Rhima RC231 User manual

Operator’s Manual
RC231, RC231 SPECIAL, RC301, RC401
Washers
Australia Tel: [phone] | New Zealand Tel: [phone] | Singapore Tel: [phone]

INSTRUCTION MANUAL FOR DISHWASHERS
●The appliance must be connected to water and electrical supplies by qualified
tradespersons only and according to local regulations.
●The appliance must be used by adults only. Do not let children play with, or operate
this machine.
●Only persons trained to use this dishwasher are permitted to operate it.
●This appliance has been designed to wash food preparation and eating utensils. It has
NOT been designed to wash objects soiled with petrol, paint, remnants of steel or iron,
corrosive chemical products such as acids, alkalis, or solvents or any item that cannot be
immersed in water.
●Do not open the appliance door(s) while the appliance is operating. The appliance has
a safety device which stops operation if a door is accidentally opened.
●After using the appliance, isolate the electric and water supply.
●Do not attempt to repair the appliance. Repairs made by unqualified persons may cause
further damage and will void warranty.
●Repairs and servicing of this appliance must be carried out by Rhima personnel only.
GENERAL INSTRUCTIONS
It is important to keep this instruction manual near the appliance for
future consultation.
If the appliance is sold or transferred to another user, make sure this
manual remains with the appliance so that the new owner is informed
about the warnings and operation of the appliance. These instructions
are given for safety reasons and they must be read carefully before
installing or using the appliance.
IMPORTANT CUSTOMER INFORMATION
●To request a service, detergents or rinse additive contact your local Rhima Service centre
below:
Australia: 1300 347 944
New Zealand: 0800 902 054
Singapore: [phone]
2

ELECTRICAL INSTALLATION
The Australian installation shall be in accordance with The Plumbing Code of Australia (PCA).
This appliance should be connected to a hot water supply (Max 65°C ) for in accordance
with Australian Standard AS/NZS 3500.1. for optimum performance.
The water supply pressure should be a minimum 200 kPa at all times and flow rate should
be at least 10 litres per minute. A static pressure higher than 600 kPa (73.5 psi) requires a
pressure reducing valve upstream of the supply line. If water pressure is below 200 kPa,
the use of a rinse booster pump is recommended.
This appliance is designed to drain to a tundish. Waste connection to a spigot is not
recommended and may cause draining issues.
The drainpipe should withstand 70°C (158°F) in continuous duty conditions.
The grey water drain hose must have a fixed watertight seal above the tundish in
accordance with the Australian Standard AS/NZS 3500.2.
A DIAGRAM SHOWING THE CORRECT METHOD OF WASTE INSTALLATION IN ACCORDANCE
WITH THE AUSTRALIAN STANDARD AS/NZS 3500.2 IS BELOW
PLUMBING INSTALLATION
This appliance must be connected to an earthed 3-phase electrical switched outlet of an
appropriate rating.

4
MACHINE DESCRIPTION
Description of the machine, its accessories and its guards
Machine description
Refer to annexes for the technical data of the machines.
Example:
MACHINE IN RIGHT EXECUTION
A- SPLASH GUARD
B- PRE-WASH
C- WASH + RINSE
D- CONTROL PANEL
E- DRYER
F- EMERGENCY BUTTON
G- HEAT RECOVERY/STEAM CONDENSER/HEAT RECOVERY WITH HEAT PUMP
H- UPPER LOADING SYSTEM
I- WALL-MOUNTED CIRCUIT BOARD
pict. 1
I
E
C
D
B
G
A
I
C
AH
A
I
C
D
A
A
I
C
D
A
A
F
noisnemiDeludoM
Width Height Depth
Amm003DRAUGHSALPS- 1520 mm
1820 mm (1)
900 mm
B mm009ro006HSAW-ERP-
Cmm0031ESNIR+HSAW-
Dmm0381mm058LENAPLORTNOC-
2130 mm (1)
Emm0702)mm0001(mm009REYRD-
2370 mm (1)
G- HEAT RECOVERY/STEAM CONDENSER 450 mm o 1300 mm 1860 mm
2160 mm (1)
G- HEAT RECOVERY WITH HEAT PUMP 1000 mm 2070 mm
Hmm0902mm016METSYSGNIDAOLREPPU-
(1) Special model for high baskets

