Cub Cadet 1333SWE Series Manual

OPERATOR’S MANUAL
IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY
CUB CADET CORP. P.O. BOX 368023 CLEVELAND, OHIO 44136-9722
Model Series
1333SWE
Snow Thrower
PRINTED IN U.S.A. FORM NO. 770-10009A
Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-
covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting
applicable local or state laws (if any). If a spark arrester is used, it should be maintained in effective working order by the operator.
In the State of California the above is required by law (Section 4442 of the CaliforniaPublic Resources Code). Other states may have
similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized
service dealer or contact the service department, P.O. Box 368023 Cleveland, Ohio 44136-9722.
(06/99)

2
SECTION 1: FINDING YOUR MODEL NUMBER
This Operator’s Manual is an important part of your new snow thrower. It will help you assemble, prepare and
maintain your snow thrower. Please read and understand what it says.
Before you start to prepare your snow thrower for its first use, please locate the model plate and copy the
information from it in this Operator’s Manual. The information on the model plate is very important if you need
help from your dealer.
• Every snow thrower has a model plate. You can locate it by standing behind the unit in the operating
position and looking down at the frame cover.
• The model plate will look like Figure 1.
Figure 1
SECTION 2: CALLING WARRANTY SERVICE
If you are having difficulty assembling this product or if you have any question regarding the controls,
operation or maintenance of this unit, please call the Customer Dealer Referral Line. You can reach them by
calling:
1-800-528-1009
Before calling your local dealer, make sure that you have your model and serial numbers ready. By having the
model and serial numbers ready, you help your local dealer give you faster service. To find your unit’s model
and serial number, see SECTION 1: FINDING YOUR MODEL NUMBER.
XXX-X-XXX-X-XXX XXXXXXXXXXX
This is where your model number will be.
This is where your serial number will be.
Copy the model number here:
Copy the serial number here:
CUB CADET CORP.
CLEVELAND, OHIO 44136
P.O. BOX 368023

3
SECTION 3: IMPORTANT SAFE OPERATION PRACTICES
WARNING: THIS SYMBOL POINTS OUT IMPORTANT SAFETY INSTRUCTIONS WHICH, IF
NOT FOLLOWED, COULD ENDANGER THE PERSONAL SAFETY AND/OR PROPERTY OF
YOURSELF AND OTHERS. READ AND FOLLOW ALL INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE YOUR SNOW THROWER. FAILURE TO COMPLY WITH
THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. WHEN YOU SEE THIS SYMBOL-
HEED ITS WARNING.
WARNING: The Engine Exhaust from this product contains chemicals known to
the State of California to cause cancer, birth defects or other reproductive harm.
DANGER: Your snow thrower was built to be operated according to the rules for safe operation in
this manual. As with any type of power equipment, carelessness or error on the part of the operator
can result in serious injury. If you violate any of these rules, you may cause serious injury to yourself
or others.
1. TRAINING
• Read this operator's manual carefully in its entirety
before attempting to assemble or operate this
machine. Be completely familiar with the controls
and the proper use of this machine before
operating it. Keep this manual in a safe place for
future and regular reference and for ordering
replacement parts.
• Never allow children under 14 years old to operate
a snow thrower. Children 14 years old and over
should only operate snow thrower under close
parental supervision. Only persons well acquainted
with these rules of safe operation should be
allowed to use your snow thrower.
• No one should operate this unit while intoxicated or
while taking medication that impairs the senses or
reactions.
• Keep the area of operation clear of all persons,
especially small children and pets.
• Exercise caution to avoid slipping or falling,
especially when operating in reverse.
2. PREPARATION
• Thoroughly inspect the area where the equipment
is to be used and remove all door mats, sleds,
boards, wires and other foreign objects.
• Disengage all clutches before starting engine.
• Do not operate equipment without wearing
adequate winter outer garments. Do not wear
jewelry, long scarfs or other loose clothing which
could become entangled in moving parts. Wear
footwear which will improve footing on slippery
surfaces.
• Before working with gasoline, extinguish all
cigarettes and other sources of ignition. Check the
fuel before starting the engine. Gasoline is an
extremely flammable fuel. Do not fill the gasoline
tank indoors, while the engine is running, or until
engine has been allowed to cool at least two
minutes. Replace gasoline cap securely and wipe
off any spilled gasoline before starting the engine
as it may cause a fire or explosion.
• Use a grounded three wire plug-in for all units with
electric drive motors or electric starting motors.
• Adjust collector housing height to clear gravel or
crushed rock surface.
• Never attempt to make any adjustments while
engine is running (except where specifically
recommended by manufacturer).
• Let engine and machine adjust to outdoor
temperature before starting to clear snow.
• Always wear safety glasses or eye shields during
operation or while performing an adjustment or
repair, to protect eyes from foreign objects that may
be thrown from the machine in any direction.
3. OPERATION
• Do not put hands or feet near or under rotating
parts. Keep clear of discharge opening and auger
at all times.
• Exercise extreme caution when operating on or
crossing gravel drives, walks, or roads. Stay alert
for hidden hazards or traffic. Do not carry
passengers.
• After striking a foreign object, stop the engine,
remove wire from spark plug, and thoroughly
inspect the snow thrower for any damage. Repair
the damage before restarting and operating the
snow thrower.

