CybioTronics CY-383 User manual

2.4 GHz Digital
Caller ID/Call Waiting Type 2.5 with Call Waiting ID Options
Owner’s Manual
Installation and
Operating Instructions
CALL ER ID / CAL L ER ID CAL L W AITING /
CALL W AITING ID OPTIONS COM PATIBLE
Caller ID, Caller ID Call W aiting, and/or Call Waiting ID Options
services, where available, are available from Verizon. After
s bscribing to Caller ID, Caller ID Call Waiting and/or Call
Waiting ID Options services, this phone will display Caller/Caller
Wait
ed party’s name and phone n mber, and the associated soft
keys of the Call W aiting ID Options service.
Please read
this m anual
carefully
efore use.
Keep for your
reference.
CY-383
EXPANDABLE CORDLESS SYSTEM

1
PAG E
IM PORTANT INFORM ATION.............................................................................................4
IMPORTANT SAFETY INSTRUCTIONS...............................................................................4
SPECIAL FEATURES...............................................................................................................5
CHOOSE THE BEST LOCATION...........................................................................................6
LOCATION OF CONTROLS...................................................................................................7
Handset....................................................................................................................................7
Base Unit.................................................................................................................................9
LC ISPLAY........................................................................................................................10
Backlit LC isplay.............................................................................................................10
Backlit Keypad......................................................................................................................10
QUICK REFERENCE.............................................................................................................11
GETTING STARTED............................................................................................................15
CHARGING THE BATTERY PACK......................................................................................15
Low Battery...........................................................................................................................15
Clean the Battery Contacts....................................................................................................15
CONNECTING THE BASE UNIT.........................................................................................16
REGISTRATION & E-REGISTRATION OF HAN SETS.................................................16
Registration...........................................................................................................................16
e-register a handset.............................................................................................................17
CHOOSE THE IALING M O E..........................................................................................18
WALLM OUNTING BASE UNIT...........................................................................................19
M EN U .....................................................................................................................................20
STRUCTURE AN OPTIONS...............................................................................................20
INITIAL SETTINGS.............................................................................................................21
Naming..................................................................................................................................21
Language...............................................................................................................................21
Ringer & Beep......................................................................................................................22
Answer M ode........................................................................................................................23
Contrast.................................................................................................................................23
Call W aiting I Options........................................................................................................23
New Call Lamp.....................................................................................................................24
Time and ate Setting...........................................................................................................24
Intercom Set Up....................................................................................................................24
M essage Waiting Indicator....................................................................................................24
Setting Alarm 24
BASIC OPERATION.............................................................................................................2
MAKING A CALL..................................................................................................................26
irect ial.............................................................................................................................26
ANSWERING A CALL..........................................................................................................27
TO RE IAL A CALL.............................................................................................................27
irectly Redial Last ialed Numbers...................................................................................27
ial from the List of ialed Numbers..................................................................................27
A JUSTING HAN SET RECEIVER VOLUM E.................................................................28
TO M UTE A CALL.................................................................................................................28
PAGING AN INTERCOM ...................................................................................................28
Locate misplaced handset(s).................................................................................................28
C O NT E NT S

