
be moved
away from the wall forservicing.
2.3.1 Overall Size (W x L x H) Sonic Cleaner - 35 x 30 or 36 x 38-1/2"
(889 x 762 or 914 x 978 mm)
•
2.3.2 Electrical Power Supply: 240 V, 60 Hz, 1-Phase (3 wire) or 208 V, 3-Phase
(5 wires including neutral and ground),208 V, 1-Phase (4 wires).
Power Cord Specification:
• Sonic Cleaner - Minimum 8 AWG, rated 194°F (90°C), 600 V
NOTE: Power cord and wall receptacle are not furnished b
y
Crest. Verif
y
power cord and wall receptacle used meet all
national and local electrical codes
(
ensure UL817 compliant
)
.
Only use green/yellow conductors for connection to
protective conductor terminals.
Disconnect Switch:
• Sonic Cleaner - 60 Amp rated, lockable, fusible, UL Listed E2875
and 154828 (or equivalent)
2.3.3 Other Facility
Requirements:
Drain: 1-1/4" CPVC Male Slip (trap and waste lines are not provided
by Crest).
Distilled (Purified) Water (Optional): 1/2" CPVC Male Slip (15-
50 psi); 100-120°F (38-49°C).
Hot Water: 1/2" CPVC Male Slip (15-50 psi); 100-120°F (38-49°C).
Cold Water: 1/2" CPVC Male Slip (15-50 psi); 40-60°F (4-16°C).
NOTE: Customer is responsible for compliance with applicable
local and national codes and regulations.
2.3.4 Weight • Sonic Cleaner - 15-gal: 452 lb (205 kg)
20-gal: 545 lb (247 kg)
2.3.5 Seismic Anchorage A Seismic Anchorage System is available for high-risk seismic zones.
Crest Healthcare Console Junior R:1 2-3
Important User Information Operator Manual

2.3.6 Environmental
Conditions
Ultrasonic Cleaning System is designed for indoor operation with
temperatures and humidity levels consistent with a hospital
environment as shown below:
Ambient Temperature Range: from 50 to 105°F (10 to 41°C)
Relative Humidity Range: from 30 to 75%
Atmospheric Pressure: from 700 to 1060hPa
2.4 Special Additives
Specifications
Selection of chemical additives is open to customer preference.
however, to achieve optimal performance, selected chemical
additives must meet as a minimum, the following specifications.
NOTE: Certain products may not be available in your area.
Contact Crest for product availabilit
y
and orderin
g
information.
Refer to Table 4-2 also.
To achieve maximum cleaning efficiency, select chemical appropriate
to soil type being processed. Crest recommends the following
chemicals:
• Chem-Crest® 14EZ - is a mildly alkaline and enzymatic liquid
detergent for the cleaning of surgical instruments. It is designed to
be used in an ultrasonic bath for the removal of blood, tissue,
ointments, light oils, bodily excretions, and other contaminants
associated with surgical instruments. It is formulated to be low
foaming and an aggressive blood remover. It is non- caustic and
phosphate free.
• Chem-Crest® LF275 - is a multipurpose, heavy-duty, phosphate
and silicate-free caustic liquid detergent. It is useful in many
applications demanding removal of various contaminants such as
oil, greases, and particulates. This detergent finds many uses
throughout industrial, mechanical and maintenance cleaning
operations including spray and turbulent environments.
NOTE: Crest does not promote, recommend or endorse the use
of any type of chemical additives (e.g ., strong alkaline
detergents [pH>12], alcohol rinses and liquid germicides
including hypocloric acid [bleach] in the processing of articles in
the Ultrasonic CleaningSystem
2-4 Crest Healthcare Console Junior R:1
Operator Manual Important User Information
Product
Description
Use Dilution
Range Oz./Gal
(mL/L)
pH Range at
Use Dilution
Other Applicable
Requirements
alkaline 1/4 - 2
(7 - 59)
9.0 - 12.0
Liquid, nonfoaming,
high chelating,
protein and blood
compatible.
enzyme
1/8 - 1/2
(4 - 15)
7.0 - 8.0 Liquid, nonfoaming,
high chelating,
protein and blood
compatible.
WARNING – EXPLOSION
HAZARD: Use only water or
water-detergent mix in
cleaning chamber. Never use
flammable solvents. Fire or
explosion could result.
CAUTION – POSSIBLE
EQUIPMENT DAMAGE: When
choosing a detergent, select
one with a low chloride
content. Detergents with a
high chloride content can be
harmful to stainless steel.

