CUES LAMP II Manual

LAMP II
OPERATION & MAINTENANCE MANUAL
P/N LM903, Revision 18: 120220
Lateral & Mainline Probe II
CUES

TABLE OF CONTENTS
II CUES Inc.,LAMPII User Manual | LM903 www.cuesinc.com,| [e-mail]
CHAPTER  - Introduction
Purpose.................................................................................
CHAPTER  - System Description
System Description ..............................................................
CHAPTER  - Equipment Overview
Components..........................................................................
LAMPII Launcher ..........................................................
Lateral Camera & Cable Assembly .................................
Lateral Pan & tilt Camera (optional)...............................
Controllers.....................................................................
Lateral Reel ...................................................................
Interconnect Cable ........................................................
Tire & Wheel Assemblies ...............................................
Large Pipe Equipment....................................................
Wheel Matrix ...............................................................
Installation Conguration Matrix ...................................
CHAPTER  - System Setup & Installation
Adapting the LAMPII to Dierent Pipe Congurations.........
Connecting the LAMPII to the Truck ...................................
Installing the Push Cable .....................................................
For Stainless Steel Cable Assemblies...........................
Remote Reel Controller (Retrieve/Release) ................
For Fiberglass Cable Assemblies..................................
When Using the Mini Pan & Tilt Compatible LAMPII
Version ........................................................................
LAMP II Push Wheel Replacement Guide ............................
Installing the Strain Relief Cables ........................................
Flipping the Push Cable.......................................................
Operating the Reel Brake ....................................................
Line Tracing Cable Extension with LAMPII...........................
Installing/Removing the LAMPII Rear-viewing Camera........
Installing the LAMPII Immobilizing Block .............................
Immobilizing The Camera Head When Using The
Mini Pan & Tilt Camera Compatible LAMPII Version ............

TABLE OF CONTENTS
CUES Inc., LAMPII User Manual | LM903 III
www.cuesinc.com,| [e-mail]
CHAPTER  - Functional Checkout
Powering Up the LAMPII on a K Summit System.................
K Summit / LAMPII Controller Functions ............................
Powering Up the LAMPII on a  PCU System..................
 PCU / LAMPII Controller Functions .............................
CHAPTER  - Operating the LAMPII
Operating the LAMPII............................................................
Launching Into Laterals..........................................................
Centering the LAMPII in the Pipe ..........................................
Changing Directions ..............................................................
Operating the Picture in Picture (PiP)...................................
Retrieving the LAMPII ...........................................................
Equipment Maintenance........................................................
CHAPTER  - Exploded View and Bill of Materials
Exploded View and BOMs .....................................................
Miscellaneous
Warranty Information ............................................................
CUES Material Return Policy.................................................
CUES Parts & Service...........................................................
Safety Precautions & Equipment...........................................
Record of Revisions...............................................................

FYI
IV CUES Inc.,LAMPII User Manual | LM903 www.cuesinc.com,| [e-mail]
® equipment is designed to be easy to use during day to day operation. However, it is powered
electrically and thus must be operated with care and safety. PLEASE READ THE INFORMATION ON SAFETY AND
MAINTENANCE EVEN IF THE SYSTEM IS SET UP BY SOMEONE ELSE.
Care was taken in the design of this product and in the production of this document and related materials. However,
® makes no warranty for the use of its products and assumes no responsibility for any errors or omissions
in this document or for incidental or consequential damages resulting from the use of the products or the information
contained in this document. Specications may change without notice.
All rights are reserved. No part of this publication may be reproduced, stored in any information system, or transmitted
by any means, manual, electronic, or mechanical without the prior written permission of ® .
We would be pleased to hear from you. If you see any errors or desirable extensions or improvements, please write
us at the following address, C/O Operator’s Manuals: ® Corporate Oce  Rio Vista Avenue
Orlando, Florida 
Copyright ©  ®
All rights reserved. No part of this publication covered by the copyright hereon may be reproduced or used in any
form by any means - graphic, electronic, or mechanical, including photocopying, recording, taping, or information
storage and retrieval systems - without the expressed written permission of ®.
Violators will be prosecuted.
Styles and specications are subject to change without notice. First version published in .
Printed in the United States of America.
® toll free hot line for
Customer Service and ordering parts:
--CUES (--)
CUES ® Canada
 Sismet Rd., 
Mississauga, Ontario
Canada LW P
--
-- FAX
AM - PM EST M-Fri
More locations to serve you!
CUES West
 S. Augusta Ct.
Ontario, CA 
--
-- FAX
AM - PM PST M-Fri
CUES ® Corporate Oce
 Rio Vista Avenue
Orlando, Florida 
--
-- FAX
am - pm EST M-Fri
CUES ® Atlanta
 Industrial Ct.
NW, Suite 
Suwannee, GA 
--
-- FAX
am - pm EST M-Fri
CUES ® Northern California
 Eubanks Court, Suite C
Vacaville, CA 
Phone: --CUES
Fax: --
:AM - PM PST M-Fri
CUES ® MidWest
 Parklawn Drive, Suite K
Waukesha, WI 
Phone:: --
Fax: --
AM – PM CST M-Fri
CUES Northwest
 NW Commerce Ct., Suite B
Estacada, OR 
Phone: ... ext: 
Fax: --

