PR2200ELCDSL / PR3000ELCDSL
User’s Manual
K01-0000393-00
IMPORTANT SAFETY INSTRUCTIONS
This manual contains important safety instructions. Please read and follow all instructions carefully during
installation and operation of the unit. Read this manual thoroughly before attempting to unpack, install, or
operate your UPS.
CAUTION! The UPS must be connected to a grounded AC power outlet with fuse or circuit breaker
protection. DO NOT plug the UPS into an outlet that is not grounded. If you need to de-energize this
equipment, turn off and unplug the UPS.
CAUTION! DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT! CyberPower Systems does
not sell products for life support or medical applications. DO NOT use in any circumstance that would affect
the operation and safety of life support equipment, medical applications, or patient care.
CAUTION! Hazardous live parts inside can be energized by the battery even when the AC input power is
disconnected.
CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity controlled indoor
area, free of conductive contaminants. (Please see specifications for acceptable temperature and humidity
range).
CAUTION! To reduce the risk of electric shock, do not remove the cover, except to service the battery.
There are no user serviceable parts inside, except for the battery.
CAUTION! To avoid electrical shock, turn off the unit and unplug it from the AC power source before
servicing the battery or installing a computer component.
CAUTION! DO NOT USE WITH OR NEAR AQUARIUMS! To reduce the risk of fire, do not use with or near
aquariums. Condensation from the aquarium can come in contact with metal electrical contacts and cause
the machine to short out.
DO NOT USE THE UPS ON ANY TRANSPORTATION! To reduce the risk of fire or electric shock, do not
use the unit on any transportation such as airplanes or ships. The effect of shock or vibration caused during
transit and the damp environment can cause the unit to short out.
INSTALLING YOUR UPS SYSTEM
UNPACKING
The box should contain the following:
(1) UPS Unit x 1; (2) Emergency Power Off Cable (gray) x 1; (3) Serial Cable x 1; (4) USB Cable x 1 (5) User
Manual x 1; (6) Management software Disk x 1; (7) Function Setup Guide x 1; (8) IEC to IEC Power cord x 4;
(9) IEC to AU Power cord x1
OVERVIEW
The PR2200ELCDSL / PR3000ELCDSL provides automatic voltage regulation for inconsistent utility power.
The PR2200ELCDSL / PR3000ELCDSL features 405 Joules of surge protection, and provides battery
backup during power outages. The PR2200ELCDSL / PR3000ELCDSL ensures consistent power to your
computer system and its included software will automatically save your open files and shut down your
computer system during a utility power loss.
HOW TO DETERMINE THE POWER REQUIREMENTS OF YOUR
EQUIPMENT
1.Make sure that the total Volt-Amp (VA) requirements of your computer, monitor, and peripheral equipment
does not exceed 2200VA/3000VA.
2.Ensure that the equipment plugged into the battery power-supplied/surge outlets does not exceed the
UPS unit's rated capacity (2200VA/1980W for PR2200ELCDSL, 3000VA/2700W for PR3000ELCDSL). If the
rated unit capacities are exceeded, an overload condition may occur and cause the UPS unit to shut down
or the circuit breaker to trip.
BASIC OPERATION
DESCRIPTION
1. Power Switch
Used as the master on/off switch for equipment connected to the battery power supplied outlets.
2. Power On Indicator
This LED is illuminated when the utility power is normal and the UPS outlets are providing power, free of
surges and spikes.
3. LCD Module Display
Intelligent LCD display shows all the UPS information using icons and messages. For more
information please review the “Definitions for Illuminated LCD Indicators” section below.
4. Down/Display Button
The button can be used to select the LCD display contents including Input Voltage, Output Voltage, and
Estimated Run Time. Short press the button to scroll down the function menu. Pressing the button for 2
seconds will keep the LCD display always on or turn the LCD display off while in AC/Utility power mode.
For more information about the Down/Display Button, please refer to the Function Setup Guide.
5. Up/Mute Button
Short press the button to scroll up the function menu. Holding the button for more than 2 seconds will
silence the alarm. For more information about the Up/Mute Button, please refer to the Function Setup
Guide.
6. Enter/Setup Button
Press the button for 2 seconds to enter the setup menu and then select the functions for configuration.
For more information about the Enter/Setup Button, please refer to the Function Setup Guide.