4
• If the snow thrower should start to vibrate
abnormally, stop the engine and check immediately
for the cause. Vibration is generally a warning of
trouble.
• Stop engine whenever you leave the operating
position, before unclogging the collector/impeller
housing or discharge guide, and making any
repairs, adjustments, or inspections. Never place
your hand in the discharge or collector openings.
Use a stick or wooden broom handle to unclog the
discharge opening.
• Take all possible precautions when leaving the unit
unattended. Disengage the collector/impeller, stop
the engine, and remove the key.
• When cleaning, repairing, or inspecting, make
certain collector/impeller and all moving parts have
stopped. Disconnect spark plug wire and keep
away from plug to prevent accidental starting.
• Do not run engine indoors, except when starting
engine and transporting snow thrower in or out of
building. Open doors. Exhaust fumes are
dangerous.
• Do not clear snow across the face of slopes.
Exercise extreme caution when changing direction
on slopes. Do not attempt to clear steep slopes.
• Never operate snow thrower without guards, plates,
or other safety protection devices in place.
• Never operate snow thrower near glass enclosure,
automobiles, window wells, drop off, etc., without
proper adjustments of snow thrower discharge
angle. Keep children and pets away.
• Do not overload machine capacity by attempting to
clear snow at too fast a rate.
• Never operate the machine at high transport
speeds on slippery surfaces. Look behind and use
care when backing.
• Never direct discharge at bystanders or allow
anyone in front of unit.
• Disengage power to collector/impeller when
transporting or not in use.
• Use only attachments and accessories approved
by the manufacturer of snow thrower (such as
wheel weights, counter weights, cabs, etc.).
• Never operate the snow thrower without good
visibility or light. Always be sure of your footing and
keep a firm hold on the handles. Walk, never run.
• Muffler and engine become hot and can cause a
burn. Do not touch.
4. MAINTENANCE AND STORAGE
• Check shear bolts, engine mounting bolts, etc., at
frequent intervals for proper tightness to be sure
equipment is in safe working condition.
• Never store the machine with fuel in the fuel tank
inside a building where ignition sources are
present, such as hot water and space heaters,
clothes dryers, and the like. Allow engine to cool
before storing in any enclosure.
• Always refer to operator's manual instructions for
important details if snow thrower is to be stored for
an extended period.
• Run machine a few minutes after throwing snow to
prevent freeze up of collector/impeller.
• Check clutch controls periodically to verify they
engage and disengage properly and readjust if
necessary. Refer to operator's manual for
adjustment instructions.
WARNING - YOUR RESPONSIBILITY: Restrict the use of this power machine to persons
who read, understand and follow the warnings and instructions in this manual and on the machine.
Figure 2 Safety Labels Found on Snow Thrower
DEBRIS AND SERVICING UNIT
STOP ENGINE BEFORE REMOVING
KEEP CLEAR OF IMPELLER WHILE
ENGINE IS RUNNING
NEVER DIRECT DISCHARGE AT
BYSTANDERS OR WINDOWS OR
ALLOW ANYONE IN FRONT OF
UNIT
THOROUGHLY INSPECT THE AREA
WHERE THE EQUIPMENT IS TO BE
USED AND REMOVE ALL DOOR
MATS, SLEDS, BOARDS, WIRES AND
OTHER FOREIGN OBJECTS
REFER TO OWNERS MANUAL FOR
FULL INSTRUCTIONS
1.
2.
3.
4.
5.
WARNING
AVOID INJURY FROM
ROTATING AUGER -
KEEP HANDS, FEET
ANDCLOTHING AWAY.
DANGER

5
SECTION 4: SET-UP INSTRUCTIONS
Figure 3
Figure 4
Figure 5
NOTE: Reference to right or left side of the snow
thrower is from behind the unit in the operating
position.
IMPORTANT: Check the adjustments as
instructed on page 6, and make any final
adjustments necessary before operating your snow
thrower. Failure to follow the instructions may cause
damage to the snow thrower.
1. Remove screws from the top sides and ends of
the shipping crate.
2. Set top, side, and end panels aside to avoid tire
punctures or personal injury.
3. Remove and discard plastic bag that covers unit.
4. Roll unit out of crate.
5. Remove the lower two plastic wing nuts, cupped
washers and carriage bolts from each side of the
upper handle. See Figure 3.
6. The chute directional control may be attached to
the lower handle with cable ties for shipping
purposes, if so, cut the cable ties and remove
the chute directional control at this time.
7. Raise the upper handle assembly until it locks
over the lower handle. See Figure 3 and Figure 4.
8. Secure the upper handle and lower handle with
the two plastic wing nuts, cupped washers and
carriage bolts previously removed. See Figure 4.
9. Slide the shift rod connector down over the end
of the lower shift rod. See Figure 5. Tap the
connector until it locks on the lower shift rod.
NOTE: If the connector is not properly assembled,
the shift rod will pivot and you will not be able to shift
gears or change directions.
10. Remove the hairpin clip from the end of the
upper chute directional control. Slide the upper
chute directional control into the lower chute
directional control. Align the holes, and secure
with hairpin clip. See Figure 5.
Shear Bolts
5/16-18 x 1-1/2" Long
(710-0890A)
Hex Lock Nuts
5/16-18 Thread
(712-0429)
AUGER SHEAR BOLTS
The augers are secured to the auger shaft with two shear bolts
and hex lock nuts. If you hit a foreign object or ice jam, the snow
thrower is designed so that the bolts will shear. Two replacement
shear bolts and nuts are provided for your convenience. Store in a
safe place until needed
Wing Nuts,
Washers
and Bolts
Wing
Nut,
Washer
and
Bolt
Upper Shift
Rod
Upper Chute
Directional
Lower
Shift Rod
Hairpin
Clip
Lower
Chute
Directional
Connector
Control
Control

6
Figure 6
11. If not already attached, slip the cables that run
from the handle panel to the chute into the cable
guide located on top of the engine. See Figure
6.
12. Unwrap the headlight wire which is attached to
the headlight, beneath the handle panel. Wind
the headlight wire around the right handle until
excess slack is removed.
13. Plug the wire from the headlight into the wire
lead coming from the right side of the engine,
underneath the fuel tank.
Figure 7
Figure 8
Figure 9
FINAL ADJUSTMENTS
Auger and Traction Control Clutch
Adjustment
To check the adjustment of either drive clutch, push
forward on the clutch grip (depress the rubber
bumper). There should be slack in the cable.
Release the clutch grip. The cable should be
straight, but not tight. Make certain you can depress
the clutch grip against the handle completely.
If necessary, thread lock-nut up to increase tension
or down to decrease tension. See Figure 7.
Skid Shoe Adjustment (See Figure 8)
The space between the shave plate and the ground
can be adjusted. For close snow removal, place skid
shoes in the low position. Use middle or high
position when area to be cleared is uneven. See
Figure 8.
Adjust skid shoes by loosening the six hex nuts and
carriage bolts and moving skid shoes to desired
position. Make certain the entire bottom surface of
skid shoe is against the ground to avoid uneven
wear on the skid shoes. Tighten nuts and bolts
securely. The skid shoes may be reversed for even
wear.
Shift Lever Adjustment (See Figure 9)
If unit does not engage properly into first gear, it may
be necessary to remove the cotter pin and washer
from the shift rod and thread the ferrule one
counterclockwise turn.
TIRE PRESSURE (Pneumatic Tires)
The tires are over-inflated for shipping purposes.
Check tire pressure and reduce to 15 to 20 psi.
(Check sidewall of tire for manufacturer’s
recommendation)
NOTE: If the tire pressure is not equal in both tires,
the unit may pull to one side or the other.
Cable Guide
Lock Nut
Cable
High
Middle
Low
Skid
Shoe Hex Nuts
Carriage Bolts
Flat Washer
Cotter Pin
Ferrule
Shift Rod

