CYCLOPS PARALYSER 355 User manual

PARALYSER 355, 375,
375b &385
USER INSTRUCTIONS
Proudly designed and engineered
in Australia by Dynamco Pty Ltd.
CYCL PS
VEHICLE SOLUTIONS
P355 P375 P375B 385 User - 2008.1 1 16/07/2008 3:20:41 PM

THIS CARD SHOULD NOT BE LEFT IN YOUR VEHICLE.
IT MUST BE KEPT IN A SAFE SECURE PLACE.
-2-
CYCL PS
VEHICLE SOLUTIONS
P355 P375 P375B 385 User - 2008.2 2 16/07/2008 3:20:41 PM

-3-
Contents
INTRODUCTION 4
OPERATIONS 5
REMOTE CONTROLS 5
ARMING AND DISARMING 5
ARM/DISARM SIREN CONFIRMATION 6
SILENT ARMING 6
AUTOMATIC ARMING 6
DOME LIGHT FUNCTION 7
PANIC FEATURE (Car Location) 7
OPEN DOOR WARNING 7
IMMOBILISATION 8
ALARM PROTECTION ZONES 8
DIAGNOSTICS 8
DIAGNOSTIC TABLE 9
EMERGENCY OVER-RIDE 9
PIN OVER-RIDE PROCEDURE 10
PROGRAMMABLE OPTIONS 11
OPTION CHANGE PROCEDURE 11
PROGRAMMABLE OPTIONS TABLE 12
PROGRAMMABLE OPTION DESCRIP-
TIONS 13
CHANGING PIN CODE 15
BATTERY REPLACEMENT 16
SPECIFICATIONS 17
PROBLEM SOLVING 18
WARRANTY 19
WARRANTY REGISTRATION 20
P355 P375 P375B 385 User - 2008.3 3 16/07/2008 3:20:41 PM

CYCLOPS P355, P375,
P375B & P385 ALARM /
IMMOBILISER USER GUIDE
INTRODUCTION
Congratulations on having one of the world’s most advanced alarm/
engine immobilisers installed in your vehicle. This manual describes
the features and functions of all four systems. Where as day to day
use of the system only involves pressing the remote control, many
features of the systems will provide additional convenience for the
user. Please read this manual to gain a full understanding of what
service a Cyclops 3 Series system can provide to you.
LEGEND:
55
P355 feature
75
P375 feature
75B
P375B feature
85
P385 feature
ALL
Featured in all systems
-4-
CYCL PS
VEHICLE SOLUTIONS
P355 P375 P375B 385 User - 2008.4 4 16/07/2008 3:20:42 PM

-5-
OPERATIONS
REMOTE CONTROLS
ALL
All systems are supplied with two rolling
code remote controls. Each time a button is
pressed, the code advances to a completely
new code. Each code is only ever used once.
ARMING AND DISARMING
ALL
To arm the system press the main button
on the remote control. The vehicle indicators
will flash twice. The red status LED on the dash will flash when the
alarm/immobiliser is armed. To disarm the system, press the main
button. The indicators will flash once.
KEYRING
SECONDARY
BUTTON
MAIN
BUTTON
LED
KEYRING
SECONDARY
BUTTON
MAIN
BUTTON
LED
P355 P375 P375B 385 User - 2008.5 5 16/07/2008 3:20:42 PM

-6-
ARM/DISARM SIREN CONFIRMATION
75B75 85
Each time the alarm is armed the siren will chirp twice to confirm
the arm operation. The siren will also chirp if the automatic arming
function arms the system. The siren will also chirp once when the
system is disarmed by remote control.
SILENT ARMING
75B75 85
The arm/disarm confirmation chirps can be suspended for one
operation by momentarily pressing the secondary button on the
remote control before pressing the main button. The chirp will re-
enable upon the next operation. The siren chirps can be permanently
cancelled by changing option #13 (see “Programmable Options”
section for details).
AUTOMATIC ARMING
ALL
The immobiliser will automatically disable the engine 40 seconds
after the ignition switch is turned off. Pressing the main remote
control button after the system has automatically armed, will
command the immobiliser to disarm for another 40 seconds.
P355 P375 P375B 385 User - 2008.6 6 16/07/2008 3:20:42 PM

