Cybernet CyberMed Rx User manual

1

Notes:
Before using this information and the product it supports,
be sure to read important Safety Information on page ii.
Some instructions in this guide may assume that you are
using Win 7/ Win 8.1/Win 10. If you are using another
Windows Operating System, some operations may be
slightly different. If you are using other Operating System,
some operation may not apply to you, but should not
affect your use of this Tablet.
Read the safety notices and important tips in the included manual before using
the Tablet.

2

Dear User,
Before using this product, make sure to read this user guide
carefully. We are pleased that you have chosen us for your
mobile computing needs. To help you master the usage of your
new Tablet quickly, we have prepared this user guide. In this
manual you will find information on the system configuration,
basic operating instructions, and important notices. We have done
our best to avoid any error in making sure that the information
provided in this manual is accurate and reliable.
However, due to the short length of the user guide it is impossible
to cover all topics in great depth. For this reason, we apologize for
any omission you might find.
Cybernet is always trying to improve the performance and
reliability of its products. For that reason, the hardware and
software components shown within the user guide might not
perfectly match those of your system. However, any inconsistency
between what is described in the user guide and the operation of
your Tablet should not substantially affect your use.
Thank you for your understanding.

3

Contents
Important Safety Information ……………………………………….Page 4
Chapter 1. Getting to know your Tablet …………………………..Page 6
Features and Specifications ………………………………………..Page 6
System over view ……………………………………………………..Page 9
Chapter 2. Learning the Basics …………………………………….Page 14
Chapter 3. Troubleshooting …………………………………………Page 16
Chapter 4. BIOS setting ………………………………………………Page 17
Appendix A. Use and Care Information …………………………...Page 21
Appendix B. Optional Devices Information …………….………...Page 24
1.) Desktop Docking station
2.) VESA Docking station
3.) Battery charging station
Appendix C. Notices …………………………………………………..Page 29
Cybernet e-recycling SOP ……………………………………………Page 32

4

Important Safety Information
Important Safety Information
This information can help you safely use your Tablet PC. Follow and retain all
information included with your Tablet. The information in this document does not alter
the terms of your purchase agreement.
Intended use:
The CyberMed Rx and Rugged X10 are intended to serve as a medical monitor that is
designed for general purpose for hospital/commercial environment and for diagnosis. It
could be used for PACS, LIS and Electronic Medical Record purposes. It shall not be
used for life-supporting system.
Intended User Profile:
Education: - Completed medical education (study), Department of Medicine or Nursing
(or equivalent)
Knowledge: – Read and understand English and Western Arabic numbers –
understanding the definition of Class I (basic insulation) and Class II (double insulation)
– could recognize the symbols of alternating current (AC), direct current (DC), protective
earth (ground), earth (ground), Class II equipment, caution, operating instructions, "ON'
(power) and "OFF" (power)
Language Skills: languages as specified in the marketing plan for tablet PC
Experience: other: no special experience needed
Permissible Impairments: – mild reading vision impairment or vision corrected to log
MAR 0.2 (6/10 or 20/32) – one arm / hand system capable of guiding and holding
device – average degree of aging-related short term memory impairment – impaired by
40 % resulting in 60 % of normal hearing at 500 Hz to 2 kHz
WARNING:
Critical diagnostic decision must not be based solely on images displayed by this
Device.
Read this first
Tablets are electronic devices. Power cords, power adapters, and other features can
create potential safety risks that can result in physical injury or property damage,
especially if misused.
The safety risks are categorized as follows:
• Danger: Physical injury or even death may be caused.
• Attention: Property damage or even minor injury may be caused.
To protect yourself from hazards and create a safer Tablet work environment,

5

follow the instructions hereafter.
UnpackInspect the covers of the Tablet and the AC adapter, especially parts with the
following labels attached for any crack or damage.
Danger: Hazardous voltage, current and energy levels are present inside any component
that has this label attached.
Workplace
Do NOT use the Tablet in humid places such as a bathroom.
Keep the Tablet and other parts away from liquids.
Danger: An electric shock may be caused by spilled liquid.
Do NOT use the Tablet during a lightning storm.
Do NOT use the Tablet during a lightning storm.
Ensure the Tablet and other components are used in areas with good ventilation.
Correct Usage Procedures
Use ONLY the power cord and power adapter provided by Cybernet. Never use
these devices with another product.
Warning: To avoid risk of electric shock, this equipment must only be connected to a
supply main with protective earth. Be sure the power outlet is suitable for the plug and
provides the correct voltage and current for the product you are using.
Danger: An unsuitable power supply may damage your Tablet and can cause an electric
shock or fire.
Do NOT wrap the power cord around the power adapter or other objects.
Do NOT squeeze or pinch the cord, or place heavy objects on it.
Attention: Stressing the cord may cause the cord to fray, crack or crimp which
may present a safety hazard.

