Cushman Spraytek DS175 Guide

Safety & Operation
Manual
By Jacobsen
WARNING
If incorrectly used, this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its
dangers, and should read the entire manual before attempting to set up,
operate, adjust, or service the machine.
When Performance Matters.
™
GB
Spraytek®DS175 Sprayer
With Four Post Roll Over Protective Structure
84055 – Suzuki K6 Gas Engine, 5 Speed Manual Transmission
4140630-Rev A

2
CONTENTS
This manual contains safety and operating instructions
for your new Cushman utility vehicle. This manual should
be stored with the equipment for reference during
operation.
Before you operate your mower, you and each operator
you employ should read the manual carefully in its
entirety. By following the safety, operating and
maintenance instructions, you will prolong the life of your
equipment and maintain its maximum efficiency.
If additional information is needed, contact your
Cushman Dealer.
The serial plate is located on the frame rail under the
steering wheel. Cushman recommends you record these
numbers below for easy reference.
MODEL
DATE CODE
LABEL #
SERIAL #
xxxxx
CHARLOTTE, NC, USA
1 800 848 1636
Jacobsen.com
xxxxx
Lb/kg W Batt
Nom Power Hp/kw
xxxxxxxx
*xxxxxxxx*
FOREWORD
CONTENTS
1SAFETY
1.1 Operating Safety.................................................. 3
1.2 Important Safety Notes ........................................ 4
1.3 Chemical Handling, Use and Storage .................. 5
1.4 Recommended Safety Equipment ....................... 5
1.5 Work Area Safety Recommendations .................. 6
2 VEHICLE IDENTIFICATION NUMBERS
2.1 Vehicle Identification Number .............................. 7
2.2 Engine Identification Numbers ............................. 7
2.3 SDI Sprayer Tank Identification Numbers ........... 7
3DECALS
3.1 Decals.................................................................. 8
3.2 Information and Operation Decals ..................... 10
3.3 Speed Chart Decals ........................................... 10
4 CONTROLS
4.1 Icons .................................................................. 11
4.2 Control Descriptions .......................................... 13
4.3 Sprayer Control Systems ................................... 15
5 OPERATION
5.1 Daily Inspection ................................................. 17
5.2 Interlock System ................................................ 17
5.3 Operating Procedures ........................................ 18
5.4 Starting .............................................................. 19
5.5 Parking ............................................................... 19
5.6 To Drive Vehicle ................................................ 20
5.7 Engine Overheat Procedure .............................. 20
5.8 Towing the Vehicle ............................................ 21
5.9 Hillside Operation .............................................. 21
5.10 Tire Pressure ..................................................... 22
5.11 Daily maintenance ............................................. 22
6 SPRAYER OPERATION
6.1 Spray System Components............................... 23
6.2 Control Valves ................................................... 24
6.3 System Dynamics .............................................. 24
6.4 Sprayer System Check ...................................... 25
6.5 Sprayer Tank additives ...................................... 27
6.6 Calibration ......................................................... 28
6.7 Measuring Ground Speed ................................. 29
6.8 Nozzle Tip Size .................................................. 29
6.9 Determining Amount of Chemicals Required .... 31
6.10 Adding water to tank. ......................................... 32
6.11 Mixing Chemicals .............................................. 33
6.12 Sprayer Cleaning ............................................... 34
7NOTES
© Copyright 2009, Jacobsen, A Textron Company. “All rights
reserved, including the right to reproduce this material or portions
thereof in any form.”
Proposition 65 Warning
This product contains or emits
chemicals known to the State of
California to cause cancer and birth
defects or other reproductive harm.
Litho In U.S.A. 11-2009