7. Battery and Surge Protected Outlets
The unit has nine battery powered/surge suppression outlets for connected equipment to ensure
temporary uninterrupted operation of your equipment during a power failure. (DO NOT plug a laser
printer, paper shredder, copier, space heater, vacuum, sump pump or other large electrical devices into
the “Battery and Surge Protected Outlets”. The power demands of these devices may overload and
damage the unit.)
8. Serial / USB Ports to PC
The Serial and USB ports allow connection and communication between the computer and the UPS unit.
Note: Only one port can be used at a time.
9. EPO Port
Use the provided gray EPO cable to connect to a provided EPO contact switch. Follow the appropriate
circuit diagram to the right to wire the cable to your EPO configuration. The EPO remote switch is a
switch installed in an outside area, connected to the unit via the Emergency Power Off cable. In case of
an emergency, it can be used to immediately cut-off power from the UPS.
10. SNMP/HTTP Network Slot
Remove the cover panel to install an optional RMCARD to remotely monitor and manage your UPS over
a network.
11. Circuit Breaker
Located on the back of the UPS, the circuit breaker provides overload and fault protection.
12. AC Input
Connect the AC power cord to a properly wired and grounded outlet.
HARDWARE INSTALLATION GUIDE
1. Your new UPS may be used immediately upon receipt. However, recharging the battery for at least 8
hours is recommended to ensure that the battery's maximum charge capacity is achieved. Charge loss
may occur during shipping and storage. To recharge the battery, simply leave the unit plugged into an AC
outlet. The unit will charge in both the on and off position.
Note: This UPS is designed with a safety feature to keep the system from being turned on during
shipment. The first time you turn the UPS on, you will need to have it connected to AC power or it
will not power up.
2. If you will use the software, connect the USB cable to the USB port on the UPS.
3. With the UPS unit off and unplugged, connect the computer, monitor, and any externally powered data
storage device (Zip drive, Jazz drive, Tape drive, etc. into the battery power supplied outlets. DO NOT
plug a laser printer, copier, space heater, vacuum, paper shredder or other large electrical device into the
battery power supplied outlets. The power demands of these devices will overload and possibly damage
the unit.
4. Plug the UPS into a 2 pole, 3 wire grounded receptacle (wall outlet). Make sure the wall branch outlet is
protected by a fuse or circuit breaker and does not service equipment with large electrical demands (e.g.
air conditioner, refrigerator, copier, etc. Avoid using extension cords.
5. Depress the power switch to turn the unit on. The power on indicator light will illuminate and the unit will
"beep".
6. If an overload is detected, an audible alarm will sound and the unit will emit one long beep. To correct this,
turn the UPS off and unplug at least one piece of equipment from the battery power supplied outlets. Wait
10 seconds. Make sure the circuit breaker is depressed and then turn the UPS on.
7. Your UPS is equipped with an auto-charge feature. When the UPS is plugged into an AC outlet, the
battery will automatically recharge.
8. To maintain optimal battery charge, leave the UPS plugged into an AC outlet at all times.
9. To store your UPS for an extended period, cover it and store with the battery fully charged. Recharge the
battery every three months to ensure battery life.
CYBERPOWER GREENPOWER UPS™ TECHNOLOGY
CyberPower’s Green Commitment
CyberPower is dedicated to the development of green products, and has adopted
Green practices throughout its business, including: membership in Climate Savers
Computing Initiative (CSCI), accordance with the Restriction on Hazardous
Substances (RoHS), Waste Electrical and Electronic Equipment (WEEE) protocols,
as well as ISO 14001 and IECQ QC080000. CyberPower pledges to provide the
advanced energy solution for the environment and become a leading eco-friendly
organization in the UPS industry.
Reduce Energy Cost with GreenPower UPS
TM
Technology
CyberPower’s goal is not only to provide eco-friendly products but also to bring the best value for consumers.
The advanced energy-saving design improves the operating efficiency and eliminates waste energy
consumption.As a result, consumers will enjoy significant energy cost savings with the adoption of
GreenPower UPS
TM
technology.
BATTERY REPLACEMENT
CAUTION! Read and follow the IMPORTANT SAFETY INSTRUCTIONS before servicing the
battery. Service the battery under the supervision of personnel knowledgeable of
batteries and their precautions.
CAUTION! When replacing batteries, replace with the same type and number of batteries or battery packs.
CAUTION! Use only the specified type of battery. See your dealer for replacement batteries.
