CyberData Wall Mount Adapter User manual

CyberData Corporation 2555 Garden Road Monterey, California 93940
[phone] [phone] www.cyberdata.net
CyberData Corporation
Wall Mount Adapter
Exploded View
11.4
[290mm]
4.9
[124mm]
10.5
[51mm]
inches
[ mm ]
Overall Dimensions
Wall Mount Adapter
The Wall Mount Adapter enables the CyberData VoIP Ceiling
Speaker for indoor wall mounting. The front plate is angled for
downward sound dispersion.
Ordering information:
When ordering CyberData’s VoIP Ceiling Speaker (PN: 010844)
with the Wall Mount Adapter (PN: 010882), please specify both
items by part number.
Features:
 Easy wall or ceiling installation
 Mounting kit included
 Electrogalvinized steel construction
 RoHS compliant
 Keyhold for easy installation
 Part number: 010882
 Top and bottom cable channels
 Two years warranty
IP Wall Speakers
Typical Installation
Generic PoE Hub
IP-PBX Server
IP Phone
1 2 3 4 5 6
CyberData Corporation Innovative Concepts in Peripheral Connectivity. 930198A/071203