SAFETY 1
3
1 SAFETY
1.1 OPERATING SAFETY ______________________________________________________
1. Safety is dependent upon the awareness, concern
and prudence of those who operate or service the
equipment. Never allow minors to operate any
equipment.
2. It is your responsibility to read this manual and all
publications associated with this equipment (Parts &
Maintenance Manual, Engine Manual, accessories,
and attachments). If the operator cannot read English it
is the owner’s responsibility to explain the material
contained in this manual to them.
3. Learn the proper use of the machine, the location and
purpose of all the controls and gauges before you
operate the equipment. Working with unfamiliar
equipment can lead to accidents.
4. Never allow anyone to operate or service the machine
or its attachments without proper training and
instructions or while under the influence of alcohol or
drugs.
5. Wear all the necessary protective clothing and
personal safety devices to protect your head, eyes,
ears, hands, and feet. Operate the machine only in
daylight or in good artificial light.
6. Evaluate the terrain to determine what accessories and
attachments are needed to properly and safely perform
the job. Only use accessories and attachments
approved by Jacobsen.
7. Stay alert for holes in the terrain and other hidden
hazards.
8. Inspect the area where the equipment will be used.
Pick up all the debris you can find before operating.
Beware of overhead obstructions (low tree limbs,
electrical wires, etc.) and also underground obstacles
(sprinklers, pipes, tree roots, etc.) Enter a new area
cautiously. Stay alert for hidden hazards.
9. Never allow anyone near the machine while in
operation. The owner/operator can prevent, and is
responsible for, injuries inflicted to themselves, to
bystanders, and damage to property.
10. Do not carry passengers. Keep bystanders and pets a
safe distance away.
11. Never operate equipment that is not in perfect working
order or is without decals, guards, shields, or other
protective devices securely fastened in place.
12. Never disconnect or bypass any switch.
13. Do not change the engine governor setting or
overspeed the engine.
14. Carbon monoxide in the exhaust fumes can be fatal
when inhaled. Never operate the engine without proper
ventilation or in an enclosed area.
15. Fuel is highly flammable; handle with care.
16. Keep the engine clean. Allow the engine to cool before
storing and always remove the ignition key.
17. Place transmission in Neutral, depress clutch and
engage parking brake before starting the engine
(motor). Start the engine only when sitting in operator’s
seat never while standing beside the unit.
18. Equipment must comply with the latest federal, state,
and local requirements when driven or transported on
public roads. Watch out for traffic when crossing or
operating on or near roads.
19. Local regulations may restrict the age of the operator.
20. Operate the machine up and down the face of the
slopes (vertically) not across the face (horizontally).
21. To prevent tipping or loss of control do not start or stop
suddenly on slopes. Reduce speed when making
sharp turns. Use caution when changing directions.
22. Always use the seat belt when operating vehicles
equipped with a Roll Over Protective Structure
(ROPS).
Never use a seat belt when operating vehicle
without a ROPS.
Accessory ROPS will continue to be offered for all
equipment currently covered. This allows for the
outfitting of any machines without previous ROPS
installations or replacement of damaged structures.
23. Keep legs, arms, and body inside the seating
compartment while the vehicle is in motion.
24. Always shift transmission to 1st Gear, engage parking
brake, and stop engine before leaving the vehicle.
25. Charge batteries in an open well ventilated area away
from spark and flames. Unplug charger before
connecting and disconnecting charger from battery.
Wear protective clothing and use insulated tools.
26. Disconnect the battery cables before performing any
welding operations on this vehicle.
WARNING
EQUIPMENT OPERATED IMPROPERLY OR BY UNTRAINED PERSONNEL CAN BE DANGEROUS.
Familiarize yourself with the location and proper use of all controls. Inexperienced operators should receive instruction
from someone familiar with the equipment before being allowed to operate the machine.
!

1 SAFETY
4
1.2 IMPORTANT SAFETY NOTES _______________________________________________
This safety alert symbol is used to alert you to potential hazards.
DANGER - Indicates an imminently hazardous situation which, if not avoided, WILL result in death or serious injury.
WARNING - Indicates a potentially hazardous situation which, if not avoided, COULD result in death or serious
injury.
CAUTION - Indicates a potentially hazardous situation which, if not avoided, MAY result in minor or moderate injury,
and property damage. It may also be used to alert against unsafe practices.
NOTICE - Indicates a potentially hazardous situation which, if not avoided, MAY result in property damage. It may
also be used to alert against unsafe practices.
For pictorial clarity some illustrations in this manual may show shields, guards or plates open or removed. Under no
circumstances should this equipment be operated without these devices securely fastened in place.
By following all instructions in this manual you will prolong the life of your machine and maintain its maximum efficiency.
Adjustments and maintenance should always be performed by a qualified technician.
If additional information or service is needed contact your Authorized Jacobsen Dealer who is kept informed of the
latest methods to service this equipment and can provide prompt and efficient service.
WARNING
The Interlock System on this vehicle prevents the vehicle from starting unless
the clutch pedal is depressed.
NEVER operate vehicle unless the Interlock System is working.
!
WARNING
1. Before leaving the operator’s position for any reason:
a. Remove foot from accelerator pedal.
b. Slow vehicle using service brake.
c. Depress clutch and shift transmission to 1st Gear.
d. Engage parking brake.
e. Stop engine and remove the ignition key.
2. Keep hands, feet, and clothing away from moving parts. Wait for all
movement to stop before you clean, adjust or service the machine.
3. Keep the area of operation clear of all bystanders and pets.
4. Never carry passengers unless a seat is provided for them.
!

SAFETY 1
5
1.3 CHEMICAL HANDLING, USE AND STORAGE ___________________________________
Chemicals are used in this sprayer and used in cleaning
after use. A manufacturers MSDS (Material Safety Data
Sheet) must be obtained from the chemical supplier for
each chemical, and a copy kept near the area that the
chemical is stored and used. Information listed on the
MSDS are the chemical characteristics and hazards
associated with its use. Special attention should be given
to recommended safety equipment, first aid treatment for
accidental inhalation, swallowing, absorption, or injection,
and compatibility with other chemicals. All sprayer
employees should know how to read an MSDS.
Use care when opening sprayer tank cover. Potentially
dangerous chemical fumes may have accumulated inside
tank.
Chemicals and cleaning solutions may be flammable or
produce flammable vapors. Do not smoke when working
with chemicals. Never store chemicals near an open
flame or spark which could ignite chemicals or chemical
vapors.
Never work alone with harmful chemicals . Always have a
second person nearby in case of emergency.
1.4 RECOMMENDED SAFETY EQUIPMENT________________________________________
Special safety equipment is required to prevent
accidental exposure to poisoning and should be worn at
all times when working with chemicals. Contact your
chemical supplier for proper material handling and
compatibility.
The following is strongly recommended, however other
safety equipment may be required. Always refer to the
chemical manufacturer’s MSDS (Material Safety Data
Sheet) that is available for all chemicals for additional
safety equipment that may be required.
Mask / Respirator - Prevents inhalation of harmful
fumes. Use an approved canister type with appropriate
filter cartridges for chemical being used.
Spray Suit - Full coverage for arms, legs, body, and free
from rips or tears.
PVC / Nylon Gloves - Protect hands and sleeve
openings.
Goggles - To cover eyes / glasses for better protection.
Face Shield - To prevent accidental facial contact with
chemicals.

