Curtis IntelliFresh GEM5IF User manual

IntelliFresh®Satellite Stand
USER GUIDE
READ AND SAVE THESE INSTRUCTIONS
NOTICE TO INSTALLER: Please leave this booklet with the machine.
øøøøø $
'$(&.*'<5>'30/5$07&3 'SFW"
Style varies with model
See brewer user guide for brewing instructions

CONTENTS CL77
Important Safeguards............................................................................................................................................... IS8
Cleaning Instructions..............................................................................................................................................CI28
Rough-In Drawing (Single) ................................................................................................................................... RD77
Rough-In Drawing (Twin)...................................................................................................................................... RD78
Illustrated Parts/Recommended Parts.................................................................................................................. IP130
Electrical Schematic (Single, 120 Volt)................................................................................................................ES111
Electrical Schematic (Twin, 120 Volt)..................................................................................................................ES112
Electrical Schematic (Single, 220-240 Volt) ........................................................................................................ES110
Electrical Schematic (Twin, 220-240 Volt)...........................................................................................................ES113
Product Warranty....................................................................................................................................................PW1
Contact Information
Wilbur Curtis Co., Inc.
6913 Acco Street | Montebello, CA 90640 US
Phone: [phone] | Toll Free: 800-421-6150
Email: [email protected] | Web: www.wilburcurtis.com
'PSUIFMBUFTUTQFDJmDBUJPOTBOEJOGPSNBUJPOHPUPXXXXJMCVSDVSUJTDPN
5PMM'SFF].POEBZ'SJEBZA.M.- 4:00 P.M.PT
Email: [email protected]
%VFUPDPOUJOVFEQSPEVDUJNQSPWFNFOUUIFQSPEVDUTJMMVTUSBUFEQIPUPHSBQIFEJOUIJTHVJEFNBZWBSZTMJHIUMZGSPNUIFBDUVBMQSPEVDU
GEM5IF[T]$0/5&/54-*45øø  100419A

IMPORTANT SAFEGUARDS IS8
Symbols
This is the safety alert symbol. It is used to alert you to potential physical injury hazards. Obey all safety
messages that follow this symbol to avoid possible injury or death.
DANGER - Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING - Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION - Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTICE - Indicates a situation which, if not avoided, could result in property damage.
IMPORTANT - Provides information and tips for proper operation.
SANITATION REQUIREMENTS
Important Safeguards/Conventions
WARNING:
• Make sure that this unit is connected to a grounded electrical circuit when in use.
• This unit is designed for commercial use. Any service other than cleaning and preventive maintenance
should be performed by an authorized Wilbur Curtis service technician.
• 5PSFEVDFUIFSJTLPGmSFPSFMFDUSJDTIPDL%0/05PQFOUIFTFSWJDFQBOFMT5IFSFBSFOPVTFS
serviceable parts inside.
• Keep hands, arms and other items away from hot surfaces during operation.
• $MFBOUIFVOJUSFHVMBSMZBTJOTUSVDUFEJOUIF$-&"/*/(*/4536$5*0/4
• 6TFUIJTBQQMJBODFPOMZGPSJUTJOUFOEFEVTFTVQQPSUJOHQPXFSJOH*OUFMMJGSFTI®dispensers.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety. Children should
be supervised to ensure that they do not play with the appliance.
• Avoid spillage onto the power (mains) connector.
*/5&--*'3&4)%*41&/4&345"/%*.1035"/54"'&(6"3%44:.#0-4 E
WARNING - 5IJTQSPEVDUDBOFYQPTFZPVUPDIFNJDBMTJODMVEJOH"DSZMBNJEFBOE#JTQIFOPM"#1"
XIJDIBSFLOPXOUPUIF4UBUFPG$BMJGPSOJBUPDBVTFDBODFSBOECJSUIEFGFDUTPSPUIFSSFQSPEVDUJWFIBSN
'PSNPSFJOGPSNBUJPOWJTJUXXX18BSOJOHTDBHPW

IMPORTANT SAFEGUARDS IS8
*/5&--*'3&4)%*41&/4&345"/%*.1035"/54"'&(6"3%44:.#0-4 E
CE Requirements
• This appliance must be installed in locations where it can be overseen by trained personnel.
• 'PSQSPQFSPQFSBUJPOUIJTBQQMJBODFNVTUCFJOTUBMMFEXIFSFUIFUFNQFSBUVSFJTCFUXFFO¡$UP¡$
• This appliance is not suitable for outdoor use.
• "QQMJBODFTIBMMOPUCFUJMUFENPSFUIBO¡GPSTBGFPQFSBUJPO
• "OFMFDUSJDJBONVTUQSPWJEFFMFDUSJDBMTFSWJDFBTTQFDJmFEJODPOGPSNBODFXJUIBMMMPDBMBOEOBUJPOBMDPEFT
'PSTBGFVTFBOBMMQPMFEJTDPOOFDUJPONVTUCFJODPSQPSBUFEJOUPUIFmYFEXJSJOHJOBDDPSEBODFXJUIUIF
XJSJOHSVMFTPVUMJOFEJODMBVTFPG*&$GPSNFFUJOHUIFNJOJNVNFMFDUSJDBMTBGFUZPGUIJTTUBOEBSE
• This appliance must not be cleaned by water jet.
• This appliance can be used by persons aged from 18 years and above if they have been given supervision or
instruction concerning use of the appliance in a safe way and if they understand the hazards involved.
• Keep the appliance and its cord out of reach of children aged less than 18 years.
• Appliances can be used by persons 18 years and above with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
• Children under the age of 18 years should be supervised to ensure they do not play with the appliance.
• If the power cord is ever damaged, it must be replaced by the manufacturer or authorized service personnel
with a special cord available from the manufacturer or its authorized service personnel in order to avoid a
hazard.
• Machine must not be immersed for cleaning.
• Cleaning and user maintenance shall not be made by children unless they are older than 18 years and
supervised.
• This appliance is intended to be used in household and similar applications such as:
 oTUBGGLJUDIFOBSFBTJOTIPQTPGmDFTBOEPUIFSXPSLJOHFOWJSPONFOUT
 oCZDMJFOUTJOIPUFMTNPUFMTBOEPUIFSSFTJEFOUJBMUZQFFOWJSPONFOUT
– bed and breakfast type environments.
• This appliance not intended to be used in applications such as:
– farm houses
• "DDFTTUPUIFTFSWJDFBSFBTQFSNJUUFECZ"VUIPSJ[FE4FSWJDFQFSTPOOFMPOMZ
• 5IF"8FJHIUFETPVOEQSFTTVSFMFWFMJTCFMPXE#"