1
CUES Inc., LAMPII User Manual | LM903 
www.cuesinc.com,| [e-mail]
The self-propelled lateral inspection / pan and tilt
mainline inspection system, referred to as LAMPII
throughout the manual, is available in several
dierent congurations.
This manual includes operating instructions for the
LAMPII system. Equipment information is included
in the Equipment Overview chapter in this manual.
The instructions in this manual are for multi-
conductor inspectionsystems. The multi-conductor
cable is approximately ½" in diameter and contains
 to  conductors depending on the age of
the system. Twelve conductors are required to
operate the LAMPII system. If uncertain about the
type of system, please call our Customer Service
Department at ---.
The LAMPII is designed to:
• Operate as one component of a
multiconductor inspection system.
• Operate on up to  feet of multi-
conductor cable utilizing dual cable reels.
• Perform one-pass inspections of  through
 inch mainline sewer pipes and house
lateral pipes  -  inches in diameter.
• Display both lateral and mainline footage
with picture in picture (PIP) capabilities.
• Optional Chute & Tube Kits are available to
adapt the LAMPII to larger pipe diameters
The LAMPII operates as part of any new or existing
CUESmulti-conductorsystem(including steerable).
All existing CUES multi-conductor systems can be
retrotted to operate the LAMPII.
If the LAMPII is being installed on an existing
TV only or TV seal system, modications to the
truck equipment layout and electrical wiring will
be required. For more information, please call our
CustomerService Departmentat---.
LAMPII INTRODUCTION
LAMPII with LATERAL PAN &TILTCAMERA OPTION
FIBERGLASS CABLE OPTION

2
 CUES Inc.,LAMPII User Manual | LM903 www.cuesinc.com,| [e-mail]
The CUES LAMPII is designed to perform pan and
tilt inspections of the mainline sewer pipe while
viewing and inspecting:
• Stainless Steel Cable Option: up to 
feet into a lateral pipe.
• Fiberglass Cable Option: up to  feet
into a lateral pipe.
The LAMPII is able to accomplish this by integrating
a self-propelled lateral launcher, transportation
platform, and two cameras, one for pan, tilt, and
optical zoom operations (mainline) and one for
lateral launching. An optional Lateral Pan & Tilt
Camera is available, but requires a specic LAMPII
compatible unit.
The LAMPII is a variable weight,motorized,wheeled
vehicle with integrated self-propelled lateral
launcher and cameras for use in sewer pipelines up
to ” in diameter. The speed and direction of the
transporter is controlled by the stand-alone, game
pad, or wireless controllers (refer to the Functional
Checkout section in this manual for more details).
The mainline camera is located on the front of the
LAMPII and is used to provide a ‘pan, tilt, optical
zoom’ viewof the mainline pipe,to locatelaterals that
are to be inspected, and to monitor the insertion of
the lateral camera into the lateral. Since the mainline
camera can locate house laterals from inside the
mainline sewer pipe, the inspection can be carried
out without any other access to the lateral being
required.
The lateral camera is xed to the push cable and is
transported through the mainline sewer pipe in the
LAMPII. After a lateral is located with the mainline
camera, the launcher performs the necessary
positioning functions to properly guide and direct
the lateral launcher into the lateral service. To
performthe lateral pipe inspection,the self propelled
launcher extends and retracts the mini-camera and
push cable into the lateral.
The optionalCUES Lateral Pan&Tilt Camera(shown
above) is designed to work with the LAMPII lateral
launcher as an optional pan and tilt push camera.
The camera is designed to navigate through multiple
wyes and  and  degree bends / sweeps.
The inner core of the push cable not only transmits
the power to the mini-camera and integral light ring,
but alsocarries the video signalfromthe mini-camera
tothe truck.This ensuresthatthe lateralinspections,
as wellas mainline inspections,arevisible on the same
video monitor located in the CUES multi-conductor
inspection system (picture-in- picture capabilities
- PIP). The lateral reel can retrieve the push cable
as the push camera is retracted.
SYSTEM DESCRIPTION
LAMPII shown with optional
Lateral Pan & Tilt Camera

