CTA PAD-ARLTD2 User manual

Height-Adjustable Rolling Desk with 2 Grommet VESA Mounts
PAD-ARLTD2
INSTRUCTION - MANUAL
CONTENTS:
INSTALLATION:
888-733-4448
1A. Screw main
body pole (A) to the
metal plate
connector (D) with
the M6x12 screws
(H) using the
included 4mm allen
key (K) until
securely tightened.
2A. Screw the now
attached metal
plate connector
(D) to the
workstation top (C)
with the M6x12
screws (I) using
the included 4mm
allen key (K) until
securely tightened.
A
x1
B
x1
D
x1
E
x2
F
x2
I
x4
J
x4
K
x1
G
x4
H
x4
L
x1
M
x1
C
x1
1. Mounting Plate to Workstation Main Pole 2. Mounting Plate to Underside of Table
HK
D
C
I
D
A
K
3A. Screw the base
(B) to the main body
(A) with the M6x60
screws (G) and the
D6 washers (J)
using the included
5mm allen key (L)
until securely
tightened.
4A. Using the provided
wrench (M), attatch the
normal casters (F) to the
narrowest part of the base
(B) and the locking casters
(E) to the widest part of the
base. Rotate clockwise until
securely tightened.
3. Mounting Base with Main Body Pole 4. Attaching Wheels to Base
G
A
L
B
JE
B
E
A
M
F

888-733-4448
5. Adjusting Workstation Height
7. Attaching Articulating Monitor Arm
5A. Press down
on pedal (A) and
manually pull or
push workstation
top (C), either up
or down, to
adjust desired
height.
7A. See included
ADD-GCADM
manual for more
detailed
instructions and
features.
C
C
C
A
Please be sure to fasten all the screws securely before using. Failure to do so may compromise integrity.
!Caution
6A. See included
ADD-DMCG
manual for more
detailed
instructions and
features.
6. Attaching Counterbalance Monitor
Arm Component