2
Page
Intercom between handsets...................................................................................................28
USING HAN SET SPEAKERPHONE..................................................................................29
INSTALLING AN USING HEA SET................................................................................29
ADVANCED OPERATION ..................................................................................................30
FLASH.....................................................................................................................................30
Call W aiting..........................................................................................................................30
PAUSE.....................................................................................................................................30
Enter a Pause in ialing Sequence.......................................................................................30
HOL .......................................................................................................................................30
SEN ING TONE SIGNALS IN PULSE IALING M O E..................................................31
IAL VOICE M AIL................................................................................................................31
Program your own Voicemail access number.......................................................................31
Using IAL V.M . softkey.....................................................................................................31
IAL BACK FROM CALLER I LIST................................................................................32
AILING FROM PHONE BOOK IRECTORY..................................................................32
CONFERENCE CALL............................................................................................................33
3 Way calling.........................................................................................................................33
Room M onitoring.....................................................................................................................33
The handset in the room to be monitored.............................................................................33
The handset used for monitoring..........................................................................................33
CALLER ID OPERATION...................................................................................................34
ABOUT CALLER I ENTIFICATION...................................................................................34
CALLER LIST.........................................................................................................................34
M emory M atch......................................................................................................................34
Review Caller List................................................................................................................34
elete Record(s) from Caller List.........................................................................................35
Call Back from Caller List....................................................................................................35
Special Call isplay..............................................................................................................35
Call isplay M essages..........................................................................................................36
CALL WAITING I OPTIONS..............................................................................................36
Call W aiting I Options Set to OFF.....................................................................................36
Call W aiting I Options Set to ON.......................................................................................37
Call W aiting I Options: JOIN.............................................................................................37
Call W aiting I Options: HOL ..........................................................................................38
PHONE BOOK DIRECTORY.............................................................................................39
CREATING A PHONE BOOK IRECTORY RECOR .......................................................39
Copy from a Caller I Number............................................................................................39
Add a New Number/Name....................................................................................................40
REVIEWING PHONE BOOK IRECTORY.........................................................................40
E ITING A PHONE BOOK NUMBER.................................................................................41
ELETING AN ENTRY FROM A PHONE BOOK IRECTORY.......................................41
ELETING ALL PHONE BOOK IRECTORY RECOR S ...............................................42
IALING FROM PHONE BOOK IRECTORY..................................................................42
M ULTI-HANDSET OPERATION .......................................................................................43
INTERCOM .............................................................................................................................43
CALL TRANSFER..................................................................................................................44
Blind Transfer.......................................................................................................................44
C O NT E NT S

3
Page
Announced Transfer..............................................................................................................44
Transferring to all handsets...................................................................................................45
CALL CONFERENCING.......................................................................................................45
M ultiple Party Conference Call............................................................................................45
WALKIE-TALKIE OPERATION............................................................................................45
Enter into Walkie-Talkie mode.............................................................................................46
Operating Walkie-talkies.......................................................................................................46
OPTIONAL FEATURES DIAL LIST.................................................................................47
IALING SERVICES .............................................................................................................47
ADDITIONAL INFORM ATION .........................................................................................48
CAPACITY..............................................................................................................................48
M emory.................................................................................................................................48
Call Repeat Number..............................................................................................................48
OUT OF RANGE.....................................................................................................................48
NO CONNECTION.................................................................................................................48
TROUBLE SHOOTING .......................................................................................................49
CARE AND M AINTEN ANCE.............................................................................................50
FCC REQUIREM ENTS........................................................................................................51
WARRANTY..........................................................................................................................53
WALL M OUNT TEM PLATE 54
C O NT E NT S

4
Important Safety Instructions:
To reduce the risk of fire, electric shock and/or injury to persons, always follow
these asic safety precautions when using your telephone equipm ent.
1. Read, understand, and follow all instructions.
2. Unplug this telephone from the wall outlet
before cleaning. Do not use liquid or aerosol
cleaners. If necessary, use a soft cloth lightly
m oistened with a m ild detergent solution.
3. Do not use this telephone near a bathtub,
itchen sin , wash bowl, laundry tub, swim m ing
pool, a wet basem ent or anywhere else there is
water or liquid.
4. Do not place this telephone on an unstable cart,
stand or table. A fall could cause serious
dam age to the phone.
5. Slots and openings in the cabinet at the bac or
bottom are provided for ventilation to protect the
unit from overheating. These openings m ust
not be bloc ed or covered. Do not place this
telephone on a bed, sofa, rug or other sim ilar
surface. This telephone should never be
placed near or over a radiator or heat register.
This telephone should not be placed in a built-in
installation unless proper ventilation is provided.
6. Never push objects of any ind through slots in
the phone. They could touch dangerous
voltage points or short out parts that could result
in a ris of fire or electric shoc . Never spill
liquid of any ind on the telephone.
7. Unplug this telephone from the wall outlet and
refer to a qualified service representative in any
of the following situations:-
a) If liquid has been spilled into the telephone.
b) If the telephone has been exposed to rain or
water.
c) If the telephone does not operate norm ally by
following the operating instructions. Adjust
only those controls that are covered by the
operating instructions. Im proper adjustm ent
of other controls m ay result in dam age and
will often require extensive wor by a
qualified technician to restore the telephone
to norm al operation.
d) If the telephone has been dropped or the
case has been dam aged.
e) If the telephone exhibits a distinct change in
perform ance.
8. Do not use the telephone to report a gas lea in
the vicinity of the lea .
9. Avoid using a telephone (other than a cordless
type) during an electrical storm. There m ay be
a rem ote ris of electric shoc from lightning.
10. Never install jac s in a wet location unless the
jac is specifically designed for wet locations.
11. Never touch uninsulated telephone wires or
term inals unless the telephone line has been
disconnected at the networ interface.
12. Use with caution when installing or m odifying
telephone lines.
13. To reduce the ris of electric shoc , do not
disassem ble this product, but ta e it to a
qualified servicem an when som e service or
repair wor is required. Opening or rem oving
covers m ay expose you to dangerous voltages
or other ris s. Incorrect reassem bly can cause
electric shoc when the appliance is
subsequently used.
14. Use only the power cord and batteries indicated
in this m anual. Do not dispose of batteries in
fire. They m ay explode. Chec with local
codes for possible special disposal instructions.
1 5 . Plug the adaptor to the soc et-outlet that near
the equipm ent and shall be easily accessible.
16. CAUTION
RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE.
USE BATTERY TY PE ONLY CYB-103, NiMH
3.6V, 750m Ah
DISPOSE OF USED BATTERIES ACCORDING
TO YOUR LOCAL CODE.
IM PO RTAN T IN FO R M AT IO N
Use only with Class 2 Power Source, 7.5V DC, 500m A for ase unit
SAVE THESE INSTRUCTIONS
SAVE THESE INSTRUCTIONS
SAVE THESE INSTRUCTIONS

