Crosley CGD126SDW0 User manual

W10096992B
W10097009B - SP
ELECTRIC or GAS DRYER
USE AND CARE GUIDE
Table of Contents
DRYER SAFETY ............................................................2
CHECK YOUR VENT SYSTEM
FOR GOOD AIRFLOW ..................................................4
USE SENSOR DRY/AUTO DRY CYCLES FOR
BETTER FABRIC CARE AND ENERGY SAVINGS ......4
CONTROL PANEL & FEATURES..................................5
CYCLE GUIDE...............................................................6
USING YOUR DRYER ...................................................7
DRYER CARE................................................................9
TROUBLESHOOTING.................................................11
ACCESSORIES............................................................12
WARRANTY.................................................................13
ASSISTANCE OR SERVICE....................BACK COVER
SÉCURITÉ DE LA SÉCHEUSE ...................................14
VÉRIFICATION D’UNE CIRCULATION D’AIR
ADÉQUATE POUR LE SYSTÈME D’ÉVACUATION ...17
UTILISATION DES PROGRAMMES DE
SÉCHAGE PAR DÉTECTION/AUTOMATIQUE
POUR UN MEILLEUR SOIN DU TISSU ET
DAVANTAGE D’ÉCONOMIES D’ÉNERGIE ................17
TABLEAU DE COMMANDE
ET CARACTÉRISTIQUES ...........................................18
GUIDE DE PROGRAMMES ........................................19
UTILISATION DE LA SÉCHEUSE...............................20
ENTRETIEN DE LA SÉCHEUSE.................................22
DÉPANNAGE. ..............................................................25
ACCESSOIRES............................................................26
GARANTIE...................................................................27
ASSISTANCE OU SERVICE... COUVERTURE ARRIÈRE
SÉCHEUSE
ÉLECTRIQUE ou À GAZ
GUIDE D’UTILISATION
ET D’ENTRETIEN
Para una versión de estas instrucciones en español, visite www.whirlpool.com
Table des matières

2
DRYER SAFETY

3

4
CHECK YOUR VENT SYSTEM FOR GOOD AIRFLOW
Good airow
Along with heat, dryers require good airow to efciently
dry laundry. Proper venting will reduce your drying times
and improve your energy savings. See “Installation
Instructions.”
The venting system attached to the dryer plays a big role in
good airow.
Service calls caused by improper venting are not covered
by the warranty and will be paid by the customer, regardless
of who installed the dryer.
Maintain good airow by:
Good Better
USE SENSOR DRY/AUTO DRY CYCLES FOR BETTER FABRIC CARE
AND ENERGY SAVINGS
Use the Sensor Dry or Auto Dry cycles to provide the most energy savings and enhanced fabric care from the dryer. During
Sensor Dry or Auto Dry cycles, drying air temperature or moisture level are sensed in the load. This sensing occurs throughout
the drying cycle and the dryer shuts off when the load reaches the selected dryness. The Energy Preferred cycle will provide
optimal energy savings.
With Timed Dry, the dryer runs the amount of time set and sometimes results in shrinkage, wrinkling, and static due to over-drying.
Use Timed Dry for the occasional damp load that needs a little more drying time or when using the drying rack.
n Cleaning your lint screen before each load.
n Replace plastic or foil vent material with 4" (102 mm)
diameter heavy, rigid vent material.
nUse the shortest length of vent possible.
n Use no more than four 90° elbows in a vent system;
each bend and curve reduces airow.
n Remove lint and debris from the exhaust hood.
n Remove lint from the entire length of the vent system at
least every 2 years. When cleaning is complete, be sure
to follow the “Installation Instructions” supplied with your
dryer for nal product check.
n Clear away items from the front of the dryer.
4"
(102 mm)

