CyberResearch CYRAQ 17A Series User manual

0
Displays
USER’S MANUAL
VER. 1.1 • MAR 2007
No part of this manual may be reproduced without permission
CYRAQ®17A Series
17" Super-Bright Rack-, Panel-, and
VESA-Mount Flat-Panel Displays with
Optional AR Bonding™ Technology
®
CyberResearch®,Inc.
www.cyberresearch.com
25 Business Park Dr., Branford, CT 06405 USA
203-483-8815 (9am to 5pm EST) FAX: [phone]

CyberResearch® Displays CYRAQ®17A Series
CyberResearch, Inc. iii
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com
©Copyright 2007
All Rights Reserved.
March 22, 2007
The information in this document is subject to change without prior notice
in order to improve reliability, design, and function and does not represent
a commitment on the part of CyberResearch, Inc.
In no event will CyberResearch, Inc. be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use of or inability
to use the product or documentation, even if advised of the possibility of
such damages.
This document contains proprietary information protected by copyright.
All rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of CyberResearch, Inc.
Trademarks
“CyberResearch®,” and “CYRAQ®17A series,” are trademarks of
CyberResearch, Inc. Other product names mentioned herein are used for
identification purposes only and may be trademarks and/or registered
trademarks of their respective companies.
• NOTICE •
CyberResearch, Inc. does not authorize any CyberResearch product for
use in life support systems, medical equipment, and/or medical devices
without the written approval of the President of CyberResearch, Inc. Life
support devices and systems are devices or systems which are intended
for surgical implantation into the body, or to support or sustain life and
whose failure to perform can be reasonably expected to result in injury.
Other medical equipment includes devices used for monitoring, data
acquisition, modification, or notification purposes in relation to life
support, life sustaining, or vital statistic recording. CyberResearch
products are not designed with the components required, are not subject
to the testing required, and are not submitted to the certification required
to ensure a level of reliability appropriate for the treatment and diagnosis of
humans.

CYRAQ 17A Series CyberResearch® Displays
iv ©Copyright 2007 CyberResearch, Inc
Intentionally Blank

CyberResearch® Displays CYRAQ®17A Series
CyberResearch, Inc. v
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com
Table of Contents
1Introduction....................................................................1
1.1 Why the CYRAQ®17A?............................................................. 2
1.2 CyberResearch®AR Bonding™ Technology ............................ 3
1.3 Product Safety and Regulatory Information ............................. 4
1.4 General Specifications.............................................................. 5
1.5 Overview................................................................................... 9
1.5.1 System Requirements................................................................................................ 9
2Setup.............................................................................10
2.1 Unpacking the CYRAQ®17A Series.........................................10
2.1.1 Your Package Contains: .......................................................................................... 10
2.1.2 Ordering Information................................................................................................ 11
2.2 Rack Mounting.........................................................................12
2.2.1 Installation................................................................................................................ 12
2.3 Panel Mounting .......................................................................14
2.3.1 Panel Mounting the Monitor..................................................................................... 14
2.4 Display Connection .................................................................17
3Using the CYRAQ®17..................................................19
3.1 User Controls ..........................................................................19
3.1.1 Hot Key Functions:................................................................................................... 21
3.2 0OSD Menu Layout .................................................................21
3.2 OSD Menu Layout ...................................................................22
4Touchscreen.................................................................23
4.1 Installation...............................................................................23
4.1.1 Serial Cable Connection .......................................................................................... 23
4.1.2 USB Cable Connection............................................................................................ 24
4.1.3 Touchscreen Driver Installation ............................................................................... 24
4.2 Calibration ..............................................................................28
4.2.1 Calibration Options: ................................................................................................. 28
4.2.2 Configure Calibration Settings ................................................................................. 28
4.2.3 Calibration Routine .................................................................................................. 30
4.2.4 Calibration Test........................................................................................................ 31
4.2.5 Drawing Test............................................................................................................ 32
4.2.6 Right Click Emulation............................................................................................... 34
4.2.7 Touch Settings ......................................................................................................... 35

