Currys ESSENTIALS CFSGSV16 User manual

GB
INSTRUCTION MANUAL
fRee STANdINg gAS COOkeR
CfSgSV16 / CfSgWH16
CFSGSV16_WH16_IB.indd 1 04/04/2016 17:43

2
Contents
Safety Warnings............................................................................................................................ 4
Unpacking..................................................................................................................................... 7
Installation .................................................................................................................................... 8
Adjusting the Feet ........................................................................................................................ 9
Moving the Cooker ....................................................................................................................... 9
Stability Bracket ........................................................................................................................... 9
Ventilation Requirements.......................................................................................................... 10
Gas Installation........................................................................................................................... 10
Installation and Service Regulations ........................................................................................ 10
Gas Connection........................................................................................................................... 11
Installation Relevant to Natural Gas ............................................................................................................... 11
Installation Relevant to Liquid Petroleum Gas (LPG)................................................................................11
To Connect the Gas Supply:...............................................................................................................................11
Replacement of Burner Injectors .............................................................................................. 12
To Replace the Hob Injectors ............................................................................................................................12
Adjusting the Reduced Flame Position ......................................................................................................... 12
To Replace the Oven/Grill Injectors ................................................................................................................13
- Removal of the Grill Burner Injector ....................................................................................................13
Adjusting the Reduced Flame Position ......................................................................................................... 13
- Removal of the Oven Burner Injector.................................................................................................. 13
Injector Size Table....................................................................................................................... 14
Lubrication of the Gas Taps ....................................................................................................... 14
Electrical Connection ................................................................................................................. 14
Product Overview....................................................................................................................... 15
Front View ................................................................................................................................................................ 15
Top View....................................................................................................................................................................15
Control Panel........................................................................................................................................................... 16
Gas Burners..............................................................................................................................................................16
Before Using Your Cooker .......................................................................................................... 16
Using the Hob Burners ............................................................................................................... 17
Flame Failure Safety Feature..............................................................................................................................17
If the Burner Does Not Light..............................................................................................................................18
If the Flame is Irregular........................................................................................................................................18
General Guidelines................................................................................................................................................ 18
CFSGSV16_WH16_IB.indd 2 04/04/2016 17:43

3
Using the Oven ........................................................................................................................... 20
First Time Use of the Oven .................................................................................................................................20
Oven/Grill Control .................................................................................................................................................20
Lighting the Oven .................................................................................................................................................20
Flame Failure Safety Feature..............................................................................................................................21
Shelf Positions.........................................................................................................................................................21
Replacing the Anti-tilting Oven Shelf ............................................................................................................21
Adjusting the Temperature................................................................................................................................21
Preheating................................................................................................................................................................22
Cooking.....................................................................................................................................................................22
Using the Grill ............................................................................................................................. 23
Lighting the Grill.................................................................................................................................................... 23
Cooking with the Grill..........................................................................................................................................24
Cleaning Instructions ................................................................................................................. 25
Cleaning the Outside of the Cooker...............................................................................................................25
Cleaning the Oven Door Glass..........................................................................................................................25
Cleaning the Inside of Your Oven .................................................................................................................... 25
Cleaning the Gas Hob ..........................................................................................................................................26
Hob Burner Parts and Pan Supports............................................................................................................... 26
Replacing the Hob Burner Parts....................................................................................................................... 26
Hob Controls (Gas Taps) ............................................................................................................. 27
Removing the Oven Door .......................................................................................................... 27
Hints and Tips ............................................................................................................................. 28
Replacing the Oven Lamp.......................................................................................................... 28
Product Fiche and Specications .............................................................................................. 29
Energy Saving Tips and Energy Label....................................................................................... 30
- Main Oven..................................................................................................................................................... 30
- Hob ..................................................................................................................................................................30
CFSGSV16_WH16_IB.indd 3 04/04/2016 17:43