7
SECTION 5: CONTROLS
Figure 10
SHIFT LEVER
(See Figures 10 and 11)
The shift lever is located in the center of
the handle panel. The shift lever may be
moved into one of eight positions. Run
engine with throttle in the fast position.
Use the shift lever to determine ground
speed.
Forward—one of six speeds. Position
number one (1) is the slowest. Position
number six (6) is the fastest.
Reverse—two reverse (R) speeds. “R”
closest to the operator (all the way back)
is the faster of the two. Figure 11
AUGER CONTROL (See Figure 10)
The auger control clutch is located on the left
handle. Squeeze the clutch grip to engage the
augers. Release to stop the snow throwing action.
(Traction control clutch must also be released.)
TRACTION CONTROL/AUGER CLUTCH
LOCK
(See Figure 10)
The traction control clutch is located on the right
handle. Squeeze the traction control clutch to
engage the wheel drive. Release to stop.
This same lever also locks the auger clutch so you
can turn the chute directional control without
interrupting the snow throwing process. If the auger
control clutch is engaged with the traction control
clutch engaged, the operator can release the auger
control clutch (on the left handle) and the augers will
remain engaged. Release the traction control clutch
to stop both the augers and wheel drive (auger
control clutch must also be released).
TRIGGER LEVERS (See Figure 10)
The trigger levers are located on the underside of
the handles and are used to help you steer your
snow thrower. To turn right, squeeze the right trigger
lever and guide the snow thrower to the right. To
turn left, squeeze the left trigger lever and guide the
snow thrower to the left. These controls should be
used while operating your snow thrower in open
areas until you become familiar with their operation.
Lift both triggers for easy transport when the engine
is not running.
CHUTE DIRECTIONAL CONTROL
(See Figure 10)
The chute directional control is located on left hand
side of the snow thrower.
To change the direction in which snow is thrown,
turn chute directional control as follows:
1. Crank clockwise to discharge to the left.
2. Crank counterclockwise to discharge to the right.
CHUTE TILT CONTROL (See Figure 10)
The distance snow is thrown can be adjusted by
adjusting the angle of the chute assembly. Move the
chute tilt control forward to decrease the distance,
toward the rear to increase.
HEADLIGHT (See Figure 10)
The headlight is on whenever the engine is running.
THROTTLE CONTROL (See Figure 12)
The throttle control is located on the engine. It
regulates the speed of the engine.
SAFETY IGNITION SWITCH (See Figure 12)
The ignition key must be inserted in the switch
before the unit will start. Remove the ignition key
when snow thrower is not in use.
FUEL SHUT-OFF VALVE
The fuel shut-off valve, located
under fuel tank, controls fuel
flow from tank.
Figure 12
Auger
Drive
Clutch
Chute
Tilt
Control
Shift
Lever
Chute
Directional
Left
Trigger
Lever
Right
Trigger
Lever
Headlight
Shift
Lever
Traction Control/
Auger Clutch
Lock
Control
Open
Closed
Muffler
Guard
Primer
Choke
Carburetor
Cover
Ignition
Key Control
Lever
Oil Drain
Plug
Starter
Handle
Fuel
Tank
Fuel Fill
Cap
Oil Fill Plug
Muffler
Electric
Starter
Button
(If Equipped)

8
SECTION 6: OPERATION
NOTE: This unit has been shipped with oil in the
engine. Check oil before starting engine.
GAS AND OIL FILL-UP
Check oil level and add oil if necessary. Service the
engine with gasoline as instructed in the separate
engine manual packed with your snow thrower.
Read instructions carefully.
WARNING: Never fill fuel tank indoors,
with the engine running or while engine is
hot. Do not smoke when filling fuel tank.
TO START ENGINE
IMPORTANT: If unit shows any sign of motion
(drive or augers) with the clutch grips disengaged,
shut off engine immediately. Readjust as instructed
in the FINAL ADJUSTMENTS on page 6.
Electric Starter
WARNING: The electric starter is
equipped with a three-wire power cord and
plug, and is designed to operate on 120
volt AC household current. It must be
properly grounded at all times to avoid the possibility
of electric shock which may be injurious to the
operator. Follow all instructions carefully. Determine
that your house wiring is a three wire grounded
system. Ask a licensed electrician if you are not
certain. If your house wiring system is not a three-
wire grounded system, do not use this electric starter
under any conditions. If your system is grounded
and a three hole receptacle is not available at the
point your starter will normally be used, one should
be installed by a licensed electrician.
When connecting the power cord, always connect
cord to starter on engine first, then plug the other
end into a three-hole grounded receptacle.
When disconnecting the power cord, always unplug
the end from the three-hole grounded receptacle
first.
1. Attach spark plug wire to spark plug. Make
certain the metal loop on the end of the spark
plug wire (inside the boot) is fastened securely
over the metal tip on the spark plug. See Figure
13.
2. Make certain the auger and traction control
clutch levers are in the disengaged (released)
position.
3. Move throttle control up to FAST position. Insert
ignition key into slot. Refer to Figure 12. Be
certain it snaps into place. Do not turn key.
4. Rotate choke knob to OFF position.
Figure 13
Figure 14
5. Connect power cord to switch box on engine.
Plug the other end of power cord into a three-
hole, grounded 120 volt AC receptacle.
6. Push starter button to crank engine. Refer to
Figure 12. As you crank the engine, move choke
knob to FULL choke position.
7. When engine starts, release starter button, and
move choke gradually to OFF. If engine falters,
move choke immediately to FULL and then
gradually to OFF.
Recoil Starter
1. From the starting instructions for an Electric
starter, follow step 1 through step 3.
2. Rotate choke knob to FULL choke position (cold
engine start).
If engine is warm, place choke in OFF position
instead of FULL.
3. Push primer button two or three times. Refer to
Figure 12.
If engine is warm, push primer button once only.
NOTE: Always cover vent hole in primer button
when pushing. Additional priming may be necessary
for first start if temperature is below 15°F.
4. Grasp starter handle (refer to Figure 12) and pull
rope out slowly, until it pulls slightly harder. Let
rope rewind slowly.
5. Pull starter handle rapidly. Do not allow handle
to snap back. Allow it to rewind slowly while
keeping a firm hold on the starter handle.
6. Repeat step 4 and step 5 until engine starts.
7. As engine warms up and begins to operate
evenly, rotate choke knob slowly to OFF
position. If engine falters, return to FULL choke,
then slowly move to OFF position.
Rubber Boot
Metal Loop
on Spark
Plug Wire
ENGINE WILL NOT START
UNLESS IGNITION KEY IS
INSERTED INTO IGNITION
SLOT IN CARBURETOR
COVER. DO NOT TURN
IGNITION KEY.