CYRAQ 17A Series CyberResearch® Displays
vi ©Copyright 2007 CyberResearch, Inc
5Product Care................................................................36
5.1 Cleaning ..................................................................................36
5.1.1 Touchscreen ............................................................................................................ 36
5.1.2 LCD.......................................................................................................................... 36
5.1.3 Fan Filters ................................................................................................................ 37
6Mechanical Drawings (Panel-Mount).........................38

CyberResearch® Displays CYRAQ®17A Series
CyberResearch, Inc. vii
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com
Table of Figures
Figure 1: Rack Mounting Illustration ............................................................................... 13
Figure 2: Panel Mounting Illustration............................................................................... 15
Figure 3: Insert Mounting Clamps Illustration ................................................................. 16
Figure 4: Tighten Mounting Clamp Illustration................................................................ 16
Figure 5: Connection Layout (Rack-Mount Version Shown)........................................... 17
Figure 6: User Controls..................................................................................................... 19
Figure 7: Touchscreen Cable Layout................................................................................ 23
Figure 8: Splash Screen .................................................................................................... 24
Figure 9: Install Products.................................................................................................. 25
Figure 10: Calibration Target............................................................................................ 30
Figure 11: Calibration Target............................................................................................ 31
Figure 12: Click Settings Tab ........................................................................................... 34
Figure 13: Touch Settings Tab......................................................................................... 35
Figure 14: Fan Filter Location .......................................................................................... 37
Figure 15 Front Panel Dimensions ................................................................................... 38
Figure 16: Depth Dimensions ........................................................................................... 39

CYRAQ 17A Series CyberResearch® Displays
viii ©Copyright 2007 CyberResearch, Inc

CyberResearch® Displays CYRAQ®17A Series
CyberResearch, Inc. 1
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com
1Introduction
Congratulations on your purchase of the most innovative and versatile LCD
monitor available today—the CYRAQ®17A series with AR Bonding™ technology.
The CyberResearch CYRAQ 17A uses a groundbreaking flush-mount bezel design
making in-wall applications completely seamless. The CyRAQ 17A is also rack-
mountable.
The CYRAQ 17A series LCD monitor emits very low radiation levels and virtually no
electromagnetic field. Fully compatible with the PC and Macintosh, the CYRAQ 17A
series provides dual inputs (VGA and DVI) is “Plug & Play” compatible and also
complies with DDC1/DDC2B. The On Screen Display menu provides users with an
intuitive interface making it simple to quickly adjust the display.
The CYRAQ 17A series is the first ever 17″1280 x 1024 flat-panel flush-mount display
with a NEMA 4 rating and AR Bonding. It sets a new standard for clear, bright, flicker-
free images and its NEMA 4X front bezel makes it ideal for use in industrial
environments.

CYRAQ 17A Series CyberResearch® Displays
2 ©Copyright 2007 CyberResearch, Inc
1.1 Why the CYRAQ®17A?
The CYRAQ®17A concept was conceived in the Engineering Department at
CyberResearch as we began to examine how the recent advances in LCD technology and
image quality could potentially affect our market and customer base. The LCD monitor
today provides viewing angles comparable to CRTs with no discernable loss of picture
quality; an LCD resultantly provides crisp, clean, deep images WITHOUT screen glare.
Coupled with a flat screen, slim design, extremely low radiation discharge, and almost no
electromagnetic emissions, an LCD monitor can provide some very distinct advantages to
users in manufacturing, commercial and scientific applications.
Put simply, the innovation of the CYRAQ 17A series is derived from its size and
applications. Never before have the industrial, scientific and marine markets been able to
utilize large LCD monitors (17" 19" & 21") versatile enough to be panel-mounted, yet
robust and capable enough to perform in harsh environments. The CYRAQ 17A series
stainless steel enclosure not only provides an unmatched degree of protection to the unit’s
components, it dually helps achieve a NEMA 4X rating capable of sustaining normal
operation (when installed correctly) while enduring screen washdown and other
procedures commonly practiced in a harsh environment.
The CyberResearch, Inc. CYRAQ 17A series displays have been engineered to couple
with a revolutionary new mounting system that allows a user to panel-mount this display
without retrofitting disparate hardware, drilling holes, or welding mounting studs. The
mounting clamp system makes it a snap to panel-mount a CYRAQ 17A series display.
Currently, the CYRAQ family is comprised of many, many models including displays
featuring rear controls only, VESA mounting, choice of color and touchscreen (serial or
USB available). CyberResearch has also expanded the CYRAQ family to include the
CYRAQ®12 (12″) & CYRAQ®15 (15″)models, (in addition to 19", 21" & 24")
models—please call us or visit our website for more information.
`