-7-
DOME LIGHT FUNCTION
ALL
When the system is disarmed by remote control, the internal
circuitry can switch on the car’s dome light for 30 seconds. This
feature will be cancelled if the driver turns the ignition switch to the
ON position. Factory setting is disabled to avoid unit damage (see
“Programmable Options” section for details).
PANIC FEATURE (Car Location)
75B75 85
The alarm can be commanded to “panic” for 30 seconds if the main
button is pressed for more than 2 seconds. The panic feature will
sound the siren and flash the indicators. To cancel the Panic Feature,
momentarily press the main button once more. The panic feature is
available only while the system is armed.
OPEN DOOR WARNING
75B75 85
If any connected door is detected as being open while arming, the
alarm will flash the indicators and chirp the siren 8 times. This can
happen if the car has a built-in feature which extends the dome light
time. These cars will need this feature disabled (see “Programmable
Options” section for details).
P355 P375 P375B 385 User - 2008.7 7 16/07/2008 3:20:42 PM

-8-
IMMOBILISATION
ALL
The system includes two independent circuits of immobilisation. Each
circuit starves the engine of one of it’s critical power supplies. The
circuits are designed to be fail-secure, so if a would-be thief was to
cut power to the immobiliser, the circuit design will ensure the car
remains immobilised.
ALARM PROTECTION ZONES
75B75 85
The alarm protects the vehicle by monitoring all door, bonnet and
boot switches, as well as “listening” for the sound of breaking glass.
Additional sensors can be installed to provide movement detection if
required, eg Soft top vehicles.
DIAGNOSTICS
75B75 85
When any circuit triggers the alarm, the number of the zone
responsible will be recorded in the system memory. The number is
flashed back through the indicators and status LED when the alarm
is next disarmed. The zones are listed in the table on page 9.
P355 P375 P375B 385 User - 2008.8 8 16/07/2008 3:20:42 PM

-9-
DIAGNOSTIC TABLE
ALL
ZONE DESCRIPTION
1 Bonnet Switch
2 Auxiliary Trigger
3 Doors / Boot Switch
4 Glass Breakage
EMERGENCY OVER-RIDE
ALL
If either of the remote controls supplied
with the system are lost, broken or
stolen, the immobiliser can be disarmed
by use of a security key and the unique
4 digit Personal Identification Number
(PIN). To disable the security system, first
turn the key in the rear of the siren 90
degrees. Then follow the PIN procedure in
the next section.
SIREN
SWITCH SIREN OFF
LOCK
KEY
DUST CAP
85
75B
P355 P375 P375B 385 User - 2008.9 9 16/07/2008 3:20:43 PM

-10-
PIN OVER-RIDE PROCEDURE
ALL
To illustrate the PIN over-ride procedure we will assume a PIN of
4,3,2,1.
If indicators are still flashing, turn the ignition on and allow the
system to reset with all doors closed.
Turn ignition switch to ON position, the status LED will remain lit.
Turn ignition switch to the ACC position and count the LED
flashes.
Turn ignition switch ON when the 4th flash has extinguished.
Turn back to ACC position and count 3 flashes, switch ignition ON.
Turn back to ACC position and count 2 flashes, switch ignition ON.
Turn back to ACC position and count 1 flash, switch ignition ON.
When all four digits have been entered correctly, the car’s indicators
will flash once to confirm that the immobiliser is disarmed. The
engine can be started and the car driven. The automatic arming
feature will ensure car is secured again if the ignition is left off for
more than 40 seconds.
•
•
•
•
•
•
P355 P375 P375B 385 User - 2008.10 10 16/07/2008 3:20:43 PM

-11-
PROGRAMMABLE OPTIONS
ALL
The systems include 9 programmable options which alter the system
functions to comply with the user’s preferences and vehicle special
needs.
OPTION CHANGE PROCEDURE
Disarm the system (status LED extinguished).
Open the driver’s side door, this must remain open throughout
the whole procedure.
Switch the ignition key ON a certain number times (this number
corresponds to the option number).
Momentarily press the remote control immediately after a single
flash from the vehicle’s indicators.
After the remote press the indicators will flash either once or three
times to show the result of the option change. Please see the
following table.
•
•
•
•
P355 P375 P375B 385 User - 2008.11 11 16/07/2008 3:20:43 PM

