Cypress PRoC CY5682 User manual

CY5682 QUICK START GUIDE
• Connect the CySmart USB dongle to a USB port on
your PC
• The red LED glows to indicate that the dongle is
powered, the green LED glows to indicate that the
enumeration has nished on the dongle side and the
blue LED breathes slowly to indicate that dongle is
scanning for the touch mouse
Note: Time taken to complete enumeration on the PC,
for the rst time, depends on the driver installation time
• Lift the mouse top cover, insert the AAA batteries, close
the top cover, switch On and move the mouse.
• The blue LED, on dongle, glows to indicate successful
connection with the mouse
The PRoC BLE touch mouse features:
Bluetooth®4.1- compliant Bluetooth Smart connectivity
Trackpad for vertical and horizontal scrolling
Buttons for quick access to Windows®8/8.1 specic features
3
• Start using the PRoC BLE touch mouse with your PC
*Only for applications which support AC Pan usage
**Only for Windows 8.0 and later ***Only for Windows
PR O CTM BLE TOUCH MOUSE REFERENCE DESIGN KIT
12
12
3
4
67
5
Two AAA Batteries On/Off Switch
4
1 Left Click
2 Middle Click
3 Right Click
4 Vertical / Horizontal* Scroll
5 Toggle Across Open Apps**
6 Windows Button***
7 Open Charms Bar**
• Unpack the kit which includes: 1. PRoCTM BLE touch
mouse, 2. CySmartTM USB dongle, 3. MiniProg3
programmer/debugger, 4. 10-pin ribbon cable,
5. Two AAA batteries, 6. USB 2.0 standard-A to
mini-B cable, 7. Tweezer
• This guide explains how to evaluate the PRoC BLE
touch mouse using a PC
5
4
7
6
123

PR O CTM BLE TOUCH MOUSE REFERENCE DESIGN KIT
© 2014 - 2015 Cypress Semiconductor Corporation. All rights reserved.
All trademarks or registered trademarks referenced herein are the properties of their respective owners.
Doc.#: 001-95209 Rev.*B
CY5682 QUICK START GUIDE
The PRoC BLE touch mouse supports:
• Buttons for left, middle and right click
• Optical sensor for cursor movement
• Trackpad with single-nger touch sensing for horizontal and vertical scrolling
• Windows button for faster access to the Start screen (Windows 8.0 and later) or Start menu
• Side button 1 to toggle across open apps on Windows 8.0 and later
• Side button 2 to open Charms Bar on Windows 8.0 and later
• Operation with one or two AAA batteries
• LED indications for low battery (red) and connection status (orange)
• 10-pin header to enable programming and debugging using MiniProg3 and current measurement header for
PRoC BLE
The PRoC BLE touch mouse works with any Bluetooth Smart Ready HID-compatible device. For details, read the
user guide available at www.cypress.com/CY5682-UserGuide
For the latest information on PRoC BLE, visit www.cypress.com/PRoCBLE
For the latest information about this kit and to download the kit installer with software and hardware les, visit
www.cypress.com/CY5682
Battery/Connection
Status LED
Optical
Sensor
Windows
Button
PRoC BLE
Current
Measurement
Header
Two AAA
Battery Holder
10-pin Header for
Programming/
Debugging
PRoC BLE
Side Button 1
Trackpad for
Vertical/
Horizontal
scrolling
Left Click
Middle Click
Right Click
On/Off
Switch
Connect
Button
Side Button 2
