CSI CS750 User manual

1
CS750
Instruction Manual
(This is a revised Version of the CSI Manual. The Information contained was created by
Independent Radio Operator. Connect Systems does not have any responsibility for its content.
Document created as an aid to other radio operators. User assumes complete responsibility for
using this document.)

2
Contents
Unpacking and Checking the Equipment ........................................................................5
Getting started.................................................................................................................5
Charging the Battery....................................................................................................5
Installing/Removing the Battery Pack..........................................................................6
Removing the battery pack..........................................................................................6
Installing the Antenna..................................................................................................7
Install external speaker/MIC ........................................................................................7
Installing/Removing the Belt Clip.................................................................................8
Radio Overview...............................................................................................................8
Basic Operations.............................................................................................................9
Power on the radio.......................................................................................................9
Adjust Volume .............................................................................................................9
Select a Channel .......................................................................................................10
Make a Call Selecting a Zone....................................................................................10
Selecting a Radio Channel, Subscriber ID, or Group ID............................................11
Receiving and Responding to a Radio Call ...............................................................11
Receiving and Responding to a Group Call...............................................................11
Receiving and Responding to a Private Call..............................................................11
Receiving an All Call..................................................................................................11
Making a Radio Call...................................................................................................12
Making a Call with the Channel Selector Knob..........................................................12
Making a Group Call ..............................................................................................12
Making a Private Call.............................................................................................12
Making a All Call ....................................................................................................13
Making a Group or Private Call with the One Touch Call Button ...............................13
Talkaround.................................................................................................................13
Monitoring Features (Analog) ....................................................................................14
Advanced Features....................................................................................................14
Radio Check ..........................................................................................................14
Sending a Radio Check .........................................................................................14
Remote Monitor.........................................................................................................14
Initiating Remote Monitor.......................................................................................14
Scan Lists..................................................................................................................15
Scan ..........................................................................................................................15

3
Starting and Stopping Scan ...................................................................................15
Responding to a Transmission During a Scan.......................................................16
Deleting a Nuisance Channel.................................................................................16
Restoring a Nuisance Channel ..............................................................................16
Contacts Settings.......................................................................................................16
Making a Group Call from Contacts.......................................................................17
Making a Private Call from Contacts......................................................................17
Call Indicator Settings................................................................................................17
Activating and Deactivating Call Ringers for Text Message...................................17
Assigning Ring Styles (Available after Version 2) ..................................................18
Escalating Alarm Tone Volume (Available after Version 2)....................................18
Call Log Features ......................................................................................................18
Viewing Recent Calls.............................................................................................18
Missed Call Screen................................................................................................19
Storing an Alias or ID from the Missed Call List.....................................................19
Deleting a Call from a Call List...............................................................................19
Call Alert Operation ...................................................................................................19
Receiving and Acknowledging a Call Alert.............................................................19
Emergency Operation................................................................................................20
Receiving an Emergency Alarm.............................................................................20
Responding to an Emergency Alarm......................................................................20
Sending an Emergency Alarm ...............................................................................21
Sending an Emergency Alarm with Call.................................................................21
Sending an Emergency Alarm with Voice to Follow...............................................22
Exiting an Emergency Mode ..................................................................................22
Text Message Features.............................................................................................22
Writing and Sending a Text Message ....................................................................22
Sending a Quick Text Message .............................................................................23
Sending a Quick Text Message with the One Touch Call Button...........................23
Managing Fail-to-Send Text Messages..................................................................24
Resending a Text Messages..................................................................................24
Forwarding a Text Message...................................................................................24
Managing Sent Text Messages..............................................................................24
Viewing a Sent Text Message................................................................................24

4
Sending a Sent Text Message...............................................................................24
Deleting all Sent Text Messages from Sent Items..................................................25
Receiving a Text Message.....................................................................................25
Reading a Text Message .......................................................................................25
Managing Received Text Messages......................................................................25
Viewing a Text Message from the Inbox................................................................25
Viewing a Text Message from the Inbox................................................................25
Deleting a Text Message from the Inbox................................................................26
Deleting All Text Messages from the Inbox............................................................26
Privacy.......................................................................................................................26
Dual Tone Multi Frequency (DTMF) (Analog)............................................................27
Security......................................................................................................................27
Radio Enable..........................................................................................................27
Utilities.......................................................................................................................28
Turning Keypad Tones On or Off...........................................................................28
Setting the Squelch Level (Analog)........................................................................28
Setting the Power Level .........................................................................................28
Turning the Voice Operating Transmission (VOX) Feature On or Off....................29
Controlling the Display Backlight............................................................................29
Turning the Radio Tones/Alerts On or Off..............................................................29
Turning the Talk Permit Tone On or Off.................................................................30
Turning the LED Indicator On or Off.......................................................................30
Turning the Introduction Screen On or Off .............................................................30
Accessing General Radio Information....................................................................30
PROGRAMMING ..........................................................................................................32
Software ....................................................................................................................32
Firmware Updates .....................................................................................................32
Determining Current Configuration.........................................................................32
Firmware Update Procedure..................................................................................35
CPS Upgrade ............................................................................................................37
Programming Cable...................................................................................................37
Trouble shooting ...........................................................................................................38
Radio Specifications......................................................................................................39