9
TO STOP ENGINE
1. Run engine for a few minutes before stopping to
help dry off any moisture on the engine.
2. To help prevent possible freeze-up of starter,
proceed as follows:
Optional Electric Starter Connect power cord
to switch box on engine, then to 120 volt AC
receptacle. With the engine running, push starter
button and spin the starter for several seconds.
The unusual sound made by spinning the starter
will not harm engine or starter. Disconnect the
power cord from receptacle first, and then from
switch box.
Recoil Starter With engine running, pull starter
rope with a rapid, continuous full arm stroke
three or four times. Pulling the starter rope will
produce a loud clattering sound, which is not
harmful to the engine or starter.
3. To stop engine, remove the ignition key. Do not
turn key. Disconnect the spark plug wire from
the spark plug to prevent accidental starting
while equipment is unattended.
NOTE: Do not lose ignition key. Keep it in a safe
place. Engine will not start without the ignition key.
4. Wipe all snow and moisture from the carburetor
cover in the area of the control levers. Also,
move control levers back and forth several
times.
TO ENGAGE DRIVE
1. With the engine running near top speed, move
shift lever into one of the six FORWARD
positions or two REVERSE positions. Select a
speed appropriate for the snow conditions that
exist. Use the slower speeds until you are
familiar with the operation of the snow thrower.
2. Squeeze the left hand auger clutch grip and
engage it.
3. While the left hand auger clutch grip is engaged,
engage the right hand traction control clutch
grip.
4. Release the left hand auger clutch grip only. The
interlock mechanism should keep the left hand
clutch engaged until the right hand clutch is
released.
NOTE: NEVER move shift lever without first
releasing the traction control clutch.
TIRE PRESSURE
Pneumatic tires only Tires are over-inflated for
shipping purposes. Correct tire pressure is 10-15
psi. (Check sidewall of tire for manufacturer’s
recommendation.)
TIRE CHAINS
Tire chains should be used whenever extra traction
is needed.
OPERATING TIPS
NOTE: Allow the engine to warm up for a few
minutes as the engine will not develop full power
until it reaches operating temperature.
WARNING: Temperature of muffler and
surrounding areas may exceed 150°F.
Avoid these areas.
1. For most efficient snow removal, remove snow
immediately after it falls.
2. Discharge snow downwind whenever possible.
The distance snow is thrown can be adjusted by
adjusting the angle of the chute assembly. The
sharper the angle, the shorter the distance snow
is thrown. Slightly overlap each previous swath.
3. Set the skid shoes 1/4”below the shave plate for
normal usage. The skid shoes may be adjusted
upward for hard-packed snow. Adjust downward
when using on gravel or crushed rock.
4. Be certain to follow the precautions listed under
previous section, “To Stop Engine”to prevent
possible freeze up.
5. Clean the snow thrower thoroughly after each
use.
SECTION 7: ADJUSTMENTS
WARNING: NEVER attempt to clean
chute or make any adjustments while
engine is running.
REMOTE CHUTE ASSEMBLY ADJUSTMENT
The remote chute control cables have been pre-
adjusted at the factory. Move the remote chute lever
on the control panel back and forward to adjust
angle of the chute assembly.
CHECK ADJUSTMENT OF CLUTCH CABLES
Proper adjustment is achieved by sliding the spring
up the cable and threading the nut in or out. Correct
adjustment on cables is minimal slack but not tight.
AUGER BELT TENSION ADJUSTMENT
Periodic adjustment of the belt tension may be
required due to normal stretch and wear on the belt.
Increase belt tension if the augers hesitate while the
augers are engaged or decrease tension if the
augers continue to turn when the augers are
disengaged. Refer to Proper Adjustment on page 12.

