CyberHome DVD 1530 User manual

-
CH DVR 1530 DVD RECORDER WITH PROGRESSIVE SCAN PLAYBACK
ON / STANDBY
UP
DOWN
LEFT
TM
S-VIDEO IN 2 VIDEO IN 2
LRAUDIO
DVD / TV LIVE
SOURCE
RECORD
ENTERRIGHT
DV IN
CHANNEL
1 2 3
4 5 6
7 8 9
0 C
TM
DVD/TV LIVE SOURCE
ANGLE
CH-
CH+
REC MODE
REC CHAP MARK
PIP
PLAY
GOTO SUBTITLE MUTE
AUDIO DISPLAY
TIMER
ENTER
REC REC
TM
JPG
PROGRESSIVE
SCAN
CH-DVD 1530 DVD Recorder
With Progressive Scan Video Playback
Operation Guide
+
Quick
Startup
Guide
Page 15

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
!
!
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
servicing instructions in the literature
accompanying the appliance.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of not isolated
dangerous voltage within the inside of the
product that may be sufficient magnitude to
constitute a risk of electric shock to persons.
WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR ANNOYING INTERFERENCE, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE AND
ONLY USE THE RECOMMENDED ACCESSORIES.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE THE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED
SERVICE PERSONNEL FOR SERVICING.
2
!Read these instructions - When using this unit, basic
precautions outlined in this section should always be followed.
!Keep these instructions - Retain this user manual for future
reference.
!Heed all warnings - Follow all warning labels on the product,
and the safety instructions in this manual.
!Follow all instructions - Adhere to the instructions outlined in
this manual and on the unit.
!Clean only with a dry cloth - Unplug the unit before cleaning.
Do not use any liquid or detergents for cleaning.
!Do not block any ventilation opening. Install in accordance with
the manufacture's instructions.
!Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
!Do not defect the safety purpose of the polarized plug. A
polarized plug has two blades with one wider than the other.
The wide blade is provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
!Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
!Only use attachments / accessories specified by the
manufacturer.
!The apparatus shall not be exposed to dripping or splashing
and no objects filled with liquids, such as vases, shall be
placed on the apparatus.
!Do not put foreign objects in the disc tray.
!Keep away from water and magnets.
!Keep the unit away from flower vases, tubs, sinks, etc. If
liquids are spilled into the unit, serious damage could occur.
Important Safety Instructions Safety
!Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart / apparatus combination to
avoid injury from tip-over.
!Unplug this apparatus during lightning storms or when unused
for long periods of time.
!Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as when the power-supply cord or plug is damaged, liquid
has been spilled, objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, or when the
unit does not operate normally, or has been dropped.
!Power cord protection - To avoid any malfunctions of the unit
and to protect against electric shock, fire or personal injury,
please observe the following:
!Hold the plug firmly when connecting or disconnecting the AC
power cord to this unit.
!Keep the AC power cord away from heating appliances.
!Do not connect or disconnect the AC power cord with wet
hands.
!Never put any heavy object on the AC power cord.
!Do not attempt to repair or reconstruct the AC power cord in
any way.
!Remove dust, dirt, etc. on the plug at regular intervals.
!If the unit has been dropped or otherwise damaged, turn off the
power and disconnect the AC power cord.
!If smoke, odors or noises are emitted from the unit, turn off the
power and disconnect the AC power cord.
!Placement - Avoid placing the unit in areas of direct sunlight,
heating radiators, closed automobiles, high temperature (over
35 C (95 F)), high humidity (over 90%), excessive dust,
vibration, impact or where the surface is tilted, as the internal
parts may be seriously damaged.
!Non-use periods - When the unit is not used, turn the power
off.
!When the unit is unused for a long period of time, the unit
should be unplugged from the household AC outlet.
!No fingers or other objects inside - Touching internal parts of
this unit is dangerous and may cause serious damage to the
unit. Do not attempt to disassemble the unit.
!Keep magnetic objects, such as speakers, distant from the
player.
!Stacking - Place the unit in a horizontal position and do not
place anything heavy on it.
!Do not place the unit on amplifiers or other equipment which
may become hot.
!Condensation - Moisture may form on the lens in the following
cases: a) Immediately after a heater has been turned on. b) In
a steamy or very humid room c) the unit is moved from a cold
environment to a warm one.
!If moisture forms inside this unit, it may not operate properly. In
this case, turn off the power and wait about one hour for the
moisture to evaporate.
!Noise interference while a broadcast is being received -
depending on the reception condition of the TV, interference
may appear on the TV screen while you are watching a TV
broadcast, if the unit is switched on. This is not a malfunction
of the unit or the TV. To watch a TV broadcast, turn off this unit.
!Caution - Use of controls or adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
SAVE THESE INSTRUCTIONS
Explanation of Warning Symbols
Safety Instructions