CyberResearch® Displays CYRAQ®17A Series
CyberResearch, Inc. 3
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com
1.2 CyberResearch®AR Bonding™ Technology
Standard LCDs used in bright ambient light may appear “washed out” due to excessive
reflection from these lighting conditions. CyberResearch has developed a manufacturing
technique that reduces ambient light reflection inside the display case, making our LCDs
appear brighter—even in direct sunlight.
CyberResearch’s CYRAQ®17A series employs our proprietary AR Bonding™
Technology, which seals the display and significantly reduces the transmission of
reflected light to the LCD. We’ve accomplished this by utilizing a high-quality bond that
optically couples the front cover glass to the face of the display. This technique
practically eliminates internal light reflection, which directly improves viewing quality.
Additionally, sealing the display with AR Bonding™ Technology greatly enhances its
structural integrity, providing superior shock protection and dually eliminating the
possibility of trapped moisture between the LCD and cover glass. This not only reduces
troublesome fogging in humid and moist conditions, it keeps condensation and wetness
away from your LCD.
Reducing the effect of ambient light reflection on your display can dramatically improve
its performance! When AR Bonding™ Technology is applied to a 250 nit display, it can
increase the effective contrast and provide the enhanced daylight viewing equivalent to
that of a 500 or 600 nit display without AR Bonding™ Technology. Minimizing refracted
ambient sunlight to the LCD yields a discernable increase in display performance.

CYRAQ 17A Series CyberResearch® Displays
4 ©Copyright 2007 CyberResearch, Inc
1.3 Product Safety and Regulatory Information
Environment
1. Dewdrop atmosphere must be avoided.
2. Do not operate and/or store in high temperature and/or high humidity
atmosphere. If customer stores the product, keep in antistatic pouch at room
temperature.
3. Do not operate in high magnetic field—circuit boards may be broken down by
it.
4. Use an original protection sheet on product surface (polarizer). Adhesive type
protection sheet should be avoided, because it may change color and/or
properties of the polarizer.
Specification for Products
1. Do not display a fixed pattern an extended period of time, it may cause image
sticking. If a fixed pattern is displayed on the screen, use a screen saver.
2. This product’s luminance is affected by voltage variation, even if power source
applies the recommended voltage to backlight inverter.
4. Optical characteristics may be changed by input signal timings.
Others
1. All GND, GNDB, VDD and VDDB terminals should be connected without a
non-connected signal line.
2. Do not disassemble the product.
3. If customer would like to replace backlight lamps, contact CyberResearch, Inc.
4. If customer users rivets, do not to leave waste material in inside of display.
5. When customer returns product for repair and so on, pack it with original
packaging to avoid damage during shipping.
General specifications for the LCD
The following items are neither defects nor failures.
1. Response time, luminance and color gamut may change with ambient
temperature.
2. Optical characteristics ( e.g. luminance, display uniformity, etc. ) gradually is
going to change depending on operating time, and especially low temperature,
because the LCD has cold cathode fluorescent lamps.

