Cypress Semiconductor WirelessUSB CY4636 User manual

CY4636 WirelessUSB™ LP Keyboard-Mouse Reference Design Kit
QUICK START GUIDE
Unpack the CY4636 WirelessUSB™ LP RDK
Bridge dongle, keyboard, and mouse from
the package.
Connect the bridge dongle to the PC. The
bridge enumerates as a HID device.
Power the mouse and keyboard with two AA
batteries each. Switch on the mouse. When you press the bind button on the bridge, the red LED blinks.
Press the bind button on the mouse to bind it
with the bridge.
Press the bind button on the keyboard to
bind it with the bridge. The mouse and key-
board work smoothly with the PC.
Insert CY4636 Kit CD/DVD. View the User
Guide. Install Kit contents, PSoC Designer and
Programmer.
1
2
3
Bind button Power switch
Bind (Connect) button
4
Bind button
5
6

© 2011-2012 Cypress Semiconductor Corporation. All rights reserved. All trademarks or registered
trademarks referenced herein are the properties of their respective owners. DOC#: 001-71384 Rev. *A
http://www.cypress.com/go/CY4636
For the latest information about this kit visit
CY4636 WirelessUSB™ LP Keyboard-Mouse Reference Design Kit
QUICK START GUIDE
CY4636 WirelessUSB LP Keyboard-Mouse RDK Details
Bridge Dongle
Keyboard
Dual LED
Antenna
12 MHz oscillator
CY7C63803 Chip
USB connector
Mouse
Antenna
CYRF6936 Chip
CY7C60123 Chip
12 MHz oscillator
Power switch
12 MHz oscillator
CYRF6936 Chip
Antenna Center button
Right button
Scroll wheel
Left button
Optical sensor
ISSP header Encoder
CY7C60323 Chip
CYRF6936 Chip
Bind button