This product incorporates copyright protection
technology that is protected by method claims of
certain U.S. Patents and other intellectual property
rights owned by Macrovision Corporation and other
rights owners. Use of this copyright protection
technology must be authorized by Macrovision
Corporation, and is intended for home and other
limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
Manufactured under license from Dolby
Laboratories. "Dolby", "Pro Logic" and the double-D
symbol are trademarks of Dolby Laboratories.
Confidential Unpublished Works.
1992-1997 Dolby Laboratories, Inc. All rights
reserved.
Consumers should note that not all high definition
television sets are fully compatible with this product
and may cause artifacts to be displayed in the
picture. In case of 525 progressive scan picture
problems, it is recommended that the user switch
the connection to the 'Standard Definition' output. If
there are questions regarding our TV set
compatibility with this model 525p DVD player,
please contact our customer service center.
Notes on Copyright Copyrights
3

WDON
T B
ONAD
/S Y
N
MT
UP EEN
TR
T
SEUP
EVO
S I D -UI
O
L DR
-A -VE
I O
D
- VR 1530 RDER T G A
CH DDVD RECO WI H PRO RESSIVE SCAN PL YBACK
RD
RECO
E
DVD/TV IV
L
URCESO
1 2 3
4 5 6
7 8 9
0 C
TM
DVD/TV LIVE SOURCE
ANGLE
CH-
CH+
REC MODE
REC CHAP MARK
PIP
PLAY
GOTO SUBTITLE MUTE
AUDIO DISPLAY
TIMER
ENTER
REC REC
The CH-DVR 1530 is a DVD Recorder/Player with Progressive Scan Video Output. DVD+R/RW Recording gives
you the ability to create your own DVD discs from your home movies, favorite TV programs and more. Because of
the outstanding compatibility of DVD+R/RW discs, the discs you create will be suitable for playback in most DVD
players.
You can record from the unit's built-in TV Tuner or an external video source like a video camera. And when you're
ready to watch your recordings or commercial DVDs, you can enjoy them in the highest quality with the unit's
Progressive Scan Video Out and Digital Audio Out.
TM
JPG
PROGRESSIVE
SCAN
CHANNEL
HT
RIG
EL F T
!Live and Timer Recording Functions.
!Multiple Recording Modes, HQ, SP, LP, EP, EP+, SLP.
!Up to 8 Hours Recording on one DVD+R/RW Disc.
!On-Screen Disc Title Navigator gives you quick, easy
access to your Recordings.
!Built-In TV Tuner.
!Front and Rear A/V Inputs.
!DV Input and Camcorder control.
!Delete/Rename Titles.
!Auto-Insert and Manual-Insert Chapter Markers.
!Your recordings are playable on most DVD Players.
!Plays DVD, SVCD/VCD, MPG, JPG, Audio CD
Formats.
!Fast Forward / Reverse.
!Slow Motion Playback, Frame-by-Frame Stepping.
!Repeat Playback (Chapter/Title/Disc & A-B).
!Restrict playback by Ratings, User Defined
Password, Password Change.
!MP3 Player with custom play list, repeat & shuffle
modes.
!JPG Slideshows with Thumbnail preview.
!Zoom to x4 with Panning.
Features Introduction
The CH-DVR 1530 DVD Recorder with Progressive Scan Video Out
Recording Features Playback Features
4