5
This machine is built with high quality materials in particular AISI 304 stainless steel (AISI 316 for boilers and tanks) with a
wall thickness to ensure a long lifetime.
Pre-wash module (the presence depends on the model chosen): a preliminary washing is carried out with low temp-
erature thermostatically controlled to melt the alimentary residuals and avoid the proteins denaturation.
Wash module: a proper washing of the baskets is performed with temperature thermostatically controlled.
Rinse module: a pre-rinse is performed that removes most of the detergent, then a final rinse is performed with high
temperature thermostatically controlled.
Autotimer: the Autotimer function (activated by default) allows stopping the machine if it is in start-mode but not operating
at the moment.
It can happen in two cases:
1. The machine is working in vain (it is in operation but it is not used).
2. The machine is in operation but a basket accumulation exiting the machine causes the limit switch SQ1 to trip (F1).
In these cases, the timer set by default at 300 seconds trips.
By inserting a basket or clearing the exit the machine restarts automatically to operate.
Available options
Dryer E:
It conveys hot and dry air that creates the ideal conditions for rapid drying.
The dryer heating can be turned on or off by the operator.
Stage dryer E:
An air knife removes the water from the basket, by using a narrow focused stream of air.
Heat recovery G:
The goal is the recovery of the steam heat exiting the machine that otherwise would be dispersed, and use it to pre-heat
the water entering the boiler.
The machine must have a cold water supply for the rinse.
Heat recovery with heat pump G:
The goal is the recovery of the steam heat exiting the machine that otherwise would be dispersed, and use it to pre-heat
the water entering the boiler.
It exploits a heat pump to further increase the water temperature entering the boiler.
The machine must have a cold water supply for the rinse.
WARNING: If this optional is present the Autotimer must be set to a minimum value of 300 seconds.
WARNING: Heat Recovery system and Steam Condenser - installation (optional)
It is strictly forbidden to connect the machine’s vent directly with the outdoor!
Cold weather conditions might seriously damage the Thermal Recovery system or the Steam
Condenser.
Upper loading system H
Pressure Increase Pump:
It allows a proper machine operation when the feeding water pressure of the machine is lower than 200 kPa.
Inverter:
It allows adjusting the speed of the conveyor in 5 steps and reaching the DIN speed.

6
MACHINE IN STAND-BY - Display 2
B: ON / OFF key with ON function.
To turn the machine ON.
F1: Display with scrolling text: provides information about the
current status of the machine.
A: START / STOP key. Function key.
B: ON / OFF key.
C and D: Scrolling keys (▼/ ▲, - / +).
E: INFO key.
F1: Display with scrolling text
F2: Scrolling LEDs bar
CONTROL PANEL AND RELATED SYMBOLS - Display 1
STAND-BY
MACHINE READY OR IN OPERATION - Display 3
E: INFO key.
It provides additional information about:
Boiler temperature
Tank temperature
Prewash temperature (if present)
Date
Hour
Factory code
Installed firmware.
It’s possible scrolling the menu items by using the Cand Dkeys.
F1: Display with scrolling text. Provides information about the status of the machine, temperatures and other indications.
Some messages are displayed alternatively to temperatures. See chapters 5 and 12 for more information.
F2: Scrolling LEDs bar.
One LED lit: indicate the machine is ON and in operation.
Series of LED lit: indicate the time remaining to the energy saving mode activation. See paragraphs Autotimer (Page 5)
for more information.
BOILER TEMPE
A: START / STOP key.
When the machine is ready, it allows the start. The conveyor is
activated by pressing this key.
When the machine is running, allows stopping and putting in
ready mode. The conveyor is stopped by pressing this key.
B: ON / OFF key with OFF function.
Allows putting the machine in STAND-BY mode.
C and D: Scrolling keys (▼/ ▲, - / +)
When in the menu either scrolls the items or modifies all
adjustable parameter (increase and/or decrease).
When the machine is ready or running: to adjust the conveyor
speed.

