Introduction
Page
www.cuesinc.com
---
Page www.cuesinc.com ---
WiFi Range Extender
User Guide
This manual includes instructions for the CUES WiFi Range Extender.
Disclaimer:
This product contains a TP-Link product modied for use with CUES equipment. TP-Link is a registered Trade-
mark of TP-Link Corporation Limited.
Basic Functions
• Power ON/OFF - Press the large button at the top of the Range Extender to turn the unit on/o. The
switch will illuminate when powered on. The switch must be in o position for charging.
• Battery Gauge - Press the button on the bottom end (threaded end) of the Range Extender to check the
battery state in the battery % window on the side of the unit.
• Charge Port - Only use the CUES supplied charger for the Range Extender. The charger will illuminate
green when battery is charged and red when charging.
• Status Light - The status light illuminates the area beneath the top cap of the Range Extender. A solid
light means the Range Extender is connected to a specied QZ/SPiDER Network; a ashing light
means the Range Extender is not connected.
POWER SWITCH
CHARGING PORT
BATTERY GAUGE BUTTON
BATTERY GAUGE
2
Page
www.cuesinc.com
---
Page www.cuesinc.com ---
Operating Instructions
PAIRING THE RANGE EXTENDER TO A QZ3/SPIDER
Follow the instructions below to pair the Range Extender with a QZ3/SPiDER. The Range Extender can be
recongured to use with another QZ3/SPiDER by repeating this procedure. Note that the Range Extender
can only be congured to one device at a time. Once paired to a QZ3/SPiDER, the Range Extender will
automatically reconnect whenever the QZ3/SPiDER is in range and powered on.
1. Press the button on top side of Range Extender to power on.
2. Using a wireless enabled tablet/PC/mobile device, connect to the Range Extender WiFi network
using the SSID (network name) and pin labeled on the side of the unit.
3. Once connected to the Range Extender’s network, open a web browser page on your device and
navigate to: tplinkwi.net
If you encounter any errors in reaching this site, you may use either of the following:
• http://192.168.0.1
• http://192.168.1.1
4. Use default username and password: admin (for both—case sensitive) to login to the Range Extender.
2
Page
www.cuesinc.com
---
Page www.cuesinc.com ---
Operating Instructions
5. Press NEXT on the Quick Setup.
6. At the next screen, you may change your login username and password; however we do not
recommend this as CUES will not be able to recover this information for you without a factory
reset of the Range Extender. Press NEXT to proceed.
2
Page
www.cuesinc.com
---
Page www.cuesinc.com ---
Operating Instructions
PAIRING THE RANGE EXTENDER TO A QZ3/SPIDER CONTINUED
7. Select Range Extender at the following screen and press Next.
8. Power on your QZ3 or SPiDER within range of the repeater and wait for it to broadcast its net
work (approximately 30 sec). Press Refresh on the screen as shown to reveal the QZ3/SPiDER
network in the list and press the connect link to the right of the network name.
2
Page
www.cuesinc.com
---
Page www.cuesinc.com ---
Operating Instructions
9. At the next screen, enter the password for the QZ3/SPiDER in the password eld and select
customize for the wireless name. The default “customized” name is recommended. Press
NEXT to proceed.
10. Press NEXT to proceed with the default settings on the following page. It is not recommended to
alter these settings.
2
Page
www.cuesinc.com
---
Page www.cuesinc.com ---
Operating Instructions
PAIRING THE RANGE EXTENDER TO A QZ3/SPIDER CONTINUED
11. The next page will conrm completion of the Range Extender setup. Press the FINISH button at the
bottom of the page to complete.
12. The Range Extender will then automatically reboot. Do not power o during this process.
2
Page
www.cuesinc.com
---
Page www.cuesinc.com ---
Operating Instructions
13. Once the Range Extender has rebooted, you can connect to its new network name from step 9 with the
same password as the QZ3/SPiDER. At this stage, you can navigate to the QZ3/SPiDER browser page
and operate the device through the Range Extender.
RESETTING THE RANGE EXTENDER NOTE: ONLY NECESSARY IF USER LOGIN/PASSWORD IS
CHANGED OR LOST
To reset the Range Extender to Factory Default settings, use a paper clip to press and hold the reset button
located in the small hole on the bottom of the Range Extender for 10 sec. The blue status light will turn o.
Release the reset button and the light will begin to ash after 10-20 sec. The Range Extender is now reset to
factory settings and can be paired to a QZ3/SPiDER following the pairing instructions using the default SSID
& PIN labeled on the unit.
This device is designed to be water resistant. However, the Range Extender is not meant to be sub-
merged or hosed o. Clean with a damp cloth and mild detergent when necessary.
LITHIUM ION BATTERY SAFETY AND CHARGING INFORMATION
Battery/Charging Precautions and Recommendations
• Do not submerge the Range Extender.
• Do not allow the Range Extender charge port to short-circuit, even for a moment.
• Always protect Range Extender from shock, puncture, and impact, i.e., do not drop or transport
in a tool box, trunk, back of van, etc. where they can “bang around”.
• Do not use or attempt to charge a Range Extender showing any signs of damage.
• Never charge the Range Extender at temperatures below or above 0°C/40°C respectively.
• Do not operate the Range Extender at temperatures below or above -30°C/55°C respectively.
• Always charge the Range Extender on a non-ammable surface and away from all ammable material.
• Do not attempt to tamper with or disassemble the Range Extender.
• The Range Extender may become warm during use or charge.
• Remaining charge on battery is indicated by pressing the button on bottom.
• The Range Extender should be recharged as soon as possible after discharge unless it is not in the
appropriate temperature range. Ideally, charging should occur at room temperature after allowing Range
Extender to warm up or cool down to room temperature.
• Partial charges or discharges are acceptable without causing “memory eect”, although constant
operation under those conditions should be avoided.
CHARGING PROCEDURE IMPORTANT! UNIT MUST BE POWERED OFF DURING CHARGING
• Connect the charger to the battery pack using the connector on the bottom of the device.
• When the charger LED is red, the battery is charging.
• When the charger LED switches to green, the battery is fully charged.
Page
www.cuesinc.com
---
Page www.cuesinc.com ---