3
CUES Inc., LAMPII User Manual | LM903 
www.cuesinc.com,| [e-mail]
The LAMPII system consists of the following:
A LAMPII Transporter
• Self-propelled wheeled transporter
• Integratedpan/tilt/zoom (OZIII camera) mainline camera with
LED lightheads and homing
• Integrated lateral push assembly (-speed)
• Lateral footage encoder
• Built-in diagnostics
The LAMPII launcher is a wheeled transporter with integrated pan and tilt/
zoom camera and lateral push cable assembly. The LAMPII lateral push
cable assembly propels the small push camera from inside the mainline
pipe into the lateral. The launcher is a wheeled transportation platform
which transports the entire LAMPII system through the mainline sewer
pipe. The integrated pan and tilt/zoom camera provides live video of the
mainline sewer pipe inspections. The mainline camera is mounted on the
front of the LAMPII transporter, which pans and tilts/zooms to monitor
the insertion of the lateral camera and view the mainline pipe. The unit
includes two LED lightheads on the camera to provide adequate lighting
for a clear picture of the mainline and lateral pipelines. The camera head
pivots for easy insertion into the pipe.
B Lateral Camera & Cable Assembly
• Self-upright camera with LED light-ring
• Camera centering ball
• Steel spring push cable (LM & LM- with stainless steel cable option up to  ft)
• Fiberglass push cable (LM- & - to - with berglass cable options up to  ft)
• Sonde (optional)
The lateral camera is xed to the push cable (stainlees steel or berglass cable assembly, depending on
your specic conguration) and is propelled into the lateral by the LAMPII push assembly.The mini-camera
light ring contains () adjustable-intensity, light-emitting diodes. The camera centering ball protects
the lateral camera and lighthead from osets and in-line obstructions and helps negotiate bends during
the pipe inspection. An optional sonde, built into the lateral mini-camera, is available to help accurately
locate the camera in metallic and non-metallic pipes. The sonde can operate with any constant tone,
Hz locator/receiver.
EQUIPMENT OVERVIEW
A
B

3
 CUES Inc.,LAMPII User Manual | LM903 www.cuesinc.com,| [e-mail]
EQUIPMENT OVERVIEW CONTINUED
The LAMPII system consists of the following:
C Lateral Pan & Tilt Camera (optional)
• Rotation: Continuous  degree rotation
• Pan: Continuous  degree rotation
• Illumination: White LED Lighting
• Scratch-resistant sapphire window
• Detachable steering wand provides the ability to navigate through multiple wyes
• () camera lens window wipers included for in-pipe cleaning of windows. No need to pull
out the camera above ground to clean the lens windows!
• Automatic, powered self-leveling camera head
• Four () banks of LED’s with variable light intensity
• Push cable lengths available up to  ft.
C
D Controllers
• Standard transporter controller
• LAMPII function controller (LM)
• Lateral power control unit (LM, LM, LM, LM, LM)
• Lateral reel controller
• Remote retrieve/release reel controller - LM
• Game pad or CUES hand-held controllers - wireless or tethered
Foradditional informationregarding the Mini Pan&TiltCamera,
refer to P/N’s UC - MINI PAN & TILT QUICK GUIDE and
LM - K/K LM MINI/MICRO P&T,QUICK CARD, for
the following instructions:
• Guide Rod Installation
• Attaching the Camera to the Lateral Push Cable
• Installing or Replacing the Shroud
• Installing or Replacing the Spring
• Pressurizing the Camera