4
Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
• This appliance must be installed by a qualied Gas Safe registered
engineer (in the UK). The manufacturer is not responsible for any
damage caused by incorrect installation.
• Check whether there is any damage to the appliance after you have
unpacked it. If any damage is found, do not use the appliance and
contact the store where you purchased it.
• This appliance is for indoor domestic use only.
• The cooker is tted with a moulded mains plug. The mains plug must
remain accessible or a switch providing full disconnection incorporated
in the xed wiring.
• If the mains cable gets damaged, it should be replaced by an authorized
service agent or qualied electrician in order to avoid a hazard.
• The oven must be installed on at/level ground.
• Only operate your appliance in a dry atmosphere.
• Keep the electrical cables of your other appliances away from hot areas;
do not let them touch the appliance.
• Ensure that the appliance is switched o at the mains supply switch and
allowed to completely cool down before cleaning, replacing the oven
lamp or performing any maintenance to avoid the possibility of an
electric shock or burns.
• The use of a gas cooking appliance results in the production of heat,
moisture and products of combustion in the room in which it is installed.
Ensure that the kitchen is well ventilated especially when the appliance
is in use. Keep natural ventilation holes open or install a mechanical
ventilation device (mechanical extractor hood).
• Prolonged intensive use of the appliance may call for additional ventilation,
for example opening of a window, or more eective ventilation, for
example increasing the level of mechanical ventilation where present.
CFSGSV16_WH16_IB.indd 4 04/04/2016 17:43

5
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory and mental capabilities, or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision.Cleaning and user maintenance shall not be made by
children without supervision.
• During use the appliance becomes hot. Care should be taken to avoid
touching the parts inside the oven or the hob burners/pan stands.
• The appliance and its accessible parts become hot during use. Care
should be taken to avoid touching heating elements. Children less than 8
years of age shall be kept away unless continuosly supervised.
• Unattended cooking on a hob with fat or oil can be dangerous and may
result in re. NEVER try to extinguish a re with water, but switch o the
appliance and then cover the ame e.g. with a lid or a re blanket.
• The cooking process has to be supervised. A short term cooking process
has to be supervised continuously.
• Danger of re: Do not store items on the cooking surfaces.
• When the oven is hot never touch the oven glass or any other parts that
get hot. Allow the oven to cool before touching these parts.
• Do not use harsh abrasives cleaners or sharp metal scrapers to clean the
oven door glass since they can scratch the surface, which may result in
the glass shattering.
• Before starting to use your appliance, keep curtains, tulle, paper or
ammable materials away from your appliance.
• Do not keep combustible or ammable things in, on or near the appliance.
• This appliance is for cooking purposes only. It must not be used for other
purposes, for example room heating.
• Do not use steam cleaners for cleaning the appliance.
• Do not rest any items on the open door and do not let children climb on
or stand on it.
• Take care when handling parts with glass, knocks, chips, heavy handling
and dropping could cause the glass to shatter.
CFSGSV16_WH16_IB.indd 5 04/04/2016 17:43

6
• The glass oven door uses toughened glass and is designed to break into
many‘nugget’ size pieces if it breaks. These pieces will still have sharp
edges, please handle broken glass with care.
• The appliance is not intended to be operated by means of an external
timer or separate remote-control system.
• This appliance is not designed to be used with hob guards. Use of
inappropriate hob guards can cause accidents.
• Do not install your appliance behind a decorative door it may over heat.
• The cooker must not to be used with an extension lead.
CFSGSV16_WH16_IB.indd 6 04/04/2016 17:43

7
Thank you for purchasing your new Currys Essentials Free Standing Gas Cooker.
You must read this manual in order to fully understand how to operate it correctly.
This unit MUST be installed by a competent and Registered Engineer (Gas Safe in the UK).
Please allow the installer to view the installation section of this manual.
Read all the safety instructions carefully before use and keep this manual for future reference.
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to local regulations.
The following items are included:
The Main Unit
Grill Pan x 1
Grill Rack x 1
Grill Pan Handle x 1 Stability Bracket x 1
Oven Tray x 1Oven Shelf x 1 Pan Supports (Left/Right) × 2
Large Burner Ring × 1
Large Burner Cap × 1
Standard Burner Ring × 2
Standard Burner Cap × 2
Small Burner Ring × 1
Small Burner Cap × 1
If items are missing or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
LPG Conversion Kit:
Fibre Washer x 1
LPG nozzles x 6
LPG Replacement Rating
Plate Sticker x 1
LPG Nozzle Installation
Guide x 1
Large Burner
Standard Burner x 2
Small Burner
Oven Burner
Grill Burner
Grill deector x 1
* All images are for indication only; please refer to your individual unit for actual item.
CFSGSV16_WH16_IB.indd 7 04/04/2016 17:43

