CyberData 011472 User manual

Quick Start Guide 931512B
The IP Endpoint Company
1.0 Out-of-Box and Prior to Final Installation
3.1. Verify that you have received all of the parts listed on the Installation Quick
Reference placemat.
3.2. Download the current manual, otherwise known as an Operations Guide,
which is available in the Downloads tab at the following webpage:
https://www.cyberdata.net/products/011472
Note You can also navigate to the Downloads tab by going to
www.CyberData.net and following the steps that are indicated by
the following figures:
2.0 Select Power Source
IEEE 802.3af or 802.3at PoE Switch IEEE 802.3af or 802.3at PoE Injector
Set PoE power type to Class 0 = 15.4W
OR
for high power PoE+ set Class 4 = 30W
CAT6 cable recommended—
for longer distances
Be sure you are using a non-PoE switch or port
Make sure port is not in trunk mode
Set port to full duplex/ 100mbps
Spanning Tree Protocol (STP) must be disabled or Portfast enabled
1
3
2
OUR PRODUCTS
VOIP PRODUCTS
A
B
011472 INFORMACAST ENABLED
Downloads
IP66 OUTDOOR HORN
INFORMACAST ENABLED
C
InformaCast Enabled IP66 Outdoor Horn
Quick Start Guide

Quick Start Guide 931512B
3.0 Power Test
3.1. Plug in the CyberData device and monitor the LED activity on the bottom
side of the horn during the initialization process. See the following figure:
3.2. After about 20 seconds, the GREEN Status LED will blink fast to indicate
that the device is acquiring an IP address and attempting to autoprovision.
It will turn off thereafter until the device has finished booting. When the
device has fully booted, the GREEN Status LED will turn on solid.
If there is no DHCP server available on the network, it will try 12 times for
60 seconds and eventually fall back to the programmed static IP address
(by default 10.10.10.10) or the previously used DHCP address if a prior
lease was established. This process will take approximately 80 seconds.
3.3. When the device has completed the initialization process, pressing and
holding the RTFM switch for a couple of seconds will announce the IP
address.
Note The RTFM button access will be on the top side of the horn hidden under a
screw that will be used to keep the unit secured. Remove the screw to gain
access to the RTFM button. Use a paper clip to feed through the hole to
press the RTFM button. See the figure above.
This concludes the power test. Go to Section 4.0, "InformaCast
Configuration File Retrieval".
Status LED
Cover screw
RTFM access
Bottom Side of the Horn
Top Side of the Horn

Quick Start Guide 931512B
4.0 InformaCast Configuration File Retrieval
4.1. DHCP should be enabled. After the device initializes, it will send a
broadcast to the DHCP server to ask for the location of its
InformaCastSpeaker.cfg configuration file.
4.2. SLP or TFTP?
•SLP should be enabled on InformaCast version 5.0.4 or higher. SLP is an
InformaCast protocol introduced in InformaCast version 5.0.4. The device
will retrieve its configuration file from an InformaCast server folder
specified by SLP. SLP method is preferred.
•TFTP servers may be used instead of SLP. In this alternate scenario,
DHCP option 150 is required to provide the device with the address of the
TFTP server. Otherwise, the device will be unable to retrieve its
configuration file.
Note The device and InformaCast server should be on the same
subnet during the device's initial configuration if it cannot access
the VLANs upon which the InformaCast Server and DHCP
servers are located. It may be necessary to manually configure
your switch port to allow access to the VLAN.
5.0 Device Identification and Testing
5.1. Ensure the InformaCast Server has detected a new device.
5.2. Test the newly detected device.
5.3. Add the newly detected device to the InformaCast Server.

Quick Start Guide 931512B
6.0 Contacting CyberData VoIP Technical Support
You are welcome to call CyberData VoIP Technical Support at 831-373-2601
x333. Business hours are 7:00 AM - 5:00 PM Pacific Time, Monday through
Friday.
We encourage you to access our Technical Support help desk at the following
address:
http://support.cyberdata.net/
Note You can also access the Technical Support help desk by going to
www.CyberData.net and clicking on the SUPPORT menu.
The Technical Support help desk provides the options of accessing
documentation for your CyberData product, browsing the knowledge base, and
submitting a troubleshooting ticket.
Please be advised requests for Returned Materials Authorization (RMA) numbers
require an active VoIP Technical Support ticket number. A product will not be
accepted for return without an approved RMA number.