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . 2
Safety
NotesonCopyright ...........................3
Copyrights
Recording & Playback Features . . . . . . . . . . . . . . . . . 4
Introduction
RemoteControl..............................6
FrontPanel .................................7
FrontVFDDisplay............................8
BackPanel..................................9
Functional Overview
TypicalConnectiontoTV......................10
S-Video & Component Video . . . . . . . . . . . . . . . . . . . 11
DigitalAudio&Antenna.......................12
RecordingSourceInputs......................13
Connections
Discs Suitable for Recording and Playback . . . . . . . . 14
CaringforOpticalDiscs.......................14
Disc Compatibility and Care
Checking the Package Contents . . . . . . . . . . . . . . . . 15
Remote Control Preparation & Use . . . . . . . . . . . . . . 16
QuickConnections...........................17
PoweringUp ...............................18
SettingtheTimeandDate.....................19
TVTunerSetup.............................20
SwitchingtoTVMode ........................21
Picture-In-Picture............................21
Quick Start Guide +
InsertingaDisc .............................22
UsingDiscMenus ...........................22
Starting, Stopping and Pausing Playback . . . . . . . . . 22
Fast Forward/Reverse Scanning . . . . . . . . . . . . . . . . 23
SlowMotionPlayback........................23
Frame-By-Frame Playback . . . . . . . . . . . . . . . . . . . . 23
Skipping to the Next / Previous Chapter . . . . . . . . . . 23
Jumping to a Chapter or Time Point . . . . . . . . . . . . . 24
RepeatPlayback............................24
Displaying Playback Session Information . . . . . . . . . 25
Multi-AngleFunction .........................25
Subtitles...................................25
ZOOMPlayback.............................26
MutingtheSound............................26
ChangingtheAudioTrack.....................26
Disc Playback
MusicPlaybackInterface......................28
Inserting a MP3 or CD Audio Disc . . . . . . . . . . . . . . . 29
Creating a Custom Playlist. . . . . . . . . . . . . . . . . . . . . 29
Skipping/ShowingSongs.....................30
Changing the Playback Mode . . . . . . . . . . . . . . . . . . 30
Choosing a File Display Mode . . . . . . . . . . . . . . . . . . 31
Playing MP3 Music Files
Common Problems and Solutions . . . . . . . . . . . . . . . 55
Troubleshooting
CH-DVR 1530 Specifications . . . . . . . . . . . . . . . . . . . 56
Specifications
..........................................57
Index
Table of Contents Contents
5
Displaying JPG Images and Slideshows . . . . . . . . . . 27
RotatingJPGImages.........................27
Viewing JPG Images
SettingsOverview ...........................45
UsingtheSetupMenu........................46
Changing Settings
Introduction to Recording. . . . . . . . . . . . . . . . . . . . . . 32
Recording Sources and Types. . . . . . . . . . . . . . . . . . 33
Controlling a DV Camcorder . . . . . . . . . . . . . . . . . . . 33
AboutTitlesandChapters.....................33
Recording Quality Setting . . . . . . . . . . . . . . . . . . . . . 34
AddingChapterMarkers ......................34
RecordingAudioVolume......................35
FormattingDiscs ............................35
Selecting an Input Source . . . . . . . . . . . . . . . . . . . . . 35
MakingaLiveRecording......................36
Using the Display Function . . . . . . . . . . . . . . . . . . . . 37
Adding Chapter Markers Manually. . . . . . . . . . . . . . . 37
Scheduled Timer Recordings. . . . . . . . . . . . . . . . . . . 38
Saving and Editing Schedules . . . . . . . . . . . . . . . . . . 39
Editing and Deleting Schedules . . . . . . . . . . . . . . . . . 40
Playing Back Your Recordings. . . . . . . . . . . . . . . . . . 41
Deleting and Renaming Titles . . . . . . . . . . . . . . . . . . 42
Using the On-Screen Keyboard . . . . . . . . . . . . . . . . . 43
Finalize and Make Compatible. . . . . . . . . . . . . . . . . . 44
Recording

1 2 3
4 5 6
7 8 9
0 C
TM
DVD/TV LIVE SOURCE
ANGLE
CH-
CH+
REC MODE
REC CHAP MARK
PIP
PLAY
7
8
12
10
11
14
16
18
19
21
20
22
21
24
27
25
28
3
4
5
1
2
6
GOTO SUBTITLE MUTE
AUDIO DISPLAY
9
26
29
13
30
31
15
TIMER
17
ENTER
REC REC
STANDBY - Turns the unit on
and sends the unit to Standby
mode.
MENU / PBC - Accesses
Menus on DVD Discs. With
VCD discs, turns the PBC
function On/Off.
SETUP - Accesses the on-
screen Setup Menu for
settings adjustment.
ANGLE - Selects between
multiple angles with DVD
Discs that support this
feature.
GOTO Press to jump to a
Title, Chapter or Time on the
disc.
SUBTITLE - Selects available
subtitles on DVD discs.
ARROW KEYS (CH+/-) - Use
to navigate disc menus, on-
screen setup menu, etc. In
TV tuner mode, use
UP/DOWN to select a
channel.
FF/FR - Scan in fast forward
or reverse on DVD and other
discs.
NEXT/PREVIOUS -
Advanced to the next track or
plays previous track on DVD
and other disc.
PAUSE/REC PAUSE - Use to
Temporarily stop play or
recording. Press REC to
resume recording and PLAY
to resume playback.
NUMBER KEYS - Use to
enter numeric values while
setting options.
PIP - Enables Picture-In-
Picture Mode.
ZOOM - Press to magnify the
screen with DVD and JPG
discs.
DVD/TV LIVE - Switches
from DVD playback mode to
Live Recording Input mode.
SOURCE - Selects between
available Input Sources when
the Recorder is in Live
Record mode - TV Tuner,
VIDEO IN 1 / 2, S-VIDEO IN
1 / 2 or DV IN.
REC - Press to begin a live
recording or resume
recording from PAUSE.
7
8
12
10
11
14
16
3
4
5
1
2
6
9
13
15
17
18
23
Remote Control Functions
CHAP MARK - Inserts a
Chapter Marker during a
live recording.
OPEN/CLOSE - Press to
open or close the disc tray.
TITLE - Accesses the title
screen on DVD+R/RW
discs, displaying a graphical
representation of the
recordings and providing
easy navigation.
DISPLAY - Brings up the
on-screen display showing
information for the playback
session.
AUDIO - Selects an audio
track on DVD or VCD discs.
MUTE - Temporarily cancels
audio playback.
ENTER - Selects options in
menus. Plays a disc,
chapter or track with some
discs. For other discs, press
PLAY.
PLAY - Plays a disc,
chapter or track.
SLOW - Slow motion
playback mode in 1/4 or 1/8
speed. Press PLAY to
resume normal playback.
STOP - Press once to stop
playback and hold the last
position in memory.
Playback can be resumed
where it was left off by
pressing PLAY. Press twice
to clear the last playback
position.
CLEAR - When entering
input, use to delete
characters.
A-B REPEAT - Sets the
beginning and end points of
a section to repeat.
REPEAT 1/ALL - Selects a
repeat option - Chapter,
Title or Disc.
REC MODE - Selects the
recording quality mode -
HQ, SP, LP, EP, EP+ or
SLP.
TIMER - Accesses the timer
menu for scheduled
recording setup.
19
21
20
22
24
27
25
28
26
29
30
31
23
6

