Csi Brute series Installation instructions

User Manual and

Product Specications

CSI BRUTE 84QT

REFRIGERATOR/FREEZER

PART#W55

Insulating Blanket PART#W56 (Sold Separately)

IMPORTANT

Read instructions before operation

(For California Residents)

WARNING: These products can expose you to chemicals including LEAD and DEHP which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more information go to

www.P65WARNINGS.CA.GOV. Wash hands following installation or handling.

SECTION PAGE

Features and Safety Instructions 2-3

Notes on using the product 3

Operating Instructions 3-4

Cleaning and Maintenance 4

Troubleshooting 5

Guidelines for Protection of the Environment 5

PART#W55 Black Ice Refrigerator/Freezer

What’s Included in the box:

• x1 #W55 Black Ice Refrigerator/Freezer

• x1 12V cable

• x1 Power supply

• x1 110V cord

• x1 Removable basket

• x1 Operations manual

Key Product Features:

• 84 Quart holding capacity and perfectly portable

• Quiet compressor operation

• 12/24V or 110V operation

• Removable wire basket included

• Digital controls with two individually adjustable zones of cooling/freezing

• CSI downloadable app for smart phone control

• 3 levels of adjustable battery protection to eliminate discharged batteries

• Built in LED lighting

• Hi/low compressor mode for energy saving or max cooling

• Brushed stainless outer nish

• Dual lids with secure latching

• Anti-rattle spring loaded handles

•

Available accessories: insulation cover (#W56), vehicle mount w/slide (#W58),

portable

battery (#W59)

Downloadable CSI Black Ice app for smart phones and tablets:

• Shows voltage, temp, and battery condition if connected

• Allows adjustment of temperature, battery protection, compressor speed, oF or oC, and all settings

• Can turn on or off via the CSI Black Ice app

• Compatible with iOS and Android mobile devices

To download the CSI Black Ice app:

• Apple phone/tablet: Visit the Apple app store and search CSI Black Ice, download the app

to your phone or tablet

• Android phone/Tablet: Visit the Google Play store and search CSI Black Ice, download the app

to your phone or tablet

(For California Residents)

WARNING: These products can expose you to chemicals including LEAD and DEHP which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more

information go to www.P65WARNINGS.CA.GOV. Wash hands following installation or handling.

PLEASE READ ALL INSTRUCTIONS AND THE SAFETY SECTION CAREFULLY BEFORE USING

YOUR REFRIGERATOR/FREEZER. KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.

1. SAFETY INSTRUCTIONS

• Warning: Do not touch exposed cables w/your bare hands when operating the refrigerator/freezer

• Warning: It is dangerous to touch the plug with wet hands. When using the refrigerator/freezer

in a vehicle or boat, please make sure the electricity has a fuse if using the main power source.

• The installation of a DC power source on a boat should be handled by qualied personnel

• Make sure the voltage is correct.

• Do not place any electrical devices inside the refrigerator/freezer

• Please keep the refrigerator/freezer away from any substance that may cause electrocution or re

• The refrigerator/freezer is not intended for use by young children without adult supervision

• Do not turn the refrigerator/freezer upside down to drain liquids. Use a dry cloth

• Do not put any objects in the air inlet or outlet vents

• Turn off and disconnect the refrigerator/freezer from the power source before cleaning

2. NOTES ON USING THE PRODUCT

• Your refrigerator/freezer requires good ventilation, especially around the back of the unit. Allow

a gap of at least 8 inches (200mm) around the back and 4 inches (100mm) on the other sides

• Avoid humidity: Humidity inside the refrigerator/freezer can form frost and impair cooling. Defrost

the refrigerator/freezer before frost is formed. Never clean the refrigerator/freezer under running

water or immerse in water

• Avoid placing your refrigerator/freezer near a heat source. This will help the refrigerator/freezer to

work more efciently and keep its contents cool

• Place the refrigerator/freezer on a at surface and away from any ledges. When placing the

refrigerator/freezer into a vehicle, use straps to fasten it securely

3. OPERATING INSTRUCTIONS

• POWER: The refrigerator/freezer controls the compressor system and adds battery

protection. When the input voltage is at minimum value, it will stop the compressor; when the

voltage comes back to the normal value, the compressor will automatically restart