3
CUES Inc., LAMPII User Manual | LM903 
www.cuesinc.com,| [e-mail]
Controllers -
For systems using a  PCU:
D. Controller for the cameras and self propelled lateral launcher- The desktop controller is used to
control the various movements of the LAMPII and the OZII and OZIII cameras.
D. Controller for the transportation platform - This controller is used to control the direction and speed
of the transportation platform for the launcher.
For K Summit Systems:
D. K Summit Hand-held Controller - The ergonomic, hand-held, wireless controller is available for all
camera, transporter, reel, LAMPII lateral launcher, and camera lift functions.
D. K Summit Game Pad Controller - An optional wireless, compact controller is available for all
camera, transporter, reel, LAMPII lateral launcher, and camera lift functions.
GAME PAD CONTROLLER
HAND-HELD K2 CONTROLLER
D D
D D
E
Lateral Reel for the LAMPII
Lateral Push Cable - Spring Cable Conguration
Lateral Reel for Fiberglass
Push Cable Conguration
E Lateral Reel - The reel stores the lateral video cable and electrically retrieves the lateral cable
upon completion of the lateral pipe inspection. It’s controller is equipped with variable speed/force
control. The new berglass cable reel will stow the lateral video cable and push cable.
• ft lateral cable
• Integrated levelwind / auto-retrieve (levelwind available with the stainless steel cable option only)

3
 CUES Inc.,LAMPII User Manual | LM903 www.cuesinc.com,| [e-mail]
F All necessary interconnect cables (not shown)
G Optional Sonde & Receiver
H Optional Wheels Sets Available (refer to the
information below and the Wheel Matrix in this document)
Optional Sonde & Receiver
Six tires and/or three wheel assemblies available in four dierent sizes (refer to the Wheel Matrix for
more information) - The transporter utilizes six tires, six steel wheels, or four pneumatic wheel assemblies,
depending on the transporter conguration for the pipe size to be inspected. The six tires/steel wheels
are used in ” - ” pipe sizes. The pneumatic wheel assemblies are available to maximize traction in pipes
ranging from ” in diameter.
P/N LM (Kit, Adapter, K Wheels to LAMPII) is available when mounting the large ” Pneumatic
Wheels to the LAMPII.
* NOTE: tires are not to scale. Part numbers are referenced on the LAMPII Wheel matrix in this chapter.
G
EQUIPMENT OVERVIEW CONTINUED
* ” steel and ” - ” rubber not shown
Pneumatic
for 12” +
6” Lined Pipe 8” Pipe - Steel
10” - 15”
Pipe
8” Pipe -
Rubber
(standard)
for 6” Pipe

3
CUES Inc., LAMPII User Manual | LM903 
www.cuesinc.com,| [e-mail]
I Optional Chute & Tube Kits are available to adapt the LAMPII to larger pipe diameters
LAMPII LARGE PIPE EQUIPMENT
LM297, MODULAR
CHUTE TUBE
To support large pipe inspections, modular chutes are available for LAMPII. The chutes are designed
for use in pipe sizes ranging from 18 to 36 inches in diameter. Large 14” wheels are included in Kit
P/N LM931, Angled Chute Kit, and can also be purchased separately. The large wheels are utilized to
increase bottom clearance.
The chutes consist of a breech and of a set of three clear polycarbonate tubes, P/N LM297-1 through
-4, for 18-36 inch pipes. The tubes are inserted and secured into the breech according to pipe size.
Two breeches are available: one straight, for use with the standard wheels, P/N LM362, and an angled
one, P/N LM363, for use with the large wheels, P/N LM935. Note: The Mini P&T Camera will not
retract into the LAMPII cradle from the chute breech. When retrieved, it should remain in the
chute breech.
P/N LM935 (Kit,Adapter,K2 Wheels to LAMPII) is available when mounting thelarge 14”Pneumatic
Wheels to the LAMPII.
For existing units, contact CUES Customer Service prior to installation to determine if the clutch is
adjusted properly. Once this is accomplished, existing units can be eld-retrotted.
I
PIPE SIZE
36 in
30 in
24 in
LENGTHS TABLE
LAMPII shown in the standard conguration
with optional Large Wheels and Chute
LM- . in . lb  in