8
Installation
• The cooker must be installed by a competent and Gas Safe Registered Engineer (in the UK) and in compliance
with local safety and building regulation safety standards.
• Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the
adjustment of the appliance are compatible. The adjustment conditions for this appliance are stated on the
label (or data plate).
• The cooker may be located in a kitchen, a kitchen/diner or bed-sitting room in accordance with the latest
editions of BS6172, BS5440-2 and BS6891, but not in a room containing a bath or shower. Please refer to the
local legislation/regulations to ensure location is permitted.
• If the cooker is installed adjacent to furniture which is higher than the gas hob, a gap of at least 100 mm must
be left between the side of the cooker and the furniture unless non-combustible materials (ceramic tiles, metal
backsplash etc.) are used which then allows this distance to be reduced to 20 mm.
• The furniture walls adjacent to the cooker must be made of heat resistant material (check with your furniture
supplier). The veneered synthetic material and the glue used must be resistant to a temperature of 100°C in
order to avoid ungluing or deformations.
• Flammable materials such as curtains, wood, wallpaper etc. must not be tted immediately behind the
appliance or within 500 mm of the sides.
• Do not place next to a refrigerator.
• This cooker must NOT be placed on a pedestal or base.
• It is essential that the cooker is positioned as stated or freestanding ensuring the distances to ammable
materials etc. are still observed.
• Any cooker hoods must be installed according to the requirements of the cooker hood instruction/installation
manual but no less than 650 mm.
• Any cupboards placed directly above the cooker must be no less than 700 mm away.
For all dimensions marked “X”, please refer to the information below:
X : 100 mm for combustible materials
20 mm for non-combustible materials.
500 mm
420 mm
700 mm
X
Cupboard
500 mm
420 mm
650 mm
X
Cupboard
Cooker Hood
* All images are for indication only; please refer to your individual unit for actual item.
CFSGSV16_WH16_IB.indd 8 04/04/2016 17:43

9
Adjusting the Feet
Your oven stands on 4 adjustable feet. When the oven is placed where it will be used, check if the oven is level. If it
is not level, you can adjust by turning the feet clockwise if required. It is possible to raise the appliance a maximum
of 30 mm by the feet. DO NOT move the appliance by dragging, it should only be moved by lifting it up.
Level the cooker by screwing the bottom of the feet in or
out, as shown.
Moving the Cooker
Stability Bracket
The supplied stability bracket or a recognized cooker stability device must be tted.
Using the tted adjustable feet is MANDATORY. For
safety reasons and to ensure adequate ventilation,
the cooker chassis MUST NOT sit directly on the
oor, a plinth, or other support surface.
• Two people must always raise the cooker, as shown, to
prevent damaging the adjustable feet.
• Do not lift the cooker by the door handles.
• DO NOT DRAG the cooker. Lift the feet clear of the oor.
50x60 : 420mm
Plastic Foot
Stability Bracket
Wall Plug
Washer
Screw
* All images are for indication only; please refer to your individual unit for actual item.
You can connect a stability
chain (not supplied) to the
screws shown here...
CFSGSV16_WH16_IB.indd 9 04/04/2016 17:43

10
Ventilation Requirements
• This appliance is not connected to a combustion products evacuation device. It should be installed and
connected in accordance with current installation regulations. Particular attention should be given to the
relevant requirements regarding ventilation.
• The appliance should be installed in a room or space with an air supply in accordance with the latest edition
of BS5440-2.
• For rooms with a volume of less than 5m3— permanent ventilation of 100cm2free area will be required.
• For rooms with a volume of between 5m3and 10m3a permanent ventilation of 50cm2free area will be required
unless the room has a door which opens directly to the outside air in which case no permanent ventilation
is required.
• For rooms with a volume greater than 10m3— no permanent ventilation is required.
Installation and Service Regulations
• Regardless of room size, all rooms containing the appliance must have direct access to the outside air
via a window that opens or equivalent.
• Where there are other fuel burning appliances in the same room, the latest edition of BS 5440-2 should
be consulted to determine the correct amount of free area ventilation requirements.
Gas Installation
This cooker uses and is ready to use NATURAL GAS only and cannot be used with any other gas without
modication. This appliance is manufactured for conversion to LPG after tting new injectors, new supply
hose and making adjustments. Refer to“replacement of burner injectors”section for details.
This appliance must be installed and serviced only by a suitably qualied and Gas Safe Registered
engineer, and in accordance with the current editions of the following standards and regulations or other
locally applicable regulations:
• Gas Safety (Installation and Use) Regulations
• Building Regulations
• British Standards (BS 5440, BS 6172 and BS 6891)
• Regulations for Electrical Installation (BS 7671, (Latest Edition))
CFSGSV16_WH16_IB.indd 10 04/04/2016 17:43