1 SAFETY
6
1.5 WORK AREA SAFETY RECOMMENDATIONS __________________________________
Read this section carefully and thoroughly in order to
become familiar with the proper safety techniques
used when operating the sprayer.
Be sure to obtain an operation demonstration from your
Cushman dealer before attempting to operate this
vehicle.
The operator must be familiar with the function of all
vehicle controls as well as the operating characteristics of
the vehicle. This is best accomplished through careful
application of proper operating procedures.
The safety of the operator and bystanders depend on
the operator’s good judgement in operating and
maintaining this vehicle.
1. It is recommended that all spray technicians obtain a
CPA (Certified Pesticide Applicators) license or
equivalent. Operators should request, read, and
follow all appropriate federal, state, and local
regulations pertaining to spraying equipment,
chemical mixing, and storage.
Be informed not a
victim
.
2. We recommend a runoff recovery or containment
system for the mix and load area. If one is not
available be certain the runoff does not contaminate
water supplies, public sewers, or natural wet land
areas. Check your local regulations for requirements
in your area.
3. Do not allow non-sprayer personnel to enter the mix
and load area. All mix and load operations should
be performed only with proper safety equipment in
place. Refer to the chemical manufacturer’s MSDS
for required safety equipment, mixing, and handling
procedures.
4. Use an anti-backflow protection device on fill hoses
and water source outlets especially if using a public
water system. An air gap filler (anti siphon) is
available as an optional accessory for the Spraytek.
5. Never place fill hose into tank. This could
contaminate the hose.
6. Keep hands, feet, and other body parts away from
moving components. Restrain loose clothing and
use caution around moving parts.
7. Follow recommended safety and maintenance
schedules for this equipment. Do not operate this
equipment without safety devices in place or if the
equipment is not working correctly.
8. Keeping proper records in regards to chemicals
being used, batch size, time, date, areas treated,
weather conditions, and unusual occurrences can
protect you and others should any problems occur
after turf application has been made.
9. In case of an accident, injury, or unprotected
exposure notify your supervisor immediately. If
necessary, operator or supervisor should contact the
poison control board, EPA, and/or local fire
department to help with the situation.
WARNING
DO NOT operate this equipment until you have read
the operator’s manual completely. Operators must be
confident and sure of their skills before operating this
unit. Only properly trained persons with proper safety
equipment should be allowed to operate this vehicle.
Use caution when operating on slopes, turning, and
braking. Avoid full throttle starts. The large liquid
payload reacts differently during vehicle movement
than an equal sized dry load. This is heavy equipment
that could cause serious injury or death to the
operators and/or bystanders if used improperly or
overturned.
Never allow minors to operate the vehicle at any time.
!

VEHICLE IDENTIFICATION NUMBERS 2
7
2 VEHICLE IDENTIFICATION NUMBERS
2.1 VEHICLE IDENTIFICATION NUMBER __________________________________________
The Vehicle Identification Number (VIN), consisting of the
model number, date code, and serial number are all
printed on the Nameplate/Identification Decal attached to
the cross member under the dash.
The serial number is also stamped on the cross member.
It is located to the left of the Nameplate/Identification
Decal.
NOTE:
Reference to the Front, Rear, Left, and Right
sides of the vehicle are always determined by the
operator’s seated position.
Record the Vehicle Identification information below for
easy reference.
Model Number: ______________________
Date Code: _________________________
Serial Number: ______________________
Figure 2A
Always provide the Vehicle Identification Number of the
unit when ordering replacement parts or requesting service
information. Vehicle Identification Numbers must appear
on all correspondence concerning this vehicle.
2.2 ENGINE IDENTIFICATION NUMBERS _________________________________________
The Truckster is equipped with a Suzuki®three cylinder
gas powered, liquid cooled, four cycle engine.
The Engine Serial Number for the Suzuki engine is
stamped onto the upper engine block on the right side of
the engine, under the engine mount and may be partially
hidden by the electrical harness. The serial number is
also hand printed on the fuel rail.
Record the Engine Serial Number below for easy
reference.
Engine Serial Number: _________________________
Figure 2B
2.3 SDI SPRAYER TANK IDENTIFICATION NUMBERS _______________________________
The model number and serial number for the sprayer
tank is stamped on a name plate located on the front of
the sprayer frame, directly above the fuel tank.
Record the Sprayer Identification information below for
easy reference.
Model Number: _____________________
Serial Number: _____________________
Figure 2C
MODEL
DATE CODE
LABEL #
SERIAL #
84055
CHARLOTTE, NC, USA
1 800 848 1636
Jacobsen.com
M1903
Lb/kg W Batt
Nom Power Hp/kw
75984G55
*2128855*
Engine Serial No.
K6A Suzuki
Sprayer Model and
Serial No.