7
LIGHTS (see paragraph Display 1 (Previous page)).
1: Flashing green: machine ON and in operation.
Still green: machine ON in energy saving mode (see paragraph Autotimer (Page 5))
2: Green: tanks filled.
3: Yellow: baskets limit switch activated.
4: Yellow: tank heating activated.
5: Still yellow: boiler heating activated.
Flashing yellow: intermittent boiler heating activated.
6: Green: lower speed selection.
7: Green: higher speed selection.
Both 6and 7lights are OFF when the machine is equipped with the optional INVERTER and an intermediate speed is
selected.
8: Green: INFO Menu
9: Unused
10: Green: clear inlet for basket (for models with pre-wash on corner only)
11:Green: machine ON.
Still red: machine in stand-by mode
Flashing red: alarm
FUNCTIONING OF THE MACHINE
Machine start-up
• Check that the overflow pipes are correctly inserted
• Turn on the wall-mounted main switch.See section MACHINE DESCRIPTION (Page 4)
• Open the water supply valves.
• Turn on the machine using the control panel.
• Wait for the filling operations to be completed.
Once filling of all the tanks is finished, the heating of the machine starts. In this phase the display shows the message
HEATING alternatively to temperatures.
• When heating is finished, the display shows the message READY TO START alternatively the wash/rinse temperatures.
To ensure proper washing, start the operations after the display shows the message READY TO START.
Washing
• To set the desired working speed, use keys D▼(decrease) and C▲(increase) to set a suitable speed for the type of
work to be carried out.
There are two possible settings:
Speed 1: minimum. (optimal cleaning results)
Speed 2: maximum. (maximum throughput)
If the machine is equipped with the optional INVERTER, there are five possible settings.
• If the machine is not equipped with an automatic chemicals dispenser, manually introduce the detergent in the wash
tank. See section DETERGENTS (Page 9) ).
• Press START / STOP A button to start the conveyor movement.
• Place the baskets on the conveyor (see paragraph Basket loading (Next page) - pict. 3 & 4).
Push the basket inside the splash guard A until engaged with the towing system.
The washing sequence is the following:
►Low temperature pre-wash (B- if there is).
►Thermostatically controlled temperature wash C, followed by a pre-rinse.
►Final rinse Ccarried out with clean water coming from the hydric network and thermostatically controlled and eventually
rinse aid.
►Drying (E- if there is the optional module).
►Baskets exit zone equipped with roller conveyor and limit switch.
• Push the START / STOP A, button to stop the operation.
N.B.: It is recommended to drain and change the tank’s water when very dirty or, at least, twice a day.

8
It is forbidden to remove the basket from the machine before it has come out of the tunnel and to insert hands or
arms inside the machine when it is in movement (see pict. 2).
Note: Always turn the machine offbefore inserting your hands or arms inside the tunnel.
End washing operations
• Press START / STOP A key.
• Press key ON/OFF B.
• Drain the tanks.
Open the doors and remove filters and overflows.
• Turn offthe wall-mounted main switch I.
• Shut the water supply valve(s).
• Start the cleaning of the machine (see chap. MAINTENANCE (Page 10) ).
WARNING: In case a dangerous situation occurs, push the emergency button F. The towing system,
pumps and heaters turn off. Before restarting the appliance, check if the emergency is over. The
emergency button rearmament does not start the machine but it position the appliance in stand-by.
The emergency button should not be used as usual machine switch offsystem.
pict. 2
Baskets loading
Before loading the baskets it is necessary to carry out a proper cleaning offof the food residuals.
Follow these tips:
• Baskets must not lie inside one another, or be covering each other.
• Place the baskets so that all the surfaces can be reached by the water; otherwise the baskets cannot be washed properly.
• Make sure that the baskets are placed in a stable position and that they do not turn upside down.
• Place the baskets upside down for washing.
Some food, like carrots, tomatoes, ketchup, may contain natural colorant substances that may alter the baskets and plastic
parts if they are in large quantity.
The eventual color alteration does not mean that the plastic is not thermo-resistant.
Items not suitable to be washed in a dishwasher:
• Wooden baskets or with wooden parts; wood wraps and loses its characteristics if it is exposed to high temperatures. In
addition the glues used are not suitable for dishwashers.
• Plastic baskets not thermo-resistant.
It is suggested to purchase only baskets suitable for washing in dishwashers.
The washing and drying effectiveness is determined by the baskets conformation. A basket with smooth and linear surfaces,
without any ribs and hollows where washing water could stand, gives the best drying results.
If after the washing the baskets are not clean or they have washing residuals it is mandatory to repeat the procedure.
If the machine is equipped with an upper loading system, do not to push forcefully the baskets on the machine, as
they must be gently placed and accompanied.
pict. 3 pict. 4