5
SPECIAL FEATURES
The CY-383 Expandable Cordless S stem is designed and engineered to exacting
standards for reliabilit, long life, and outstanding perform ance.
Note:
Charge all of the atteries for at least 15 hours prior to initial use.
SEE PAGE 15 FOR DETAILS!
• 2.4 GHz Digital FHSS Cordless Phone
• Multiple handsets capability, supports up to 4 handsets
If you want an additional handset s) for this m ulti-handset s ystem , you m ay
purchase model CY-381 from SBC Com m unications at 1-800-667-2118)
• Multi-party Conference call between handset s) and an external line
• Two-way intercom between 2 handsets
• Ornam ental lighting with on/off s witch. This night light is selectable in blue and
violet.
• Room m onitoring
• 3 Ringer selections and 10 s electable ring tones
• Handset-to-Hands et W alkie-Talkie function totally independent of the base unit.
• Handsfree speakerphone on handset
• Caller ID Type I, II and Call W aiting ID Options capability
• Backlit 7-Line Multi-Function LCD on handsets
• Five soft keys on each handset to access different functions depending on which
m ode the phone is currently in.
• Volum e Controlled Handset Earpiece and Speakerphone
• New Call/Voice Mail Mes sage W aiting Indicator on handset
• Out of Range indication
• Non-volatile m em ory for 40 Nam e and Num ber Caller ID Records, 40 Pers onal
Nam es and Num bers on each handset, 32 General Nam es and Num bers Phone
Book Directory s hared am ong all handsets, and 22 Las t Dialed Num ber directory on
each hands et.
• English/Spanis h Intelligent LCD Display
• Real Tim e Clock and Alarm Clock
• Built-in DSL Filter
• 2.5 m m Heads et Jack
I MP O R T AN T IN F O R M AT IO N

6
Check to be s ure that the following item s com e with the phone. If there is anything
m issing or any vis ible dam age, contact the original place of purchase. Do not attem pt
to operate the s ystem if it is damaged.
• Base Unit
• One Handset with Belt Clip
• One Battery Pack
• One Long Telephone Line Cord
• One Short Telephone Line Cord for W all Mounting
• One AC Adaptor
• Owner’s Manual s)
CHOOSE THE BEST LOCATION
Calls are transm itted between the base unit and the handset, or between hands ets, by
using wireless radio waves. For m axim um dis tance and noise-free operation, here are
som e im portant guidelines you s hould cons ider:
1. The location s hould be close to both a phone jack and a continuous power outlet
which is not switch-controlled.
2. Keep the bas e and the handset away from s ources of electrical nois e such as TV,
pers onal com puter, or another cordless phone.
3. Place base in a HIGH, CENTRAL location with no obs tructions s uch as walls.
4. The bas e can be placed on a desk, tabletop or m ounted on wall.
Note:
W hile using the handset:
If you are near a m icrowave oven which is being used, noise m ay be heard from the
receiver or the speaker. Mo ve away from the m icrowave oven and closer to the bas e
unit.
If m ore than one cordless phone is being us ed and your handset is near another
cordless phone’s base unit, noise m ay be heard. Move away from other cordless
phone’s base unit and closer to your base unit.
I MP O R T AN T IN F O R M AT IO N