3
OPERATING INSTRUCTIONS
3.1 Before Operating
This Equipment
Before operating the Ultrasonic Cleaning System, it is important to
become familiar with controls, their functions and options available
(see SECTION 3.2, CONTROLS AND INDICATORS). Read this section
carefully and refer back to it when selecting cycle phases and setting
cycle operations. Also note the following:
•
A
lthough the ultrasonic tank is constructed to withstand impact,
operators should avoid dropping the instrument tray or individual
items on the work platform or the tank bottom.
Never place any body part inside the Ultrasonic Cleaning System
during operation.
Ensure Ultrasonic Cleaning System is installed properly (see
SECTION 2.1, INSTALLATION CHECKLIST).
•
•
Crest Healthcare Console Junior R:1 3-1
Operating Instructions Operator Manual
WARNING – EXPLOSION
HAZARD: Use only water or
water-detergent mix in
cleaning chamber. Never use
flammable solvents. Fire or
explosion could result.
WARNING – PINCHING
HAZARD: Pinch point is
created during lid articulation.
Keep hands clear when
opening or closing the lid.
CAUTION – POSSIBLE
EQUIPMENT DAMAGE:
• Never use CLEANING
Chamber as a sink. Under
no circumstances should
waste water be poured into
either chamber as water
could overflow drain and
damage delicate
components.
• Never drop or rest parts
directly on chamber bottom
or on top of immersible
transducers.
• Never scratch chamber
walls or transducers. This
can increase cavitation
erosion.
IMPORTANT: A listing of the Safety Precautions to be observed when operatin
g
or servicin
g
this
Ultrasonic Cleaning System can be found in SECTION 1. Do not operate or service equipment until
y
ou have become familiar with this information. Also, the instructions included in this section
must be combined with safe instrument handlin
g
practices in accordance with the facilit
y
’s
policies and procedures.

3.2 Controls and
Indicators
The Ultrasonic Cleaning System operational controls consist of three
types: pushbuttons, indicator light and digital timer. The other main
operator interaction controls consist of the lid(s) mechanical foot pedal,
and generator power switch.
3.2.1
Operator Controls and
Indicators
The Ultrasonic Cleaning System contains the following operator
controls and indicators (see Figure 3-1 and Figure 3-2):
NOTE: Console configurations vary according to different
user requirements, and all of the controls
section do not appear on all machines. listed in this
Figure 3-1. Sonic Cleaner Control Panel (Typical)
MAIN POWER ON/OFF: Use this lighted pushbutton to turn
Ultrasonic Cleaning System power on/off. When pushbutton is ON
power is available from facility. Cycle timer(s) automatically activates.
FILL: Use this pushbutton to activate the fill phase of the Wash Cycle.
When pressed, fill solenoid circuit activates and drain valve is disabled.
DRAIN ALERT: Indicator light comes ON when it is necessary to
drain the Wash tank.
DRAIN: Use this pushbutton to order wash tank drainage. When
pressed, drain valve actuates and fill solenoid circuit deactivates.
STOP: Use this pushbutton to immediately halt all Ultrasonic Cleaning
System functions. When pressed, facility power is disconnected from
system circuits.
LID: Use this pushbutton to interrupt cycle and raise lid.
Timer(s): Use digital timer to set Wash Cycle
3-2 Crest Healthcare Console Junior R:1
Operator Manual Operating Instructions
Indicator Pushbutton
DRAIN
ALERT STOP
Main
Power
0N/OFF FILL
DRAIN LID
Pushbuttons Cycle Time Pushbuttons Display