6

Caution:
Chapter 1. Getting to know your Tablet
This manual refers to both the Medical model known as CyberMed Rx and
the Enterprise model known as Rugged X10 Windows Tablet.
1) CyberMed Rx Medical Tablet
2) Rugged X10 Enterprise Grade Tablet
Note: CyberMed Rx is white color plastic housing with anit-germ technology.
Rugged X10 is black color plastic housing for commercial application.
Both of CyberMed Rx and Rugged have same configuration.
Features and Specifications
Model Name: CyberMed Rx / Rugged X10

7

Note: The following specification may contain technical inaccuracies or typographical
errors. Cybernet reserves the rights to improve and/or change specifications at any time
without notice.
Form Factor
Display 10.1” (16:10 format) with LED
backlight
Maximum resolution 1920 x 1200
Back light: 400nits
Power Input 1 x DC-19V
With 3.15A / 3.78A / 6.31A
CPU Support Intel Broadwell platform
Intel® Core™ i7-5600U
Intel® Core™ i5-5300U
Touch Screen
10F-Multi-touch capacitive touch.
Support Digitizer Pen
Support Palm rejection
Support water proof
3rd CORNING GORILLA GLASS
Memory 1 x DDR3L So-DIMM sockets,
populated up to 16GB
Supports memory data transfer
rates of 1600MHz for DDR3L, un-
buffered non-ECC DDR3L DIMMs
Integrated
communications Intel AC7265 support
IEEE802.11ac
Bluetooth 4.0
Storage Integrated Serial ATA controller
facilitates high-speed transfers at
up to 6Gbps
M.2 Solid State Drive (SSD) with
capacities of 128GB, 256GB,
512GB
M.2 Self-encryption drives (SED),
AES-256 bits optional
Camera 1 x 2.0M camera (Front facing)
1 x 5.0M camera support Flash
LED and auto-focus (Rear
facing)(optional)
Video &
Graphics Integrated Intel HD graphic
Rotation: 0°, 90°, 270°
Battery 2 x hot swappable battery with
46WHr capacity
Battery life: Idle time 6~8hrs
Normal using 4~6hrs
Charging time: 2.5hrs
(Validated charging from 5% to
100% with system on or off.)
Made by FUJI ELECTRONICS
(SHENZHEN) CO.,LTD / PN:
495001 / 10.8V, 2200mA
Durability Meet MIL-STD-810G drop test
IP65 front panel
IPX1 back cover
Gorilla 3rd Glass
Four corner rubber designs help
prevent drop.
Operating
system Windows 10 / 8.1 / 7
Ubuntu 14.04
Fedora 20
CentOS7.0
Debian 8.2.0
Audio Realtek High Definition Audio
Built-in 2 x 1 watt stereo speakers
Internal Analog microphone
Audio combo-jack for headphone
out and microphone
Operating
Environment Ambient Temperature: 0°C ~
35°C (operating).
Relative
Humidity 10% ~ 90% (non-condensing)

8

Built-in Echo cancellation
I/O Port 1 x USB3.0 connector
1 x Audio combo Jack
1 x Micro-SIM slot
1 x DC Jack
1 x Docking connector
Available Color White Anti-Microbial coating.
Dimensions 265mm x 254mm x 20mm (W x D
x H)
Weight 1.1 Kg with battery
Control
buttons One 5-way direction buttons
Two programmable
Windows Home button /
SAS button
Volume control
Power button
Scanner on/off button
Scanner trigger button
Optional Devices
Scanner LED aimer
Support 1D/2D barcode scanner
Made by Honeywell / N6600SR-
W4-102 and N56XX USB1.1 /
3.3V, 276mA
Smart card
reader ISO7816-1,2,3
Adapter
Certifications
EDAC EM10681V
FSP FSP065-DBBM1
EDAC EM11011M
FCC Class B
CE
ANSI/AAM1 ES60601-1+A1
SAR
RoHs
REACH
Finger print
Full type biometric module