7
LOCATION OF CONTROLS
Handset
Line Indicator
a) Flashes rapidly when ringing.
b) Flashes regularly if you have m essage in your voicem ail or new Caller ID in Call Log.
c) Lights when the handset is in use.
Talk / OFF Key
Allows you to access the telephone line or to release the line.
Speakerp one Indicator
Lights when speakerphone is in us e.
Speakerp one Key [Spk.]
a) Press to activate / deactivate the hands free s peakerphone during a call
b) Dial the num ber on the dis play with s peakerphone m ode.
You are still required to press [OFF] to end your call.
Mute / Dial 7 Key
a) W hile reviewing the Call ID Record, press [Dial 7] to Call Back in 7-digit form at.
b) W hile on a call, press [Mute] to m ute the m icrophone for privacy.
Redial / Pause / Dial 10 Key
a) W hile reviewing the Call ID Record, press [Dial 10] to Call Back in 10-digit form at.
b) W hile off-hook, press [Redial] to recall and dial the las t phone num ber dialed.
c) W hile on-hook, press [Redial] to access the Redial List. Us ing [▼ ] or [▲ ] to select
the desired num ber and press [Talk] or [O.K.] softkey to dial it.
d) Pressing the key during Pre-dial or Phone book directory num ber entry will enter a
3-second pause into a dialing s equence, indicated by “P”.
I MP O R T AN T IN F O R M AT IO N

8
Flas / Dial 11 Key
a) W hile reviewing the Call ID Record, press [Dial 11] to Call Back in 11-digit form at.
b) The [Flas h] key is us ed to access telephone com pany services s uch as Call W aiting.
Scroll Keys [▼] / [▲]
a) W hile on a call, press [▼ ] / [▲ ] to adjust the volum e.
b) During s tandby, press [▼ ] / [▲ ] to s croll through Menu options ; access Caller ID
Records , Phonebook Directory Records and Redial Lis t.
Intercom Key [Int.]
During standby, press the key to activate the intercom function between hands ets ,
answer a paging call, or term inate an intercom call. W hile on a line, press the key to
trans fer the call to a particular hands et.
5 Softkeys
These softkeys are us ed to select functions dis played directly above the keys .
Functions displayed above the keys will change depending on the m ode of operation.
For exam ple, on the display below, [SAVE], [SERVICE], [M ENU], [DIR.] & [DIAL V.M.] are
displayed above the s ofkeys. To operate the phone book directory, press the second
softkey from the right-hand-side.
I MP O R T AN T IN F O R M AT IO N
e.g.
Pressing this softkey
during idle m ode will
enter into phone book
directory.

9
Base Unit
C arge Indicator
Illum inates when handset is charging
Page Key
During standby, press the key to page all handsets within range.
Lig ting On / Off Key
Press to switch on/off the base unit lighting or to select the blue or violet night light.
I MP O R T AN T IN F O R M AT IO N

10
LCD DISPLAY
Backlit LCD Display
The handset has the backlit LCD display. It will light when you start using the handset
or when a call is received. The dis play light will stay on for a few seconds after press ing
a button or lifting the handset off the bas e unit.
Backlit Keypad
The Talk, Int., Spk. and the num eric keys will be lit when you press a key or when a call is
received. The light will s tay on for a few seconds after press ing a key or ans wering a
call.
Caller’s Nam e
Caller’s Num ber
Calling Tim e
& Date
Sequence in caller list
Labels of 5 softkeys
I MP O R T AN T IN F O R M AT IO N
Num ber of calls
from sam e caller
Special call
inform ation