5
Unpacking and Checking the Equipment
Unpack the radio carefully. We recommend that you identify the items listed below in the
following table before discarding the packing material. If any items are missing or have been
damaged during shipment, please contact the carrier or the dealer immediately.
Supplied Accessories
Item
Quanty
1
Radio
1
2
Antenna
1
3
Battery
1
4
Hand Strap
1
5
Charger
1
4
Power Adapter
1
7
Belt Clip
1
8
Instruction Manual
1
Getting started
Charging the Battery
Plug the power adapter into the proper AC wall outlet and insert the DC plug in the charger
base. The Red LED will flash for 4.5 seconds after it is first turned on.
Insert the battery or the radio to be charged into the charger slot. Please turn off the radio
before inserting it into the charger.
Make sure the battery is in good contact with the charger terminals. When the red indicator is lit,
the charger begins to charge the battery.
After charging for about 3 hours, the red LED will turn OFF and the green LED will turn on
indicating the battery has been fully charged.
Only for NiMH battery on the first charge, please leave the battery in for two more hours after
the green light first turns on before you remove it from the charger to achieve the best
performance of the battery. Then you can disconnect the power adapter from the AC outlet.
If the Red LED flashes quickly (0.2s on 0.2s off), this means the charging process has stopped
because the charging temperature is too high or the battery has a problem. If that happens the
charger enters a protective state and no more charge is delivered to the battery. Please stop
charging in such situation and remove the battery from the charger.
Notice:
The new battery is not fully charged in the factory, and needs to be fully charged when you use
the radio for the first time.
The radio is supplied with a standard battery manufactured by the factory.

6
The battery, after been in storage for a long period ,will not reach the full capacity till several
charging and discharging (during use) cycles.
Do not recharge the battery after it has been fully charged or it is partially discharged, otherwise
it might affect the battery life or performance. Remove the battery from the charger after
charging is finished.
If the radio enters a low battery warning state, please recharge the battery. Do not use the radio
in a low power warning state because it will affect the battery life and performance.
Installing/Removing the Battery Pack
To install the battery, please place it into the groove on the top of the radio chassis about 5mm
away from latch.
If the radio has the belt clip installed, you will have to press one side of the clip to raise it and
then slide the battery in proper position.
Press the battery with your fingers and push the battery until you hear a latch click. The battery
is now installed.
Removing the battery pack
If you want to remove the battery from the radio, first press the battery latch located on the
bottom of the radio, and then press down to slide the battery about 5mm to release the
latch.
Notice:
• Do not short-circuit the battery terminals or dispose the battery in fire.
• Do not disassemble the battery case.

7
Installing the Antenna
Screw the antenna into the connector at the top of the radio by holding the bottom of the
antenna and turn it clockwise until secure.
Install external speaker/MIC
Open the cover of the jack for external speaker/MIC, and then insert the plug of the external
speaker or microphone into the jack on the radio. When inserting the accessory plug, make sure
it is properly aligned (straight) to avoid internal damage to the connector in the radio.

8
Installing/Removing the Belt Clip
Use the 2 screws (M2.5x8.0) supplied with the radio and insert these screws through the holes
in the radio clip and into the holes in the aluminum case. If you want to remove the clip from
the radio, just unscrew them, and remove the clip. You can put the screws back into the radio to
make sure you do not lose them.
Radio Overview
1.PTT ( PUSH-TO-TALK) Button
To make a call, press and hold the PTT button, then speak into the microphone in normal voice.
Release the PTT button to receive signals.
2. Side Button 1 (Programmable Button)
3. Side Button 2 (Programmable Button)
4. MIC lnput
Please keep your mouth about 10 cm (3-4 inches) away from the microphone to achieve the
best voice quality. If the distance is too far or too close to the radio, it will affect the voice quality
5. LCD
6. Key Pad
7. Top Button (Programmable Button)
8. Channel Selector, Rotate to select Channel

9
9. Power/Volume Knob. Turn clockwise to switch on the radio. Turn counterclockwise till a click
is heard to switch off the radio.
10. LED Indicator. LED Indicator Status/Alert: Green LED lights a carrier is detected in the
current channel. Red LED lights during transmission. Orange LED flashes when scanning.
Red LED flashed when low battery
Basic Operations
Power on the radio
Turn on the radio by turning the Power/Volume switch clockwise till a click is heard, and you will
hear a Power up beep if the dealer has set it. The radio is now in Rx mode.
Adjust Volume
Rotate the Power/Volume knob to adjust the volume. Turn clockwise to increase the volume and
counterclockwise to decrease the volume.

10
Select a Channel
Rotate the channel selector to the desired channel. When a signal is received, it will be heard in
the speaker.
Each channel in your radio can be configured as an analog channel or a digital channel. Use the
Channel Selector Knob to switch between an analog channel or a digital channel. When switch
from digital to analog mode, certain features are unavailable. Icons for the digital features (such
as Messages) reflect this change by appearing "grayed out". Disabled features are hidden in the
menu.
Your radio also has features available in both analog and digital mode. However, the minor
differences in the way each feature works does not affect the performance of your radio.
NOTE: Your radio also switches between digital and analog modes during a dual mode scan
Make a Call Selecting a Zone
A zone is a group of channels. Your radio supports up to 250 zones, with a maximum of 16
channels per zone. Use the following procedure to select a zone.
Procedure:
Press the programmed Zone button and proceed to step 2.
OR Follow the procedure below.
1. Press then press to Zone and press to select.
2. The current zone is displayed an indicated by a √
3. Press to the required zone and press to select.
4. The display shows <Zone> Selected momentarily.
