CY8CKIT-007 PSoC®3 PRECISION ANALOG VOLTMETER DEMO KIT
QUICK START GUIDE
1. Power the Kit through USB Connector
from 2-AA battery pack.
2. Switch SW1 to the USB position (right).
Connect the test leads.
CAUTION The input range is limited to
-30V DC to +30V DC DO NOT use
AC voltage.
Press the source button to toggle
between voltage inputs (Thermocouple
and test leads).
Use TP1 and TP2 test points to measure kit
power source.
Touch thermocouple and monitor voltage
displayed on LCD. Refer to the Kit Guide for project files.
1
2
3
4
5
6

© 2009 Cypress Semiconductor Corporation. All rights reserved. All trademarks or registered trademarks
referenced herein are the properties of their respective owners. DOC#: 001-55169 REV **
www.cypress.com/go/CY8CKIT-007
For the latest information about this kit visit
CY8CKIT-007 PSoC 3 PRECISION ANALOG VOLTMETER DEMO KIT
QUICK START GUIDE
USB
Program/Debug
Interface
Voltage Input
Source Selector
Thermocouple Voltage
Reference
Power Source
Selector
External Voltage
Input Test Lead
Connectors