19 20 21
12 13 14 15 16
-
CH DVR 1530 DVD RECORDER WITH PROGRESSIVE SCAN PLAYBACK
ON / STANDBY
UP
DOWN
LEFT
TM
S-VIDEO IN 2 VIDEO IN 2
LRAUDIO
DVD / TV LIVE
SOURCE
RECORD
18
17
ENTER
16
RIGHT
DV IN
CHANNEL
12 3 4 5 6
910 11
78
ON / STANDBY - Turns the unit on and sends the NEXT/FAST FORWARD - Press to advance to the
unit to standby mode. The main power switch on next chapter or track. Press and HOLD to scan in
the back of the unit must be turned on before reverse mode at 2X, 4X, 8X, 16X, 30X or 60X
using the standby button. In standby mode, the speed.
unit will use a minute amount of power to enable SETUP/TIMER - Accesses the On-Screen Setup
power-on by the remote control. Menu and Timer Schedule screen. Use SETUP to
VFD DISPLAY - The front Vacuum Flourescent change options and settings for the Recorder. Use
Display shows information about the unit's the Timer for scheduling recordings that will begin
operation, such as current chapter and elapsed automatically.
time during playback and disc tray status. DOWN - Navigates downward in menus.
DISC TRAY - Loads DVD+R/RW, DVD, CD-ROM, UP - Navigates upwards in menus, etc.
VCD/SVCD, MP3, JPG and other optical discs. LEFT - Navigates to the left in menus, etc.
OPEN/CLOSE - Press to open or close the disc RIGHT - Navigates to the right.
tray.
ENTER - Confirms a choice in menus or settings.
RECORD - Begins a Live Recording.
DV IN - Front DV Input for recording. To select,
DVD/TV LIVE - Switches between Live Recording use the SOURCE key and select DV IN
mode and DVD Player mode.
S-VIDEO IN 2 - Front S-Video Input for recording.
PLAY/PAUSE - Begins playback of a disc, chapter To select, use the SOURCE key and select S-
or track. Press again during playback to pause, VIDEO IN 2.
and again to resume playback.
LEFT/RIGHT AUDIO IN 2 - Front Stereo Audio
STOP - Press once to stop playback of a disc and Inputs for recording. These inputs are shared with
save the location of the stop point. The disc can the VIDEO IN 2 and S-VIDEO IN 2 inputs.
be played back from the stop point by pressing
COMPOSITE VIDEO IN 2 - Front Composite
PLAY. To erase the stop point and reset the play
Video Input for recording. To select, use the
location to the beginning of the disc, press STOP
SOURCE key and select VIDEO IN 2.
a second time.
SOURCE - Selects the input video source for
recording. Choices include built-in TV Tuner and
AV Inputs.
PREV/FAST REVERSE - Press to return to the
previous chapter or track. Press and HOLD to
scan in reverse mode at 2X (twice normal speed).
Press and hold again repeatedly to scan at 4X,
8X, 16X, 30X or 60X speed.
7
8
12
10
11
14
16
3
4
5
1
2
6
9
13
15
17
18
19
21
20
Front Panel Functions
7

REPEAT ALL A-B
MP3
SVCD
DVD PBC
CHANNEL DIGITAL REC
Su Mo Tu We
Th Fr Sa
AM
PM
L/R
123457
6
810 119
REPEAT PLAYBACK - Displays the repeat status: PLAY / PAUSE - Displays playback status.
REPEAT (Chapter/Track/Title), REPEAT ALL or PBC - Shows the status of PBC for SVCD discs.
REPEAT A-B. NUMERIC DISPLAY - When playing a DVD or
CHANNEL - Displays the current TV channel. other optical disc, displays the Chapter/Track and
DTS - Glows if the currently selected audio track is the elapsed time of the playback session. Also
in DTS format. displays disc tray status, system messages and
more. When the unit is in Standby Mode, displays
DOLBY DIGITAL - Glows if the currently selected the system clock.
audio track is in Dolby Digital format.
L/R - Indicates L/R Stereo Mode.
CLOCK - Glows when the system clock is
displayed in Standby Mode. DAY - Shows the day of the week when the clock
is displayed in Standby Mode.
REC INDICATOR - Shows recording status.
AM/PM - Displays AM or PM time.
DISC TYPE - Shows the type of disc currently
playing: MP3, SVCD, VCD or DVD.
7
8
12
10
11
3
4
5
1
2
6
9
13
Front VFD Display Functions
8
12 13