9
WARNINGS:
• Do not slam the doors when opening and closing.
• Do not put material or objects on top of the machine.
• The water used for the washing and the rinsing is not potable because of the presence of chemical additives. In
case of contact with skin or eyes wash them immediately with plenty of water and check the safety instructions of
the detergent manufacturer. If necessary, contact a doctor.
• Some important rules must be followed for the use of this appliance:
1) Never touch the appliance with wet hands or feet
2) Never use the appliance when barefooted
3) Do not install the appliance in places exposed to water splashes.
• This machine must be disconnected from the main electrical supply after use at the end of the day and for
any service/maintenance operation. Switch offthe main switch located on the wall, which shall be installed
by a professional installer. Shut the water supply valve(s).
• In case a crate or bin becomes stuck, first switch offthe wall-mounted main switch and then remove the cause of
the block.
WARNING: INTERNAL CLEANING OF THE MACHINE SHALL BE CARRIED OUT AT LEAST 10 MINUTES AFTER
IT HAS BEEN TURNED OFF.
WARNING: DO NOT INSERT HANDS AND/OR TOUCH THE PARTS LOCATED AT THE BOTTOM OF THE WASH
TANK AND/OR AT THE END OF THE WASH CYCLE.
WARNING: DO NOT TOUCH THE CONVEYOR WHILE IT IS WORKING.
DETERGENTS
Using detergent
The detergent must be of good quality, of NON-FOAMING type, specific for use in automatic washing equipment.
The use of liquid detergents is recommended.
The dosing has to be done following the recommendations of the detergent manufacturer and in accordance with the water
and baskets characteristics.
The detergent has to be inserted only in the wash tank 1. For manual dosing remember that the wash tank contains about
85 litres of water.
Note: It is highly recommended NOT to use detergents with chlorine-based reagents as they may damage stainless steel
Using rinse aid
It is possible to use the rinse aid to get quicker drying.
The dosing has to be done following the recommendations of the rinse aid manufacturer and in accordance with the water
characteristics.
Note: too much chemicals produces foam that reduces the effectiveness and lifetime of the washing pump.
Too much chemicals might leave residuals on the baskets.
OBSERVANCE OF THE RULES OF HYGIENE AND H.A.C.C.P.
In order to meet the correct H.A.C.C.P. procedures remember to prepare a sheet with tables where the shift operator enters
the date and time the washing starts, the time the washing ends, the tanks and boilers temperatures and any other note/
alarms that have tripped and what he/she has done to ensure sanitary safety.
This is the reason why the machine is equipped with:
• Temperature gauges that indicate the boiler and tank temperature.
• Malfunctioning gauges.
• Possibility to consult the washing parameters.
RL
BASKET BASKET BASKET
BASKET BASKET
BASKET
BASKET
ONE BY ONE !!!
pict. 5
baskets must be loaded one by one. Entering into the machine
the baskets have to hook the basket runners properly (see
pict. 5).
Maximum width 500 mm - Minimum width 450 mm
Maximum height 500 mm or 800 mm (depends on the model
chosen)
If the machine is equipped with an upper loading system, the
Basket dimensions:
Maximum lenght 800 m
components including heater elements.

Special Maintenance – by qualified Service Personnel only
Once or twice per year, the machine should be checked by qualified Service Personnel:
• Remove scaling from the heating elements
• Check the status and the tightness of all gaskets
• Check the perfect state and/or wear of the components
• Check the efficiency of the dispensers
• Tighten firmly all electrical connections at least once per year
• Clean the intake filter of the solenoid valve
• Check the state of the safety devices of the doors/boilers, limit switches
• Check the calibration of the clutch.
Pay attention to not wet the motor or any electric part. Perform maintenance with the wall-mounted main switch
turned OFF.
10
• Extract the wash and the rinse arms (see pict. 9) and carefully clean the nozzles and the dome filters of the rinse nozzles
underneath running water.
• Carefully clean the tanks avoiding the use of chlorine-based detergents.
• Clean the shutters (long on the outside, short on the inside).
• Clean the entry and exit shelves.
• Reassemble all the parts and replace the arms in their seats.
• It is suggested to leave the doors of the machine open at the end of the day.
Do not use a metal scouring pad and/or corrosive products to clean the dishwasher.
Do not use pressure cleaning systems.
MAINTENANCE
WARNING: The machine including the electrical cabinet is not protected against pressure water jets, therefore
avoid the use of this type of cleaning.
It is also suggested to contact cleaning product dealers for detailed information about methods and products for
a periodical sanitizing of the machine.
Do not use bleach or chlorine-based detergents to clean the machine.
Regular maintenance
The perfect operation of the machine depends on a careful cleaning that is necessary at least once a day with the
following procedure:
• Turn offthe machine as explained in the paragraph End washing operations (Page 8).
• If the machine is equipped with Heat Recovery with the heat pump clean the extractable filter (see pict. 8).
• With empty tank, extract the filters of the tanks and the pumps (see pict. 6 & 7). Be careful that the washing residuals
in the filters do not fall in the tanks. Clean the filters with a rigid brush underneath a powerful water jet.
pict. 7
pict. 6
pict. 9pict. 8