 CUES Inc.,LAMPII User Manual | LM903 www.cuesinc.com,| [e-mail]
WHEEL MATRIX FOR LAMP II
Installation Configuration Matrix
LM907-INST INST SHEET, WHEEL MATRIX, LAMP2 REV: D
6" LINED RUBBER 6" RUBBER 6" STEEL 8" RUBBER 8" STEEL 10" RUBBER 10" STEEL 12" RUBBER 12" STEEL 15" RUBBER 15" STEEL 12" PNEU 15-18" PNEU
WHEEL/KIT Number WM097 WM209 WM307-1 WM308 WS906 WM310 WM310-2 WM310 WM310-2 WM310 WM310-2 WM312 WM312
(6 ea.) (6 ea.) (6 ea.)
SPACER -- -- -- WM058 WM058 WM061 WM061 WM058 WM058 WM061 WM061 -- WM058
(6 ea.) (6 ea.) (6 ea.) (6 ea.) WM061 WM061 (6 ea.) (6 ea.) WM061
(6 ea.) (6 ea.) (4 ea.)
CHUTE KIT LM902 LM902 LM902 LM902 LM902 LM902 LM902 LM902 LM902 LM902
CHUTE LM143 LM143 LM144 LM144 LM145
LM145 LM146 LM146 LM145 LM146
ATTACHMENT SCREW WM098-1 WM098-1 WM098-1 WM099-1 HW2819 HW1567 HW1567 HW1568 HW1568 HW1569 HW1569 HW1568 HW1570
(6 ea.) (6 ea.) (included in kit) (included in kit) (included in kit) 1.5" Length 1.5" Length 2.0" Length 2.0" Length 2.5" Length 2.5" Length 2.0" Length 3.5" Length
NOTES: Captive Screw Captive Screw Captive Screw Captive Screw Captive Screw Screw included
in WM317 kit
Screw included
in WM317 kit
Screw included
in WM317 kit
Screw included
in WM317 kit
Screw included
in WM317 kit
Screw included
in WM317 kit
Screw included
in WM317 kit
Screw included
in WM317 kit
24" K2 30" K2 36" K2
18" 21" 24" 30" 36" CHUTE KIT Number LM931 LM931 LM931
CHUTE KIT Number LM932 LM932 LM932 LM932 LM932 CHUTE TUBE LM297-3 LM297-2 LM297-1
CHUTE TUBE LM297-4 LM297-3 LM297-3 LM297-2 LM297-1
\ \\\\ WHEEL LM935 LM935 LM935
WHEEL WM312 WM312 WM312 WM312 WM312 LM294-1 LM294-1 LM294-1
SPACER WM058 WM058 WM058 WM058 SPACER LM294-2 LM294-2 LM294-2
WM061 WM061 WM061 WM061 (2 ea.) (2 ea.) (2 ea.)
(4 ea.) (4 ea.) (4 ea.) (4 ea.) ATTACHMENT SCREW HW2405/HW2475 HW2405/HW2475 HW2405/HW2475
ATTACHMENT SCREW HW1570 HW1570 HW1570 HW1570 HW1570 (included in kit) (included in kit) (included in kit)
3.5" Length 3.5" Length 3.5" Length 3.5" Length 3.5" Length
Screw included
in WM317 kit
Screw included
in WM317 kit
Screw included
in WM317 kit
Screw included
in WM317 kit
Screw included
in WM317 kit
NOTES:
NOTES:
21" 24" Note: When setting up for relined pipe select configuration for next smallest pipe and add 6x WM223 wheel spacers (included in WM317).
CHUTE KIT Number LM931 LM931
CHUTE TUBE LM297-4 LM297-3
\ \
WHEEL WM312 WM312
SPACER WM058 WM058
WM061 WM061 TITLE:
(4 ea.) (4 ea.) DWG NO: LM907-INST DFTR: DATE:
ATTACHMENT SCREW HW1570 HW1570 ECN: 14454 CHKR: DATE:
3.5" Length 3.5" Length PRODUCT: LAMP II ENGR: PS DATE: 11/24/2020
Screw included
in WM317 kit
Screw included
in WM317 kit
NEXT ASSY: LM900 MFG: DATE:
LAMP II Quick Change Wheel BOM Matrix 6"-15" PIPE
24-36" MODULAR TUBE
LARGE 14" WHEEL ANGLED CHUTES
INST SHEET,WHEEL MATRIX, LAMP2
CHUTES WILL NOT CLEAR LARGE 14" WHEELS
18-36" STANDARD WHEELS AND STRAIGHT CHUTES
ANGULED CHUTES
21-24" STANDRARD WHEELS AND
Use WM224-1 screws for 7in pipe setup.