10
SHIFT ROD ADJUSTMENT
To adjust the shift rod, remove the cotter pin which
secures the shift rod to the shift lever. For proper
adjustment, refer to FINAL ADJUSTMENTS on page
6.
SKID SHOE ADJUSTMENT
The space between the shave plate and the ground
can be adjusted. Refer to Skid Shoe Adjustment
(See Figure 8) on page 6.
CARBURETOR ADJUSTMENT
WARNING: If any adjustments are
made to the engine while the engine is
running (e.g. carburetor), keep clear of
all moving parts. Be careful of heated
surfaces and mufflers.
Minor carburetor adjustment may be required to
compensate for differences in fuel, temperature,
altitude and load.
Refer to the separate engine manual packed with
your unit for carburetor adjustment information.
NOTE: Failure to comply with suggested
maintenance and lubrication specifications on pages
10 and 11 will void warranty.
SECTION 8: LUBRICATION
WHEELS
Oil or spray lubricant into bearings at wheels at least
once a season. Remove wheels, clean and coat
axles with a multi-purpose automotive grease. See
Figure 15.
CHAINS AND SHIFTING MECHANISM
Remove lower cover. Oil all chains, sprockets,
bearings, the hexagonal shaft, round shaft, and
shifting mechanism at least once a season. Use
engine oil or a spray lubricant. Avoid getting oil on
rubber friction wheel and aluminum drive plate.
CHUTE DIRECTIONAL CONTROL WORM
The worm gear on the chute directional crank should
be greased with multi-purpose automotive grease.
IMPELLER PULLEY
The impeller pulley should be lubricated once a
season. Refer to exploded view of parts, found in the
back of the book, for correct location.
AUGER SHAFT
Remove auger bolts on auger shaft, see Figure 16.
Oil or spray lubricant inside shaft.
ENGINE
Refer to engine manual for engine lubrication
instructions.
HEX SHAFT
Lubricate the hex shaft with a good all-weather multi-
purpose light grease at least once a season or after
every 25 hours of operation (available from an
authorized service dealer or an automotive store.)
See Figure 15.
If for any reason your transmission was
disassembled and the auger cable disconnected,
make sure when reassembling to pass the cable
above the hex shaft before reconnecting to the
auger actuator bracket.
WARNING: When following instruc-
tions in separate engine manual for
draining oil, be sure to protect frame to
avoid oil dripping onto transmission
parts.
Figure 15 Viewed from the underside of snow
thrower
Auger
Actuator
Shift Arm
Assembly Drive
Actuator
Hex
Shaft
Friction
Wheel
Hex Nut
and
Cupped
Washers
Bracket Bracket
Trigger
Cables

11
SECTION 9: MAINTENANCE
WARNING: Disconnect the spark plug
wire and ground against the engine
before performing any repairs or
maintenance.
AUGERS
The augers are secured to the spiral shaft with two
shear bolts and hex lock nuts. See Figure 16. If you
hit a foreign object or ice jam, the snow thrower is
designed so that the shear bolts will shear.
If the augers will not turn, check to see if the hex
bolts have sheared. Two replacement shear bolts
and hex lock nuts have been provided with the snow
thrower. When replacing bolts, spray an oil lubricant
into shaft before inserting new bolts.
Figure 16
SHAVE PLATE AND SKID SHOES
The shave plate and skid shoes on the bottom of the
snow thrower are subject to wear. They should be
checked periodically and replaced when necessary.
NOTE: All models are equipped with reversible
skid shoes.
To remove skid shoes, remove the carriage bolts,
Belleville washers and hex nuts which attach them to
the snow thrower. Reassemble new skid shoes with
the carriage bolts, Belleville washers (cupped side
goes against skid shoes) and hex nuts.
To remove shave plate, remove the carriage bolts,
Belleville washers and hex nuts which attach it to the
snow thrower housing. Reassemble new shave
plate, making sure heads of the carriage bolts are to
the inside of the housing. Tighten securely.
BELT REMOVAL AND REPLACEMENT
WARNING: Remove the spark plug
wire from the spark plug and ground.
Drain gasoline from the fuel tank, or
place a piece of plastic film underneath
the gas cap to prevent gasoline from
leaking.
Auger Belt
To remove and replace either the auger belt or the
drive belt, proceed with the following instructions:
1. Disconnect chute directional control assembly at
the discharge chute by removing the cotter pin
and flat washer.
2. Remove the plastic belt cover on the front of the
engine by removing three self-tapping screws
and flat washers. See Figure 17.
Figure 17
3. Remove the large shoulder bolt and washer on
the left hand side of the engine pulley with an
adjustable wrench. Refer to Figure 18.
NOTE: Reference to right hand or left hand side of
machine are observed from the operating position.
4. Remove the cotter pin and washer from the
ferrule in order to disconnect the auger idler rod
from the brake bracket assembly as shown in
Figure 19.
5. Slip the auger control belt (the front belt) off the
engine pulley. Refer to Figure 19.
6. Pull the brake bracket assembly towards the
cable guide roller and unhook the auger cable
“Z”fitting.
7. Remove the top screws and lock washers which
attach the auger housing assembly to the frame
assembly. A 9/16”wrench is required. Refer to
Figure 20.
Auger Shaft
Auger Shear Bolts
Hex Lock Nuts
Shave Plate
Belt
Cover
Self-Tapping
Screw
Flat Washer

12
Figure 18
Figure 19
Figure 20
8. Separate the auger housing from the frame
assembly by tilting the housing forward and
pulling up the handles.
9. Using a 1/2”wrench remove the hex screw and
belleville washer from the centre of the pulley on
the auger housing. Lift the brake bracket
assembly out of the pulley groove and remove
the pulley. See Figure 21. Be careful not to lose
the key.
10. Remove and replace auger belt inside belt
keepers.
11. Reassemble pulley to auger housing with hex
screw and belleville washer (cupped is toward
the pulley). Be certain key is in place on shaft
and brake puck is seated in the pulley groove.
Figure 21
Proper Adjustment With the auger clutch lever in
the disengaged position the top surface of the new
belt should be even with the outside diameter of the
pulley. To adjust, disconnect ferrule from the brake
bracket assembly and thread ferrule in (towards
idler) to increase tension on belt, out to decrease
tension.
NOTE: The brake puck must always be firmly
seated in the pulley groove when the auger clutch
lever is in the disengaged position.
Drive Belt
1. Unhook extension spring from the belt cover
plate. See Figure 18.
2. Remove drive belt from the engine pulley and
bottom drive pulley.
3. Replace belt and reassemble in reverse order.
4. Reassemble the two halves of the unit hooking
the lower portion of the auger housing over the
stationary shoulder bolts in the frame assembly.
5. Secure the two halves with the two screws and
lock washers
6. Attach the “Z”fitting of the cable into the brake
bracket assembly. See Figure 19.
7. Slip the auger control belt over engine pulley.
8. Insert ferrule on auger idler rod into bracket
assembly and secure with flat washer and cotter
pin.
9. Reassemble the large shoulder bolt and lock
washer as shown in Figure 18.
10. Reassemble belt cover and chute directional
control.
11. Remove plastic film from gas cap.
Engine
Pulley
Large
Shoulder
Bolt Extension
Spring
Auger
Idler
Rod
Ferrule
Brake
Bracket
Assembly
“Z”
Fitting
Cable
Roller
Guide
Remove
Screw
Lock Washer
Auger
Housing
Frame Assembly
Brake
Bracket
A
ssembly Auger Control
Belt
Pulley
Hex Screw
Belleville Washer
Belt
Keepers