11
Special Maintenance - Heat Recovery with heat pump optional
Every two months the Heat Recovery should be checked by qualified Service Personnel to:
• Clean the finned exchangers inside the Heat Recovery.
• Check the heat pump's flow is properly charged.
Special Maintenance - Heat Recovery
Every three months the Heat Recovery should be checked by qualified Service Personnel to:
• Clean the finned exchanger inside the Heat Recovery.
ECOLOGICAL ASPECTS
Recommendations for optimum use of energy, water and additives
If possible, use the machine at full load: This will avoid wasting detergent, rinse aid, water and energy.
Detergents and rinse aids: Use detergents and rinse aids having the highest biodegradability so that the
environment is better respected. Have the correct dosage according to the water hardness checked at least
once a year. An excess of product pollutes rivers and seas, whereas an insufficient amount compromises basket
washing and/or hygiene.
Tank and boiler temperatures: The temperatures of the tank and boiler are set by the manufacturer so as to get the best
washing results with the majority of detergents on the market. These can be reset by the installer according to the detergent
used.
Cleaning off: Carefully clean offthe baskets using water at ambient temperature with moderation so as to make removal of
animal fats easier. To remove encrusted matter, soaking in hot water is recommended.
Notes: Wash the objects as soon as possible in order to prevent the deposits from drying and jeopardizing the effectiveness
of the washing. To get an efficient wash, it is advisable to regularly clean and maintain the dishwasher (see par. MAIN-
Non-compliance with the above points and all the information described in this manual could determine a waste of
energy, water and detergent, with consequent increase in operating costs and/or decrease in performance.
Packing
The packing consists of the following:
• a wooden crate;
• extensible belt in nylon (LDPE);
• polystyrene foam (PS).
Please dispose of the materials listed above, according to the current regulations.
Disposal
The symbol WEEE used on this product indicates that it cannot be treated as domestic waste. Proper
disposal of this product contributes to protecting the environment. For more information on product recycling,
contact the local authorities, domestic waste authorities or the shop where the product was purchased.
For product or part disposal, follow the Council directives 2011/65/EU and 2012/19/EU as amended and/
or application legislative decrees.
The present product or parts can not be disposed of as urban waste but shall be collected in separate
containers (see the waste bin on wheels symbol - pict. 10 - with an "X" on the product).
At the time of product disposal, the user shall refer to the waste electrical and electronic equipment (WEEE)
specification.
The manufacturer guarantees the absence of dangerous substances in the EEA used in conformity to the directive 2011/65/EU.
If the user does not comply with the regulations he/she shall be subject to the penalties foreseen by each member state.
Disconnect electricity and water before disposal.
Cut the electrical cable to ensure that further use is impossible.
All metal parts are recyclable as they are made of stainless steel.
Recyclable plastic parts are marked with the plastic material symbol.
ENVIRONMENTAL ASPECTS
pict. 10
TENANCE (Page 10)).