3.2.2 Other Controls The Ultrasonic Cleaning System also contains the following controls.
Audible Alarm: Activates when lid/tray elevator is in motion and
when Wash Cycle is complete to alert operator.
Automatic Liquid Level Control: Control ensures proper liquid
depth for Wash Cycle. Using a float switch sensor, ultrasonics and
heaters are deactivated if fluid level drops below safe level.
Generator Power Switch: Use rocker switch to turn generator
ON. Generator is located inside Ultrasonic Cleaning System (see
Figure 3-2).
CYCLE START: Use this foot pedal (touch plate) to start Ultrasonics
Cleaning System Wash Cycles (see Figure 3-3).
Crest Healthcare Console Junior R:1
Operating Instructions
3-3
Operator Manual

Figure 3-2. Generator Power Switch
Figure 3-3. CYCLE START Foot Pedals
3-4 Crest Healthcare Console Junior R:1
Operator Manual Operating Instructions
Sonic Cleaner Console Junior(CJ)
Wash Cycle Start Foot Pedal
Generator Power Switch

3.3 Operating
Instructions
The Crest Healthcare Ultrasonic Cleaning System is designed to
thoroughly wash (remove tissue, blood, and other contaminants)
instruments prior to final disinfection and sterilization as required.
Operation other than as specified and described in this section is not
recommended, may not be effective in cleaning instruments and may
not be safe. Please contact Crest for appropriate guidance, in-service
and training.
NOTE: If there is any doubt about a specific material or
product, contact the product manufacturer for recommended
technique.
Prior to loading the Ultrasonic System and starting a Wash
Cycle, perform or ensure the following:
3.3.1 InitialStart-up
NOTE: The Ultrasonic Cleanin
g
S
y
stem lid
(
s
)
is to be closed at
all times except for loading/unloading procedures.
1. Ensure the following initial system status:
a. Lid(s) closed.
b. System not powered.
Turn Generator Power Switch to ON (see Figure 3-2).
Ensure access doors are completely closed. Access doors are
equipped with a safety interlock switch and power is interrupted
to Ultrasonic System if door is open or removed.
Push Main Power pushbutton to turn system ON (see Figure 3-1).
All cycle settings are factory preset. However, a trained Service
Technician or Supervisor may change timers to meet specific
needs. Factory set times are as follows:
NOTE: All Wash Cycle settings in place at initial start-up
remain in memor
y
for subsequent Wash C
y
cles unless
changed by authorized Service Technician or Supervisor.
a. Ultrasonic Wash: 5 minutes, 0 seconds.
Check Detergent supply. If detergent needs to be changed,
proceed as follows (refer to SECTION 2.4, SPECIAL ADDITIVES
SPECIFICATIONS):
2.
3.
4.
5.
6.
a. Remove cap and detergent injector suction tube from empty
bottle.
Properly dispose of empty detergent bottle.
Position new detergent bottle and remove shipping cap.
Install cap and detergent injector suction tube into detergent
bottle.
Adjust tube length and tighten cap.
b.
c.
d.
e.
Crest Healthcare Console Junior R:1
Operating Instructions
3-5
Operator Manual
WARNING – CHEMICAL BURN
HAZARD: Detergents are
caustic and can cause
adverse effects to exposed
tissues. Do not get in eyes, on
skin or attempt to ingest by
mouth.
• Read and follow
precautions and
instructions on detergent
label and in Material Safety
Data Sheet (MSDS) prior to
handling chemical, refilling
chemical containers or
servicing chemical
injection pumps and lines.
• Wear appropriate Personal
Protective Equipment(PPE)
whenever handling
chemicals or servicing
chemical injection pumps
and lines.

