Critical Environment Technologies YESDUST User manual

Operation Manual
www.critical-environment.com
YESDUSTParticulate Sensor
Rev. D | 2015.04

2 © 2015 All rights reserved. Data subject to change without notice.
YESDUST - Operation Manual Rev. D | 2015.04
TABLE OF CONTENTS
1 POLICIES...................................................................................................... 4
1.1 Important Note...................................................................................................4
1.2Warranty Policy ..................................................................................................5
1.3 Service Policy......................................................................................................5
1.4 Copyrights ..........................................................................................................6
1.5 Disclaimer...........................................................................................................6
1.6 Revisions ............................................................................................................7
2 INTRODUCTION ......................................................................................... 8
2.1 General Description............................................................................................8
2.2 Key Features .......................................................................................................8
3 INSTRUMENT SPECIFICATIONS ...............................................................9
3.1 Technical Specications ......................................................................................9
3.2 Standard Enclosure Dimensions..........................................................................9
4 SENSOR SPECIFICATIONS.......................................................................10
4.1 Sensor Specications........................................................................................10
5 FEATURES & FUNCTIONS........................................................................11
5.1 Exterior Enclosure.............................................................................................11
5.2 Interior System Layout......................................................................................12
5.3 Exterior Sides....................................................................................................13
5.4 Exterior Top.......................................................................................................14
6 OPERATION...............................................................................................14
6.1 Operating Instructions......................................................................................14
Battery Replacement ................................................................................................ 14
Connecting to aYES Multi-Channel Monitor.............................................................. 15
Monitoring................................................................................................................ 15
Charging ................................................................................................................... 16
Disconnecting ........................................................................................................... 16
Powering Down......................................................................................................... 16

© 2015 All rights reserved. Data subject to change without notice. 3
Rev. D | 2015.04 YESDUST - Operation Manual
6.2 LED Patterns .....................................................................................................17
7 MAINTENANCE.........................................................................................17
8 TROUBLE SHOOTING...............................................................................17

4 © 2015 All rights reserved. Data subject to change without notice.
YESDUST - Operation Manual Rev. D | 2015.04
1 POLICIES
1.1 Important Note
Read and understand this manual prior to using this instrument. Carefully read the warranty
policy, service policy, notices, disclaimers and revisions on the following pages.
This product must be used according to instructions indicated in this manual.This instrument
has not been designed to be intrinsically safe. For your safety, do not use it in classied
hazardous areas (explosion-rated environments).
INSTRUMENT SERIAL NUMBER:
__________________________________________________________
PURCHASE DATE:
__________________________________________________________
PURCHASED FROM:
__________________________________________________________

© 2015 All rights reserved. Data subject to change without notice. 5
Rev. D | 2015.04 YESDUST - Operation Manual
1.2 Warranty Policy
Critical EnvironmentTechnologies Canada Inc. (CETCI), also referred to as the manufacturer,
warrants this instrument, (excluding sensors, battery packs, batteries, pumps and lters) to be
free from defects in materials and workmanship for a period of two years from the date of
purchase from our facility. The sensors have a warranty period of one year on a pro-rated
basis from the date of purchase from our facility. If the product should become defective
within this warranty period, we will repair or replace it at our discretion.
The warranty status may be aected if the instrument has not been maintained as per
the instructions indicated in this manual or has been abused or damaged in any way. The
manufacturer is not liable for auxiliary interfaced equipment or consequential damage.This
instrument is only to be used for purposes stated herein.
Warranty does not include third party trouble-shooting costs or freight to / from the
manufacturer’s facility. CETCI’s liability is limited to replacement or repair of the equipment
manufactured.
Due to ongoing research, development and product testing, the manufacturer reserves the right
to change specications without notice.The information contained herein is based on data
considered accurate. However, no warranty is expressed or implied regarding the accuracy of this
data.
All goods must be shipped to the manufacturer by prepaid freight. All returned goods must be
pre-authorized by obtaining a return merchandise authorization (RMA) number. Contact the
manufacturer for a number and procedures required for product transport.
1.3 Service Policy
CETCI maintains an instrument service facility at the factory. Some CETCI distributors / agents
may also have repair facilities; however, CETCI assumes no liability for service performed by
anyone other than CETCI personnel.
Repairs are warranted for 90 days after date of shipment (sensors have individual warranties).
Should your instrument require non-warranty repair, you may contact the distributor from
whom it was purchased or you may contact CETCI directly.