Alarms - Display 6
The alarms are displayed with an alphanumeric code followed by a brief description.
Alarm screen example:
E7 WASCH1 PUM
FREE THE OUT
SIGNALS AND ALARMS - Display 4
During the operation, the machine visualises the current
status of the machine, the alarms and other situations that
need the operator attention.
Example: machine ready to start display notification:
READY TO S
Signals - Display 5
The signal messages are displayed and signalized with a beep.
When DETERGENT LEVEL appears on the display it means that the detergent is empty.
When RINSE-AID LEVEL appears on the display it means that the rinse aid is empty.
When DOOR OPEN appears on the display it means that you are trying an operation that cannot be done with the door
opened or that you opened the door and interrupted a cycle in progress.
When DRAIN THE TANKS appears on the display it means that you are trying an operation that cannot be done with the
tanks full.
When FREE THE OUTLET appears on the display it means that it is necessary to remove the baskets from the exiting shelf
to continue the operation.
When HEAT PUMP MAINTENANCE appears on the display it means that you must call a technician for the Heat Recovery
with heat pump maintenance (see par.Special Maintenance - Heat Recovery (Page 11) - only if the machine is equipped
Signal screen example:
with the optional).
12

Alarms description
1
3
ALARM ALARM DESCRIPTION REMEDIES
B2
B3
B5
B10
E1
E2
E3
E5
E7
M1
M2
M3
M7
U10
W1
Z8
Z17
BOILER 1 PROBE FAILURE
BOILER 1 HEATING FAILURE
BOILER 1 OVERTEMPERATURE
RINSE LOW TEMPERATURE
WASH TANKS FILLING FAILURE
WASH1 PROBE FAILURE
WASH1 HEATING FAILURE
WASH1 OVERTEMPERATURE
WASH1 PUMP THERMAL PROTECTION
PREWASH FILLING FAILURE
PREWASH PROBE FAILURE
PREWASH COOLING FAILURE
PREWASH PUMP THERMAL PROT.
OPTIONAL MOTORS THERMAL PROT.
THERMAL PROTECTION
GENERAL ALARM
RINSE WATER SUPPLY FAILURE
It is recommended to turn OFF the appliance and contact the
Rated temperature cannot be reached.
Please turn OFF the appliance, by pressing the ON/OFF B button,
Please make sure that rinse arms and nozzles are in the right
Please check that water inlet connection is working. Please turn
Washing results may be affected.
Please turn OFF the appliance, by pressing the ON/OFF B button,
It is recommended to turn OFF the appliance and contact the
It's recommended to suspend the washing.
Please check that water inlet connection is working. Please turn
Washing results may be affected.
Please check that the cold water inlet connection is working.
Washing results may be affected.
Please contact the Rhima Service Department.
Please contact the Rhima Service Department.
Emergency button pressed. Make sure that the emergency is
Please check if the water supply is working and make sure that
It's recommended to suspend the washing.
Contact the Rhima Service Department.
and turn it ON again, after a few seconds. Should the alarm
persist, please contact the Rhima Service Department.
Rhima Service Department.
position. Should the alarm persist, please contact the Rhima
Service Department.
OFF the appliance, by pressing the ON/OFF B button, and turn it
ON again, after a few seconds. Should the alarm persist, please
contact the Rhima Service Department.
Please contact the Rhima Service Department.
and turn it ON again, after a few seconds. Should the alarm
persist, please contact the Rhima Service Department.
Rhima Service Department.
Please contact the Rhima Service Department.
OFF the appliance, by pressing the ON/OFF B button, and turn it
ON again, after a few seconds. Should the alarm persist, please
contact the Rhima Service Department.
Please contact the Rhima Service Department.
Please turn OFF the appliance, by pressing the ON/OFF B button,
and turn it ON again, after a few seconds. Should the alarm
persist, please contact the Rhima Service Department.
Please contact the Rhima Service Department.
solved. To resume working, release the emergency button.
WARNING: the emergency button should not be used as ordinary
mean to turn the appliance ON/OFF.
rinse arms and nozzles are in the proper position. Please turn OFF
the appliance, by pressing the ON/OFF B button, and turn it ON
again, after a few seconds. Should the alarm persist, please
contact the Rhima Service Department.