3 DECALS
8
3 DECALS
3.1 DECALS _________________________________________________________________
Familiarize yourself with the following decals. They are critical to the safe operation of the
machine. REPLACE DAMAGED DECALS IMMEDIATELY.
!WARNING
PARKING BRAKESARE NOT AUTO-
MATICALLY APPLIED. VEHICLE MAY
MOVE CAUSING PERSONAL INJURY
AND/OR PROPERTY DAMAGE. ALWAYS
APPLY HAND OR FOOT BRAKES.822819
!!
WARNING
Failure to follow thiswarningcan cause severe
personal injury or death.
Thisvehicle isdesigned and constructed for OFF-ROAD USE. Use
of thisvehicle on any public roadway where automobilesor other
motor vehiclesare present can be dangerousto the operator and
other drivers, passengersor bystanders.
29165G01
!WARNING
FAILURE TO HEED THESE
WARNINGSMAY RESULT IN
SERIOUSINJURY OR DEATH.
1. READ AND UNDERSTAND ALL LABELSAND THE OPERATOR’S MANUAL.
2. DO NOT ALLOW UNTRAINED PERSONNEL TO OPERATE THISVEHICLE.
3. DO NOT MODIFY THISVEHICLE WITHOUT MANUFACTURER’S AUTHORIZATION.
4. PLACE LOADSFOWARD OF REAR AXLE.
5. TOP HEAVY LOADSCAN CAUSE UPSETTING. DO NOT EXCEED PAYLOAD
CAPACITY.
6. DO NOT OPERATE IF REPAIRSARE REQUIRED.
7. KEEP ALL SHIELDSIN PLACE.
8. SHIFT INTO NEUTRAL OR PARK BEFORE STARTING ENGINE.
9. ONLY CARRY PASSENGERSIN SEATSPROVIDED.
10. WHEN PARKING (LEAVING) VEHILE, FOLLOW ALL INSTRUCTIONSIN
OPERATOR’S MANUAL.
11. AVOID SUDDEN STRATS, SOPSAND SHARP TURNSESPECIALLY ON SLOPES, OR
WITH HEAVY LOADS.
12. KEEP ALL LABELSAND INSTRUCTIONAL LITERATURE LEGIBLE AND INTACT.
13. KEEP ARMSAND LEGSWITHIN VEHICLE BODY.
845038
840754
!WARNING
Use seat belt
!WARNING
Thisstructure's
proctective capability
may be impaired by
structural damage,
overturn, or alteration.
If any of these
conditionsoccur, this
structure must be
replaced.
WARNING
To prevent serious bodily injury from hot coolant or steam blow-out, never
attempt to remove the radiator cap while the engine is running. Stop the engine
and wait several hours until it is cool. Even then, use extreme care when
removing the cap.
Located on Four Post
ROPS.

DECALS 3
9
PART NUMBER: 893146
4175340
MeetsSAE: J1040 MAY94
Only to be used on Cushman truck models
with matchinglower structure The protection offered by thisROPSwill be impaired if it has
been subjected to any modification or structural damage.
ThisROPSmust be replaced after a rollover. Seat beltsmust
be worn at all times.
Manufactured by JACOBSEN a Textron Company
11524 Wilmar Blvd. Charlotte NC 28273
! !
WARNING
009034880
STOP
2702014
THISCUSHMAN UTILITY VEHICLE DOESNOT COMPLY WITH
FEDERAL MOTOR VEHICLE SAFETY STANDARD 571.500 FOR
ON-ROAD USE. THISCUSHMAN UTILITY VEHICLE ISA
FIRST STAGE UNIT THAT CAN BE COMPLETED BY FINAL STAGE
MANUFACTURESFOR COMPLIANCE WITH FMVSS 571.500.
CUSHMAN AND TEXTRON MAKE NO WARRANTY FOR COMPLIANCE
OF THISUTILITY VEHICLE WITH ANY FEDERAL OR STATE
MOTOR VEHICLE SAFETY STANDARD.
821071
NOTICE
WARNING
The cooling fan is controlled by a temperature
switch and may start at any time coolant
temperature is above 150° F (65 ° C), even
with the ignition switch in the OFF position. Do
not attempt to service the cooling system
without first disconnecting the negative battery
cable or removing the fan fuse. WARNING
Read the vehicle’s manuals before attempting
to start or operate this vehicle.
Used only with Upper ROPS installed.

3 DECALS
10
3.2 INFORMATION AND OPERATION DECALS ____________________________________
Familiarize yourself with the following decals. They are critical to the safe operation of the
machine. REPLACE DAMAGED DECALS IMMEDIATELY.
3.3 SPEED CHART DECALS____________________________________________________
POWER
POINT
15
INSPANEL
FUEL RELAY
20
RADIATOR
FAN
25
HEAD LTS
TAIL LTS
15
ACCY
PLUG
10
MAIN RELAY
ENGINE
15
BRK LTS
5TH WHEEL BRAKE
10
HEATER
ACCY PLUG
10
BACK UP
ALARM
10
HORN
TURN SIGNAL
10
WIPER
DOME LT
10
ECU
10
4117221
FUSE PANEL
844177
Two Speed Differential Shifter
Fast Position
Neutral Position
Slow Position
4147585
1 2 34
RPM 2.7 4.6 7.311.0
2.84.87.6 11.4
2.9 4.9 7.811.8
3.0 5.1 8.1 12.2
3.1 5.38.312.6
3.2 5.4 8.6 13.0
3.35.6 8.9 13.4
3.4 5.89.1 13.8
2800
2900
3000
3100
3200
3300
3400
3500
3600 3.5 5.9 9.4 14.1
5
13.9
14.4
14.9
15.4
15.9
16.4
16.9
17.4
17.9
MPH
1 2 34
0.9 1.4 2.33.4
0.9 1.5 2.4 3.6
0.9 1.5 2.4 3.7
0.9 1.6 2.5 3.8
1.0 1.6 2.6 3.9
1.0 1.7 2.7 4.1
1.0 1.7 2.84.2
1.1 1.82.84.3
1.1 1.9 2.9 4.4
5
4.3
4.5
4.7
4.8
5.0
5.1
5.3
5.4
5.6
MPH
1 2 34
4.4 7.4 11.7 17.7
4.5 7.7 12.2 18.3
4.7 8.0 12.6 19.0
4.9 8.2 13.0 19.6
5.0 8.5 13.4 20.2
5.2 8.7 13.820.9
5.39.0 14.2 21.5
5.5 9.314.7 22.1
5.6 9.5 15.1 22.8
5
22.4
23.2
24.0
24.8
25.6
26.4
27.2
28.0
38.8
KPH
1 2 34
1.4 2.33.7 5.5
1.4 2.4 3.85.7
1.5 2.5 3.9 5.9
1.5 2.6 4.1 6.1
1.6 2.7 4.2 6.3
1.6 2.7 4.36.5
2.7 2.84.5 6.7
2.7 2.9 4.6 6.9
2.83.0 4.7 7.1
5
7.0
7.2
7.5
7.7
8.0
8.2
8.5
8.7
9.0
KPH

