Cudy RE750 User manual

Quick Installation Guide
Hardware Overview
1. Launch a web browser and type http://192.168.10.254/ (or
http://ap.setup/) in the address field. Enter admin for password to
login.
2. Below picture will pop up automatically if it is your first time to
configure , or you should click Wizard to make it show up.
Configure
1. Switch the mode selector to Repeater position.
2. Plug the Device into an electrical outlet near your Wi-Fi router.
3. Shift the power switch to ON and wait until Wi-Fi LED is flashing.
Wired
Turn off the Wi-Fi on your computer and connect it to the LAN port of
Cudy Repeater via an Ethernet cable.
Wireless
1.Disconnect the Ethernet (Wired) connection if using a laptop or PC.
2.Connect your device to extender’s Wi-Fi
Cudy-RE750 or
Cudy-RE750-5G.
Power ON
Connect to the Device
Not connected
Connections are available
Wireless Network Connection
Cudy-RE750
Cudy-RE750-5G
Connect
Connect automatically
Method Two: Using Web browser
2
Login
admin
English
Wi-FI Range Extender
Repeater Wizard
Connect
Select a Wi-Fi Manually enter
Cudy-XXXX
Cudy-XXXX-5G
Cudy-Guest
Connect to:
Wi-Fi Password:
Extended 5G:
Extended 2.4G:
Repeater Mode: Bridge
Repeater Mode
1. Switch the mode selector to Repeater position.
2. Plug RE750 into an electrical outlet near your Wi-Fi router. Power on
and wait until the WLAN LED is flashing.
3. Press and hold RE750's WPS button for 1~2 seconds before release,
then press WPS button of your router.
4. Waiting for them to connect, it may take 2 minutes.
1Method One: Using WPS button
5. When successful, all of the 3 Wi-Fi LEDs of RE750 should turn on and
stay solid. And it will create 2 network names which contains the words
of your router's Wi-Fi name and "EXT2G"or "EXT5G" , the password is
the same as your router‘s Wi-Fi.
6. Then plug it to a suitable location(ensure at least 2 Wi-Fi LEDs solid
on), no need to configure again.
WPS
Press 1~2 seconds
WPS
Press 1~2 seconds
Video Installation Guide
https://youtu.be/S9bfh9g6Q9Y
[email protected]
Default Parameters
Web Setup: http://ap.setup/
Default IP: http://192.168.10.254/
Password: admin
SSID1:Cudy-RE750
SSID2:Cudy-RE750-5G
Technical Support
[email protected]
Power On/Off
Mode Selector
WPS Button
Wi-Fi LED
WAN/LAN LED
LAN LED
Power/WPS LED
LAN Port
WAN/LAN Port
Reset Button
1
2
3
4
5
6
7
8
9
10

The Device also supports Router/AP Mode which you could also choose
the mode that you prefer.
Router Mode and Access Point Mode
Router Mode
PPPoE
Enter the User Name and Password
provided by your ISP, these fields are
case-sensitive.
AP Mode The device gets the IP address automatically from
your Router or ISP DHCP server.
Enter the IP Address, Subnet Mask,
Default Gateway and DNS provided
by your ISP.
Static IP
The device gets the IP address
automatically from your Router or ISP
DHCP server.
Dynamic IP
Q2: What should I do if my handy can not find Wi-Fi signal?
A: Please make sure the device is connected, power on. If everything is
normal but still no signal, please try to use computer to set, or restore
the extender to factory settings. If after restoring factory settings but
still no signal, you can restart the extender, if it still doesn’t work,
maybe the device has fault.
Q1: What can I do if the login window does not appear?
A1: If your computer is wirelessly connected, make sure that you have
connected to the extender’s SSID.
A2: If your computer is connected via an Ethernet cable, please make
sure that the connection is stable.
A3: Make sure your computer is set to obtain an IP address and DNS
server address automatically.
A4: Verify that http://192.168.10.254/ (or http://ap.setup/) is correctly
entered in the web browser and press Enter.
A5: Reset the device and try again.
Q3: How to Reset to defaults?
A: While the power is still on, keep pressing the reset button for
2seconds, and wait for 1-2 minutes and it will restore to factory
settings.
Q4: What should I do if I forget the Wi-Fi password or the username
and password of the Login settings Page?
A: please reset the device to defaults.
Frequently Asked Questions (FAQ)
810600015
Q5: How to find a suitable placement to extend Wi-Fi?
A: Follow the Wi-Fi LED to help you find the best spot
to extend Wi-Fi.
Best BadGood
3. Select a Wi-Fi SSID of your router (Host Wi-Fi) and enter the password.
Either keep the same SSID as your host Wi-Fi or create a new name for the
extended network.
4. Verify your wireless settings and click Connect. The Wi-Fi LEDs
should turn on and stay solid,indicating successful connections.
Plug the Device halfway between your router(Host Wi-Fi) and the Wi-Fi
dead zone.Wait until the Wi-Fi LEDs are ON. If the signal is weak,
relocate it closer to the router to achieve better quality.
Note: By default, RE750 will create a network name which contains the
words of your router's WiFi name and "EXT2G" or "EXT5G", the
password is the same as your router‘s Wi-Fi.
Relocate
Repeater Wizard
Connect
Select a Wi-Fi Manually enter
Cudy-XXXX
Cudy-XXXX-5G
Cudy-Guest
Connect to: xxxxxxxx
Wi-Fi Password: xxxxxxxx
Extended 5G: xxxxxxxx-EXT5G
Extended 2.4G: xxxxxxxx-EXT2G
Repeater Mode: Bridge
Firmware Upgrade
Download the latest firmware file for the device from our website
www.cudytech.com.
Note:Never interrupt the upgrade procedure by closing the web
browser or physically disconnect your computer from the device.
Change Login Password
The default password of the device is admin, we strongly recommend
you change the default password of the device.
1.Visit http://192.168.10.254/ (or http://ap.setup/), and log in with the
default password admin.
2. Click Setup->Login Password.
3. Enter the old password.Then enter the new password and click Apply.
4. Use the new password for future login attempts.