CUES Inc., LAMPII User Manual | LM903 
www.cuesinc.com,| [e-mail]
WHEEL MATRIX FOR LAMP II
Installation Configuration Matrix
LM907-INST INST SHEET, WHEEL MATRIX, LAMP2 REV: D
Kit No. Qty. Part Number Nomenclature
WM307-1 6 ea. WM096-1 Wheel, Steel, 6" Pipe
Kit No. Qty. Part Number Nomenclature
LM931 1
LM363
CHUTE ASSY,MODULAR,ANGLED,14" WHEEL
WM308 6 ea. WM089 Hub, Inner, 8-15" (21-36" pipe) 1
LM297-1
TUBE,POLYCARB,MOD CHUTE,18"L
(8" pipe) 6 ea. WM090 Hub. Outer, 8" 1
LM297-2
TUBE,POLYCARB,MOD CHUTE,14"L
6 ea. WM092 Tire, Rubber, 8" Pipe 1
LM297-3
TUBE,POLYCARB,MOD CHUTE,10"L
12 ea. WM099-1 Screw, Captive, BHCS, 5/16-24UNF x 1.000 1
LM935
KIT,ADAPTER,14" PNEU WHEELS,LAMP II
18 ea. 103052 Screw, Flat, Phillips, 10-32UNF x 1/2 1
LM931-INST
INST SHEET,MOD,WHL/ANG CHUTE,24-36"
1
LM297-4
TUBE,POLYCARB,MOD CHUTE,5.5"L
WM906 6 ea. WS112-1 Wheel,Steel,8" Single Pt 10/12 Grit (8" pipe) (included) HW2819 Screw,Hex,5/16-24X1,17-4PH SST Kit No. Qty. Part Number Nomenclature
LM935 4ea. MD046 Wheel Assy, Pneumatic, 14"
(24-36" pipe) 2ea. LM294-1 Spacer,Adapter, Inner, K2 Wheels
WM310 / WM310-2 6 ea. WM089 Hub, Inner, 8-15" (part of LM931) 2ea. LM294-2 Spacer,Adapter, Outer, K2 Wheels
(10-15" pipe) 6 ea. WM091 Hub, Outer, 10-15" 2ea. LM295-1 Plate, Retaining, Inner, K2 Wheels
6 ea. WM093 Tire, Rubber, 10-15" Pipe 2ea. LM295-2 Plate, Retaining, Outer, K2 Wheels
6 ea. WM108-1 Wheel, Steel, 10-15" Pipe 2ea. HW2475 Screw, Hex, 5/16-24, Mod
18 ea. 102001 SCREW,CAP,SKT HD,10-32X1/2,SST 2ea. HW2405 Screw, Hex, 5/16-24 x 3 1/4, Zn Pl
12ea. HW2407 Screw, Hex, M6 x 75mm, Zn Pl
12ea. HW1738 Washer, Flat, m6 x Ø12 x 1.5mm SST
WM312 4 ea. WM100 Adapter, Hub, Pneu. Wheels 4ea. 101741 Washer, Flat, 5/16, SST
(pneu. 12-15" pipe) 4 ea. WT331 Pneumatic Wheel Assy WM317 6 ea.
WM058
SPACER,.5",QUICK CHANGE,CPR,BRASS Kit No. Qty. Part Number Nomenclature
(6-15" pipe) 12 ea.
WM061
SPACER,1",QUICK CHANGE,CPR,BRASS LM932 1
LM362
CHUTE ASSY,STRAIGHT,LRG PIPE
CPR & WTR3 6 ea. WM223 (18-36" pipe) 1
LM297-1
TUBE,POLYCARB,MOD CHUTE,18"L
6 ea. WM224-1 SCREW,CAPTIVE,HEX,5/16-24 X .75 1
LM297-2
TUBE,POLYCARB,MOD CHUTE,14"L
12 ea.
HW1567
SCREW,SHCS,5/16-24UNF X 1.50,SS 1
LM297-3
TUBE,POLYCARB,MOD CHUTE,10"L
12 ea.
HW1568
SCREW,SHCS,5/16-24UNF X 2.00,SS 1
LM297-4
TUBE,POLYCARB,MOD CHUTE,5.5"L
12 ea.
HW1569
SCREW,SHCS,5/16-24UNF X 2.50,SS
8 ea.
HW1570
SCREW,SHCS,5/16-24UNF X 3.50,SS
1 ea. WM902-INST INST SHT,WHEEL MATRIX, CPR
5
MR539
TUBE,SEALED BOTTOM,2½"DIA X 3½"LG
5
MR540
PLUG,POLYPROPYLENE,BLACK,2½"DIA
1
440014
MRO-CARTON,SHIPPING 12X7X7
1
CS488
ANTI-SEIZE,BRSH,NICKL GRAF,2 OZ
SPACER,.25,QUICK CHANGE,CPR/LAMPII