CONTROLS 4
11
4 CONTROLS
4.1 ICONS ___________________________________________________________________
WARNING
Never attempt to drive this vehicle unless you have read the Safety and Operation Manual
and know how to operate all controls correctly.
Familiarize yourself with the icons shown above and what they represent. Learn the
location and purpose of all the controls and gauges before operating this tractor.
!
STOP
Coolant
Temperature
Read Manual Engine Throttle
High Low
Hour Meter
Brake
Parking Service
Fuel Governor Control
Throttle Governor
Glow Plug
Ignition Switch
ACC OFF ON Start
Turn Indicators
Left Right
Engine Oil Pressure
High Beam
!

4 CONTROLS
12
Z
AA
AB
AC AD
AE
AF
V
W
X
NPY
Side Panel Rotated 90 Degrees
For Clarity
844116
RS
TU
STOP
2702014
M
E
14
F
0
050
HOURS
x 100
545
10
10
!
16
12 14
140 88
60 104 138
280
190 220
40
15 35
20 30
25
00000
34
12
F
C
COOLANT
A
BC
D
E
F
F
G
H
J
K
L
ATachometer
BHour Meter
CFuel Gauge
DVoltmeter
ETemperature Gauge
FTurn Signal Indicator
GOil Pressure Light
HGlow Plug Light
JService Brake Fluid Light
KParking Brake Light
LHigh Beam Indicator
MIgnition Switch
NGear Selector
PAccessory Power Plug
RHand Throttle
SGovernor Control
TLight Switch
UHorn Button
VClutch Pedal
WService Brake Pedal
XAccelerator Pedal
YSprayer Control Mount
ZParking Brake Lever
AA Differential Shift Cable
AB Sprayer Pump Switch
AC Agitation Control Handle
AD Boom/Hose Supply Valve
AE Boom Valve
AF Supply Valve

CONTROLS 4
13
4.2 CONTROL DESCRIPTIONS __________________________________________________
Figure 4A
A.
Tachometer
Indicates the engine speed (x 100) in revolutions per
minute (RPM).
B.
Hour Meter
Records the number of hours the unit has been
operated. The hour meter is active when the ignition
switch (M) is in the ON position.
C.
Fuel Gauge
Indicates the amount of fuel remaining in the tank.
Do not allow the tank to run dry.
D.
Voltmeter
The voltmeter indicates the voltage level of the
battery. Under normal operation it should display
between 12 and 18 volts. A reading below 12 volts
indicates the battery is not charging correctly and is
being drained.
E.
Water Temperature Gauge
Indicates engine coolant temperature. If temperature
rises above 230° F (110° C), a buzzer located under
dash will sound.
F.
Turn Signal Indicators
Used with optional turn signal kit. Left or
right indicators flash when turn signal lever
is moved to left or right position. Both
indicators will flash when hazard button is
pressed.
G.
Oil Pressure Light
Light will come on when ignition switch is
turned to on position and will go out once
engine starts. Do not continue to operate
truck if light does not go out, or comes on
during operation.
H.
Glow Plug Light
Does not have a function on this vehicle.
Glow plug light is used for diesel engines.
J.
Service Brake Fluid Light
Indicates low fluid level in master cylinder
reservoir. Fill with clean DOT 3 brake fluid.
K.
Parking Brake Light
Indicates parking brake is engaged. Do not
drive unit without disengaging parking
brake.
L.
High Beam Indicator
Indicates light switch (T) is in high beam
position.
Figure 4B
M.
Ignition Switch - The ignition switch has four
positions. ACC - OFF - ON - START.
ACC (Accessory) Position - Allows use of various
instruments and accessories without causing ignition
system damage.
OFF Position - Prevents function of all vehicle
electrical power operated features except for the
flasher (hazard), lights, and the radiator cooling fan.
Switch must be in OFF position for key removal.
ON Position - Key is placed in this position for
normal engine operation.
START Position - Hold key in start position to
engage engine starter. Upon release, key will return
to ON position automatically. Key must be returned to
the OFF position before the starter can be
reactivated.
E
14
F
0
050
HOURS
x 100
545
10
10
!
16
12 14
140 88
60 104 138
280
190 220
40
15 35
20 30
25
00000
34
12
F
C
COOLANT
A
BC
D
E
F
F
G
H
J
K
L
!
STOP
2702014
M
ACC
OFF ON
START

