cultsport smartrun c2 User manual

1

1
Contents
1.Product Brief ……………………………………….................…… 1
2.Security Precautions and Warning…………………………....…………3
3.Installation Instructions …………………………………….……...…...5
4.Using Instructions…………….……………………………....……….7
5.Routine Maintenance and Instructions …………………………….……10

2
1. Product Brief
Product name: Single Function Electric Treadmill
Main technical parameters
NO
.
Parameters
Description
1
Input power voltage
AC220-240V(50~60Hz)
2
Power
4 HP
3
Speed
0.8-16 Km/h
4
Running surface
1260*450 mm
5
Max user weight
120KG
6
Expand dimension
1670*720*1320 mm
Packing list
NO
.
Name
Units
QTY
1
Complete machine
set
1
2
Accessory bag
set
1
3
Base cover
set
1
Accessory bag list
NO
.
Name
QTY
NO
.
Name
QTY
1
Screw M8*22
6
6
Combination wrench
1
2
Screw M8*45
2
7
Safety key
1
3
Locknut M8
1
8
Silicon oil
1
4
Inner hexagon wrench 5mm
1
9
User’s manual
1
5
Inner hexagon wrench 6mm
1
10
MP3 cable
1

3
2. Security Precautions and Warnings
:Please read the instructions carefully before use
◆Indoor using and storing the treadmill, avoid dampness, and can not be spilled by water.
◆Please wear suitable clothes and sneakers before exercise. Prohibited to exercise on the treadmill
barefoot.
◆High power plug must be grounded, electric outlet should have a dedicated circuit, do not share
with other electrical equipment.
◆Keep children away from the machine to avoid accidents.
◆Avoid too long time and overload operation, otherwise will cause motor and controller damaged,
and will accelerate the deterioration of bearing, running belt and running board. Should maintain
machine on a regular basis.
◆Keep machine away from dust to avoid strong static.
◆Please cut the electric power off after using.
◆Please maintain good ventilation when running.
◆Please clamp security lock cable on your clothing to make sure the machine stops at emergency
condition.
◆If you feel not very well when using this machine, please stop and consult a doctor.
◆Silicone oil must be kept away from children after use.
◆If power cord is damaged, please contact our qualified maintenance personnel for service rather
than disassemble it at your own discretion.
Forbidden
◆Don't use the machine in the status of the shell break in or break off (the internal structure
exposed)or under the condition of welding-parts may fall off.
---- Otherwise an accident or injury may happen.
◆Don't jump up and down in the process of movement.
---- May be injuries caused by the fall.
Notice:
Tips: Before folding the treadmill, make sure that the gradient is "zero".
!

4
◆Don't keep machine in or near moist space such as the bathroom.
◆Don’t place machine in direct sunlight, or high temperature places such as near a stove or a
heating appliance .
----Otherwise may cause the leakage and burst into flames.
◆Don't use when the power cord is damaged or power plug pin is loose.
----Otherwise will lead to an electric shock, short circuit or fire.
◆Don't damage or bent by force or reverse the power cord. Don’t place heavy objects on machine,
don't clamp the power line.
----Otherwise will cause fire or get an electric shock.
◆Don't use machine for more than 2 people at the same time, and don't get close to the machine
when it is in use.
---- Or it may be an accident or injury due to falls.
◆People who can’t express their consciousness or can’t operate the machine by themselves cannot
use the treadmill.
----May occur accident or injury.
Avoid drinking water or pouring water when operation.
---- May cause electric shock and fire. Forbidden!
◆People who seldom do exercise shouldn't suddenly do intense exercise.
◆After eating or when feel tired, do not use machine.
---- May lead damage to your health.
◆This product is suitable for family use, does not apply to schools, gymnasium and so on. ----
There is the danger of injury.
◆Don’t use when hard objects are in pants pockets.
----May cause accident or injury.
◆Don’t use when the power plug is on the needle, garbage, or water.
----May cause electric shock, short circuit, or fire. Do not use with wet hands!
◆when not in use, pull out the power plug from the socket.
----The dust and moisture can age the insulation, and result in leakage fire.
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved, children shall not play with the appliance, cleaning and user maintenance shall not be made

5
by children without supervision.
Ground protection system!
◆This product must be grounded. If the machine is dysfunctional, grounding will provide a good
channel for electric current, in order to reduce the electric shock risk.
◆This product is equipped with power plug with grounding conductor and plug. Completely insert
the plug to standard socket.
◆If the equipment grounding conductor’s connection is improper, it will cause electric shock. If
you have doubts about whether your product is grounded correct or not, please entrust
professional to check.
◆Please use the socket which has the same shape with the grounding plug. Don’t use plug adapter.
3. Installation Instructions
When installed, simple fix all screws, and finally tighten them when the installation of frame and
column is done.
1. Put the machine flat on the ground. And stand the upright columns and console as below:
2. Use the 5# hexagon wrench and nut M8*45(A) and M8*22(B) to lock washers and nuts through the
column in the base, and tighten them with nut M8.
!
Gro
undi
ng
instr
uctio
ns!
M8*45
M8*22
A
B·