CyberResearch® Displays CYRAQ®17A Series
CyberResearch, Inc. 5
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com
1.4 General Specifications
Display
Display Type LCD flat panel
Video Input Types Standard analog VGA (15-pin)
DVI (Digital Visual Interface)
Screen Size (viewable area, diagonal) 17"
Display Filter Screen Size 15" to 18"
Display Brightness 500 nits (Super-Bright)
Display Filter Brightness Super-bright (350 to 740 nits)
Resolution, maximum 1280 x 1024 pixels
Resolutions Supported 1280 x 1024 pixels
Screen Protection Glass
Anti-reflective coating
Display Special Features Optional AR-Bonding
Maximum Number of Colors 16 million colors
Maximum Color Depth in Bits 24-bit color
Contrast Ratio 600:1
Aspect Ratio 5:4
° Horizontal 140°
Viewing Angle ° Vertical 130°
Vertical 56Hz....75Hz
Scanning
Frequency Horizontal 31.5KHz....60KHz
Dot Pitch 0.26mm
Response Rate GTG (gray-to-gray) 8ms
Backlight Type CCFT
Chassis
Mounting Configuration Rack-mount (EIA 19")
Swivel-arm mount
Protection Rating NEMA 4X
Display Filter Protection Water-resistant, corrosion-resistant (NEMA 4X)
Front Panel Material Stainless steel
Chassis Material Stainless steel
Height, Rack Units 8U (14")
Front Panel Color Black
Chassis Special Features
•Features an ultracompact, corrosion-
resistant enclosure of heavy-duty
stainless steel (304 SS). All models
come with a water-resistant sealed
front panel suitable for washdown.
•Built-in Poron® gasket seals between
rear of display and user panel. When
properly mounted in an appropriate
enclosure, these displays meet NEMA
4X standards for watertightness.
However, please note that most racks
do not meet NEMA 4 or 4X standards.
•Units without touchscreen feature
antireflecting, antiglare, hard-coat
glass screens.

CYRAQ 17A Series CyberResearch® Displays
6 ©Copyright 2007 CyberResearch, Inc
Mounting
VESA Mounting Hole Pattern 100x100mm VESA mounting holes
Mounting Flanges Built in (integral)
Touchscreen
Touchscreen Type Resistive touchscreen
Touchscreen Interface USB
Light Transmittance of Touchscreen 80%
Touchscreen Quantity of Wires 5-wire
Touchscreen Manufacturer Hampshire
Touchscreen OS Support
Windows XP
Windows NT
Windows 2000
Windows Me
Windows 98
Windows 95
Windows 3.x
MS-DOS
Linux
Macintosh OS
Windows CE
Windows NT 4
Windows 98SE
Touchscreen Resolution 4096 x 4096 points
Indicators, Switches, & Controls
On Screen Display (OSD) Control Functions
Brightness
Contrast
Horizontal position
Vertical position
Horizontal size
Color balance
Color temperature adjustment
Video source selection
Graphics/text mode select
Select language for OSD controls
Position of OSD controls
Reset to factory defaults
Phase adjustment
Sharpness
Auto adjustment
Gamma
Power On/Off Switch 1 on/off switch
OSD Controls Sealed OSD controls for menu navigation (5
membrane keys)
Brightness Via OSD controls
Front Panel
Controls
Contrast Via OSD controls
Power On/Off LED indicates power on
Indicators System in Sleep Mode Shown by change in LED color
Signal Connectors
Video Input Connectors HD15 (standard VGA) connector
DVI-D Dual Link (25-pin) connector
Touchscreen Connector USB (Type A / rectangular female)
Cables
Video Cable Length (included) 6 feet
Pointing Device Cable Length (included) 6ft (1.83m)