4 CONTROLS
14
N. Gear Selector
The gear selector is used to shift transmission into
desired gear. Refer to ground speed decal to
determine required gear.
Gear selector knob has the “H” shift pattern design
molded into the top surface.
Figure 4C
P.
Accessory Power Plug
Allows operation of approved 12 Volt accessories
and attachments. To prevent excessive battery drain,
only use 12 volt outlet with engine running.
Figure 4D
R.
Hand Throttle
Used to set engine speed for remote operations.
Increasing hand throttle speed will depress
accelerator pedal.
Never attempt to drive the vehicle with the engine speed
controlled by hand throttle.
S. Governor Control
Used to lower pre-set governor RPM limits for hand
and foot throttle operation.
Push lever all the way up to use pre-set RPM limit.
Pull lever down as required to lower maximum RPM.
T.
Light Switch
The light switch is used to turn the headlights and
taillight on. The switch has three positions, OFF,
LOW BEAM, and HIGH BEAM. Push switch up one
detent for LOW BEAM or push switch up two detents
for HIGH BEAM.
U.
Horn Button
The horn button is located to the left of the steering
wheel, below the dash panel. Depress to sound horn.
Horn will not sound when the ignition switch is in the
OFF position.
Figure 4E
V.
Clutch Pedal
Used to disengage the power output from engine to
transmission. This allows shifting of transmission
gears. Do not attempt to shift gears without fully
depressing clutch pedal.
The clutch pedal is equipped with an interlock switch.
This switch prevents the starter from operating
unless the clutch is disengaged (the clutch pedal is
depressed). See 5.2.
W.
Service Brake Pedal
Depress the pedal to slow or stop the vehicle.
If the brakes DO NOT stop the vehicle properly, the
brakes must be adjusted or repaired.
CAUTION
The 12 Volt Accessory outlet circuit is protected by a
15 Amp fuse. Do not attempt to use attachment(s)
with a combined power rating greater than 180 Watts.
To prevent the risk or burns or fire do not replace 15
amp fuse with a higher amperage rating fuse.
1
2
3
4R
“H” Shift
Pattern
!
844116
RS
TU
V
W
X
NPY

CONTROLS 4
15
X. Accelerator Pedal - Push pedal down to open
throttle (increase speed), release to return throttle to
idle position (decrease speed).
Y.
Sprayer Control Mount
Used to mount sprayer control.
Figure 4F
Z.
Parking Brake Lever
The park brake lever is located to the left side of the
drivers seat. Whenever using the parking brake, shift
transmission to 1st Gear, and shut off engine.
To engage the brake, pull up on the lever until park
brake is applied.
To release; while slightly pulling up on the handle,
push the button at the end of the lever and while
holding the button in, lower the lever to it's original
position.
AA.
Differential Shift Cable
Used to shift differential from LOW to
HIGH speed range. Do not shift
differential while vehicle is moving.
Push handle all the way down to shift
differential into LOW speed range.
Pull handle up all the way to shift
differential into HIGH speed range.
Placing handle in middle detent position places the
differential in NEUTRAL. Parking brake must be
engaged or service pedal depressed with differential
in NEUTRAL to prevent the vehicle moving.
Spraying operations must be performed with
differential in LOW speed range
AB.
Sprayer Pump Switch
Used to engage and disengage sprayer pump. Do
not allow pump to run dry. Permanent damage may
result.
AC.
Agitation Control Handle
Controls the amount of liquid passing through the
nozzles allowing complete agitation for mixing loaded
chemicals with carrier (water). It is recommended to
leave this valve fully open at all times even with low
tank liquid level.
AD.
Boom/Hose Supply Valve
Allows isolated use of either the hose reel or the
boom. The hose reel position allows hook-up to a
hand-held spray gun or walking type spray boom.
The boom position allows use of all spray boom
accessories.
AE.
Boom Valve
Needs to be open if the Boom/Hose Supply Valve
(AC) is in the boom position, if the selector valve is in
the hose reel position, this control valve needs to be
in the closed position.
AF.
Suction Valve
Needs to be in the open position for normal
operation. If the pump and/or the filter need servicing
or repair, this valve can be turned to the closed
position (with liquid in the tank) allowing these items
to be worked on.
4.3 SPRAYER CONTROL SYSTEMS______________________________________________
There are three different sprayer control systems that can
be used with this sprayer. The sprayer control systems do
not come with the Spraytek and must be ordered
separately.
All information pertaining to the set-up and installation of
the booms and control systems is furnished with the
accessory.
Z
AA
AB
AC AD
AE
AF