13
Changing the Friction Wheel
The rubber on the friction wheel is subject to wear
and should be checked after 25 hours of operation,
and periodically thereafter. Replace the friction
wheel rubber if signs of excessive wear or cracking
are found.
1. Drain the gasoline from the snow thrower, or
place a piece of plastic under the gas cap.
2. Tip the snow thrower up and forward, so that it
rests on the housing.
3. Remove six self-tapping screws from the frame
cover underneath the snow thrower.
4. Remove the wheels from the axle.
5. Using a 7/8”wrench hold the hex shaft and
remove the hex bolts and cupped washer and
bearing from left side of the frame. See Figure
15. Hold the friction wheel assembly, and slide
the hex shaft out of the unit toward the right
hand side.
6. Remove the six screws from the friction wheel
assembly (three from each side).
7. Reassemble new bonded friction wheel rubber
to the friction wheel assembly, tighten the six
screws in rotation and with equal force. See
Figure 22.
Figure 22
Figure 23
8. Position the friction wheel assembly up onto the
pin of the shift rod assembly and slide the shaft
through the friction wheel. See Figure 23.
9. Slide the hex shaft into the hex I.D. of the
sprocket, the spacer and the left ball bearing and
secure with the bell washer and hex bolt.
NOTE: Make sure the pin from the shift arm
assembly is assembled to the new friction wheel
assembly.
CAUTION: Check engine and snow
thrower frequently for loose nuts, bolts, etc.
and keep these items tightened.
SECTION 10: OFF-SEASON STORAGE
WARNING: Never store engine with fuel
in tank indoors or in poorly ventilated areas
where fuel fumes may reach an open
flame, spark or pilot light as on a furnace,
water heater, clothes dryer or other gas
appliance.
1. If unit is to be stored over 30 days, prepare
engine for storage as instructed in the separate
engine manual included with your unit.
2. Remove all dirt from exterior of engine and
equipment.
3. Follow lubrication recommendations on page 10.
4. Store in a clean, dry area.
NOTE: When storing any type of power equipment
in an unventilated or metal storage shed, care
should be taken to rust proof the equipment. Using a
light oil or silicone, coat the equipment, especially
any chains, springs, bearings and cables.
Bonded Friction
Wheel Rubber
Hex Self-tapping
Screws
Spacer
Sprocket
Support
Pin
Bracket
Shaft
Shift Rod
Friction Wheel
Assembly
Assembly

14
SECTION 11: TROUBLE SHOOTING GUIDE
Note: For repairs beyond the minor adjustments above, contact your local authorized service dealer.
Trouble Possible Cause(s) Corrective Action
Engine fails to start Fuel tank empty, or stale fuel.
Blocked fuel line.
Choke not in ON position
Faulty spark plug.
Key not in switch on engine.
Spark plug wire
disconnected.
Primer button not depressed.
Fuel shut-off valve closed
Fill tank with clean, fresh gasoline. Fuel will not last over thirty
days unless a fuel stabilizer is used.
Clean fuel line.
Move switch to ON position
Clean, adjust gap or replace.
Insert key.
Connect spark plug wire.
Refer to the engine manual packed with your unit.
Open fuel shut-off valve.
Engine runs erratic Unit running on CHOKE.
Blocked fuel line or stale fuel.
Water or dirt in fuel system.
Carburetor out of adjustment.
Move choke lever to OFF position.
Clean fuel line; fill tank with clean fresh gasoline. Fuel will not last
over thirty days unless a fuel stabilizer is used.
Drain fuel tank. Refill with fresh fuel.
Refer to the engine manual packed with your unit or have
carburetor adjusted by an authorized service dealer.
Loss of power Spark plug wire loose.
Gas cap vent hole plugged.
Exhaust port plugged.
Connect and tighten spark plug wire.
Remove ice and snow from cap. Be certain vent hole is clear.
Clean-see Maintenance section of engine manual.
Engine overheats Carburetor not adjusted
properly. Refer to the engine manual packed with your unit or have carburetor adjusted by an authorized service dealer.
Excessive vibration Loose parts or damaged
auger. Stop engine immediately and disconnect spark plug wire. Tighten all bolts and nuts. Make all necessary repairs. If vibration
continues, have unit serviced by an authorized service dealer.
Unit fails to propel
itself Incorrect adjustment of drive cable.
Drive belt loose or damaged.
Adjust drive cable. Refer to Adjustment section of this manual.
Replace drive belt. Refer to Belt Replacement in Maintenance
section of this manual.
Unit fails to
discharge snow Discharge chute clogged.
Foreign object lodged in
auger.
Incorrect adjustment of drive
cable.
Drive belt loose or damaged.
Stop engine immediately and disconnect spark plug wire. Clean
discharge chute and inside of auger housing.
Stop engine immediately and disconnect spark plug wire.
Remove object from auger.
Adjust drive cable. Refer to Adjustment section of this manual.
Replace drive belt. Refer to Belt Replacement in Maintenance
section of this manual.