-12-
PROGRAMMABLE OPTIONS TABLE
IGNITION SWITCH TURNS 1 FLASH 3 FLASHES
3 Anti Hijack DISABLED ENABLED
7 Program New Remote Press remote
9 Dome light upon disarm *** Disabled Enabled
11 Horn / Siren Output Style Horn (pulsed) Siren (constant)
13 Arm / Disarm audio confirm Enabled Disabled
15 120 Second re-lock Enabled Disabled
17 Central Locking Pulse Time *** 0.8 Second 3 Seconds
19 Change PIN Begin new PIN
21 Open Door Warning Disabled Enabled
*** do not change - installer setting only (incorrect setting can damage the system, vehicle or central locking)
P355 P375 P375B 385 User - 2008.12 12 16/07/2008 3:20:43 PM

-13-
PROGRAMMABLE OPTION DESCRIPTIONS
ALL
Option #3** the Anti Hijack feature locks the car doors when the
ignition is switched on, except when a connected door is open. The
anti hijack feature unlocks the doors when the ignition is switched
off (when driver has reached destination). The feature is disabled if
the dome light illumination is extended by the vehicle’s timing circuit.
Option #7 programming remote isn’t strictly an optional feature. This
feature is used if a spare remote is purchased. Carry out the same
procedure as normal option changes. The first flash indicates the
system is ready to accept a new remote code. Press the main button
of the new remote control within two seconds to teach system. Four
indicator flashes indicates successful programming procedure.
Option #9*** illuminates the dome light of the vehicle for thirty
seconds when the system disarmed. The light will extinguish early if
the ignition switch is turned to the ON position. Installer may have
disabled this function to prevent damage to system from multiple
courtesy lights (enquire before enabling).
** optional feature - will require additional connection(s).
*** do not change - installer setting only (incorrect setting can damage the system or central locking)
P355 P375 P375B 385 User - 2008.13 13 16/07/2008 3:20:43 PM

-14-
Option #11** determines whether the 30 seconds of siren output
is constant or pulsed. The constant output suits a connection to
a siren, which allows the siren to sound at full volume. The pulsed
output suits the car horn.
Option #13** Permanently enables or disables the arm/disarm silent
mode. The arm/disarm indicator flashes will occur regardless of
whether this option is enabled/disabled.
Option #15** enables the auto re-lock feature. The doors will
automatically re-lock when the vehicle has been disarmed by remote
control and the doors remain closed for more than 120 seconds. This
prevents accidental disarm.
Option #17*** is used to extend the time length of the central locking
pulses. Vehicles that use a pneumatic central locking system require
about three seconds to allow the pump to charge the air hoses.
Enable this option only to extend the time in these situations.
Option #19 is used to change the values of the Emergency PIN.
** optional feature - will require additional connection(s).
*** do not change - installer setting only (incorrect setting can damage the system, vehicle or central locking)
P355 P375 P375B 385 User - 2008.14 14 16/07/2008 3:20:43 PM

-15-
A card with the PIN details must be supplied by your installer. Please
contact your installer if the card is missing.
Option #21 the alarm system can be set to produce an open door
warning when arming. The warning is in the form of a short series of
chirps from the siren or horn. This option may not be suitable in cars
with dome lights that fade out slowly.
CHANGING PIN CODE
ALL
To alter the PIN code of the system, follow the standard option
change procedure; select option #19.
The vehicle indicators will flash twice to inform you that the
system is ready to accept the new PIN. The “time-out” is set to
two seconds. If the programming has not begun before then, the
system will drop-out of programming mode.
Enter the new digits by momentarily pressing the main button
on a valid remote control. The vehicle indicators will flash in
response to each press.
Stop pressing when the correct digit count is achieved. Each digit
•
•
•
P355 P375 P375B 385 User - 2008.15 15 16/07/2008 3:20:43 PM

-16-
will be confirmed by two indicator flashes.
Enter the remaining digits in the same fashion. Four flashes will
confirm the programming procedure is complete.
Arm the system and confirm the new PIN by completing override
procedure. Ensure the new PIN is recorded, but do not leave these
details in the vehicle.
BATTERY REPLACEMENT
ALL
Use a flat head screwdriver to carefully separate the two body
pieces taking care not to disturb the circuit board. Remove the
old batteries whilst paying attention to the orientation of the
positive and negative terminals. Insert
new batteries in identical fashion to the
original and re-assemble remote. Test
remote control by pressing main button.
For further information, please contact
your local Cyclops service centre. Remote
battery type is CR2016.
•
REMOVE BATTERIES
IN THIS DIRECTION
CASE TOP MEMBRANE
PCB
CASE BOTTOM
KEYRING
REMOVE BATTERIES
IN THIS DIRECTION
CASE TOP MEMBRANE
PCB
CASE BOTTOM
KEYRING
P355 P375 P375B 385 User - 2008.16 16 16/07/2008 3:20:43 PM