11
QUICK REFERENCE
Task Steps Page
1 Adjust receiver /
Speakerphone volum e
The handset has 4 Adjustable volum e
levels VOL-1 – VOL-
4) showing the current
display during off hook. Press [
▼ ] / [▲ ] to
adjust during a call.
28
2 Making a call 1. Press [Talk] or [Spk.] on the handset
and lis ten for a dial tone.
2. Dial num ber.
3.
To hang up, press [OFF] on the handset
or return the hands et to charge cradle.
26
3 Answering a call Auto m ode is the default m ode setting of
the phone:
If the handset is on the charge cradle, just
lift the handset and the line is autom atically
connected.
If the phone is set to Manual m ode, or
whenever the handset is not on the charge
cradle, to answer a call:
1. Press [Talk] or [Spk.] key on the
handset to pick up a call
2.
To hang up, press [OFF] on the handset
or return the hands et to charge cradle.
27
4 Last num ber redial 1. Press [Talk] key and lis ten for dial tone.
2. Press [Redial] to dial the last dialed
num ber.
27
5 Dial from the Redial Lis t 1. Press [Redial].
2. Use [▼ ] / [▲ ] scroll keys to access
desired num ber from the list of up to 22
last dialed num bers.
3. Press [Talk] or [OK] ke y to dial the
num ber.
27
6 Review Caller Lis t Use [▼ ] / [▲ ] scroll keys to review caller’s
inform ation during s tandby m ode.
34
I MP O R T AN T IN F O R M AT IO N

12
QUICK REFERENCE
Task Steps Page
7 Call back a num ber in
Caller Lis t
1. Scroll to a desired record in Caller Lis t.
2. Press [Talk] to dial.
3. If the num ber dis played is not in the
desired dialing pattern, press [Dial7],
[Dial10] or [Dial11] to dial in the correct
num ber of digits .
35
8 Store Caller ID num ber
into Phone Book
Directory
1. Scroll to the desired Caller ID num ber.
2. Press [SAVE] softkey to s tore.
3. Press [OK] or [JOIN] softkey to select
storing in Private or General Directory
39
9 Manually add a new
num ber into Phone Book
Directory
1. Press [DIR.] s oftkey.
2. Press [SAVE] softkey to s tore.
3. Press [OK] or [JOIN] softkey to select
storing in Private or General Directory
4. Follow the on-s creen instructions to
enter the phone num ber, nam e, and to
select the ring tone.
39
10 Dial from Phone Book
Directory
1. Press [DIR.] s oftkey.
2. Press [OK] or [JOIN] softkey to select
from Private or General Directory
3. Use [▼ ] / [▲ ] scroll keys to find the
desired directory record.
4. Press [Talk] or [Spk.] to dial.
5. If the num ber dis played is not in the
desired dialing pattern, press [Dial7],
[Dial10] or [Dial11] to dial in the correct
num ber of digits .
42
11 Switch to a waiting call Press [Flash] to put the talking party on
hold and talk to the waiting party.
If Call W aiting ID OPTIONS is subs cribed
to, m ore options are available.
30
36
12 Page from base to
handset s)
1. Press [Page] key.
2. To term inate the paging, press [EXIT]
softkey on handset or [Page] key on
bas e unit again.
28
I MP O R T AN T IN F O R M AT IO N

13
QUICK REFERENCE
Task Steps Page
13 Intercom call between
two handsets
1. Press [Int.].
2. Use [▼ ] / [▲ ] scroll keys to select the
desired handset and press [O.K.].
3. To term inate the paging, press [EXIT]
softkey or [Int] key.
28
43
14 Blind Call Transfer 1. W hile connected to an external line,
press [Int.] ke y.
2. Use [▼ ] / [▲ ] scroll keys to select the
handset to which the call is trans ferred.
3. On the recipient side, press [O.K.] soft-
key or [Talk] to take the call.
44
15 Announced Call Trans fer
1. W hile connected to an external line,
press [HOLD] softkey to put the line on
hold.
2. Press [Int.] and s croll to the desired
recipient and press [O.K.].
3. After the private convers ation, the
recipient press es [Talk] to take the call.
44
16 Multiple Hands ets
Conference
W hile a handset is engaged in an external
call, another handset can press [Talk] key
to join the convers ation. The maxim um
num ber of parties in the conference is 2
handsets.
45
I MP O R T AN T IN F O R M AT IO N