6
3. Hold left right columns, use 5# hexagon wrench to lock the console frame on the columns with
screw M8*22.
4. Use screwdriver to lock the base covers onto the base with screw M5*14 .
5. Keep the safety key on the position as the following picture.
NOTE: please confirm that all screws are locked uniformly according to the requirements after
installation, and check no part is left out before plugging electricity.
Please find the red color
safety key in the accessory
bag. The treadmill can only
start when the safety key is
put in the right position.
M8*22
M5*14

7
4. Using Instructions
Using treadmill
1. Insert the power plug properly and turn on the switch(in red color)(1). When the light is on, you
will hear a beep sound, and then the screen will be light up(Systems of TFT screen takes more time to
enter the start interface).
2. Please keep the safety key away from children when the treadmill is not in use. Please put the
silicon oil bottle in places where children cannot reach. If it is eaten or split into eyes by mistake,
please use water to wash and consult doctor immediately.
3. Safety key Introduction
The treadmill can only start when the safety key is put on the yellow area of the console. Clip the
safety key on clothes when using the treadmill to prevent accidents. Put the safety key back when
continue using the treadmill.
Folding Instruction
Fold the treadmill:
It will save space when the treadmill is folded.
Please turn off the switch and pull out the power plug before folding. Lift the running deck until it
is held.
Unfold the treadmill:
Kick the pressure rod, hold the running deck and then let the running deck to fall gradually.
4.1 Start-up
Place the safety key on the yellow zone, and the treadmill starts after 5 seconds of countdown.
4.2 Amount of programs
3 manual programs, 12 automatic programs, 1 FAT program.
4.3 Safety key function
Disconnect the safety key, E7 shows on the screen, and the treadmill stops immediately, and you
will hear a beep sound. Put the safety key back, all the data will be cleared in 2 seconds and the screen
1
Kick this
part to lower
the running
deck.

8
goes back to the main interface.
4.4 Button Functions
4.4.1 Start button:
When the power is on, press the rotation knob to start the treadmill.
4.4.2 Stop button:
When the treadmill is in running state, press the rotation knob for 3-5 seconds to stop the
treadmill.
4.4.3 Pause button:
When the treadmill is in running state, press the rotation knob once to pause the treadmill/
4.4.4 Program button:
When the treadmill is in standby state, press Program button to choose manual mode or
automatic program (P1 - P12); the default setting is manual mode.
4.4.5 Mode button:
Three different countdown modes are available in standby mode: Time countdown mode, Distance
countdown mode, and Calorie countdown mode. Use the rotation knob to control the countdown value,
and after the setting is done, press the rotation knob to start the treadmill.
4.4.6 Speed increase and decrease:
When the treadmill is running, rotate the rotation knob clockwise to increase the speed and rotate
counter clockwise to decrease the speed.
4.4.7 Speed shortcut button:
Use speed shortcut button to adjust the speed into 3,6, 9, and 12 directly in running state.
4.4.8 Incline increase and decrease buttons:
When the treadmill is running, press Incline increase button to increase the incline level and press
Incline decrease button to decrease the incline level.
4.4.9 Incline shortcut button:
When the treadmill is running, use incline shortcut button to change the incline level into 3,6, 9,
and 12 directly in running state.
4.5 Display Function
4.5.1 Speed Display.
Display the current running speed value.
4.5.2 Time Display
Display the time of manual mode and the countdown time under automatic modes and programs.
4.5.3 Distance display
Display cumulative distance under manual mode and programs. Display the distance countdown in
automatic mode.
4.5.4. Calorie display
Display cumulative calorie under manual mode and programs. Display the calorie countdown in
automatic mode.
4.5.5. Heart rate display
When the treadmill is energized, hold the pulse sensor on the handles for a while, the heart rate
value will show on the screen. This data is for reference only, it cannot be considered as medical
data.
4.6 Automatic program
Each program is divided into 10 segments, and the running time of each segment of the program
is evenly distributed. Following is a form of time distribution of 24 programs.