5
CONTROL PANEL & FEATURES
DRYER CYCLE KNOB
Use your Dryer Cycle Knob to select available cycles on
your dryer. Turn the knob to select a cycle for your laundry
load. See “Cycle Guide” for detailed descriptions of cycles.
SENSOR DRY/AUTO DRY
Senses moisture in the load or air temperature and shuts
off when the load reaches the selected dryness level.
Gives the best drying in the shortest time. Drying time
will vary based on fabric type, load size, and temperature
setting.
TIMED DRY
Will run the dryer for the specied time on the control.
On models with a selectable temperature knob, you
may choose a setting based on the fabrics in your load.
On some models, temperature is included in the cycle
selections. Drying time and temperature will depend
on your dryer model.
TEMPERATURE (on some models)
Select a drying temperature based on the fabrics in your
load. If you are unsure of the temperature to select for a
load, select the lower setting rather than the higher setting.
1
2
WRINKLE PREVENT Feature (on some models)
The WRINKLE PREVENT feature will run after your drying
cycle is complete. It periodically starts and stops the dryer,
tumbling the load without heat to help avoid wrinkling.
On some models, WRINKLE PREVENT automatically starts
at the end of the cycle. Opening the door will stop this
feature.
NOTE: A signal will sound periodically when the WRINKLE
PREVENT setting is selected, but only if the End of Cycle
signal is also selected.
PUSH TO START/END OF CYCLE SIGNAL
The End of Cycle Signal produces an audible sound when
the drying cycle is nished. Promptly removing clothes at
the end of the cycle reduces wrinkling.
Turn the END OF CYCLE SIGNAL knob to select the
desired setting (On or Off). Press the PUSH TO START knob
to start the dryer.
3
4
21
4
Not all features and options are available on all models.
Appearance may vary.
1
4
3

6
Items to dry: Dryness Level: Temperature: Available Options: Cycle Details:
Jeans, heavy work
clothes, towels Heavy Dry Very or More Dry
Energy Preferred
Less Dry
High Wrinkle Prevent
End of Cycle Signal
Automatic cycles give the
best drying in the shortest
time. Drying time varies
based on fabric type, load
size, and dryness setting.
Select a drying temperature
based on the fabrics in
your load. If you are unsure
of the temperature to select
for a load, select the lower
setting rather than the
higher setting.
Work clothes, medium
weight fabrics, sheets Heavy Dry Very or More Dry
Energy Preferred
Less Dry
Medium or Low Wrinkle Prevent
End of Cycle Signal
Casual, shirts, pants,
lightweight items,
synthetics, delicates,
athletic wear
Heavy Dry
Very or More Dry
Energy Preferred
Less Dry
Low Wrinkle Prevent
End of Cycle Signal
SENSOR DRY/AUTO DRY – Senses moisture in the load or air temperature and shuts off when the load reaches the selected dryness
level. Choose ENERGY PREFERRED cycle for optimal energy savings.
Not all cycles and settings are available on all models. Settings and options shown in bold are default settings for that cycle.
CYCLE GUIDE — SENSOR DRY/AUTO DRY CYCLES
CYCLE GUIDE — TIMED DRY CYCLES
TIMED DRY – Will run the dryer for the specied time on the control.
Not all cycles and settings are available on all models.
NOTE: If loads do not seem as dry as you would like, select Heavy Dry or Very Dry/More Dry next time you dry a similar load. If loads
seem drier than you like, select Less Dry next time you dry a similar load.
Setting the Drying Temperature
If your dryer has multiple heat settings:
A High temperature setting may be used for drying
heavyweight items such as towels and work clothes.
A Low to Medium temperature setting may be used for
drying medium-weight items such as sheets, blouses,
dresses, underwear, permanent press fabrics, and
some knits.
Use the Air Dry/No Heat setting for foam, rubber, plastic,
or heat-sensitive fabrics.
Line-dry bonded or laminated fabrics.
NOTE: If you have questions about drying temperatures for
various loads, refer to the care label directions.
Items to dry: Cycle: Temperature: Available Options: Cycle Details:
Large or heavy items
such as thick towels
or robes
Heavy Dry High End of Cycle Signal Choose high to dry large or heavy loads.
Heavy or bulky items Timed Dry
High Heat High End of Cycle Signal Completes drying if items are still damp.
Small loads, lightweight
items Timed Dry Low End of Cycle Signal Dries items to a damp level or for items that do not require an entire drying cycle.
Rubber, plastic,
heat-sensitive fabrics Air Dry/ No Heat Air Only/ No Heat End of Cycle Signal No-heat drying.