ON
OFF
I
O
AC IN
~100-230V
VIDEO INAUDIO IN
1 2 3456
910 11
78
12
STEREO AUDIO OUTPUT - Connect to TVs or OPTICAL DIGITAL AUDIO OUTPUT - Use to
other audio equipment supporting Stereo Audio in. connect to a receiver or other device with 5.1
channel decoders. Requires a special Optical
COMPONENT/PROGRESSIVE SCAN VIDEO Digital Cable. This output is the coded digital
OUTPUT - Use this output with TVs supporting signal.
Component Video or Progressive Scan input for
best video quality. Select the PROGRESSIVE COAXIAL DIGITAL AUDIO OUTPUT - Use a
SCAN MODE in the Recorder's SETUP MENU for special Coaxial Digital Cable to send the raw
P-SCAN TVs. coded digital signal to devices supporting digital
decoding.
COMPOSITE VIDEO OUTPUT - Standard Video
Output supported by most TVs. S-VIDEO OUTPUT - Connect to TVs with S-
VIDEO in for better picture quality than standard
STEREO AUDIO INPUTS - Use with S-VIDEO IN composite video.
1 or VIDEO IN 1 for recording.
S-VIDEO INPUT 1 - S-VIDEO input for recording.
VIDEO INPUT 1 - Composite Video input for To select this input, press SOURCE and choose
recording. To select this input, use the SOURCE S-VIDEO IN 1.
button and choose VIDEO IN 1.
ANTENNA IN / OUT - For Antenna or Cable TV
connection. Passthrough connection to TV does
not transfer the output signal from the DVD
Recorder.
POWER CORD SOCKET - Plug the matching end
of the power cord into the unit before connecting
the other end to the wall socket.
MAIN POWER SWITCH - The main power switch
must be set to ON for the unit to function. Make
sure all cable connections are complete before
switching the main power switch to ON. When the
main power switch is turned ON, the unit will enter
Standby Mode, where it may be turned on with the
remote control or the front power switch.
7
8
12
10
11
3
4
5
1
2
6
9
Back Panel Functions
9

TV with
Composite
Video Input
(Typical
Connection)
VIDEO INPUT
R
STEREO AUDIO IN
L
This unit ships with a composite video (A/V) cable for connection to TVs with a standard video input as shown below.
This is the most widely used type of connection. On most TVs, this connector is colored yellow, and is normally
accompanied by stereo audio inputs, colored red and white for stereo channels right and left, respectively.
Composite Video /
Stereo Audio Cable
First, use the supplied A/V cable to connect to
the composite video input on your TV. This is
normally a yellow-colored connector that
matches the Video output on the back of this
unit. To hear sound through the TV, connect the
red and white stereo audio connections as well.
1
Turn on the DVD Recorder. You must first set the
Power Switch on the back of the recorder to ON.
Then, press STANDBY/ON on the remote
control or front panel.
2
V
Audio/Video
Input Jacks
VIDEO L - AUDIO - R
Your TV must be equipped with AV inputs like those pictured to the right
in order to connect this unit. If your TV does not have AV inputs, you will
need a RF Modulator to connect the recorder to your TV's
antenna/cable input as shown below. RF Modulators are available at
major electronics retailers.
i
RF Modulator
Older TV with
coaxial
antenna/cable
connector
DVD Recorder
Composite Video Out
VIDEO R - AUDIO - L
Typical Connection to TV Connections
10
On your TV, select the video input. This is
normally done by selecting "Video 1" or "Video
Input" with the remote control. On some TVs, this
is done by selecting a particular channel.
3
ON
OFF
I
O
AC IN
~100-230V
VIDEO INAUDIO IN

S-VIDEO is a higher quality connection than standard composite video, and requires a special S-Video cable (not
included). The S-Video connector is distinguishable by its 4 pins, as shown below. If your TV has an S-Video input,
it's recommended that you use this type of connection for better picture quality.
First, obtain a special S-Video cable. Connect the
S-Video output from the unit to the corresponding
input on your TV.
1On your TV, select the S-Video input. This is
normally done by selecting "Video 2" or "AV2" with
the remote control. On some TVs, this is done by
selecting a particular channel.
2
S-Video
Input Jack
S-Video Cable
TV with
S-Video Input
S
VIDEO
INPUT
TV with
Component
Video Input
Y Pb Pr
VIDEO
INPUT Component Video
Input Jacks
Y Pb Pr
Component
Video Cable
COMPONENT VIDEO, the highest quality video connection, requires a special Component/P-SCAN Video Cable
(not included), with separate connectors for the Y, Pb/Cb, and Pr/Cr signals. You can only use the Progressive Scan
Video Out feature with a TV supporting Component Video Inputs and P-SCAN capability.
Obtain a special Component Video Cable and
connect the YCbCr outputs from the DVD Recorder
to those on your TV.
1
TO USE PROGRESSIVE SCAN - Press SETUP to
enter the SETUP MENU and navigate to the A/V
OUTPUT / VIDEO menu. Move to the SCAN MODE
option with the 6key and then select
PROGRESSIVE with the 4key.
3
Select the Video Input on your TV that corresponds
to the Component Video Input.
2
iIf you do not see the video from the recorder on
your TV, press the 3key to change the setting
back to INTERLACE - the default mode.
S-Video & Component Video Connections Connections
11
ON
OFF
I
O
AC IN
~100-230V
VIDEO INAUDIO IN