14
QUICK REFERENCE
Task Steps Page
17 Room Monitoring On the handset in the room to be
m onitored:
1. Press [MENU] softkey
2. Scroll to the [MONITOR ROO M ] m enu
and press [O.K.]. The handset will
display “ READY TO ROO M
MONITORING”.
On the handset us ed for m onitoring:
1. Press [Int.] key.
2. Using [▼ ] / [▲ ] scroll keys to select the
handset in the room to be m onitored
and press [O.K.] to s tart.
The link is autom atically s et up while the
com m unication is only one-way.
To end the m onitoring, press [EXIT] or [Int.]
key on either handset.
33
18 W alkie-Talkie m ode
Two or m ore hands ets
entered into walkie-talkie
m ode can com m unicate
with each other totally
independent of the base
unit if they are within
range of each other.
To enter walkie-talkie FRS) m ode:
1. Press [MENU] softkey.
2. Using [▼ ] / [▲ ] scroll keys to access
W alkie- talkie m enu.
3. Press [O.K.] to confirm s election and
the dis play shows “W ALKIE-TALKIE”.
To operate as walkie-talkie FRS):
1. Press [Int.] key.
2. Press the handset num ber which is in
W alkie-talkie m ode. The called
handset can answer by pressing [Talk],
[Int.] or [O .K.] key.
45
I MP O R T AN T IN F O R M AT IO N

15
Your new telep one includes t e ig est quality NiMH (Nickel Metal Hydride)
rec argeable batteries available. Following t ese sim ple instructions can
significantly im prove your operational results.
CHARGING THE BATTERY PACK
Charge all battery packs for at least 15 hours prior to connecting to the telephone line.
1. Press the battery release point on the back of the handset and slide downward to
open the battery com partm ent.
2. Insert the battery pack into the battery com partm ent and m ake sure to position the
battery pack s o that it is touching the charging contacts .
3. Slide the battery co ver upward until it s naps into place.
4. Connect the AC adapter to the 7.5V DC jack of the base unit and to a s tandard 120V
AC wall outlet.
5. Place the handset on the base unit. Make sure the Charge indicator on the bas e
unit lights, and charging begins .
6. The battery icon on the handset changes from very low, to low, to m edium , to full
and repeats as a cycle. It only stops after leaving the charging cradle.
Low Battery
The battery icon on the right of the dis play shows the level of battery.
Full Medium Low Very low
If the handset battery is not properly charged, there is a warning tone while the handset
is in use and “BATTERY LOW ” is dis played. W hen this occurs the hands et does not
function when you press the keys .
Cleaning t e Battery Contacts
To m aintain a good charge, it is im portant to clean all battery contacts on the handset
and the base unit with a soft, dry cloth about once a month. You m ay also us e a pencil
eras er or other contact cleaner. Do not use any liquids or solvents.
G ET T IN G STAR T ED

16
AC POW ER
Caution:
1. Use ONLY with the supplied AC Adaptor AC 120V, DC7.5V, 500m A).
2. Plug the adaptor to an electrical outlet that is near the equipm ent and is easily
access ible.
3. The AC adaptor m ust rem ain connected at all tim es It is norm al for the adaptor to
be warm during use).
4. Do not rem ove the battery from the handset to charge it. Do not dispose of
batteries in a fire. They m ay explode. Check with local codes for possible special
disposal instructions.
5. Do not rem ove or dam age the battery cas ing.
6. If you do not expect to us e your phone for a m onth or longer, rem ove the batteries .
Batteries can leak chem icals that can destroy electronic parts .
7. For the longest battery life and optim al operation of the phone s ystem ALW AYS
com pletely charge and dis charge the batteries.
CONNECTING THE BASE UNIT
1. Plug one end of the telephone line cord into the jack at the bottom of the bas e unit
and plug the other end of the cord into the m odular telephone wall jack.
2. Plug the AC adapter into the 7.5V DC jack on the bas e and the other end into a
standard 120V AC wall outlet.
3. Set the base unit on a tabletop and then place the handset on the base unit.
Note:
1. Use only the AC adaptor supplied.
2. Connect the AC adaptor to a continuous power outlet.
3. Place the base unit close to the AC outlet s o that you can unplug the AC adaptor
easily.
Tip:
If your telephone outlet is not m odular, contact your telephone com pany for ass is tance.
REGISTRATION & DE-REGISTRATION OF HANDSET
The first regis tered hands et will be autom atically ass igned as HS 1). W hen additional
handsets are regis tered to the sys tem , they will be ass igned extension num bers in the
following s equence: HS 2), HS 3) and HS 4). They can be renam ed later.
Registration
An unregis tered handset will dis play “HS_ _”.
NO NEW CALLS
HS_ _
12:00AM 01/01