8. Press LID pushbutton to raise tray elevator(s) and open lid(s).
Carefully remove any objects or debris from chamber(s). Press
LID pushbutton to lower tray elevator(s) and close lid(s).
Prepare CLEANING Chamber for first cycle as follows:
NOTE: Ensure CLEANING Chamber is filled with the lid
closed.
9.
a. Press FILL pushbutton (see Figure 3-1).
NOTE: Once the chamber tank fill circuit is energized,
control automatically maintains liquid level through
additional filling as liquid losses occur through
evaporation, load removal, etc.
Once water level reaches liquid low-level probe, control
orders chamber heater ON.
NOTE: Control brings the liquid to operating temperature
and maintains temperature by cycling heaters on and off.
Control orders addition of detergent as chamber fills.
Chamber fills to high liquid level probe where control orders
fill circuit to de-energize.
b.
c.
d.
10. After chamber filling is complete, press CYCLE START foot
pedal (see Figure 3-3) to process chamber solution through one
cycle to degas.
NOTE: Solution in the CLEANING Chamber need not
be changed after each cycle. Change solution when it
becomes visually dirty, at end of workday or at least
every 12 cycles (factory setting).
3-6 Crest Healthcare Console Junior R:1
Operator Manual Operating Instructions
EXPLOSION HAZARD: Use
only water or water-detergent
mix in cleaning chamber.
Never use flammable
solvents. Fire or explosion
could result.
PINCHING HAZARD: Pinch
point is created during lid
articulation. Keep hands clear
when opening or closing the
lid.
CAUTION – POSSIBLE
EQUIPMENT DAMAGE: When
choosing a detergent, select
one with a low chloride
content. Detergents with a
high chloride content can be
harmful to stainless steel.

–
3.3.2 Wash Cycle After cleaning solution has been degassed (see SECTION 3.3.1,
INITIAL START-UP) and using facility safe instrument handling
practices, process load as follows:
1.
2.
Press LID pushbutton to open CLEANING Chamber lid.
Place loaded instrument basket into CLEANING Chamber onto
tray elevator.
Press CYCLE START foot pedal to start Wash Cycle (see
Figure 3-3). Elevator lowers and lid closes.
Ultrasonic Wash Timer begins to count down.
At cycle completion, CLEANING Chamber lid opens, and tray
elevator automatically rises to top load/unload position.
NOTE: Cleaning phase may be repeated (repeat Steps 2-6).
Carefully lift instrument basket from CLEANING Chamber and
allow it to fully drain before moving. Move instrument basket per
facility procedures.
NOTE: Solution in the CLEANING Chamber need not be
changed after each cycle. Change solution when it
becomes visually dirty, at end of workday or at least
every 12 cycles (factory setting).
3.
4.
5.
6.
7. Wearing appropriate Personal Protective Equipment (PPE), lift
and remove instrument basket from unit.
Follow facility procedures for distribution of instrument load. Do
NOT touch with bare hands.
8.
Crest Healthcare Console Junior R:1
Operating Instructions
3-7
Operator Manual
INCHING HAZARD:
Pinch point is created during
lid articulation. Keep hands
clear when opening or closing
the lid.
POSSIBLE
EQUIPMENT DAMAGE:
• Never drop or rest parts
directly on chamber bottom
or on top of immersible
transducers.
• Never scratch chamber
walls or transducers. This
can increase cavitation
erosion.
PINCHING HAZARD:
Pinch point is created during
lid articulation. Keep hands
clear when opening or
closing the lid.
– ELECTRIC SHOCK
HAZARD: Allow instrument
tray to fully drain prior to
moving to next cleaning
station. Excess water spillage
may cause electrical shock
and serious injury.
SLIPPING HAZARD:
To avoid slippery floor
conditions, immediately wipe
up any spilled liquid or
condensation. If spills or
drippage are detergents or
other chemicals, follow safety
precautions and handling
procedures set forth on
detergent or chemical label
and/or Material Safety Data
Sheet (MSDS).
POSSIBLE
EQUIPMENT DAMAGE:
• Never drop or rest parts
directly on chamber bottom
or on top of immersible
transducers.
• Never scratch chamber
walls or transducers. This
can increase cavitation
erosion.
