Cub Cadet CC 2000 User manual

Item Part No. Description
41 791-181079 Pull Handle
42 791-182118 Pulley Assembly (includes 43-45)
43 791-181745 Ratchet
44 791-181746 Spring
45 791-181747 Retaining Ring
46 791-181716 Screw
47 791-181748 Throttle Bracket
48 753-04389 Carburetor (includes Primer Bulb)
49 791-181750 Screw
50 791-181751 O-Ring
51 791-181752 Air Cleaner Assembly
(includes 52-56)
52 791-181753 Sleeve
53 791-181754 Choke Plate
54 791-181755 Choke Lever
55 791-181756 Screw
56 791-181757 Air Filter
57 791-181752 Air Cleaner Cover (includes 56)
58 753-1178 Clutch Housing Assembly
59 791-181760 Bolt
60 791-181761 Nut
61 791-181762 Screw
62 753-04390 Engine Cover
63 791-181716 Screw
64 791-181762 Screw
65 791-181765 Spark Plug
66 791-182519 Screw
67 791-181766 Fuel Tank (includes 68-69)
68 791-182612 Fuel Cap Assembly
69 791-181767 Fuel Line Assembly
70 791-181768 Screw
71 791-181769 Lead Wire Assemby
72 753-04020 Pin
73 753-04021 Needle Bearing
74 753-04022 Piston Washer
*791-181696 Spark Arrestor
*791-181701 Primer Bulb
*753-04014 Carburetor Repair Kit
*753-1248 Gasket/Diaphragm Repair Kit
*not shown
46
38 39 36
37
35
34
67
70
69
18
19
16
15
14
43
42
14
25
20
30
29
28
27
49
53
56
51
48
6
57
49
54
55 52
50
7
12
13
71
10
9
8
11
1
5
47
63
62
33
31
65
58
64
66
59
61
60
32
26
4
74
17
16
74
22
2
3
21
23
45
44
68
41
40
Item Part No. Description
1753-04015 Cylinder
2753-04016 Cylinder Base Gasket
3791-181706 Bolt
4791-181707 Insulator
5791-181708 Insulator Gasket
6791-181709 Carburetor Gasket
7791-181710 Screw and Washer
8753-1176 Muffler Assembly (includes 9 & 10)
9753-1177 Muffler
10 791-181713 Screw
11 791-181714 Muffler Gasket
12 791-181715 Muffler Plate
13 791-181716 Screw
14 791-181717 Crankcase Service Assembly
(includes 15-19 & 25)
15 753-04017 Crankcase Gasket
16 791-181719 Bearing
17 791-181720 Oil Seal
18 791-181721 Oil Seal
19 791-181722 Snap Ring
20 791-181723 Screw
21 753-04018 Piston
22 791-182014 Ring
23 791-182015 Piston Pin
24 791-181727 Snap Ring
25 753-04019 Crankshaft
26 791-181729 Key
27 791-181730 Clutch
28 791-181074 Clutch Washer
29 791-181731 Spacer
30 791-181732 Flywheel Assembly
31 791-181733 Module Assembly (includes 32 & 33)
32 791-181734 Spacer
33 753-1181 Screw
34 791-181777 Recoil Assembly (includes 35-41)
35 791-181737 Recoil Case
36 791-181738 Recoil Pulley
37 791-181739 Recoil Spring
38 791-181740 Screw
39 791-181741 Washer
40 791-181742 Rope
Issued 2/03
ENGINE PARTS - CC2000
2-CYCLE GAS TRIMMER
PPN 41CDC02G100
72
73
24 24

Issued 2/03
BOOM AND TRIMMER PARTS - CC2000
2-CYCLE GAS TRIMMER
PPN 41CDC02G100
5
2
1
5
6
7
9
13
12
43
8
15
14
18
17
16
23
21
24
20
22
Item Part No. Description
1791-180866 Grip
2791-181688 Throttle Cable Assembly
3791-180975 Throttle Trigger
4791-610314 Throttle Trigger Spring
5753-1150 Throttle Trigger Assembly (includes 3 & 4)
6791-180252 Switch Assembly
7791-181690 Wire Lead Assembly
8753-1151 Loop Handle Assembly
9753-1152 Screw
10 753-1153 Washer
11 753-1154 Nut
12 791-182838 Drive Shaft Housing Assembly
13 791-182839 Flexible Drive Shaft
14 791-153597 Lower Clamp Assembly
15 791-180531 Shield Mounting Screw
16 791-153312 Bushing Housing Assembly
17 791-145569 Anti-Rotation Screw
18 791-181659 Shield and Blade Assembly (includes 19)
19 791-181823 Blade Assembly
20 791-153619 Outer Spool w/ Retainer (includes 21)
21 791-610660 Retainer
22 791-610317 Spring
23 753-1155 Inner Reel
24 791-153066B Bumb Knob Assembly
Optional Accessories
*791-180120 Replacement Line, 0.095 Diameter
*153-1156 Reel and Line Assembly New
*153-1157 Bumb Head Assembly
*791-682075B Shoulder Harness
*Items Not Shown
19
10
11