• BATTERY PROTECTION: Select low, med or high settings. Below you can nd the battery voltage

levels values when the compressor stops running (cut-out) & when the compressor restarts (cut-in)

BATTERY ELECTRIC POWER

DISPLAY IF CONNECTED TO

W59 PORTABLE BATTERY

BATTERY

PROTECTION 12V CUT-OUT 12V CUT-IN 24V CUT-OUT 24V CUT-IN

LOW 8.5V 10.9V 21.3V 22.7V

MED 10.1V 11.4V 22.3V 23.7V

HIGH 11.1V 12.4V 24.3V 25.7V

(For California Residents)

WARNING: These products can expose you to chemicals including LEAD and DEHP which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more

information go to www.P65WARNINGS.CA.GOV. Wash hands following installation or handling.

• ON/OFF POWER BUTTON: Press ON/OFF button to turn the unit on, then press the ON/OFF

button to turn unit off

• Press the sbutton to increase or the tbutton to decrease the temperature

• Press the left box sand tbutton at the same time to cut off the left box cooling

(only right box cooling)

• Only set one temperature at a time

• If the power source is cut off or disconnected, the unit will switch off automatically and once the

power is restored it will automatically switch back on with the same settings

• Press the Compressor Speed button to set the speed of the compressor, MAX 3000 RPM,

MIN 2000 RPM. The LCD display will show which speed is selected.

• Press the Battery Protection button to set the desired voltage, cut-off level - LOW, MED, HIGH.

The LCD display will show which voltage is selected

• Press the button to turn on the box lights. Press the button again to turn the box lights off. If

you forget to turn the box lights off they will automatically turn off in 3 minutes

• The left box temperature can be set colder or the same as the right box

4. CLEANING AND MAINTENANCE

• Be sure to turn off all power sources to the refrigerator/freezer before cleaning

• Clean the refrigerator/freezer inside and out with a damp cloth once a week using a solution of

baking soda dissolved in lukewarm water. Rinse using a clean damp cloth, fresh water and

dry thoroughly. Never use abrasive products, detergents or soap. Do not leave refrigerator/freezer

turned off with food inside and the lid closed

• Never clean the refrigerator/freezer under running water or immerse in water.

Do not use abrasive cleaning agents or brushes/scrubbers when cleaning,

as these can damage the unit

(For California Residents)

WARNING: These products can expose you to chemicals including LEAD and DEHP which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more

information go to www.P65WARNINGS.CA.GOV. Wash hands following installation or handling.

5. TROUBLESHOOTING

THE REFRIGERATOR/FREEZER IS NOT WORKING:

• Check the power supply

• Check whether the plug and the socket have a good connection

• Check whether the refrigerator/freezer has been turned on

THE FOOD INSIDE IS FROZEN:

• The temperature setting is too low

BAD PERFORMANCE IN REFRIGERATION:

• The door is not fully closed

• The door seal is broken

• Never place heated food inside the refrigerator/freezer. Always allow food to cool at room

temperature before placing in the unit

• Problems arising from poor ventilation - There is not enough room around the unit:

See page 3, #2 “Notes on using the product”)

• There is a source of heat around. Never place near a heat source

• The temperature setting is inappropriate

NOISE? RATTLING?

• The refrigerator/freezer is not placed on a level surface

• The unit is touching a wall or surface other than the oor

• You may hear liquid sounds from inside the unit, this is normal, due to the ow of the refrigerant

ERROR PROTECTION FUNCTION

8. PROTECTION OF THE ENVIRONMENT

• PLEASE DO NOT DISPOSE of this product as unsorted municipal waste.

Collection of such waste separately for special treatment is necessary

(For California Residents)

WARNING: These products can expose you to chemicals including LEAD and DEHP which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more

information go to www.P65WARNINGS.CA.GOV. Wash hands following installation or handling.

ERROR

CODE PROBLEMS SOLUTION METHOD

F1 Input low voltage protection

1. Charge the battery

2. Lower battery

protection switch

F3 Compressor protection Disconnect power

30 minutes, then restart

F5 Temperature of the unit

is abnormal

Put unit in a ventilated