Receiver with Digital
Audio Input
COAXIAL DIGITAL AUDIO IN
OPTICAL DIGITAL AUDIO IN
R
STEREO AUDIO IN
TV or receiver
with stereo
audio in
L
This unit features a variety of audio line outputs for connection to a receiver or other audio equipment. Use the
included A/V cable to connect the stereo audio outputs for connection to a TV or stereo receiver.
OPTICAL and COAXIAL digital audio outputs send an encoded digital bitstream, suitable for receivers with Dolby or
DTS decoding capability. These outputs require special cables (not included).
TV with
coaxial
antenna or
cable TV
connection
Antenna/Cable TV Connections
Connect your Antenna or Cable to the
Antenna Input, then use the supplied RF
Cable to pass the signal through to your TV.
Antenna, Cable or
Set-Top Box Input
RF Cable
You can also connect a Cable Set-Top Box to
the Antenna Input. In this case, you can use
the Tuner on the Set-Top Box by setting the
DVD Recorder's built-in TV Tuner to channel 3
or 4, depending on which channel your Set-
Top Box is configured for.
RF Cable
Audio Output & Antenna Connections Connections
12
ON
OFF
I
O
AC IN
~100-230V
VIDEO INAUDIO IN
VIDEO INAUDIO IN

-
CH DVR 1530 DVD RECORDER WITH PROGRESSIVE SCAN PLAYBACK
ON / STANDBY
UP
DOWN
LEFT
TM
S-VIDEO IN 2 VIDEO IN 2
LRAUDIO
DVD / TV LIVE
SOURCE
RECORD
ENTERRIGHT
DV IN
CHANNEL
Audio/Video source such as
camcorder supporting
S-VIDEO Out
L R V
COMPOSITE VIDEO /
STEREO AUDIO OUTPUT
VIDEO IN 1
SL R
S-VIDEO / STEREO
AUDIO OUTPUT
S-VIDEO IN 1
Audio/Video source such as
DVD player or VCR with
Composite Video Out
Audio/Video source such as
camcorder supporting
S-VIDEO Out
L R
VVIDEO IN 2
S
L R
S-VIDEO IN 2
COMPOSITE VIDEO /
STEREO AUDIO OUTPUT
S-VIDEO / STEREO
AUDIO OUTPUT
Audio/Video source such as
DVD player or VCR with
Composite Video Out
Audio/Video source such as
camcorder supporting
DV Output
DV OUTPUT
DV IN
REAR RECORDING INPUTS - There are (2) recording source inputs on the back panel, (1) S-VIDEO (referred to as
"S-VIDEO 1") and (1) Composite Video (referred to as "VIDEO 1"). Note that both of these video inputs share the
same stereo audio input.
FRONT RECORDING INPUTS - There are (3) recording source inputs on the front panel, (1) S-VIDEO (referred to
as "S-VIDEO 2"), (1) Composite Video (referred to as "VIDEO 2") and (1) DV (referred to as "DV"). Note that VIDEO
2 and S-VIDEO 2 share the same stereo audio input.
Recording Source Input Connections Connections
13
ON
OFF
I
O
AC IN
~100-230V
VIDEO IN
AUDIO IN

TM TM
TM TM
TM TM
TM TM
11ALLALL
DVD Video: This unit plays DVDs recorded for a
particular region. The region mark on the back of the
player must correspond to that on any DVD discs you
wish to play. Units sold in North America are coded
for Region 1, and are compatible with discs marked
accordingly.
DVD-R/RW: These discs can be played back when
recorded in standard DVD Video format.
DVD-Audio: This unit will playback only the 5.1CH
sound track on DVD-Audio discs.
Video CD (VCD/SVCD): On VCD/SVCD discs,
advanced features such as PBC (Playback Control)
are available.
CD-R/RW: This unit features an on-screen navigator
for easy access to playable files stored on CD-R/RW
discs, such as JPG images and MP3 music.
CD-Audio: An on-screen navigator is provided to
select and play tracks when using CD-Audio discs.
JPG
!Finger prints or stains on the surface of the disc may
cause signal loss.
!Use a soft cloth and wipe in a radiating manner from
the center of the disc to the outer rims when cleaning
the disc surface.
!Never add labels or adhesive tapes on the discs and
be careful not to scratch or damage the disc surface.
!To prevent discs from becoming bent or deformed,
they should be vertically kept in the disc storage case.
To prevent damage, avoid leaving discs in your car,
where they may be subject to direct sunlight and high
temperature.
!Do not use any disc accessory to improve the audio
quality, disc protective solutions or lens cleaner.
These products may damage the disc surface.
!Hold a disc by the rim or with an index finger in the
central hole. Never touch the signal surface.
Labels
Tapes
Labeling Side
Surface
Disc Compatibility & Care Discs
Discs Suitable for Playback
Caring for Optical Discs
14
DVD+R: These discs can only be written to once.
Existing recordings can be hidden but not deleted.
So, any disc space already used by a recording
cannot be regained. DVD+R discs are required to be
"Finalized" before they will be compatible with
standard DVD Players. Once a disc is finalized, no
further recordings can be made.
DVD+RW: DVD+RW discs can be written to and
erased multiple times. Existing recordings can be
deleted and disc space regained. These discs do not
require a finalization procedure. As soon as a
recording is made, the disc will be compatible with
standard DVD Players.
Discs Suitable for Recording