9
Time
Program
Set time / 10 = Running time of each segment
1
2
3
4
5
6
7
8
9
10
P1
SPEED
3
4
5
5
5
5
5
5
5
3
INCLINE
2
2
2
2
2
2
2
2
2
0
P2
SPEED
4
5
6
6
6
6
6
6
6
4
INCLINE
2
2
2
2
2
2
2
2
2
0
P3
SPEED
5
6
7
7
7
7
7
7
7
5
INCLINE
2
2
2
2
2
2
2
2
2
0
P4
SPEED
5.5
6.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
5.5
INCLINE
2
2
2
2
2
2
2
2
2
0
P5
SPEED
6
8
9
8
9
8
9
8
9
3
INCLINE
2
4
4
4
4
4
4
4
4
0
P6
SPEED
7
9
10
9
10
9
10
9
10
4
INCLINE
2
4
4
4
4
4
4
4
4
0
P7
SPEED
9
11
12
11
12
11
12
11
12
6
INCLINE
2
4
4
4
4
4
4
4
4
0
P8
SPEED
10
12
13
12
13
12
13
12
13
7
INCLINE
2
4
4
4
4
4
4
4
4
0
P9
SPEED
4
7
5
7
5
7
5
7
5
3
INCLINE
4
6
6
6
6
6
6
6
6
0
P10
SPEED
5
8
6
8
6
8
6
8
6
4
INCLINE
4
6
6
6
6
6
6
6
6
0
P11
SPEED
6
9
7
9
7
9
7
9
7
5
INCLINE
6
9
7
9
7
9
7
9
7
5
P12
SPEED
6.5
9.5
7.5
9.5
7.5
9.5
7.5
9.5
7.5
5.5
INCLINE
4
6
6
6
6
6
6
6
6
0
P13
SPEED
3
7
7
7
7
7
7
7
6
3
INCLINE
2
2
2
2
2
2
2
2
2
2
P14
SPEED
4
8
8
8
8
8
8
8
7
4
INCLINE
2
2
2
2
2
2
2
2
2
2
P15
SPEED
6
10
10
10
10
10
10
10
8
5
INCLINE
2
2
2
2
2
2
2
2
2
2
P16
SPEED
8
12
12
12
12
12
12
12
11
8
INCLINE
2
2
2
2
2
2
2
2
2
2
P17
SPEED
5
7
6
7
6
7
6
7
6
4
INCLINE
3
4
5
4
5
4
5
4
5
2
P18
SPEED
5
7
6
7
6
7
6
7
6
4
INCLINE
4
5
6
5
6
5
6
5
6
3
P19
SPEED
5
7
6
7
6
7
6
7
6
4
INCLINE
6
7
8
7
8
7
8
7
8
5
P20
SPEED
5
7
6
7
6
7
6
7
6
4
INCLINE
8
9
10
9
10
9
10
9
10
7
P21
SPEED
8
12
10
12
10
12
10
12
10
5

10
INCLINE
3
6
3
6
3
6
3
6
3
0
P22
SPEED
9
13
11
13
11
13
11
13
11
6
INCLINE
4
7
4
7
4
7
4
7
4
1
P23
SPEED
11
15
13
15
13
15
13
15
13
8
INCLINE
6
9
6
9
6
9
6
9
6
3
P24
SPEED
12
16
14
16
14
16
14
16
14
9
INCLINE
7
10
7
10
7
10
7
10
7
4
Translation of Error Codes
Error Code
Description
Check and solution
E1
Communication Abnormal:
when the power is on, the
connection between lower
controller and the console is
abnormal.
Check the cable connection between the console and the control
border to ensure that each core is fully plugged in. Replace the
connection cable if it is damaged.
E2
No detection of motor
Possible Cause:
Check the motor cable to see whether it is connected well or not,
if not, connect the motor wire again.
Check the motor cable, replace it if it is damaged or has a burnt
smell.
E5
Over current protection:
In working , the lower
controller detects the current
to be over 6A for more than
3 seconds.
Possible Cause:
Overloading leads to excessive current, and the system stops out of
self-protection, or some part is stuck, causing the motor to stop.
Adjust the treadmill and restart it. Check if there is liquid or burnt
smell while the motor is running, if yes, replace the motor; check if
the controller has a burnt smell, if yes, replace the controller; check
the power supply voltage, if it does not match the specifications ,
change into correct voltage and test the machine again.
E6
Explosion-proof impact
protection: the abnormal
voltage or motor cause the
faulty of circuit that drive the
motor.
Possible Cause:
Check if the power supply voltage is 50% lower than normal
voltage ,use the correct voltage and test the machine again;check
if the controller has a burnt smell and replace the controller; Check
if the motor cable is connected and connect the motor wire again.
E7
No safety key
Put the safety key on the right place.

