CyberData 011472 Manual

Quick Reference 931962A © 2022, CyberData Corporation, ALL RIGHTS RESERVED© 2022, CyberData Corporation, ALL RIGHTS RESERVED 931962A Quick Reference
RTFM Switch
Contacting CyberData
1.0" [25 mm]
Dimensions are in Inch [Millimeters]
Paper Clip
RTFM
Cover Screw
RTFM Access
The RTFM switch access will be on the top side of the horn hidden under a screw that will be used to keep the unit IP66
sealed with the gasket washer. To access the RTFM, complete the following steps:
1. Remove the RTFM cover screw to gain access to the RTFM switch (see the figure below).
2. Use a paper clip to feed through the hole to press the RTFM switch (see the figure below).
Announce the IP Address
To broadcast the device’s current IP address, press and hold the RTFM switch for a couple of seconds and then release
it.
Restore the Factory Default Settings
To restore the factory defaults, complete the following steps:
1. Press and hold the RTFM switch until you hear the device announce the words, “restoring defaults” and “rebooting”.
2. Release the RTFM switch. The device will be restored to the factory default settings.
Sales: 831-373-2601 ext. 334
Support: 831-373-2601 ext. 333
Support Website: https://support.cyberdata.net/
RMA Department Contact and Status: https://support.cyberdata.net/
Warranty Information: https://support.cyberdata.net/
Corporate Headquarters
CyberData Corporation
3 Justin Court
Monterey, CA 93940, USA
Phone: [phone]
Fax: [phone]
https://www.cyberdata.net/
Typical System Installation
Getting Started
• Download the Operations Guide PDF file from the Documents tab at the following webpage:
https://www.cyberdata.net/products/011472
• Create a plan for the locations of your paging amplifiers.
• WARNING: This product should be installed by a licensed electrician according to all local electrical and building codes.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation
instructions.
• WARNING: The PoE connector is intended for intra-building connections only and does not route to the outside plant.
• WARNING: The InformaCast Enabled IP66 Indoor / Outdoor Horn enclosure is not rated for any AC voltages!
Parts
Parameter Factory Default Setting
IP Addressing DHCP
IP Addressa
a. Default if there is not a DHCP server present.
192.168.1.23
Web Access Username admin
Web Access Password admin
Subnet Maska255.255.255.0
Default Gatewaya192.168.1.1
*See the Operations Guide for more
installation options.
802.3at Compliant PoE Switch
VoIP Phone InformaCast ServerInformaCast Enabled
IP66 Outdoor Horn
(1) Assembly
The IP Endpoint Company
Installation Quick Reference
InformaCast Enabled IP66 Indoor / Outdoor Horn
011472

© 2022, CyberData Corporation, ALL RIGHTS RESERVED 931962A Quick Reference Quick Reference 931962A © 2022, CyberData Corporation, ALL RIGHTS RESERVED
Dimensions
6.772 [172]
14.404 [366]
6.730 [171]
2.008 [51]
4.016 [102]
Ø0.433 [Ø11]
(3 Places)
1.457 [37]
10.630 [270]
9.291 [236]
RTFM
Status LED
Dimensions are in Inches [Millimeters]
DIMENSIONS ARE IN
INCHES [MILLIMETERS]
With screws, dimensions
are approximate.
Install the Network Cable Through Weatherproof Cable Gland
Network Cable Gland
Weatherproof
Socket
RJ45
Plug
RJ45
Critical areas for the installation to preserve the IP66 rating of the speaker.
Gasket must be preserved and all threaded components must be tightened.
Critical areas for the installation to preserve the IP66 rating of the speaker.
Gasket must be preserved and all threaded components must be tightened.
The rubber gasket must be
oriented and installed correctly
if these bolts are removed.
These parts also have sealing
washers that must be tight.