SPECIFICATIONS
Manufactured by Dynamco Pty Ltd
Model Number P355, P375, P375B, P385
Standards Compliance P355 AS/NZS 4601
P375 AS/NZS 4601 and AS/NZS 3749
P375B AS/NZS 4601
P385 AS/NZS 4601 and AS/NZS 3749
Supply Voltage +9VDC - +15VDC
Current Consumption less than 20mA (while armed)
Country of manufacture China (In Dynamco’s ISO-9002 facility)
RF Transmission frequency 433MHz
-17-
P355 P375 P375B 385 User - 2008.17 17 16/07/2008 3:20:43 PM

PROBLEM SOLVING
System won’t arm. LED on dash won’t flash.
Make sure that ignition switch is in the OFF position.
Ensure the vehicle battery is not flat.
Try your spare remote transmitter unit.
System won’t disarm. LED on dash won’t extinguish.
Try spare remote control.
Use Emergency PIN to override system and contact nearest
Cyclops service centre.
The remote fails to operate
If the remote fails to operate and the LED does not light
up when the button is pressed then change the battery.
To do this you will need a small screwdriver. See battery
replacement procedure.
•
•
•
•
•
•
•
•
•
-18-
P355 P375 P375B 385 User - 2008.18 18 16/07/2008 3:20:43 PM

WARRANTY
The Dynamco range of Cyclops Security Systems is covered by an extensive two year warranty (parts & accessories one
year). In the unlikely event of a faulty system Dynamco will either replace or repair the system at no cost during the 2 year
period.
The warranty does allow for the following conditions ~
Subject to the conditions stated below, Dynamco Pty Ltd warranty the product to be free from manufacturing defects and
faulty material within the warranty period stated.
That the warranty registration has been completed in full at the time of purchase / installation and is produced when
warranty service is sought
The warranty does not cover general maintenance such as cleaning / adjusting of door, boot, bonnet or any entry point
switch, nor replacement of consumables items such as transmitter batteries, lighting circuit bulbs / switches.
The warranty shall be null & void if: -
Any person other than by an Authorised Cyclops Sales, Service & Installation Centre has repaired the product.
Should a system / part defect become apparent within the warranty period DYNAMCO PTY LTD will repair the product
free of charge for parts and labour. The warranty does not cover service labour content or mobile service content.
The product has been altered or tampered with in any way, or the serial number altered, defaced or removed.
The defect has been caused by negligence by the owner or their agent / third party.
The product has not been operated correctly, installed by an unauthorised Cyclops installer or has been subjected to
misuse or undue wear and tear
Siren, control module, remote controls or any other system part are damaged by water.
The warranty does not cover the following costs: -
Transport of the product to and from Cyclops Service Centres.
Insurance of the product whilst in transit to or from the Cyclops Service Centres.
Cost of any service call / labour where the product is found by Cyclops to be in good working order.
The benefits conferred by this Warranty are in addition to all other rights and remedies, which the consumer has conferred
in law.
“No liability is accepted for any loss from, damage to or inability to use the vehicle to which the system is installed”.
1.
2.
3.
4.
5.
6.
1.
2.
3.
-19-
P355 P375 P375B 385 User - 2008.19 19 16/07/2008 3:20:43 PM

WARRANTY REGISTRATION
PURCHASED FROM
OWNER’S NAME
TYPE OF VEHICLE
VEHICLE REGO
MODEL OF UNIT P.I.N
DATE OF MANUFACTURE
DATE OF INSTALL’
WARRANTY PERIOD
CONTROL MODULE
SIREN & REMOTES
INSTALLER’S NAME
AFTER HOURS EMERGENCY PHONE
-20- Production pack Version #1
P355 P375 P375B 385 User - 2008.20 20 16/07/2008 3:20:43 PM
