Current MP410 User manual
(c)CURRENT,INC. www.crnt.co.jp 1
2-26-11 AKATSUTSUMI, SETAGAYA-KU, TOKYO, 156-0044 JAPAN TE :81-3-3321-9559 FAX:81-3-5376-2735
The specifications are s bject to change witho t notice.
CURRENT
MP410 MULTI HEADPHONE AMP
MAINS
010
HP LEVEL HEADPHONES MONITOR
123456 78910
MAINS:100VAC 50/60Hz
DISCONNECT INPUT POWER BEFORE REPLACING FUSE
FUSE
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
!
MODEL:MP410 SN_______
100VAC 50/60Hz, MAX25W
FUSE=250V 1A, IEC127 5x20mm
MADE IN JAPAN
CURRENT,INC.
PUSHPUSH
INPUT_L
THRU_L
INPUT_R
THRU_R
CURRENT PRODUCTS model:MP410
MULTI HEADPHONE AMP
10 distribution headphone
Super high-quality sound
High power
XLR through out is with it
19 inches 1U size
MP410 i the multi headphone amp which i available in 10
imultaneou ly. It provide powerful, clear ound by u ing
circuit configuration identical to SC8016A of the CUE y tem
for recording tudio where there i the reputation for
ound quality in the power amp ection and part .
"Line inp t"
The inp t of MP410 provides in the thro gho t with XLR connecter,
and the way of sing inserting on the way of a line is possible.
"Monitor"
There are 10 headphone jacks to front panel and can monitor 10
people sim ltaneo sly. A headphone level is only a master level.
"Others"
Please refer abo t the man fact ring of the type that level control is
possible individ ally.
AUDIO INPUTS: BA ANCED, 12kΩ
INPUTS CONNECTOR: X R3-F
MAXIMUM INPUT LEVEL: +24dBu
CONTROL: HEADPHONES EVE
HEADPHONES OUTPUT: 10
FREQUENCY RESPONSE: 20~20kHz, ±0.1dB
THD: < 0.01%
NOISE: < -90dBu
MAXIMUM OUTPUT: 2.5W at 50Ω
CONTROL: HP(MASTER) ,EXT MIX 1,2 EVE
MAINS: 100VAC 50/60Hz MAX 25W
DIMENSIONS: 482W x 44H x 303D 4kg
Headphones amp MP410 ¥248,000
accessory : AC cable
SPECIFICATIONS
(c)CURRENT,INC.
H.ICHIHASHI PANEL DIAGRAM
MP410 HEADPHONE DISTRIBUTOR MAY 98
MP410-D
482
44 302.6
CURRENT
MP410 MUTI HEADPHONE AMP
MAINS
010
HP LEVEL HEADPHONES MONITOR
12345678910
MAINS:100VAC 50/60Hz
DISCONNECT INPUT POWER BEFORE REPLACING FUSE
FUSE
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION !
MODEL:MP410 SN_______
100VAC 50/60Hz, MAX25W
FUSE=250V 1A, IEC127 5x20mm
MADE IN JAPAN
CURRENT,INC.
PUSHPUSH
INPUT_L
THRU_L
INPUT_R
THRU_R