11
5. Routine Maintenance and Instructions
Warning: Before cleaning or maintaining products, please make sure the power plug of the
treadmill is pulled out.
Cleaning: Comprehensive cleaning will extend the using life of the electric treadmill.
Remove dust periodically in order to keep the parts clean. Make sure to clean running belt with both
sides of the exposed portion, which will reduce the accumulation of impurities. Make sure to wear
clean shoes to avoid carrying the dirty matters into running board and belt. Treadmill belts shall be
cleaned by a damp cloth with soap. And please pay attention to avoid wet the electrical components
and running belt.
Warning:Make sure power plug disconnect before moving motor cover away, clean the motor at least
once a year.
Running belt specialized lubricant
This electric treadmill’s running board and running belt has been lubricated in factory. Friction
between the running belt and running board has a great influence to the using life and the performance
of the electric treadmill, therefore regular applying of lubricant is needed. We advise you to check the
board regularly. If the board’s surface is damaged, please contact our customer service center.
We advise using lubricant between running belt and running board with following schedule:
Lightweight user (use less than 3 hours a week) once per month;
Heavyweight use (use more than 7 hours a week) once every half month.
1.In order to better safeguard your electric treadmill and extend the life of the machine, it is
recommended that after your continued use of two hours, turn off the machine and let it rest for 10
minutes before using again.
2.If the treadmill belt is too loose, there will be skid phenomenons while running; if it’s too tight, it
may reduces motor performance and harden the abrasion of roller and the running belt. You can lift
two sides of the running belt for 50-75mm when the tightness is appropriate.
Running with adjusted alignment and tightness
In order to better use the treadmill and make the treadmill functions work better, it is necessary for
you to adjust the running belt into the best condition.
Running Belt alignment
⚫Put electric treadmill flat on the ground.
⚫Make the electric treadmill run at a speed of about 6-8km/hour .
⚫If the running belt is closer to the right, rotate the right adjusting bolt with 1/2 turn clockwise,
then rotate the left adjusting bolt with 1/2 turn counter-clockwise. (Picture B)
⚫If the running belt is closer to the left, rotate the left adjusting bolt with 1/2 turn clockwise, then
rotate the right adjusting bolt with 1/2 turn counter-clockwise. (Picture A)
Picture A Picture B

12
Multi-wedge Belt Tension Adjusting
When you use the treadmill for a long time, the multi-wedge belt becomes loose because of the
abrasion, then you have to do some appropriate adjustment to facilitate the safe use.
Judgment: the feeling of running with the occasional pause phenomenon, which indicating that the
treadmill belt or multi-wedge belt are a little loose and further affirmation need to be made.
Method of judging which part is loose: Remove the four screws on protective cover, make the
treadmill run at a speed of 1 km/h, and then stand on the running belt, grip the handle, and tread the
treadmill belt slightly. (We advise treading the treadmill belts with the user's own weight)
A. The instantaneous step cannot stop the belt, the tightness is appropriate.
B. If your instantaneous step stops the running belt, but the multi-wedge belt and former roller is still
running, it indicates that the running belt is loose and appropriate adjustments must be made to
facilitate the safe use
C. If you observe that the instantaneous step makes the treadmill belt and multi-wedge belt stop, but
the motor is still running, it indicates that the multi-wedge belt is loose and appropriate adjustments
must be made to facilitate the the safe use
Step 2: Use a wrench to adjust the screws on the motor base according the the condition. Meanwhile,
gently flip the multi-wedge belt between the motor shaft and the front roller, if it is too loose, you can
flip the multi-wedge belt by 100%; if it is too tight, the degree for you to flip the belt is very limited. It
is appropriate to flip the multi-wedge belt by 80% after adjustment. Please adjust the tightness of the
multi-wedge belt into the state that it could be flipped by 80%.
Step 3: Finally lock the motor base, and install the front cover.
Applying silicone oil
Step 1: Lift the treadmill belt slightly.
Step 2: Open the silicone oil bottle, squeeze the silicone oil to the side of running board, as shown in
the following picture:

13
Scan QR code below to download cultsport App
cultsport tracks your Health data by connecting to your health equipment and your fitness band and tracking all your
health data in once place. The cultsport app tracks Exercise (steps), Calories burnt and Sleep besides other health
data. We connect to most fitness bands so our customers do not need to invest on another product. cultsport certified
panel of Nutritionists will interact (speak) and build customized plans for each customer. Our certified panel of
Fitness Experts will build customized plans of each customer based on their equipment and age/health. We keep all
your data in one place- on the cultsport app so that it can be referenced by you, your Coach or medical practitioners.
Customer Care Support
•Write to us: hello@curefit.com
•Website: www.cult.fit
•Contact No. 1800-572-6402/1800-572-6303
Table of contents