9

System overview Front
No. Item Description
1 Microphone Analog Microphone

10

2 Finger Print Full type biometric module, Startek standard, Optional
Crossmatch, FIPS 201 certified and Imprivata OneSign.
3 Front Camera 2.0 Mega pixel Webcam

11

Back

12

No. Item Description
1 Internal USB port USB2.0 internal port for external module device (Only for
service personnel)
Pin definition:
1: 5V, 2: USB-, 3: USB+, 4: GND
2 Battery Hot swap battery have Blue LED indicator. When press the
button indicator will display battery capacity
3 Rear Camera (option) 5.0 Mega pixel camera support flash light and auto-focus

13

Side
No. Item Description
1 1D/2D scanner (Option) Support 1D/2D white LED barcode scanner
2 DC Jack Support 19V input adapter
3 Smart Card Reader (Option) Support ISO7816-1,2,3
4 I/O USB3.0 x 1, support 900mA output
Audio Jack x 1, support CTIA*type
Micro SIM*slot x 1

14


15

TOP & Bottom
No. Item Description
1 Power Button Press to turn the Tablet on; Press again to turn the Tablet
to sleep mode; Press and hold 4 seconds to force
shutdown.
2 Scanner On/Off Press to turn on or off scanner device power, the status
shown as LED indicator
3 Scanner Trigger Press to trigger scanner for scan barcode.
4 Docking connector Water proof docking connector to connect Desktop / VESA
docking device.
Chapter 2. Learning the Basics
First Use
User environment:
Temperature:
Operating: 0°C to 35°C
Non-operating: -20°C to 60°C

16

Humidity (Non-condensing):
Operating: 10% to 90%
Non-operating: 10% to 90%
Pressure
700 to 1060hPa (0-3000m)
Connecting to the power:
The battery is not fully charged at purchase. To charge the battery and begin using your
Tablet, connect a Hospital Grade power cord to the AC adapter. The battery is
automatically charged while the Tablet is running on AC power.
Connecting the Tablet to an electrical outlet:
1. Connect Hospital Grade used Power Cord to the AC Adapter.
2. Connect the DC cable to the DC jack of the Tablet.
3. Plug the power cord into an electrical outlet.
Power information:
EM11011M, 120W, Made by EDAC Power Electronics Co., Ltd. for EN60601-
1:2006,IEC60601-1:2005 with Cybernet Desktop docking station.
FSP065-DBBM1, 65W, Made by FSP TECHNOLOGY INC. for EN60601-
1:2006,IEC60601-1:2005 with CyberMed Rx tablet.
EM10681V, 72W, Made by EDAC Power Electronics Co., Ltd. for EN60601-
1:2006,IEC60601-1:2005 with CyberMEd Rx tablet and Cybernet VESA docking station.
Configuring the Operating System:
You may need to configure the Operation System when it is first use. The configuration
process may include the procedures below.
Accepting the end user license agreement
Configuring the Internet connection
Registering the Operating System
Creating a user account
Putting your Tablet into sleep mode or shutting it down:
When you finish working with your Tablet, you can put it into sleep mode or shut it
down.
Disconnect Devices:
The Tablet is not difficult to operate the disconnect device from power supply cord and
to fully disengage the power to the unit, please disconnect the power cord from the AC
inlet.
Connecting External Device
Your Tablet has a wide range of built-in features and connections capabilities.