CAUTION! The battery may present the risk of electrical shock. Do not dispose of batteries in
a fire, as they may explode. Follow all local ordinances regarding proper disposal of batteries.
CAUTION! Do not open or mutilate the batteries. Released electrolyte is harmful to the skin
and eyes and may be toxic.

CAUTION! A battery can present a high risk of short circuit current and electrical shock. Take
the following precautions before replacing the battery:
1. Remove all watches, rings or other metal objects.
2. Only use tools with insulated handles.
3. DO NOT lay tools or other metal parts on top of battery or any battery terminals.
4. Disconnect the charging source prior to connecting or disconnecting battery terminals.
5. Wear rubber gloves and boots.
6. Determine if the battery is inadvertently grounded. If inadvertently grounded, remove source
of ground. CONTACT WITH A GROUNDED BATTERY CAN RESULT IN ELECTRICAL
SHOCK! The likelihood of such shock will be reduced if such grounds are removed during
installation and maintenance (applicable to a UPS and a remote battery supply not having a
grounded circuit)
CAUTION - RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF
USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
BATTERY REPLACEMENT PROCEDURE:
Turn off and unplug all connected equipment.
2. Turn the UPS off and unplug it from the AC power source.
3. Remove the front panel of the UPS.
4. Remove two screws from the battery compartment cover and slide the cover completely off of
the unit.
5. Remove the batteries from the compartment.
6. Disconnect the battery wires from the batteries.
7. Install the replace batteries by connecting the red wire (+) and black wire (-) to the same color
connectors from the battery pack.
8. Put the batteries back into the compartment.
9. Re-install the battery compartment cover and tighten the retaining screws.
10. Put the front panel back on the UPS.
11. Connect to AC power and charge the new batteries for up to 16 hours to insure a full charge.
REMINDER: Batteries are considered HAZARDOUS WASTE and must be disposed of properly. Almost any
retailer that sells lead-acid batteries collects used batteries for recycling.
DEFINITIONS FOR ILLUMINATED LCD INDICATORS
1. ONLINE: The UPS is supplying utility power to
connected equipment.
2. BATTERY: During a severe brownout or blackout,
this icon appears and an alarm sounds (two short beeps
followed by a pause) to indicate the UPS is operating
from its internal batteries. During a prolonged brownout
or blackout, the alarm will beep rapidly every 1/2 second
(and the BATT.CAPACITY meter shows one 20%
capacity segment shaded. The capacity depends on how
much load added and the runtime left.) to indicate the
UPS’s batteries are nearly out of power. You should save
files and turn off your equipment immediately or allow the
software to shut the system down.
3. Energy-Saving: The UPS in energy-saving bypass mode. When the utility power is normal and the
battery is fully charged, the UPS will go into energy-saving bypass mode automatically. See “CyberPower
GreenPower UPSTM Technology” section for more information.
4. LOAD capacity / Sensitivity setup: This meter displays the approximate output load level (in 20%
increments) of the UPS battery outlets. It can also be sensitivity setup meter if you are in Setup mode. It is to
control the sensitivity of the UPS to switch to Battery Mode by selecting UPS shutdown voltage range. When
the sensitivity is increased, the UPS will switch to Battery Mode with less input power variation.
5. BATTERY capacity: This meter displays the approximate charge level (in 20% increments) of the
UPS’s internal battery. During a blackout or severe brownout, the UPS switches to battery power, the
BATTERY icon appears, and the charge level decreases.
6. FAULT: This icon appears if there is a problem with the UPS. Press the POWER button to turn off the
UPS.
F01: Battery Mode or AC/Utility Power Mode Overload fault (Turn on the UPS again.)
F02: Battery Output Short fault (Turn on the UPS again.)
F03: Charger Fault (Contact CyberPower Systems for support.)
F04: Internal Fault (Contact CyberPower Systems for support.)
F05: Fan Abnormal (Contact CyberPower Systems for support.)
7. OVER LOAD: This icon appears and an alarm sounds to indicate the battery-supplied outlets are
overloaded. To clear the overload, unplug some of your equipment from the battery-supplied outlets until the
icon turns off and the alarm stops.
8. SCHEDULE: Users can setup the schedule to turn on and shut down the computer and UPS through
PowerPanel® Personal Edition software. The LCD display will show how much time is left before the UPS
will turn back on or shut down.
9. ESTIMATED RUNTIME: This displays the run time estimate of the UPS with current battery capacity
and load.