MACHINE PROBLEMS, CAUSES AND CURES
14
Type of Problem Possible Causes Cure
The machine does not load
water
Water supply tap is closed
Shortage of supply water
pressure
Open the water supply tap
Turn off and turn back on when the pressure increases
or install a booster pump
Solenoid valve filter blocked Contact the Rhima Service Department
Unsatisfactory washing results The washing nozzles are
clogged
Clean the nozzles and correctly reposition the arms
in the proper seats
Detergent consentration too low Change the dosage of detergent
Filters too dirty Remove and clean the filters with a brush under
running water, then replace them in their seats
Presence of foam Always use a non-foaming detergent. Check the
detergent and rinse-aid dosages and reduce them if
necessary
Check the tank temperature
(Which must be between 50°C
and 60°C)
Contact the Rhima Service Department
Length of washing cycle inadequate
for the type of grime build-up
Choose a longer cycle if possible, otherwise repeat
the wash cycle
Washing water too dirty Drain the water in the tanks, clean the filters. Reload
the tank and replace the filters properly.
The objects are not dried
properly
Insufficient rinse-aid dosage Increase the amount of rinse-aid. Contact the
Rhima Service Department.
Rinse water temperature under
80°C
Check the temperature of the water entering the
system.
Streaks or smears on the
objects
Rinse-aid concentration too
high
Always use a non-foaming detergent. Check the
detergent and rinse-aid dosages and reduce them if
necessary. Contact the Rhima Service Department.
During wash cycle the machine
stops and draws water
Check overflow/drain pipe is correctly
seated and/or seal is not damaged
Faulty water level switch Contact the Rhima Service Department
Remove and correctly reposition the overflow/drain
A tank emptied due to excess of
foam or lack of curtains/splash
guards
Reduce the concentration of rinse-aid/detergent or
correctly reposition the curtains or the other guards
that may have been removed.
Wash arms incorrectly positioned Check and correctly reposition the wash arms.
During wash cycle the machine
stops
Check the exit conveyor (If
fitted) is not full of crates/baskets
Empty exit conveyor.
The machine does not wash and
the pump is noisy on machines
with three-phase pump
The pump direction is inverted
due to incorrect connection of
the power supply cable
Contact the Rhima Service Department
The level of water inside the
tank is too low
Remove and correctly replace the overflow pipe
Correctly reposition the curtains or the other guards
that may have been removed.
Check and correctly reposition the wash arms.
If the level of water continues to fall, contact the
Rhima Service Department
The suction of the pump is
clogged
Check if the suction filters of the pump (placed in the
tanks) are clogged. If the problem persists contact
the Rhima Service Department.
pipe. Replace seal if required.

1
5
OPTIONALS PROBLEMS, CAUSES AND CURES (if fitted)
Heat recovery with heat pump
Heat Recovery
Dryer
Type of Problem Possible Causes Cure
Compressor attach/detach Safety pressure switches
intervention
Contact the Rhima Service Department
Water temperature supply too
high
Varify the water temperature supply
Water capacity not sufficient Varify the static pressure of water supply
Dirty steam coil Clean the filter. Should the alarm persists, please
contact the Rhima Service Department to clean the
Heat Recovery.
Low boiler temperature Dirty steam coil Clean the filter. Should the alarm persists, please
contact the Rhima Service Department to clean the
Heat Recovery.
Heat pump has lost gas Contact the Rhima Service Department
The Heat Recovery has been
switched OFF and then
switched ON.
Wait a couple of minutes to restart the compressor
and that the boiler temperature is restored.
Safety pressure switches
intervention
Contact the Rhima Service Department
The objects are not dried
properly
Insufficient rinse-aid dosage Verify the rinse-aid dosage and increase it, if needed.
Dirty steam coil Clean the filter. Should the alarm persists, please
contact the Rhima Service Department to clean the
Heat Recovery unit.
Heat pump has lost gas Contact the Rhima Service Department
Type of Problem Possible Causes Cure
Low boiler temperature Dirty steam coil Should the alarm persist, please contact the Rhima
Service Department to clean the Heat Recovery.
The objects are not dried
properly
Insufficient rinse-aid dosage Verify the rinse-aid dosage and increase it, if needed.
The ventilation motor is damaged
Contact the Rhima Service Department
Dirty steam coil Should the alarm persist, please contact the Rhima
Service Department to clean the Heat Recovery.
Type of Problem Possible Causes Cure
The objects are not dried
properly
Cold air is emitted Contact the Rhima Service Department
The fan direction in inverted
due to incorrect power cable
connection
Contact the Rhima Service Department

Australia Tel: [phone]
New Zealand Tel: [phone]
Singapore Tel: [phone]
DETERGENTS
To request detergents or rinse additive contact your local Rhima Service centre
below:
Australia: 1300 347 944
New Zealand: 0800 902 054
Singapore: [phone]
Superwash
10L Drum
For all other washing
Version 1.0
