Cybertek PS202 User manual

Shenzhen Zhiyong Electronics Co., Ltd
www.cybertek.cn
Current Transducer Power Supply
PS202/204
Shenzhen Zhiyong Electronics Co., Ltd
CYBERTEK

Shenzhen Zhiyong Electronics Co., Ltd
Preface
First of all, thank you for purchasing our products, this instruction manual is the description about the
function, usage, operation attention points, etc. Before use, please read the instructions carefully and use
correctly.
Manual annotation will use the following symbols to distinguish.
This product is the power supply designed for our CTAseries high accuracy current transducer, so we
require users to:
 Do not try to connect cables or open the shell during operation. Do not use the device in damp or
combustible environment. Make sure the surface of the device is dry and clean before usage.
 Make sure the product is used in rated voltage and current range.
 If there’s anything wrong with our product, please contact us immediately. Do not open the shell
and try to repair on your own to avoid accident.
Notice
Warning
In the case of wrong operation, the user risk injury. The content under this mark records
the relevant matters needing attention to avoid such dangers.
The user may suffer minor injuries and material damage with the wrong operation. To
avoid such situation, the matters under this mark need attention.
This symbol means it is harmful to the machine and human body; you must strictly
follow the instruction manual to operate.
Note
This symbolizes important note about how to use the machine.
CYBERTEK

Shenzhen Zhiyong Electronics Co., Ltd
1. Summary
PS202/204 is the power supply designed for CTA series high accuracy current transducer. PS202
has two channels and can power up two CTA series at max. PS204 has four channels and can power up
four CTA series at max.
2. Electronic Specification
Input Voltage Range
90~264VAC
Frequency
47~63Hz
Output Voltage Range
±15V
Output Current Range
0~6A (1.5A for each channel)
Max Output Power
180W
VoltageAdjust Range
14.25~15.75V
Efficiency
80%
Power Factor
≥0.9
Overload Protection
130%~160% of rated output power
Over Voltage Protection
17.25~20.25V
CK-330 (Accessories)
2m (length optional) max current 1.2A
Operating environment humidity
20~70%RH no cooling
Operating environment temperature
-20~+70℃
Storing temperature and humidity
-40~+85℃、10~95%
Size
210mm(L)×110mm(W)×170mm(H)
Weight
1.83kg
3. Test Diagram
3.1 Test Diagram of PS202/204 and CTA700/1000
CYBERTEK

Shenzhen Zhiyong Electronics Co., Ltd
3.2. Test Diagram of PS202/204 and CTA60/200
4. Accessories
5. Steps of Test Installation

Plug in the LEMO connector before testing and turn on the power of PS202/204

The output connector of CTAseries transducer cannot be open circuit.

The female connector of DB-9 must be connected tightly and fix the screws on two sides
6. Precautions
 Please do not open the shell during the operation. Do not use the device in damp or combustible
environment. Make sure the surface of the device is dry and clean before usage.
 Please carefully read the instruction manual and learn the knowledge before testing. Please test
according to the correct step.
 We recommend using this power supply together with the CTA High Accuracy Current series
transducer of our company in order to avoid accident.
 If there’s anything wrong with our product, please contact us immediately. Do not open the shell
and try to repair on your own to avoid accident.
CYBERTEK

Shenzhen Zhiyong Electronics Co., Ltd
7. Packing List
Packing list
Name
Number
Power Supply
1
AC Power supply cable
1
Instruction Manual
1
Warranty Card
1