4 CONTROLS
16
SDI Control System with Motorized Valve __________________________________________________________
Cushman part number 4119052
1. Pressure Gauge (Boom Pressure)
2. Pressure Adjust Switch (Up/Down)
3. Master Boom (On/Off)
4. Boom 1 (Left Boom)
5. Boom 2 (Center Boom)
6. Boom 3 (Right Boom)
7. Power Switch
8. Foam Marker
9. Boom 1 Lift
10. Boom 2 Lift
11. Boom 3 Lift Figure 4G
Raven SCS330 Control System with Motorized Valve ________________________________________________
Cushman part number 4119056
1. Master Boom (On/Off)
2. Boom 1 (Left Boom)
3. Boom 2 (Center Boom)
4. Boom 3 (Right Boom)
5. System Select Power Switch
6. Rate Adjust/Override Switch
7. Rate/Data LCD Screen
8. Data Input Keypad
Figure 4H
Raven SCS440 Control System with Motorized Valve ________________________________________________
Cushman part number 4119057
1. Master Boom (On/Off)
2. Boom 1 (Left Boom)
3. Boom 2 (Center Boom)
4. Boom 3 (Right Boom)
5. System Select Power Switch
6. Rate Adjust/Override Switch
7. Rate Selector Switch
8. Data Input Keypad
9. Data LCD Screen
10. Rate LCD Screen Figure 4I
1
26
PSI
345
7
910 11
8
347
568
1
2
BOOM 1
CAL
BOOM 2
CAL
BOOM 3
CAL
SPEED
CAL
METER
CAL
FLOW
RATE
DISTANCE SPEED
CE
TOTAL
VOLUME
TOTAL
AREA
1234
5678
90
ENTER
MASTER BOOM 1 BOOM 2 BOOM 3
FLOW CONTROL
INC
DEC
ON
OFF
AUTO
MAN
OFF
RAVEN
Sprayer Control
SCS-330
1
9
BOOM 1
CAL
BOOM 2
CAL
BOOM 3
CAL
SPEED
CAL
METER
CAL
VALVE
CAL
RATE 1
CAL
RATE 2
CAL
TOTAL
VOLUME
TIME
1234
RATE DATA
567890
TOTAL
AREA
TOTAL
VOLU ME
FIELD
AREA
FIELD
VOLU ME
DISTANCE SPEED VOL/
MIN
AREA/
HOUR
DATA
MENU
SELF
TEST
CE ENTER
MASTERBOOM 1FLOW CONTROLPOWER BOOM 2 BOOM 3
ON
OFF
INC
RATE 1
RATE 2
MAN DEC
ON
OFF
234
56
7
8
10
R AVEN Sprayer Control SCS 440 NVM

OPERATION 5
17
5 OPERATION
5.1 DAILY INSPECTION ________________________________________________________
1. Perform a visual inspection of the entire unit, look for
signs of wear, loose hardware, and missing or
damaged components. Check for fuel or oil leaks to
ensure connections are tight and hoses and tubes
are in good condition.
2. Check the fuel supply, radiator coolant level,
crankcase oil, and air cleaner indicator. All fluids
must be at the full level mark with engine cold.
3. Check tires for proper inflation.
4. Test the Interlock System.
Note: For more detailed maintenance information,
adjustments and maintenance/lube charts, see the
Parts & Maintenance manual.
5.2 INTERLOCK SYSTEM ______________________________________________________
1. The Interlock System prevents the engine from
starting unless the clutch pedal is depressed.
2. Perform each of the following two tests to insure the
Interlock System is functioning properly. Stop the
test and have the vehicle inspected and repaired if
truck fails either test.
●the engine does not start in test 1;
●the engine does start during tests 2;
3. Perform actions described for each test. Shut
engine off between each test.
Test 1: Represents normal starting procedure. The
clutch pedal is depressed. The engine should start.
Test 2: The engine must not start if the clutch pedal
is not depressed.
CAUTION
The daily inspection should be performed only when
the engine is off and all fluids are cold. Engage the
parking brake, stop engine, and remove ignition key.
!
WARNING
Never operate equipment with the Interlock
System disconnected or malfunctioning. Do not
disconnect or bypass any switch.
Never turn the key to the START position unless
the clutch pedal is depressed (pushed down) or
the gear selector is in neutral. If the vehicle is in
any gear other than neutral, and the clutch pedal
is not depressed when the engine is started, the
vehicle may lurch forward or backward depending
which gear the vehicle is in. This lurching could
cause serious personal injury or death.
!

5 OPERATION
18
5.3 OPERATING PROCEDURES_________________________________________________
1. Under no circumstances should the engine be
started without the operator seated in the vehicle.
2. Do not operate utility vehicle or attachments with
loose, damaged, or missing components. Whenever
possible spray when grass is dry.
3. Never remove or install the engine cover while the
engine is running. The engine cover is a
machinery
guard
and its removal exposes you to moving parts.
Keep hands, hair, and clothing away from flywheel,
radiator cooling fan, alternator fan, engine belts,
pulleys, and air intake.
4. First spray using water in a test area to become
thoroughly familiar with the operation of the truck
and sprayer.
5. Study the area to determine the best and safest
operating procedure. Consider the type of terrain,
and condition of the surface. Each condition will
require certain adjustments or precautions.
6. Never direct discharge of material toward
bystanders, nor allow anyone near the machine
while in operation. The owner/operator is
responsible for injuries inflicted to bystanders and/or
damage to their property.
7. Always turn pump switch off when not spraying.
8. Disengage the sprayer pump and raise the booms
when crossing paths or roadways. Look out for
traffic.
9. Stop and inspect the equipment for damage
immediately after striking an obstruction or if the
machine begins to vibrate abnormally. Have the
equipment repaired before resuming operation.
10. Slow down and use extra care on hillsides. Read
Section 5.9. Use caution when operating near drop
offs.
11. Look behind and down before backing up to be sure
the path is clear. Use care when approaching blind
corners, shrubs, trees, or other objects that may
obscure vision.
WARNING
A Rollover Protection Structure (ROPS) for this utility vehicle is included as standard equipment. Seat belts must be
worn whenever a ROPS is installed on the vehicle. Always keep seat belt snugly adjusted. DO NOT use seat belts
on a utility vehicle without a ROPS.
If a ROPS is installed and the vehicle is overturning, hold onto the steering wheel. Do not attempt to jump out or
leave the seat.
!
CAUTION
To prevent injury, always wear safety glasses, leather work shoes or boots, a hard hat, and ear protection. Wear any
protective equipment recommended by the chemical manufacturer.
!
WARNING
Failure to latch the engine cover properly can result in
the engine cover tipping forward causing loss of
control of the vehicle and possible personal injury.
!
CAUTION
Before spraying, pick up all debris such as rocks, toys,
and wire which can be thrown by the machine. Enter a
new area cautiously. Always operate at speeds that
allow you to have complete control of the sprayer.
WARNING
Before you clean, adjust, or repair this equipment,
always disengage sprayer pump, lower booms to the
ground, engage parking brake, stop engine, and
remove key from ignition switch to prevent injuries.
!
!