SAVE SERVICE MENU DIR. DIAL V.M.
G ET T IN G STAR T ED

17
Press [MENU] soft key, “REGISTR ATION” is dis played.
Press [O.K.] and ADD A HANDSET?” is displayed.
Press [O.K.] again. “PRESS AND HOLD BASE [PAGE]
KEY UNTIL HS BEEPS” will be displayed.
On t e Base unit
Press and hold the [Page] button until beeps are heard.
The registration process is now com plete.
De-register a andset
You can de-register a regis tered handset from the base unit.
On t e Handset:
Press [M ENU] and “REG STRAT ON” appears on the
display.
Press [OK] to enter Registration m enu.
Using [▼ ] / [▲ ] to select “DEL HANDSET?”.
Press [O.K.] and “DEREG STER HS (#)” is displayed.
REGISTRATION 
NAME HANDSET
USE / =REVIEW
O.K. EXIT
ADD A HANDSET?

O.K. EXIT
.
PRESS AND HOLD
BASE [PAGE] KEY
UNTIL HS BEEPS

EXIT
REGISTRATION 
NAME HANDSET
USE / =REVIEW
O.K. EXIT
DEREGISTER
HS (1)?

O.K. EXIT
G ET T IN G ST AR T E D

1 8
Press [OK] to confirm . “DEREGISTERING…” will be
dis layed during the rocess. W hen deregistration
rocess is com leted, the unit will return to Registration
m enu.
“HS_ _” will be shown after the handset return to standby.
CHOOSE THE DIALING M ODE
If your tele hone is equi ed with a touchtone dialing system , the hone will be ready to
use as soon as the battery is charged. If your line uses ulse (rotary) dialing, you will
need to set the dialing mode as follows:
Press [M ENU] and “REGISTRATION” appears on the
display.
Usin [▼ ] / [▲ ] to access “DIAL M ODE”.
Press [OK] to enter Dial m ode m enu.
Using [▼ ] / [▲ ] to select “PULSE MODE”.
Press [SAVE] to confirm .
The dis lay will return to “DIAL MODE”, ress [EXIT] to
return to standby.
You are now ready to use your new telephone
REGISTRATION 
NAME HANDSET
DIAL MODE

O.K. EXIT
REGISTRATION 
RINGER & BEEP
USE / =REVIEW
O.K. EXIT
WALKIE-TALKIE v
NAME HANDSET
DIAL MODE

O.K. EXIT
TONE v
PULSE
USE SAVE = DONE
EXIT
MESSAGES
HS (2)
10:08AM 01/1

SAVE SERVICE MENU DIR. DIAL V.M.
SAVE
G ET T IN G ST AR T E D

1 9
WALLMOUNTING BASE UNIT
The base unit can be m ounted on a standard wall phone plate
1. Plug the AC adapter’s barrel plug into the jack marked “7.5 500m A” at the bottom
of the base unit.
2. Plug the short telephone line cord into the jack m arked “LINE”.
3. Hold the base unit up next to the wall jack and plug the line cord into the wall jack.
4. Place the base unit on the posts of the wall plate and push down until the unit is
secured firm ly.
5. Plug the AC adapter into a standard wall outlet.
Note: If you are not using a standard wall plate to m ount the phone on a wall, you m ay
also m ount it with ordinary screws. Use the W all Mount Tem plate on page 54 to affix
two screws at your desired location. Rem em ber to leave 1/8 inch of the screw
extending from the wall.
Please charge all the batteries for at least 15 hours prior to initial use.
G ET T IN G ST AR T E D