In addition to the DVD Recorder, your package should
contain the following accessories. Check the contents of
the package carefully, as some items may be located
under the packing foam.
1 2 3
4 5 6
7 8 9
0 C
TM
DVD/TV LIVE SOURCE
ANGLE
CH-
CH+
REC MODE
REC CHAP MARK
PIP
PLAY
GOTO SUBTITLE MUTE
AUDIO DISPLAY
TIMER
ENTER
REC REC
7
345
1
2
6
7
3
4
5
1
2
6
Remote control
Batteries (2) AAA
A/V cable (Video, Stereo Audio)
Power cord
RF Cable for TV
This operation manual and warranty card
Blank DVD+RW Disc (1)
Checking the Package Contents Quick Start Guide
+
15

This unit comes complete with batteries for the
remote control. When installing batteries, be sure
to take note of the polarity markings on the inside
of the battery compartment and match them up
with those on the batteries.
Slide off the back cover.
1
2Install the batteries in the correct orientation as
shown below and marked on the battery
compartment.
+
+
-
-
15
30 30
ON / STANDBY
1 2 3
4 5 6
7 8 9
0 C
TM
DVD/TV LIVE SOURCE
ANGLE
CH-
CH+
REC MODE
REC CHAP MARK
PIP
PLAY
GOTO SUBTITLE MUTE
AUDIO DISPLAY
TIMER
ENTER
REC REC
When using the remote control, be sure to stay within a
30 degree angle of the sensor on the receiver. Keep in
mind that any obstructions between the remote control
and the receiver will effect performance.
!If the remote control functions better when it is
closer to the unit, the batteries may be running low.
!In case of any leakage of batteries, dispose of the
batteries right away and avoid touching the
chemical discharge.
!Make sure to clean the remote control's battery
compartment before installing new batteries.
!Do not mix batteries of different types, or use old
batteries with new ones.
¤Notes on Remote Control
Slide the back cover back on.
3
Remote Control Preparation & Use Quick Start Guide
+
Installing Batteries Using the Remote Control
16

VIDEO INAUDIO IN
CH-DVR 1530
TV
VIDEO R - AUDIO - L
ANTENNA / CABLE IN
A/V Cable
!You cannot use this recorder with only
the RF connection. The A/V Cable is
required to transmit the Audio/Video
signals from the unit.
!The RF Antenna/Cable TV connections
are used only for the built-in TV Tuner
and as a passthrough for the signal
from your antenna /cable to your TV.
Your TV must be equipped with AV inputs like those pictured to the
right in order to connect this unit. If your TV does not have AV inputs,
you will need a RF Modulator to connect the recorder to your TV's
antenna/cable input as shown below. RF Modulators are available at
major electronics retailers.
RF Cable
Use the AV (Audio/Video) cable
provided to connect the DVD
recorder's Video (YELLOW) and
Stereo Audio (R-RED, L-WHITE)
outputs to your TV.
1
Connect your TV Antenna or Cable
TV input to the Recorder's
ANTENNA INPUT, then use the RF
Cable provided to connect the TV
OUT to your TV.
2
i
RF Modulator
Older TV with
coaxial
antenna/cable
connector
DVD Recorder
Composite Video Out
W
W
R
R
Y
Y
VIDEO R - AUDIO - L
A/V Cable
RF Cable
Antenna or
Cable TV In
Quick Connections Quick Start Guide
+
Connecting the Recorder to Your TV
¤Notes on Connections
17

The goal is to see the DVD player's splash
screen on your TV. To do this, select the Video
Input channel on your TV that corresponds with
the input the player is plugged into.
This procedure differs among TVs, but is
normally done by pressing the VIDEO IN,
INPUT or TV/VIDEO button on the TV's remote
control to select the Video Input.
1
When the DVD player's splash screen appears
on your TV, you're ready to go!
2
Plug the DVD player's electrical plug into a wall
socket or power strip.
1
Press the ON / STANDBY button on the front panel,
or the STANDBY button on the remote control to
turn the DVD recorder on.
3
ON / STANDBY
Turn the POWER SWITCH on the back of the DVD
recorder ON.
2
ANGLE
GOTO SUBTITLE MUTE
AUDIO DISPLAY
ON
OFF
O
I
TM
¤
There are 3 power states for this unit:
!OFF - The main power switch is turned off. The
unit draws no power and cannot be turned on by
the remote control.
!STANDBY - The main power switch has been
turned ON, but the unit has not been taken out of
standby by pressing either the STANDBY key on
the remote control or the ON / STANDBY button on
the front panel. The unit draws a slight amount of
power to enable the remote control receiving
circuit.
!ON - The main power switch has been turned ON,
and either the STANDBY button on the remote
control or the ON / STANDBY button on the front
panel has been pressed. The unit is ready to use.
Notes on Power States
Powering Up Quick Start Guide
+
Plugging In and Power On Select the Video Input on Your TV
18
When there is no activity or disc playback remains
paused for a period of about 5 minutes, the Screen
Saver will load, protecting the television from “screen
burn”, which could occur if an unusually bright image
is displayed on-screen for an extended period of time.
¤About the Screen Saver
TM