15
SECTION 12: Illustrated Parts
Model 1333SWE
Ref.
No. Part No. Description Qty.
1 731-1364 Halogen Lamp Housing 1
2 710-1240 Phillips Pan Head Screw M 4 x 16 2
3 712-0271 Hex Sems Nut 1/4-20 1
4 725-1669 Lamp/Lens Housing Ass’y1
629-0059 Halogen Light Wire Harness 1
725-1658 #890 Halogen Bulb 1
6 710-0451 Carriage Bolt 5/16-18 x .75 1
7 710-1003 Pan Head B-Tapp Screw #10 2
8 736-0159 Fl-Wash .344 ID x .88 OD 1
9 712-0429 Hex Ins L-Nut 5/16-18 1
10 731-0061 Handle Panel 1
11 735-0225 Grommet .38 ID x .50 OD x 12 1
12 705-5217 Lamp Mounting Bracket 1

16
Model 1333SWE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
34
35
36
37
39
39
40
41
42
43
44
45
44
47
48
49
50
51
52
53
54
55 56
57
58
59
60
61
64
66
67
70
72
73
74
43
39
48
49
41
48
1
68
75 75
8
8
712
13
11
68
65
71
81
79 80
68
68 71
84
85
85
84
86
63
69
62
62
69
63
76
77
78
83
82
83
27
27
72
37
64
66
82
27
27
7
12
12
75

17
Model 1333SWE
Ref.
No. Part No. Description Qty.
1 720-0232 Sml Shift Knob 2
2 705-5218 Engage Handle RH 1
3 705-5219 Engage Handl LH 1
4 710-0351 Pan Head B-tapp Scr #10 x .5 2
5 710-0599 Hwhd Sf-tap Scr 1/4-20 x 1/2 Lg. 4
6 711-0653 Clevis Pin .31 Dia x 1.0 1
7 712-3010 Nut Hex 5/16-18 Gd 5 6
8 714-0507 Cot-pin 3/32 Dia x 1.0 3
9 732-0145 Comp Spring .36 Dia x 1.0 Lg 1
10 732-0746 Spring Torsion .44 ID 1
11 735-0199A Rubber Bumper .63 Dia 2
12 736-0119 Lock Washer 5/16 6
13 736-0509 Wsher Spcl. .345 Sq. x .72 OD 2
14 747-0877 Cam Rod 2
15 748-0362 Clutch Lock Cam 2
16 748-0363 Clutch Lock Pawl 1
17 784-5679 Supt Brkt 5/8 Lh 1
18 784-5680 Supt Brkt 5/8 Rh 1
19 784-5681 Supt Brkt 3/8 Lh 1
20 784-5682 Supt Brkt 3/8 Rh 1
21 684-0102 Pnl Asm Hndl W/tilt 1
22 710-0459A Scr Hex Cap 3/8-24 x 1.5 Gd 5 1
23 712-0116 Hex Ins L-nut 3/8-24 1
24 732-0193 Compression Spring .39 ID x .88 1
25 736-0105 Bell Wash .40 ID x .88 OD x .06 1
26 784-5619A Shift Handle 1
27 710-0458 Carriage Bolt 5/16-18 x 1.75 6
34 710-0276 Carriage Bolt 5/16-18 x 1.00 1
35 710-0458 Carriage Bolt 5/16-18 x 1.75 1
36 710-0805 Hex Scr 5/16-18 x 1.5 1
37 710-0896 HWHD B Tapp Scr 1/4 x 5/8 Zn 2
39 712-0429 Hex Ins L-nut 5/16-18 3
40 731-0846C 6”Upper Chute Remote Tilt 1
41 731-1313C Chute Tilt Cable Guide 2
42 731-0903D 6”Lower Chute Remote Tilt 1
43 731-1319 Chute Pivot Spacer 2
44 736-0159 Fl-wash .344 ID x .88 OD x .063 2
45 736-0231 Flt Wshr .344 x 1.125 x .125 1
47 736-0506 Contoured Washer 1
48 746-0902 Chute Control Cable 66”1
49 746-0903 Chute Control Cable 66”W/clip 1
50 784-5594 Cable Bracket Chute Tilt 1
51 784-5604 Chute Tilt Handle 1
52 684-0053A Lower Chute Directional Control 1
53 710-3015 Hex Scr 1/4-20 x .75 Lg Gd5 1
54 712-0287 Hex Nut 1/4-20 1
55 720-0201A Chute Directional Control Knob 1
56 726-0100 Push Cap 3/8 Palnut #375011 1
57 736-0117 Flat Washer .38 ID x .60 OD x .033 1
58 736-0270 Bell Wash .26 ID x .75 OD x .06T 1
59 747-0624 Upper Chute Directional Control 1
60 705-5266 Brkt Chute Directional Control 1
61 741-0475 Plastic Bushing .380 ID 4
62 710-0216 Hex Scr 3/8-16 x .75 2
63 710-0347 Hex Scr 3/8-16 x 1.75 2
64 710-1625 Scr Oval C/sunk #10-24 x 1.75 2
65 711-0677 Adjustment Ferrule 1
66 712-0127 #10-24 Flat Weld Nut 2
67 714-0101 Internal Cot-pin 1/2 Dia 1
68 714-0104 Inter Cot-pin 5/16 Dia 4
69 736-0105 Bell Wash .4 ID x .88 OD x .06 4
70 736-0185 Fl-wash .406 ID x .74 OD x .063 2
71 736-0275 Fl-wash Sae .34 x .68 x .062 2
72 746-0950 Trigger Ass’y Steer 2
73 712-0324 Hex Ins L-nut 1/4-20 2
74 732-0184 Extension Spring 2
75 746-0952 Cable Clutch Drive 2
76 646-0012 Handle Lower 2
77 749-0990A Handle Upper Rh 1
78 749-0989A Handle Upper Lh 1
79 747-0997 Upper Shift Rod 5/16 x 10.57 1
80 750-0963 2 Pc Shift Rod Connector 1
81 747-0983 Lower Shift Rod 3/8 x 14.75 1
82 712-0287 Hex Nut 1/4 - 20 2
83 736-0270 Bell Wash .26 ID x .75 OD x .06T 2
84 720-0284 Wingnut 4
85 736-0242 Bell Wash .345 ID x .88 OD x .060 4
86 710-0572 Carriage Bolt 5/16 -18 x 2.5 4
Ref.
No. Part No. Description Qty.
NOTE: For painted parts, please refer to
the list of color codes below. Please add the
applicable color code, wherever needed, to
the part number to order a replacement part.
For instance, if a part, numbered 700-xxxx,
is painted Cub Yellow, the part number to
order would be 700-xxxx-0498.
Cub Yellow: 0498
Cub Beige: 0499
Powder Black: 0637