4
 CUES Inc.,LAMPII User Manual | LM903 www.cuesinc.com,| [e-mail]
SYSTEM SET-UP & INSTALLATION
ADAPTING THE LAMPII TO DIFFERENT PIPE CONFIGURATIONS
The adaptation of the LAMPII to dierent pipe sizes is accomplished by changing the wheels. The
wheel sets adjust to allow for the inspection of 6” through 36” diameter pipelines. This is accomplished
by adding various types and quantities of wheels and spacers.The wheels and spacers not only widen
the base of the transportation platform for stability, but also positions the LAMPII approximately in the
center of the pipe for optimum viewing.
The LAMPII incorporates the new quick-change wheel assemblies that are designed for maximum
eciency and ease-of-use.
To remove the wheels:
IMPORTANT! When changing wheels, always apply anti-sieze compound, P/N CS or P/N 
grease, to all screw threads.
1. For 6” rubber and steel wheel assemblies, loosen the large center captive screw using a socket.
For 8” - 15” wheel assemblies, loosen and remove the large center screw using an Allen wrench.
2. Separate the wheel assembly and spacer, if applicable, from the shaft.
3. For 24” - 36” wheel assemblies, refer to the instructions in P/N LM931-INST for more information.
To mount the wheels:
4. Select the appropriate wheel, spacer, and screw, if applicable, for the pipe size to be
inspected. If necessary, refer to the wheel matrix shown in the previous chapter.
5. Install the spacer, ensuring that the tri-lobe pocket on the spacer is aligned with the tri-lobe
on the shaft.
6. Hold the wheel and spacer against the LAMPII shaft and secure the appropriate screw
using an Allen wrench.
7. Tighten to 15 ft. lbs.
IMPORTANT!
When changing wheels, always apply
anti-sieze compound, P/N CS or P/N
 grease, to all screw threads!

4
CUES Inc., LAMPII User Manual | LM903 
www.cuesinc.com,| [e-mail]
CONNECT THE LAMPII TO THE TRUCK AS FOLLOWS:
Connecting the multi-conductor mainline cable:
. Attach the quick-connector (P/N LM) to the end
of the -pin gold cable.
. Connect the multi-conductor gold cable to the
top of the LAMPII, ensuring that the quick-connector
is secure.
1
Note
the orientation of the top-
conductor position for proper
connector alignment.
2

4
 CUES Inc.,LAMPII User Manual | LM903 www.cuesinc.com,| [e-mail]
SYSTEM SET-UP & INSTALLATION
CONNECT THE LAMPII TO THE TRUCK  CONTINUED:
. Attach the tow cables to the strain relief on the gold cable, ensuring that the gold cable has at
least ” - ” of slack when the tow cables are taut.
. Lay out the push cable and install the
camera and centering ball.
. Pivot the camera head UP and insert the push
camera up through the bottom of the unit as
shown.
Refer to the Stainless Steel or Fiberglass Cable
instructions in this section, depending on your specic
conguration.
INSTALL THE PUSH CABLE
For Stainless Steel Push Cable Assemblies:
If you have the berglass push
cable assembly, refer to the
next procedure for installation
instructions.
1
2
NOTE: Tow Cable P/N LM is recommended for use when the rear viewing camera is not used. Tow
Cable P/N LM is recommended when the rear viewing camera is used. Tow Cable P/N LM has an
extra loop which captures the rear view camera. Refer to the RVC installation instructions in this chapter
for further details.