7
USING YOUR DRYER
1. Clean the lint screen
Clean the lint screen before each load. Pull the lint screen out
of its holder. Roll lint off the screen with your ngers. Do not
rinse or wash screen to remove lint. Push the lint screen rmly
back into place.
For additional cleaning information, see “Dryer Care.”
2. Load the dryer
Place laundry in the dryer. Close the door.
NOTE: Your model may have a different door than the one
shown. Some models have drop down doors.
Do not tightly pack the dryer; clothes should be able to tumble
freely.
WARNING: To reduce the risk of fire, electric shock, or injury to
persons, read the “IMPORTANT SAFETY INSTRUCTIONS” before
operating this dryer.
Before using your dryer, wipe the dryer drum with a damp cloth
to remove dust from storing and shipping.
3. Select the desired cycle
Select the desired cycle for your load. See the “Cycle Guide”
for more information about each cycle.
SENSOR DRY/AUTO DRY Cycles
You can select a different dryness level, depending on your load,
by turning the knob to dryness level.
Selecting Heavy Dry, Very Dry/More Dry, ENERGY PREFERRED,
or Less Dry automatically adjusts the dryness level at which the
dryer will shut off. Once a dry level is set, it cannot be changed
without stopping the cycle.
SENSOR DRY/AUTO DRY cycles give the best drying in the
shortest time. Drying time varies based on fabric type, load size,
and dryness setting.
NOTE: Heavy Dry or Very Dry/More Dry removes more load
moisture. ENERGY PREFERRED is used for a starting point for
Sensor Dry/Auto Dry cycles. Choose ENERGY PREFERRED for
optimal energy savings. Less Dry removes less moisture and is
used for loads you may want to put on a hanger to complete
drying.

8
6. Press PUSH TO START to
begin cycle
Push and hold the PUSH TO START knob to begin the cycle.
Promptly remove garments after cycle has completed to
reduce wrinkling. Use the Wrinkle Prevent feature to avoid
wrinkling when you are unable to remove a load from the
dryer as soon as it stops.
4. Set temperature and options
(on some models)
Select temperature and options by turning the knob to the
desired position or select the Automatic Dry Cycle that has
the temperature included in the cycle selections.
NOTE: Not all options and settings are available with all cycles.
TEMPERATURE
Turn the TEMPERATURE knob to change the drying
temperature setting. See “Setting the Drying Temperature.”
Wrinkle Prevent feature (on some models)
n Get up to 40 minutes of heat-free, periodic tumbling at the
end of a cycle. Turn the WRINKLE PREVENT knob to select
ON or OFF at any time before the cycle has ended.
5. Select End of Cycle Signal
(if desired)
Turn the END OF CYCLE SIGNAL knob to select the desired
setting (On or Off). The End of Cycle Signal produces an
audible sound when the drying cycle is nished. Promptly
removing clothes at the end of the cycle reduces wrinkling.
NOTE: When the Wrinkle Prevent setting is selected and the
End of Cycle Signal is on, the tone will sound every 5minutes
until the clothes are removed, or the Wrinkle Prevent setting
ends.
Drying Rack (optional on some models)
Use the Drying Rack to dry items such as sweaters and
pillows without tumbling. The drum turns, but the drying
rack does not move.
If your model does not have a drying rack, you may be
able to purchase one for your model. To nd out whether
your model allows drying rack usage and for information
on ordering, please refer to the “Accessories” section
or contact the dealer from whom you purchased your dryer.
NOTE: The drying rack must be removed for normal
tumbling.
To use the drying rack
1. Place drying rack in dryer. Slide rear pegs into the dimples
on the back wall of the dryer. Lower the front legs to rest
on the dryer opening.
2. Put wet items on top of drying rack, leaving space
between items. Do not allow items to hang over the
edge of the drying rack. Close the door.
3. Select a Timed Dry cycle and temperature, or an air
cycle (on some models). Items containing foam, rubber,
or plastic must be dried on a clothesline or by using an
air cycle. Refer to the following table.
4. Start the dryer. Reset cycle to complete drying, if needed.
Rack Dry: Cycle: Temp.: Time:
Washable wool items
(block to shape, lay at
on drying rack)
Timed
Dry Low 60 min.
Stuffed toys/pillows
(cotton or polyester
lled)
Timed
Dry Low 60 min.
Stuffed toys/pillows
(foam rubber lled)
(on some models)
Air
(no heat) N/A 90 min.