NOTICE -Do not use cleaning liquids, compounds or powders containing chlorine (bleach) or corrosives.
5IFTFQSPEVDUTQSPNPUFDPSSPTJPOBOEXJMMEBNBHFUIFmOJTIFT USE OF THESE PRODUCTS WILL VOID
THE WARRANTY.
CLEANING INSTRUCTIONS CI28
Cleaning the Satellite Stand - As Needed
INTELLIFRESH SATELLITE STAND, CLEANING INSTRUCTIONS 070717NC
WARNING: HOT SURFACES -To avoid injury, allow the satellite stand to cool before cleaning.
1 Disconnect the power cord or turn off power to the circuit supplying power at the circuit breaker panel.
2 Remove the satellite(s). Wipe exterior surfaces with a damp cloth to remove spills and debris. Dry with a soft
clean cloth.
3 Once dry, reconnect power.
WARNING: DO NOT immerse the satellite stand in water or any other liquid. Do not allow liquids to get
into the Intellifresh®connector during cleaning. To avoid an electric shock hazard, disconnect power.

ROUGH-IN DRAWINGS RD77
GEM5IF - Intellifresh Satellite Stand
GEM5IF, ROUGH-IN DRAWING 021518A
13.88 in
[35.3 cm]
9.36 in
[23.8 cm]
4.22 in
[10.7 cm]
9.24 in
[23.5 cm]
7.45 in
[18.9 cm]
11.65 in
[29.6 cm]
0.54 in
[1.4 cm]
13.63 in
[34.6 cm]

ROUGH-IN DRAWINGS RD78
GEM5IFT - Twin Intellifresh Satellite Stand
GEM5IFT, ROUGH-IN DRAWING 021518A
13.93 in
[35.4 cm]
9.40 in
[23.9 cm]
4.23 in
[10.7 cm]
18.27 in
[46.4 cm]
18.35 in
[46.6 cm]
7.45 in
[18.9 cm]
11.70 in
[29.7 cm]
0.54 in
[1.4 cm]
13.68 in
[34.7 cm]

ILLUSTRATED PARTS LIST IP130
GEM5IF[T], ILLUSTRATED PARTS/RECOMMENDED PARTS 100719B
GEM5IF[T] - Exploded View
GEM5IF[T] - Main Chassis - Parts List
ITEM # PART # DESCRIPTION
1 WC-38535 LABEL, SLIDE CONTAINER TO CONTACT BACK
PANEL GEMTIF/GEMSIF
2 WC-38504 LABEL, WARNING SHOCK HAZARD INTELLI-FRESH
3 WC-571K-R KIT, IF CONNECTOR- RIGHT
4A WC-61315K KIT, TOP COVER ASSY GEM5IF
4B WC-61382K KIT, TOP COVER ASSY GEM5IFT
5 WC-61307 HOLDER, CONNECTOR FEMALE GEMTIF
ITEM # PART # DESCRIPTION
6A WC-165aSWITCH, WARMER (RED) 120V NEON SPST 20A/250V
HI TEMP CAFE/AW
6B WC-166bSWITCH, WARMER (RED) 250V NEON SPST 20A/250V
HI TEMP CAFE/AW
6C* WC-135a,b SWITCH, ON/OFF (RED) 220V WRMR
7A WC-3503 LEG, 3/8”-16 STUD SCREW BUMPER
7B WC-3528 LEG, 4” ADJUSTABLE 3/8-16 THRD ITALIAN STYLE
7C WC-3512 LEG, 2 1/2’ ADJUSTABLE SATIN
1
2
4A
3
5
4B
7A
7B
7C
Single version shown
6A
6C
6B
*Older units a120 Volt versions b220-240 Volt versions

GEM5IF, GEM5XSIFT
ELECTRICAL SCHEMATICS ES111
Model Voltage
V
Amps
A
WaƩs
W
Hertz
Hz
# of
Conductor
Wires
Phase
# of
Elements
(Inside
GEM3IF)
Element
RaƟng
W/V
GEM5IFx 120 0.60 71 50/60 2 1 1 75W/120V
ELECTRICAL RATING TABLE
(&.*'&-&$53*$"-4$)&."5*$ø #

GEM5IFT, GEM5XTIFT
ELECTRICAL SCHEMATICS ES112
Model Voltage
V
Amps
A
WaƩs
W
Hertz
Hz
# of
Conductor
Wires
Phase
# of
Elements
(Inside
GEM3IF)
Element
RaƟng
W/V
GEM5IFTx 120 1.20 142 50/60 2 1 1 2x 75W/120V
ELECTRICAL RATING TABLE
(&.*'<5>&-&$53*$"-4$)&."5*$ø #