18
Model 1333SWE
8

19
Model 1333SWE
Ref.
No. Part No. Description Qty.
1 736-0159 Flat Washer .344 ID x .875 OD 7
2 710-3015 Truss. Hd. Mach. Scr. 1/4-20 x .75 6
4 736-0105 Belleville washer 6
6 731-0903D 6”Lower Chute Remote Tilt 1
8 784-5711 Chute Bracket 1
15 784-5123 Chute Bracket 1
16 731-1696 Chute Adapter 1
17 736-0242 Bell. Washer .345 ID x .88 OD x .06 15
19 712-3027 Hex Cent. L-Nut 1/4-20 w/ Flange 6
20 731-0851A Chute Flange Keeper 3
23 710-0601 Hex Wash HD Self-Tap Scr 5/16-18 x
.75 9
26 710-0371 Hex Screw 5/16-18 x .75 1
28 756-0243 1/2”V-Pulley .875 ID x 10.12 OD 1
29 714-0126 #9 Hi-Pro Key 3/16 x 3/4 Dia HT 1
30 741-0185 Self-Aligning Bearing .875 ID 1
31 712-3010 Hex Nut 5/16-18 GD. 5 12
32 736-0119 L-Wash 5/16 ID 7
33 05244A Bearing Housing 2
34 711-0640 Belt Keeper Studs 3/8-16 x 2.75 5
38 710-0451 Carriage Bolt 5/16-18 x .75 16
45 684-0093A 33”Snowthrower Hsg. Ass’y 1
46 784-5714 Shave Plate 33”1
52 710-3168 Carriage Bolt 3/8-16 x 1.00 Gr. 5 2
53 710-0389 Carriage Bolt 3/8-16 x .75”Lg. 4
54 784-5710 Gear Housing Support Plate 1 x 3/16 1
56 712-0798 Hex Jam Nut 3/8-16 6
58 715-0118 Spring Spiral Pin Heavy 5/16 dia x
1.7 2
59 684-0090 Blower Fan Ass’y Complete 1
60 784-5076 Gear housing Support Bracket 1 x
3/16 1
61 721-0325 Barbed Plug 1
63 738-0491 Spiral Axle -33”1
64 721-0146 Oil Seal 1.50 ID Garlock (76 x 6223) 2
65 719-0348 Gear Housing Half - RH 1
67 714-0126 #9 Hi-Pro Key 3/16 x 3/4 dia HT 1
68 711-1133 Auger Control Shaft 1
69 716-0111 Snap Ring for .875 dia. shaft 1
70 721-0145 Oil Seal for .875 ID (76 x 6133) 1
71 741-0217 Sleeve Bearing .875 ID 2
72 741-0184 Thrust Bearing .88 ID x 1.44 OD x
.078 1
73 736-0291 Flat Washer .88 ID x 1.4 OD x .125 3
74 717-0299 Worm Gear LH Double Thread 1
75 741-0670 Flange Brg. 1.5 ID x 1.75 OD x .80 2
76 736-0266 Flat Washer 1.5 ID x 2.0 OD x .03 2
77 717-1425 Worm Gear LH Double Thread
(Bronze) 1
78 738-0275 Worm Gear Shaft 1
79 714-0135 #91 Woodruff Key 1/4 x 3/4 dia 1
80 719-0349 Gear Housing Half LH 1
81 710-1260A Hex Flange Scr. 5/16-18 x .75 7
82 712-0429 Hex Ins. L-Nut 5/16-18 12
83 714-0135 #91 Woodruff Key 1/4 x 3/4 dia 1
84 736-0250 Flat Washer 4
85 741-0494 Flange Bearing 4
87 710-0891 Shear Bolt 5/16-18 x 1.75 2
90 05845B Housing bearing 1.5 Dbl D 2
91 741-0192 Flange Bearing w/flats 2
94 754-0222 V-Belt 1/2 x 44 LG 1
96 618-0257 Worm Gear Box Ass’y1
98 784-5697 Reversible Skid Shoe 2
100 705-5210A RH Spiral Ass’y Serrated - 33”1
705-5211A LH Spiral Ass’y Serrated - 33”1
101 710-0528 Hex Scr 5/16-18 x 1.25 1
102 736-0271 5/16 Sprg Wash 1
103 736-0169 3/8 Sprg Lock Wash 5
104 618-0281 Brkt Ass’y Brkt 1
105 710-0459A Scr Hex Cap 3/8-24 x 1.5 GRD 5 1
106 711-0677 Adjustment Ferrule 1
107 712-0116 Hex Ins L-Nut 3/8-24 1
108 714-0104 Intern Cot-Pin 5/16 dia 1
109 732-0858 Spr Extn .470 dia x 4.75 Lg 1
110 736-0174 Wave Washer .66 ID x .88 OD 2
111 736-3008 Fl-Wash SAE .34 x .68 1
112 738-0281 Shld Scr .625 dia x .170 x .062 2
113 747-0980 Rod Idler Auger 1
114 756-0240 3.0 OD Flat Idler with Flanges 1
115 784-0385 Brkt Idlr Auger 1
116 741-0475 Plastic Bushing .380 ID 1
Ref.
No. Part No. Description Qty.
NOTE: For painted parts, please refer to
the list of color codes below. Please add the
applicable color code, wherever needed, to
the part number to order a replacement part.
For instance, if a part, numbered 700-xxxx,
is painted Cub Yellow, the part number to
order would be 700-xxxx-0498.
Cub Yellow: 0498
Cub Beige: 0499
Powder Black: 0637

20
Model 1333SWE
6
13
25
5
4
11
18
3
12
16
12
14
20
9
3
6
14 10
713
21
1
17
8
19 22
24
23