9
DRYER CARE
Keep dryer area clear and free from items that would
block the airow for proper dryer operation. This includes
clearing piles of laundry in front of the dryer.
Cleaning the lint screen
Every load cleaning
Clean lint screen before each load. A screen blocked by lint
can increase drying time.
To clean:
1. The lint screen is located on top of the dryer. Pull the lint
screen out of its holder. Roll lint off the screen with your
ngers. Do not rinse or wash screen to remove lint. Wet
lint is hard to remove.
2. Push the lint screen rmly back into place.
IMPORTANT:
n Do not run the dryer with the lint screen loose,
damaged, blocked, or missing. Doing so can cause
overheating and damage to both the dryer and fabrics.
n If lint falls off the screen into the dryer during
removal, check the exhaust hood and remove the lint.
The exhaust hood is located where the dryer exhaust
exits your home.
As needed cleaning
Laundry detergent and fabric softener residue can build
up on the lint screen. This buildup can cause longer drying
times for your clothes, or cause the dryer to stop before
your load is completely dry. The screen is probably clogged
if lint falls off while the screen is in the dryer.
Clean the lint screen with a nylon brush every 6 months,
or more frequently, if it becomes clogged due to a residue
buildup.
To wash:
1. Roll lint off the screen with your ngers.
2. Wet both sides of lint screen with hot water.
3. Wet a nylon brush with hot water and liquid detergent.
Scrub lint screen with the brush to remove residue
buildup.
4. Rinse screen with hot water.
5. Thoroughly dry lint screen with a clean towel.
Reinstall screen in dryer.
Cleaning the dryer interior
To clean dryer drum
1. Apply a liquid, nonammable household cleaner to the
stained area of the drum and rub with a soft cloth until
stain is removed.
2. Wipe drum thoroughly with a damp cloth.
3. Tumble a load of clean cloths or towels to dry the drum.
NOTE: Garments that contain loose dyes, such as denim
blue jeans or brightly colored cotton items, may discolor the
dryer interior. These stains are not harmful to your dryer and
will not stain future loads of clothes. Dry these items inside
out to avoid drum staining.
Removing accumulated lint
From Inside the Dryer Cabinet
Lint should be removed every 2 years, or more often,
depending on dryer usage. Cleaning should be done
by a qualied servicer.
From the Exhaust Vent
Lint should be removed every 2 years, or more often,
depending on dryer usage.
Cleaning the dryer location

10
Vacation, storage, and moving care
Non-Use or Storage Care
Operate your dryer only when you are at home. If you will
be on vacation or not using your dryer for an extended
period of time, you should:
1. Unplug dryer or disconnect power.
2. For gas dryers only: Close shut-off valve to gas supply
line.
3. Clean lint screen. See “Cleaning the Lint Screen.”
Moving Care
For power supply cord-connected dryers:
1. Unplug the power supply cord.
2. Make sure leveling legs are secure in dryer base.
3. Use tape to secure dryer door.
For direct-wired dryers:
1. Turn off power at fuse or breaker box.
2. Disconnect wiring.
3. Make sure leveling legs are secure in dryer base.
4. Use tape to secure dryer door.
For gas dryers:
1. Unplug or disconnect power to dryer.
2. Close shut-off valve in gas supply line.
3. Disconnect gas supply line pipe and remove ttings
attached to dryer pipe.
4. Cap the open fuel supply line.
5. Make sure leveling legs are secure in dryer base.
6. Use tape to secure dryer door.
Reinstalling the Dryer
Follow the “Installation Instructions” to locate, level,
and connect the dryer.
Changing the drum light
(on some models)
1. Unplug dryer or disconnect power.
2. Open the dryer door. Locate the light bulb cover
on the back wall of the dryer. Using a Phillips-head
screwdriver, remove the screw located in the lower
right-hand corner of the cover. Remove the cover.
3. Turn bulb counterclockwise. Replace the bulb
with a 10-watt appliance bulb only. Replace the
cover and secure with the screw.
4. Plug into a grounded outlet or reconnect power.