17

Connecting a universal serial bus (USB) device:
Your Tablet comes with one USB port compatible with USB devices.
Note: When using a high power consumption USB device such as USB ODD, use the external
device’s power adapter. Otherwise, the device may not be recognized resulting in system
shutdown.
Connecting a Bluetooth enabled device (Selected models only):
If your Tablet has an integrated Bluetooth adapter card, it can connect to and transfer
data wirelessly to other Bluetooth enabled devices, such as notebook computers, PDAs
and smart phones. Enable transfer data between these devices without cables at up to
10-meter range in open space.
Notes: When Bluetooth function is not in use, turn it off to save battery power.
You need to pair the Bluetooth-enabled device with your Tablet before you can transfer data
between them. Read the documentation supplied with the Bluetooth-enabled device for details
on how to pair the device with your Tablet.
Disconnect Devices:
To fully disengage the power to the unit, please disconnect the power cord from the AC
inlet.
Wireless Connection:
Wireless connection provides mobile access to the Internet, allowing the user to stay
online anywhere the wireless signal covers.
WiFi networks cover a small physical area, like a home, office, or small group of
buildings. An access point is necessary for the connection.
Using WiFi (Selected models only):
Your Tablet may be able to connect via WiFi network within your home or office.
Consult your router or wireless access equipment documentation for information on how
to connect devices wirelessly to the equipment.
Battery Capacity check:
Each Battery provides an LED indicator, allowing the user to press the button and get
an indication of battery capacity and status.
LED Level meaning:
1x LED – 1~20% capacitive level
2x LED – 21~40% capacitive level
3x LED – 41~60% capacitive level
4x LED – 61~80% capacitive level
5x LED – 81~100% capacitive level (all LEDs are on-full bar)

18

Chapter 3. Troubleshooting
Troubleshooting
This section only describes problems that might negate the need to refer to
the more comprehensive information in Chapter 2.
Start Up problems:
1. When I turn on the Tablet, nothing appears on the screen.
If the screen is blank, make sure that:
- The AC adapter is connected to the Tablet and the power cord is
plugged into a working electrical outlet.
- The Tablet power is on. (Press the power button again and check
power LED indicator for confirmation.)
2. The critical low-battery error message appears, and the Tablet
immediately turns off.
- Means your battery capacity is lower than 10%, Cybernet strongly
suggest to plug-in AC power immediately to prevent the tablet
abnormal shutdown.
3. “Please check your battery connection” error message appears
- Means battery may not install as well. Please press power button
to force shutdown your tablet first then re-install battery again. If
the message still happens please return your battery to RMA
process.

19

Chapter 4. BIOS Setup
The BIOS provides a Setup utility program for specifying the system
configurations and settings. The BIOS ROM of the system stores the Setup
utility. When you turn on the computer, the BIOS is immediately activated.
Pressing the <Del> key immediately allows you to enter the Setup utility. If
you are a little bit late pressing the <Del> key, POST (Power On Self Test)
will continue with its test routines, thus preventing you from invoking the
Setup. If you still wish to enter Setup, restart the system bypressing the
<Ctrl>, <Alt> and <Delete> keys. You can also restart by turning the
system Off and back On again. The following message will appear on the
screen:
Press <DEL> to Enter Setup
In general, you press the arrow keys to highlight items, <Enter> to select,
the <PgUp> and <PgDn> keys to change entries, <F1> for help and <Esc>
to quit.
When you enter the Setup utility, the Main Menu screen will appear on the
screen. The Main Menu allows you to select from various setup functions
and exit choices.
Warning: It is strongly recommended that you avoid making any changes
to the chipset defaults. These defaults have been carefully
chosen by both AMI and your system manufacturer to provide
the absolute maximum performance and reliability. Changing the
defaults could cause the system to become unstable and crash
in some cases.
Main Settings
Main Advanced Chipset Security Boot Save & Exit
BIOS Information
BIOS Version V3
Processor Information
Name Broadwell

20

Brand String Intel(R) Core(TM)
i5-530
→←Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save & Exit
ESC: Exit
Frequency 2700 MHz
Processor ID 306d4
Stepping F
Number of Processors 2Corer(s)/4Threa
d(s)
Microcode Revision 16
GT Info GT2 (600 MHz)
IGFX VBIOS Version 1036
Memory RC Version 2.5.0.3
Total Memory 4096 MB (DDR3)
Memory Frequency 1600 Mhz
MCU Information
MCU FW Version 1.0
System Date [Tue 01/20/2009]
System Time [00.00.00]
Access Level Administrator
Advanced Settings
This section allows you to configure and improve your system and allows you to set up some
system features according to your preference.
Main Advanced Chipset Security Boot Save & Exit
→←Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Default
F4: Save & Exit
ESC: Exit
►CPU Configuration
►Trusted Computing
►ACPI Settings
►AMT Configuration
►Hardware Monitor
►SATA Configuration
►CSM Configuration
►Integrated Peripherals
►USB Configuration
Chipset Settings
This section allows you to configure and improve your system and allows you to set up some
system features according to your preference.
Main Advanced Chipset Security BootSave & Exit
→←Select Screen
►System Agent (SA) Configuration