6 © 2015 All rights reserved. Data subject to change without notice.
YESDUST - Operation Manual Rev. D | 2015.04
Prior to shipping equipment to CETCI, contact our oce for an RMA #. All returned goods must
be accompanied with an RMA number.
If CETCI is to do the repair work, you may send the instrument, prepaid, to:
Attention: Service Department
Critical Environment Technologies Canada Inc.
Unit 145, 7391 Vantage Way
Delta, BC, V4G 1M3
Always include your Returned Merchandise Authorization (RMA) number, address, telephone
number, contact name, shipping / billing information, and a description of the defect as
you perceive it.You will be contacted with a cost estimate for expected repairs, prior to the
performance of any service work.
For liability reasons, CETCI has a policy of performing all needed repairs to restore the instrument
to full operating condition.
Pack the equipment well (in its original packing if possible), as we cannot be held responsible for
any damage incurred during shipping to our facility.
1.4 Copyrights
This manual is subject to copyright protection; all rights are reserved. Under international and
domestic copyright laws, this manual may not be copied or translated, in whole or in part, in any
manner or format, without the written permission of CETCI.
All software which CETCI utilizes and / or distributes holds a proprietary interest and is also
subject to copyright protection and all rights are reserved. No party may use or copy such
software in any manner or format, except to the extent that CETCI grants them a license to do
so. IFTHIS SOFTWARE IS BEING LOADED ONTO MORETHAN ONE COMPUTER, EXTRA SOFTWARE
LICENSES MUST BE PURCHASED.
1.5 Disclaimer
Under no circumstances will CETCI be liable for any claims, losses or damages resulting from or
arising out of the repair or modication of this equipment by a party other than CETCI service
technicians, or by operation or use of the equipment other than in accordance with the printed
instructions contained within this manual or if the equipment has been improperly maintained

© 2015 All rights reserved. Data subject to change without notice. 7
Rev. D | 2015.04 YESDUST - Operation Manual
or subjected to neglect or accident. Any of the forgoing will void the warranty.
1.6 Revisions
This manual was written and published by CETCI. The manufacturer makes no warranty or
representation, expressed or implied including any warranty of merchantability or tness for
purpose, with respect to this manual.
All information contained in this manual is believed to be true and accurate at the time
of printing. However, as part of its continuing eorts to improve its products and their
documentation, the manufacturer reserves the right to make changes at any time without
notice. Revised copies of this manual can be obtained by contacting CETCI or visiting
www.critical-environment.com.
Should you detect any error or omission in this manual, please contact CETCI at the following
address:
Critical EnvironmentTechnologies Canada Inc.
Unit 145, 7391VantageWay, Delta, BC,V4G 1M3, Canada
Toll Free: +1.877.940.8741
Telephone: [phone]
Fax: [phone]
Email: mark[email protected]
Website: www.critical-environment.com
In no event will CETCI, its ocers or employees be liable for any direct, special, incidental
or consequential damages resulting from any defect in any manual, even if advised of the
possibility of such damages.

8 © 2015 All rights reserved. Data subject to change without notice.
YESDUST - Operation Manual Rev. D | 2015.04
2 INTRODUCTION
2.1 General Description
Thank you for purchasing our YESDUST Particulate Sensor.
TheYESDUST is a general purpose particulate sensor for use with aYES multi-channel monitor
(e.g.YESAIR, YESAIR-D andYES Plus LGA). It operates from an internal rechargeable nickel
hydride battery pack and connects to the auxiliary port of the YES multi-channel monitor with
the supplied interface cable.The measured readings are displayed as another sensor on the LCD
display of theYES multi-channel monitor, and are also data logged to the YES multi-channel
monitor internal ash card, if utilized.
YESDUST counts particulates between 1 and 10 microns in size. It has been designed for use
as a general purpose indication of a particulate problem and should not be considered for
applications requiring high accuracy such as“clean rooms”.
2.2 Key Features
• Low cost
• Light weight
• Quick response
• Long life
• Real time display on aYES multi-channel monitor (e.g.YESAIR & YES Plus LGA)
• Data logs to SD ash card in a YES multi-channel monitor
• Rechargeable nickel hydride battery pack
• Wall adapter for continuous operation
• RoHS compliant circuit boards

