CSI BRUTE Series Installation instructions

User Manual and
Product Specications
CSI BRUTE 63QT
REFRIGERATOR/FREEZER
PART#W53
Insulating Blanket PART#W54 (Sold Separately)
IMPORTANT
Read instructions before operation
(For California Residents)
WARNING: These products can expose you to chemicals including LEAD and DEHP which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more information go to
www.P65WARNINGS.CA.GOV. Wash hands following installation or handling.

SECTION PAGE
Features and Safety Instructions 2-3
Notes on using the product 3
Operating Instructions 3-5
Cleaning and Maintenance 5
Troubleshooting 6
Guidelines for Protection of the Environment 6
PLEASE READ ALL INSTRUCTIONS AND THE SAFETY SECTION CAREFULLY BEFORE USING
YOUR REFRIGERATOR/FREEZER. KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
PART#W53 Black Ice Refrigerator/Freezer
What’s Included in the box:
• x1 #W53 Black Ice Refrigerator/Freezer
• x1 12V Cable
• x1 Power Supply
• x1 110V Cable
• x1 Removable Partition
• x2 Removable Basket
• x1 Operations Manual
Key Product Features:
• 12/24V or 110V operation
• Quiet compressor operation
• 63QT of holding capacity (57 12ozs cans)
• Removable partition with sensor
• Automatically changes to single zone when removed
• Dual removable baskets
• Rear wheels and extendable handle for mobility
• USB charging port
• LCD controls with two individually adjustable zones of cooling/freezing
• CSI downloadable app for smart phone control
• Available accessories – insulation cover (#W54), vehicle mount with slide (#W57), portable battery (#W59)
• 3 levels of adjustable battery protection to eliminate discharged batteries
• Built in LED lighting
• Drain plug in bottom for easy clean out
• Hi/low compressor mode for energy saving or max cooling
Downloadable CSI Black Ice app for smart phones and tablets:
• Shows voltage, temp, and battery condition if connected
• Allows adjustment of temperature, battery protection, compressor speed, oF or oC, and all settings
• Can turn on or off via the CSI Black Ice app
• Compatible with iOS and Android mobile devices
To download the CSI Black Ice app:
• Apple phone/tablet: Visit the Apple app store and search CSI Black Ice, download the app
to your phone or tablet
• Android phone/Tablet: Visit the Google Play store and search CSI Black Ice, download the app
to your phone or tablet
2
(For California Residents)
WARNING: These products can expose you to chemicals including LEAD and DEHP which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more
information go to www.P65WARNINGS.CA.GOV. Wash hands following installation or handling.

3
(For California Residents)
WARNING: These products can expose you to chemicals including LEAD and DEHP which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more
information go to www.P65WARNINGS.CA.GOV. Wash hands following installation or handling.
1. SAFETY INSTRUCTIONS
• Warning: Do not touch exposed cables w/your bare hands when operating the refrigerator/freezer
• Warning: It is dangerous to touch the plug with wet hands. When using the refrigerator/freezer
in a vehicle or boat, please make sure the electricity has a fuse if using the main power source.
• TheinstallationofaDCpowersourceonaboatshouldbehandledbyqualiedpersonnel
• Make sure the voltage is correct.
• Do not place any electrical devices inside the refrigerator/freezer
• Pleasekeeptherefrigerator/freezerawayfromanysubstancethatmaycauseelectrocutionorre
• The refrigerator/freezer is not intended for use by young children without adult supervision
• Do not turn the refrigerator/freezer upside down to drain liquids. Use the drain plug and a dry cloth
• Do not put any objects in the air inlet or outlet vents
• Turn off and disconnect the refrigerator/freezer from the power source before cleaning
2. NOTES ON USING THE PRODUCT
• Your refrigerator/freezer requires good ventilation, especially around the back of the unit. Allow
a gap of at least 8 inches (200mm) around the back and 4 inches (100mm) on the other sides
• Avoid humidity: Humidity inside the refrigerator/freezer can form frost and impair cooling. Defrost
the refrigerator/freezer before frost is formed. Never clean the refrigerator/freezer under running
water or immerse in water
• Avoid placing your refrigerator/freezer near a heat source. This will help the refrigerator/freezer to
 workmoreefcientlyandkeepitscontentscool
• Placetherefrigerator/freezeronaatsurfaceandawayfromanyledges.Whenplacingthe
refrigerator/freezer into a vehicle, use straps to fasten it securely
3. OPERATING INSTRUCTIONS
• POWER: The refrigerator/freezer controls the compressor system and adds battery
protection. When the input voltage is at minimum value, it will stop the compressor; when the
voltage comes back to the normal value, the compressor will automatically restart
• BATTERY PROTECTION: Selectlow,medorhighsettings.Belowyoucanndthebatteryvoltage
levels values when the compressor stops running (cut-out) & when the compressor restarts (cut-in)
BATTERY ELECTRIC POWER
DISPLAY IF CONNECTED TO
W59 PORTABLE BATTERY
BATTERY
PROTECTION 12V CUT-OUT 12V CUT-IN 24V CUT-OUT 24V CUT-IN
LOW 8.5V 10.9V 21.3V 22.7V
MED 10.1V 11.4V 22.3V 23.7V
HIGH 11.1V 12.4V 24.3V 25.7V