OPERATION 5
19
5.4 STARTING________________________________________________________________
IMPORTANT: Do not use starting assist fluids. Use of
such fluids in the air intake system may be potentially
explosive, or cause a “Runaway” engine condition and
could result in serious engine damage.
1. Make sure fuel shut off valve is completely open.
2. Sit in operator’s seat, make sure the parking brake
is engaged, and transmission is in neutral.[See 4.2]
3. Depress clutch pedal. [See 4.2 and 5.2]
4. Turn ignition switch (M) to ON position.
a. Engine Oil light (G) will come on and will stay on
until engine starts.
b. Parking brake light (K) will be on when parking
brake is engaged.
5. Turn key (M) to START position. Release as soon
as engine starts. Do not hold switch in the START
position for more than 15 seconds. Make sure
engine oil light (G) turns off.
6. Allow the engine to become warm and properly
lubricated before operating at high RPM.
Figure 5A
5.5 PARKING_________________________________________________________________
To park the utility vehicle under normal conditions:
1. Disengage the sprayer pump switch, raise the
booms, and move away from the area of operation.
2. Select a flat and level area to park.
a. Remove your foot from foot throttle, apply service
brake, and depress clutch pedal.
b. Once vehicle has stopped, shift transmission to
Neutral, and apply the parking brake. Allow
engine to operate at no load for a minute.
3. Stop the engine and always remove the ignition key.
If an emergency arises and the utility vehicle must be
parked in the area of operation, follow the guidelines
outlined by the grounds superintendent. If the utility
vehicle is parked on an incline, chock or block the
wheels.
E
14
F
0
050
HOURS
x 100
545
10
10
!
16
12 14
140 88
60 104 138
280
190 220
40
15 35
20 30
25
00000
34
12
F
C
COOLANT
A
BC
D
E
F
F
G
H
J
K
L
STOP
2702014
M
ACC
OFF ON
START

5 OPERATION
20
5.6 TO DRIVE VEHICLE ________________________________________________________
Read and follow all safety notes contained in this manual
when driving vehicle. Refer to Section 5.3 for general
operating instructions. When operating in reverse look
behind you to ensure you have a clear path.
Important: If this truck is driven on public roads, it must
comply with federal, state, and local ordinances. Contact
local authorities for regulations and equipment
requirements.
1. Disengage sprayer pump switch and raise booms to
when driving to and from the area of operation.
2. Apply service brake and disengage parking brake.
3. The gear selector has an "H" pattern (there is also a
shift-pattern design molded into the top of the gear
selector handle).
4. With the clutch pedal fully depressed, select the
appropriate gear (forward or reverse), release the
clutch pedal slowly while depressing the throttle
pedal.
NOTE:
As you release the clutch pedal you will notice
after the pedal has been partially released the vehicle will
begin to move. When the vehicle begins to move,
depress the throttle a little more and at the same time
keep releasing the clutch pedal. DO NOT drive with the
clutch pedal partially depressed.
5. When the vehicle gains enough speed, depress the
clutch pedal and shift to the next higher gear and so
on. When you shift gears remember that as you
push in the clutch you need to release the throttle
pedal. DO NOT push in the accelerator at the same
time you are pushing in the clutch while shifting to a
higher or a lower gear (downshifting).
6. You can down-shift from 4th to 3rd and from 3rd to
2nd and so on while the vehicle is moving and the
engine's speed is decreasing.
NOTE:
Only downshift if the vehicle is at a complete stop
or if the engine's speed is decreasing.
Remember, before shifting to any gear you have to
depress the clutch pedal before you shift to that
particular gear.
5.7 ENGINE OVERHEAT PROCEDURE ___________________________________________
During vehicle operation, if the water temperature gauge
shows 230° F (110° C) or above, and/or the overheat
warning buzzer sounds, follow this procedure.
1.
Stop the vehicle. DO NOT shut the engine off.
Place vehicle in neutral and engage the parking
brake.
2. Immediately disengage any accessories that are
operating.
3. Slow the engine speed to a fast idle.
4. Remove any dirt, chaff, debris, etc. from the radiator
intake screen located on the right side of the
vehicle.
Temperature gauge needle should start to go down
approximately 30 seconds after the screen is cleaned. If
temperature does not go down, STOP the engine and
check the following.
1. Check to see if cooling fan is operating. Fan should
be turning with coolant above 180° F, even with
ignition switch in OFF position.
2. Check engine oil level.
3. Check for a leak in the cooling system. Do not open
radiator when hot. Check coolant levels after system
completely cools.
Failure to heed the overheat warning and properly
maintain the cooling system will cause permanent
engine damage.
CAUTION
To prevent tipping or loss of control, travel at reduced
speed when making turns.
!
CAUTION
Be careful when opening the engine access cover or
cleaning the intake screen. Metal surfaces near the
radiator and engine may be hot to the touch. Use a
brush or gloves to clean screen.
!