4
CUES Inc., LAMPII User Manual | LM903 
www.cuesinc.com,| [e-mail]
. Guide the cable into the channel and install the guide
plate to capture the push cable.
. To install the pressure plate, apply blue threadlocker to
all screw threads and secure the screws. Adjust the set
screw on the pressure plate to provide the lightest
possible pressure against the cable.
. Turn ON the reel controller and set to REAR and
RELEASE. Ensure that the cable easily unrolls from
the reel.
SPEED AND FORCE ADJUSTMENT -
Spring Push Cable System:
To ensure the lateral cable unrolls easily, perform the
following:
• When driving the launcher forward or extending
the lateral camera, the lateral reel RETRIEVE/
RELEASE switch must be set to RELEASE - or -
• the lateral reel controller power switch must be in
the OFF position
FOR STAINLESS STEEL PUSH CABLE ASSEMBLIES ONLY:
When retracting the lateral camera:
• Ensure that the lateral reel RETRIEVE/RELEASE switch is set to RETRIEVE.
• Adjust the SPEED/FORCE knobs clockwise to the desired position.
• Recommended initial settings: SPEED:  o’clock FORCE:  o’clock
When pulling the launcher backwards:
• Ensure that the lateral reel RETRIEVE/RELEASE switch is set to RETRIEVE.
• Adjust the SPEED/FORCE knobs clockwise to the desired position to keep up with the gold cable
speed.
• Recommended initial settings: SPEED:  o’clock FORCE:  o’clock
• Retrieval speed will vary depending on the pipe condition and wheel conguration.
• To prevent the transporter from driving over the cables and hindering retrieval, use caution and
do not allow the transporter to track faster than the lateral reel.
• Recommended settings: Gold Cable retrieval speed should be set according to pipe conditions
with cables visually monitored for synchronization to prevent potential damage to the equipment.
3
4
5

4
 CUES Inc.,LAMPII User Manual | LM903 www.cuesinc.com,| [e-mail]
SYSTEM SET-UP & INSTALLATION
CONNECT THE LAMPII TO THE TRUCK  CONTINUED:
FOR STAINLESS STEEL PUSH CABLE ASSEMBLIES
ONLY:
. Route the lateral camera cable through the cable
guides.
. Connect the lateral camera cable to the metal push
cable:
a. Align the pins of the lateral camera cable connector
with those of the metal push cable and connect
them. Push until the ends pop together.
b. Install the spacer in the chamber before
installing the nut.
Apply anti-sieze compound, P/N CS or P/N
 grease, and then tighten the metal
chamber nut (do not cross-thread).
c. Connect the strain relief cables.
6
7a
7b
7c

4
CUES Inc., LAMPII User Manual | LM903 
www.cuesinc.com,| [e-mail]
A remote desktop controller is available for both LAMPII lateral reels. This controller allows switching
the reel between release and retrieve without having to stand up to use the switch on the lateral PCU.
With this device, the operator can choose to use the switch on the desk or the one on the PCU.
This controller does not overide the functions on the lateral reel controller or replace the button on
the PCU or at the reel controller.
P/N LM, CONTROLLER, REMOTE, RETRIEVE/RELEASE, LAMPII REEL
REMOTE REEL CONTROLLER (RETRIEVE / RELEASE) INSTRUCTIONS -
REEL TOGGLE SWITCH: PRESS TO RELEASE
OR RETRIEVE THE CABLE ON THE REEL.
CONTROL TOGGLE SWITCH: PRESS TO
SELECT LOCAL HANDHELD CONTROLLER
OR REMOTE CONTROLLER LATERAL PCU.
POWER LED  INDICATES THE CONTROLLER IS
PLUGGEDIN TO THE LATERAL PCU. NOTE: THE
CONTROLLER IS ALWAYS ACTIVE REGARDLESS
OF THE LATERAL PCU BEING ON OR OFF.
CONTROL LED  INDICATES THE
LOCAL/REMOTE SWITCH IS
SET TO “LOCAL”.
REEL LED  INDICATES THE
RETRIEVE/RELEASE SWITCH
IS SET TO “RETRIEVE” WHEN IN
“LOCAL” CONTROL.

4
 CUES Inc.,LAMPII User Manual | LM903 www.cuesinc.com,| [e-mail]
SYSTEM SET-UP & INSTALLATION
Ensure that the grey/yellow cable is plugged into the rear of the Lateral PCU as shown below.
REMOTE REEL CONTROLLER IN THE CONTROL ROOM