Select the CLOCK menu and press ENTER. The
CLOCK SETTING screen appears with the
following options.
!Clock Settings - Set the time. This setting will
show AM or PM if the Hour Mode is set to 12HR.
!Date Settings - Set the date. Use 2-digit year
format.
!Hour Mode - 12HR or 24HR. 12HR mode is the
normal time system used in the USA, relying on
the use of AM /PM to indicate night or day. In
24HR mode, the AM/PM designation is not used,
with 12:00 indicating noon time and 24:00
indicating midnight.
2
Notice that UP/DOWN ARROW symbols appear on
the TOP/BOTTOM of a field in edit mode. Use the
5/6keys to increase or decrease the value of the
field and press ENTER to confirm. Alternatively, you
can use the NUMBER keys to enter a time or date
value directly.
4
Use the 3/4and 5/6keys to choose a field to
change and then press ENTER to enable editing for
that field.
3
When the unit is first powered on, you'll be prompted to
set the time and date as well as TV Tuner options. You
can change any of the settings you choose during the
Initial Setup later in the recorder's SETUP MENU.
Press SETUP to exit. The Initial Setup is now
complete. Remember, any settings chosen during
the Initial Setup can be changed later in the DVD
Recorder's SETUP MENU.
5
ANGLE
GOTO SUBTITLE MUTE
AUDIO DISPLAY
CH-
CH+
ENTER
If you are not already in the CLOCK menu, press
SETUP to enter the SETUP MENU. Select the
GENERAL menu with the 5/6keys and press
ENTER.
1
Setting the Time and Date Quick Start Guide
+
19
Setup
Recording
Tuner
Disc Maintain
A/V Output
General
Timer
Language
Rating
Clock
Version
Clock Settings
Hour Mode:
06:55 PM
12 HR
Press SETUP to exit
Clock
Date Settings 03.02.04
1 2 3
4 5 6
7 8 9
0C
PIP
Clock Settings :55 PM
09
:55 PM
05
Restore

Once your Antenna or Cable TV input is connected to
the connector on the back of the unit, you can setup the
recorder's built-in TV Tuner by auto-scanning for
available channels and then adding or deleting the
channels you choose.
2You can press SETUP repeatedly to exit the
SETUP MENU at any time.
Here is where you can customize your channel list by
SKIPPING or SHOWING any channel you choose.
Use the 5/6 keys to select a channel you wish to
SKIP and press ENTER. The SKIPPED icon
appears to the right of the channel, letting you know
that it will no longer be accessible when you scan
through the channels with the 5/6keys while
watching TV. You can, however, select any channel
directly with the NUMBER keys.
CH-
CH+
ENTER
2
To show any channel again after it has been
skipped, simply select the channel and press
ENTER again. The SKIPPED icon is removed from
the right of the channel.
3
TV Tuner Setup Quick Start Guide
+
Channel Setup Set Channels
20
Setup
Recording
Tuner
Disc Maintain
A/V Output
General
Timer
Press SETUP to enter the SETUP MENU.
Select the TUNER menu with the 5/6keys and
press ENTER.
1
Auto Scanning Channels
This is the easiest way to fill your channel list with those
channels available in your area. The unit scans for
channels automatically. When complete, press SETUP
to return to the TUNER SETUP menu.
Select the AUTO SCAN option from the TUNER
SETUP and press ENTER. Select your connection
type (Antenna or Cable TV) and press ENTER.
1
Notification
Choose your connection type
AntennaCable
?
Cancel
The unit scans for channels automatically. When
complete, press SETUP to return to the TUNER
SETUP menu.
2
Select the SET CHANNELS option from the TUNER
SETUP and press ENTER. You will see a list of all
possible channels. The SKIPPED icon to the right of
a channel means it was not detected during the
AUTO SCAN.
1
Channel 34
Channel 35
Channel 36
Channel 37
Channel 38
Channel 34
Channel 35
Channel 36
Channel 37
Channel 38
Channel 34
Channel 35
Channel 36
Channel 37
Channel 38
Restore Defaults
This is the easiest way to fill your channel list with those
channels available in your area. The unit scans for
channels automatically. When complete, press SETUP
to return to the TUNER SETUP menu.
Choose this option to clear the channel list of all your
previous changes.
Press SETUP to exit the SETUP MENU.
4
Auto Scan
Restore Defaults
Press SETUP to exit
Tuner Setup
Set Channels