10. OUTPUT meter: This meter measure, in real time, the AC voltage that the UPS system is providing to
the computer, such as normal AC line mode, AVR mode, and battery backup mode. (Note: The OUTPUT
meter shows the status of the battery backup outlets in terms of load, frequency, and voltage.)
11. INPUT meter: This meter measures the AC voltage that the UPS system is receiving from the utility
wall outlet. The UPS is designed, through the use of automatic voltage regulation, to continuously correct
output voltage to connected equipment to a safe voltage output range. In the event of a complete power loss,
severe brownout, or over-voltage, the UPS relies on its internal battery to supply consistent output voltage.
The INPUT voltage meter can be used as a diagnostic tool to identify poor-quality input power.
12. EVENT: This meter records the number of power outages.
13. MUTE: This icon appears whenever the UPS is in silent mode. The alarm does not beep during silent
mode until the battery reaches low capacity.
14. AVR (Automatic Voltage Regulation): This icon appears whenever your UPS is automatically
correcting low AC line voltage without using battery power. This is a normal, automatic operation of your
UPS, and no action is required on your part.
For more information about functions setup, please refer to the Function Setup Guide.
TECHNICAL SPECIFICATIONS
Model PR2200ELCDSL PR3000ELCDSL
Capacity (VA) 2200VA/1980W 3000VA/2700W
Input
Frequency Range 50/60Hz +/-3 Hz (Auto Sensing)
AVR Function Yes
Output
On Battery Output Voltage 230Vac +/-10%
On Battery Output
Frequency 50/60Hz +/-1%
Overload Protection On Utility: Circuit Breaker & Internal Current Protection
On Battery: Internal Current Limiting
Surge Protection
Lightning / Surge
Protection Yes
Operating Temperature +32
°
F to 104
°
F ( 0
°
C to 40
°
C )
Physical
Total # of UPS outlets IEC x 8 IEC x 9
Maximum
Dimensions(LxWxH) 221 x 170 x 432 mm
Weight (kg) 23.3 24.5
Battery
Battery Sealed Maintenance Free Lead Acid Battery
Typical Recharge Time 8 hours
Charging Current(Max.) 1A
User Replaceable Yes
Status Indicators
Indicators Power On, LCD Display, Online, On Battery, Fault, Replace Battery
Audible Alarms On Battery, Low Battery, Overload
Communication
PowerPanel
®
Business
Edition Software Windows 8/7/Vista/XP/2000/Server 2003, Linux
Management
Self -Test Yes
Auto-Charger Yes
Auto-Restart Yes
USB interface Yes
Expansion Port Yes
EPO Port Yes
Certifications
Certifications CE, RCM
TROUBLESHOOTING
Problem Possible Cause Solution
Circuit breaker button is
projecting from the back of the
unit.
Circuit breaker has
tripped due to an
overload.
Turn the UPS off and unplug at least one
piece of equipment. Wait 10 seconds, reset
the circuit breaker by depressing the button,
and then turn the UPS on.
The UPS does not perform
expected runtime.
Battery not fully
charged.
Recharge the battery by leaving the UPS
plugged in.
Battery is slightly worn
out.
Contact CyberPower Systems about
replacement batteries at
[email protected]
The UPS will not turn on.
The on/off switch is
designed to prevent
damage by rapidly
turning it off and on.
Turn the UPS off. Wait 10 seconds and
then turn the UPS on.
The battery is worn
out.
Contact CyberPower Systems about
replacement batteries at
[email protected]
Mechanical problem. Contact CyberPower Systems at
[email protected]
PowerPanel® Business Edition
is inactive.
The USB cable is not
connected.
Connect the USB cable to the UPS unit and
an open serial port on the back of the
computer. You must use the cable that
came with the unit.
The unit is not
providing
battery power.
Shutdown your computer and turn the
UPS off. Wait 10 seconds and turn the
UPS back on. This should reset the unit.
The fault LED is illuminated.
Overload Remove excessive load and restart the
UPS.
Output Short Contact CyberPower Systems at
[e-mail]
Battery Overcharge Contact CyberPower Systems at
[e-mail]
Over Temperature Contact CyberPower Systems at
[e-mail]
Additional troubleshooting information can be found at www.cpsww.com.au
For more information, visit www.cyberpower.com or contact
Cyber Power Systems, Inc.
All rights reserved. Reproduction without permission is prohibited.