CyberResearch® Displays CYRAQ®17A Series
CyberResearch, Inc. 7
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com
Power Supply
Nominal Input Voltage(s) 115/230VAC
Input Voltage Range(s) 100...240VAC
Input Frequency 50/60Hz
Power Supply Input Connector NEMA standard male PC cord socket
Cable from Power Supply to Display (length) 6ft (1.83m)
DC Input Power Info
DC Power Input Connector on Display On rear panel
On bottom of unit
Power Consumption
Power Consumption, typ. (power supply) 48W (on), 2W (standby)
Power Consumption Details Input: 100-240VAC @ 50/60Hz
Cooling
Cooling Summary 2 cooling fans
Number of Fans of This Type 2
Fan Size 60mm X 60mm
Volume of Air Movement (CFM
per fan) 16cfm
Cooling Fans
Fan Location(s) Rear
Air Filter Location Rear
Environmental Specifications
Operating Temperature 32°F....122°F (0°C....50°C)
Storage Temperature -4°F....140°F (-20°C....60°C)
Relative Humidity, noncondensing 10%....95%
Power Management EPA Energy Star compliant
Dimensions – PANEL-MOUNT
Width 16.02" (407mm)
Height 14.49" (368mm)
Depth (including handles) 3.03" (77mm)
Depth Behind Panel 2.8" (71mm)
Protrusion from Rack (including
handles) 0.3" (7.62mm)
Panel-Mount Cutout, Width 15.2" (386mm)
Panel-Mount Cutout, Height 13.7" (348mm)
Dimensions – RACK-MOUNT
Width 19" (482.6mm)
Height 14" (355.6mm)
Depth (including handles) 3" (76.2mm)
Width, Rack-Mount EIA standard 19 inches at flanges
Height, Rack Units 8U (14")
Depth Behind Panel 2.8" (71.12mm)
Protrusion from Rack (including handles) 0.3" (7.62mm)
Weight
Weight 17.5lbs (7.94kg )
Weight of External Power Supply 1.4lbs (635.03g )
Display Filter Weight Under 20 lbs.

CYRAQ 17A Series CyberResearch® Displays
8 ©Copyright 2007 CyberResearch, Inc

CyberResearch® Displays CYRAQ®17A Series
CyberResearch, Inc. 9
25 Business Park Drive P: [phone]; F: [phone]
Branford, CT USA www.cyberresearch.com
1.5 Overview
The CyberResearch®CYRAQ®17A series is a 17-inch analog/digital LCD monitor that
offers the highest quality images possible with dual analog and digital source input. The
CYRAQ 17A offers a 600:1 contrast ratio, 1280 x 1024 resolution, pixel pitch of
0.260mm, 140°/130° viewing angle, Analog/Digital video inputs, a scanning frequency
of 31.5-60 kHz horizontal and 56-75 Hz vertical, and advanced image scaling.
¾17" Viewable Screen Size
¾1280 x 1024 @ 67 Hz
¾0.26 MM Dot Pitch
¾Connects Via VGA (15-Pin) and Digital (DVI)
¾NEMA 4X Rating
¾Rack, Panel, or Swivel-Arm Mounted
1.5.1 System Requirements
To achieve optimum response time the CYRAQ 17A requires a computer with CPU
speeds of 486 or higher. The CYRAQ 17A is compatible with Windows and Macintosh
operating systems. To operate the display at its highest resolution a video card that
supports 1280 x 1024 pixels is required.

CYRAQ 17A Series CyberResearch® Displays
10 ©Copyright 2007 CyberResearch, Inc
2Setup
2.1 Unpacking the CYRAQ®17A Series
Before unpacking it is very important to locate the CYRAQ 17A series monitor in a
suitable environment. Make sure the installation location has good ventilation, is out of
direct sunlight, away form excessive dust, dirt, heat, water, moisture and vibration. Please
see General Specifications section for environmental details.
2.1.1 Your Package Contains:
1) 1 CYRAQ 17A series display
2) 1 CYRAQ Drivers & Manuals CD
3) 1 Power Cable and connector
4) 1 AC to DC Power Converter
5) 1 VGA cable
6) 1 DVI cable
7) 1 User’s Manual
8) 10-32 x 1/2″Button Head Mounting Bolts.....................Rack-Mount Models Only
9) Mounting Clamps...........................................................Panel-Mount Models Only
Optional Accessories:
1) Longer VGA and DVI cables (call for available lengths)
2) 1 Touchscreen connector cable (USB or Serial) for Touchscreen models
3) SWC VESA mounting plate for VESA mount models
3 NOTE: If any of these items are missing or damaged contact
CyberResearch, Inc. immediately