© 2015 All rights reserved. Data subject to change without notice. 9
Rev. D | 2015.04 YESDUST - Operation Manual
3 INSTRUMENT SPECIFICATIONS
3.1 Technical Specications
GAS TYPE
Particulates
MECHANICAL
Enclosure General Purpose ABS
Weight 450 g (1.0 lbs)
Size 4.6”x 6.1”x 2.4”(118 mm x 156 mm x 60 mm)
ELECTRICAL
Power 9 V wall adapter for rechargeable Nickel Hydride rechargeable
battery pack.
Battery Life 16 hours continuous on a full charge.
ChargeTime Approximately 6 hours
ENVIRONMENTAL (sensor dependant)
OperatingTemperature 0°C to 45°C (32°F to 113°F)
Humidity 15 - 90% RH non-condensing
3.2 Standard Enclosure Dimensions

10 © 2015 All rights reserved. Data subject to change without notice.
YESDUST - Operation Manual Rev. D | 2015.04
4 SENSOR SPECIFICATIONS
4.1 Sensor Specications
Particulate
Type Highly sensitive, focused, infrared light beam. Self aspirated,
convection.
Warm-UpTime 1 minute
Particle Size Range 1 - 10 microns
ResponseTime (T90) < 30 seconds
OperatingTemperature 0°C to 45°C (32°F to 113°F)
Operating Humidity 0 - 95% RH non-condensing
Expected Life Span Infrared light source estimated to be seven years.
Resolution 250 particulates / cubic foot
Sample Method Diusion
Measurement Range 7000 ug / m3

© 2015 All rights reserved. Data subject to change without notice. 11
Rev. D | 2015.04 YESDUST - Operation Manual
5 FEATURES & FUNCTIONS
5.1 Exterior Enclosure
NUMBER FEATURE FUNCTION
ŒScrews Secures face plate
•Label Lexan label
Œ
•
ŒŒ
Œ

12 © 2015 All rights reserved. Data subject to change without notice.
YESDUST - Operation Manual Rev. D | 2015.04
5.2 Interior System Layout
NUMBER FEATURE FUNCTION
ŒNickel Hydride Rechargeable
Battery
Power source
•Data Out Port Connects to theYES multi-channel monitor
ŽVents Allows air ow
•Particulate Sensor Senses particulate
•Power Switch Switches power on / o
Œ
•
Ž
Ž
Ž
•
•

© 2015 All rights reserved. Data subject to change without notice. 13
Rev. D | 2015.04 YESDUST - Operation Manual
5.3 Exterior Sides
NUMBER FEATURE FUNCTION
ŒData Out Connects to theYES multi-channel monitor
•Vents Allows air ow
ŽComm LED Indicates communication status
•Charge LED Indicates charge status
•Power Switch Switches power on / o
‘9 VDC Connects to the wall adapter
Œ
•
•
Ž
•
‘
•

14 © 2015 All rights reserved. Data subject to change without notice.
YESDUST - Operation Manual Rev. D | 2015.04
5.4 Exterior Top
NUMBER FEATURE FUNCTION
ŒVents Allows air ow
6 OPERATION
NOTE: Batteries have been disconnected from the YESDUST for shipping. Install the batteries
before using. Observe polarity when reinstalling batteries.
For proper operation, the YESDUST must be placed in a vertical position.
Before use, the sensor requires a one-minute warm up.
6.1 Operating Instructions
Battery Replacement
Step 1:
Open the YESDUST by removing the screws from the four corners of the front cover
Step 2:
Remove the old batteries by pressing the battery towards the spring in the battery holder and
lifting the opposite end.
Œ