4
(For California Residents)
WARNING: These products can expose you to chemicals including LEAD and DEHP which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more
information go to www.P65WARNINGS.CA.GOV. Wash hands following installation or handling.
4. OPERATION METHOD
• Connect to the power source, press the ON/OFF
button for 3 seconds to show inner temperature
and start the compressor to enter cooling mode
• Press the ON/OFF button for 3 seconds to turn the
refrigerator/freezer off
• Only 1 temperature will display if the inner middle plate
has been removed
• To change mode settings, press the gear button
ECO (energy saving mode) or MAX (fast cooling
mode). MAX is the factory setting.
• Press the + or - buttons to set the temperature between 50oF to -4oF
(10oC to -20oC)
INSTRUCTIONS FOR IN-VEHICLE USE
• The refrigerator has a 3-level battery protection function, which not only guarantees the normal
operation of the refrigerator but also protects the battery of the vehicle. When in the power-on
 state,presstheSETbuttonfor3secondsandthedisplayscreenashesH.Selectlowvoltage
protection L (low), M (medium) and H (high) by pressing the SET button. The factory defaults to
H (high) protection.
• H (high) should be set when the refrigerator is connected to the car power and M (medium)
or L (low) should be set when it is connected to a portable backup battery. Because of the different
output voltage between different vehicles, the battery gear can be set from H (high) to M (medium)
or M (medium) to L (low) if there is a voltage protection code F1 displayed on the panel. The
battery gear should be set to H (high) if the refrigerator needs to keep working after turning off the
car engine and to avoid the possibility of overuse or draining the battery to the point where the
vehicle cannot be restarted.

5
(For California Residents)
WARNING: These products can expose you to chemicals including LEAD and DEHP which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more
information go to www.P65WARNINGS.CA.GOV. Wash hands following installation or handling.
6. CLEANING AND MAINTENANCE
• Do not spray down or immerse in water
• Always unplug before cleaning the refrigerator to avoid electric shock
Follow below instructions if unit will not be
used for extended time period
• Turn it off and unplug
• Remove all contents
• Drain any water and dry it with a soft cloth
• Store in clean, dry, temperate area
• Drain the refrigerator simply
by removing the stopper
in the bottom
• Clean and rinse
with soft damp
cloth
5. COMPONENT DETAILS

6
(For California Residents)
WARNING: These products can expose you to chemicals including LEAD and DEHP which are known to the state of California to cause cancer and birth defects or other reproductive harm. For more
information go to www.P65WARNINGS.CA.GOV. Wash hands following installation or handling.
6. TROUBLESHOOTING
THE REFRIGERATOR/FREEZER IS NOT WORKING:
• Check the power supply
• Check whether the plug and the socket have a good connection
• Check whether the refrigerator/freezer has been turned on
THE FOOD INSIDE IS FROZEN:
• The temperature setting is too low
BAD PERFORMANCE IN REFRIGERATION:
• The door is not fully closed
• The door seal is broken
• Never place heated food inside the refrigerator/freezer. Always allow food to cool at room
temperature before placing in the unit
• Problems arising from poor ventilation - There is not enough room around the unit:
See page 3, #2 “Notes on using the product”)
• There is a source of heat around. Never place near a heat source
• The temperature setting is inappropriate
NOISE? RATTLING?
• The refrigerator/freezer is not placed on a level surface
• Theunitistouchingawallorsurfaceotherthantheoor
• Youmayhearliquidsoundsfrominsidetheunit,thisisnormal,duetotheowoftherefrigerant
ERROR PROTECTION FUNCTION
7. PROTECTION OF THE ENVIRONMENT
• PLEASE DO NOT DISPOSE of this product as unsorted municipal waste.
Collection of such waste separately for special treatment is necessary
ERROR
CODE PROBLEMS SOLUTION METHOD
F1 Input low voltage protection
1. Charge the battery
2. Lower battery
protection switch
F3 Compressor protection Turn off power and wait
30 minutes, then restart
F5 Temperature of the unit
is abnormal
Put unit in a ventilated
place, allow to cool,
then restart