© 2015 All rights reserved. Data subject to change without notice. 15
Rev. D | 2015.04 YESDUST - Operation Manual
Step 3:
Insert the batteries into the battery holder, taking care to match the polarity markings.
WARNING: USE RECHARGEABLE NICKEL HYDRIDE BATTERIES ONLY. USING NON-
RECHARGABLE BATTERIES MAY RESULT IN DAMAGE TO THE UNIT.
Step 4:
Replace the front cover and secure it with the screws.
Connecting to a YES Multi-Channel Monitor
NOTE: Ensure that theYES multi-channel monitor is powered o before connecting the
YESDUST.
Step 1:
Connect the included communications cable to the DATA OUT port on the YESDUST
Step 2:
Connect the other end of the cable to the AUX port on the YES multi-channel monitor.
Step 3:
Set the switch on the YESDUST to the ON position. The COMM light will turn on red to indicate
that there is power but the YESDUST has not established communications with theYES multi-
channel monitor.
Step 4:
Power up the YES multi-channel monitor.
Step 5:
Once communications have been established, the COMM light will turn green, and occasionally
ash amber during communication.
Monitoring
Step 1:
Connect the YESDUST to the YES multi-channel monitor.

16 © 2015 All rights reserved. Data subject to change without notice.
YESDUST - Operation Manual Rev. D | 2015.04
Step 2:
Place theYESDUST in the area to be monitored, ensuring that the vents on the enclosure are at
the top of the unit.
Step 3:
TheYES Multi-channel Monitor will display and log real time readings in the same manner as its
other channels.
Charging
NOTE: The CHARGE light on theYESDUST will turn RED if it is running on battery power and
needs to be charged.
Step 1:
Connect the wall adapter to the 9VDC jack on theYESDUST
Step 2:
Turn the switch to the OFF position
Step 3:
The CHARGE light will turn amber while the batteries are charging. Once complete, the CHARGE
light will turn green.
Disconnecting
To disconnect theYESDUST from theYES multi-channel Monitor, unplug the communication
cable.TheYES multi-channel monitor will display“Aux port has been removed”and the COMM
light on theYESDUST will turn RED after approximately 45 seconds.
Powering Down
To power down theYESDUST, turn the switch to the OFF position. If theYESDUST is plugged in to
the wall adapter, battery charging will start, otherwise the batteries are disconnected internally
and the unit is powered down.

© 2015 All rights reserved. Data subject to change without notice. 17
Rev. D | 2015.04 YESDUST - Operation Manual
6.2 LED Patterns
MEANING COMM LED CHARGE LED
Not Connected RED *
Connected and Communicating GREEN *
Battery Low * RED
Battery Charged, Switched o OFF GREEN
Battery Charging, Switched o OFF AMBER
7 MAINTENANCE
TheYESDUST requires virtually no maintenance; however CETCI recommends a service check of
the YESDUST once per year to ensure that the sensor is in proper working order.
8 TROUBLE SHOOTING
YESDUST won’t power up with batteries:
1. Check that the batteries are installed and that the polarities are correct
2. Ensure that the batteries are charged.
3. If the batteries do not hold a charge, replace them with 4 new rechargeable AA nickel metal
hydride batteries.
YESDUST won’t communicate with YES Multi-channel Monitor:
1. Check that the interface cable is undamaged
2. Check that the interface cable is connected to the DATA OUT port on the YESDUST and the
AUX port on the YES Multi-channel Monitor.
3. Turn the YESDUST o, wait 30 seconds, and turn it back on.
4. Turn the YES Multi-channel Monitor o, wait 30 seconds, and turn it back on.
YESDUST won’t power up with wall adapter, or will not go into charge mode:
1. Unplug the wall adapter from the YESDUST and the wall.
2. Check the cord, wall plug, and jack for damage.
3. Reconnect the power jack to the YESDUST and plug in the wall adapter.
If these troubleshooting steps do not resolve the issue, or if an issue not covered above arises,
please contact the CETCI service department, at [email protected] or +1.604.940.8741, for
further assistance.

18 © 2015 All rights reserved. Data subject to change without notice.
YESDUST - Operation Manual Rev. D | 2015.04
NOTES

© 2015 All rights reserved. Data subject to change without notice. 19
Rev. D | 2015.04 YESDUST - Operation Manual
NOTES

Critical Environment Technologies Canada Inc.
Unit 145, 7391VantageWay, Delta, BC,V4G 1M3, Canada
Toll Free: +1.877.940.8741
Tel: [phone]
Fax: [phone]
www.critical-environment.com
© 2015 Critical Environment Technologies Canada Inc. All rights reserved. Data in this publication may change without notice.
YESDUST201504-D
