d & b audiotechnik C4-SUB Assembly instructions

C4-SUB
Manual
(3.0E)

General Information
C4-SUB Manual
Version 3.0E, 10/2003, D2075.E.03
© by &b au iotechnik AG 2003; all rights reserve .
The information containe in this manual has been carefully
checke for accuracy, at the time of going to press, however no
guarantee is given with respect to the correctness.
&b au iotechnik AG accepts no responsibility for any errors or
inaccuracies that may appear in this manual or the pro ucts an
software escribe in it.
Technical specifications, imensions, weights an properties o not
represent guarantee qualities.
As manufacterers we reserve the right to make alterations an
mo ifications within the framework of legal provisions, as well as
changes aime at improving quality.
&b au iotechnik AG
Eugen-A olff-Strasse 134, D-71522 Backnang, Germany
Telephone [phone], Fax [phone]
E-mail: oca min@ bau io.com, Internet: www. bau io.com
References in the manual
ARNING!
This refers to a potentially dangerous situation
which may lead to personal injury.
CAUTION!
This refers to a potentially dangerous situation
which may lead to damage to the equipment.
IMPORTANT!
This refers to a situation which may cause the
equipment to malfunction.
Symbols on the equipment
Please refer to the information in the operating
manual.
ARNING!
Dangerous voltage!

C4-SUB Manual (3.0E) Page 3 of 8
C4-SUB Manual (3.0E) Safety instructions
Safety precautions
Before you use our products, read the manual
carefully and observe all the safety precautions.
They will protect you and help to avoid equipment
failures.
Keep this manual in a safe place so that it is
available for future reference.
If you supply d&b products, please draw the
attention of your customers to these safety
guidelines. Enclose the relevant manuals with the
systems. If you require additional manuals for this
purpose, you can order them from d&b.
Information regarding use of loudspeakers
ARNING!
Never stan in the imme iate vicinity of lou speakers riven at a
high level. Professional lou speaker systems are capable of causing
a soun pressure level etrimental to human health. Seemingly non-
critical soun levels (from approx. 95 B SPL) can cause hearing
amage if people are expose to it over a long perio .
In or er to prevent acci ents when eploying lou speakers on the
groun or when flown, please take note of the following:
When setting up the lou speakers or lou speaker stan s, make sure
they are stan ing on a firm surface. If you place several systems on
top of one another, use straps to secure them against movement.
Only use accessories which have been teste an approve by &b
for assembly an mobile eployment. Pay attention to the correct
application an maximum loa capacity of the accessories as
etaile in our specific “Mounting instructions” or in our "Flying
system an Rigging manuals”.
Ensure that all a itional har ware, fixings an fasteners use for
installation or mobile eployment are of an appropriate size an
loa safety factor. Pay attention to the manufacturers instructions
an to the relevant safety gui elines.
Regularly check the lou speaker housings an accessories for visible
signs of wear an tear, an replace them when necessary.
Regularly check all loa bearing bolts in the mounting evices.
CAUTION!
Lou speakers pro uce a static magnetic fiel even if they are not
connecte or are not in use. Therefore make sure when erecting
an transporting lou speakers that they are nowhere near
equipment an objects which may be impaire or amage by an
external magnetic fiel . Generally speaking, a istance of 0.5 m
(1.5 ft) from magnetic ata carriers (floppy isks, au io an vi eo
tapes, bank car s, etc.) is sufficient; a istance of more than 1 m
(3 ft) may be necessary with computer an vi eo monitors.

C4-SUB Manual (3.0E) Page 4 of 8
C4-SUB
The C4-SUB is a compact, hornloa e ban pass esign employing
a single 18" river. It is esigne for use with the C4-TOP cabinet
as a part of the C4 system.
The C4-SUB cabinet is constructe from marine plywoo an has
an impact resistant paint finish. The front of the lou speaker
cabinet is fitte with a rigi metal grill covere with a replaceable
acoustically transparent foam, an fitte with catches to the top
an bottom for securing an optional transport li E7908. The
cabinet incoporates two steel han les an MAN CF4 stu plate
rigging points. Mounte on the rear panel are ratchet strap gui e
plates (kelping bars) an four heavy uty wheels.
CAUTION!
Only operate C4-SUB cabinets with a &b D12 or E-PAC amplifier
in C4-SUB mo e or a P1200A mainframe fitte with a C4-SUB
controller mo ule, otherwise there is a risk of amaging the
lou speaker components.
Connections
1
2
3
4
5
1
2
3
4
5
Sense Drive
n.c.
Connector wiring
The C4-SUB cabinet is fitte with a pair of EP5 connectors. All pins
of both connectors are wire in parallel.
The C4-SUB uses the pin assignments 3/4 an 5 (Pin 5: SenseDrive
- D12 only an in conjunction with 5-wire cables).
Pins 1/2 are esignate to &b full range systems.
Using one connector as the input, the secon connector allows for
irect connection to a itional cabinets.
The C4-SUB can be supplie with NL4 connectors as an option
using the pin assignment 2+/2–. Pins 1+/1– are esignate to &b
full range systems.
Pin equivalents of EP5 an NL4 connectors are liste in the table
below.
EP5
1 2 3 4 5 (SenseDrive SUB)
NL4
1+ 1– 2+ 2– n.c.
EP5 and NL4 pin assignments

C4-SUB Manual (3.0E) Page 5 of 8
Operation with D12
Selecting C4-SUB mo e in the D12 enables up to two C4-SUB
cabinets to be riven by each channel. In applications with low
continuous levels an low ambient temperatures up to three
cabinets per channel may be connecte .
When the D12 is operate in "Mix TOP/SUB" mo e the C4-SUB
cabinet an a respective full range system can be linke together
locally an fe by a single 4-wire cable from either amplifier
output connector.
IMPORTANT!
To apply SenseDrive for the subwoofer, EP5 connectors an 5-wire
cables have to be use . When operate in "Mix TOP/SUB" mo e
mo e the subwoofer has to be fe from the output B connector of
the D12 amplifier.
Controller settings
For acoustic a justment the +B2 setting can be selecte .
+B2 circuit
When C4-SUB cabinets are use with a itional B2 subwoofers
(INFRA mo e) the C4-SUB controller can be set to +B2 mo e. This
intro uces a relatively narrow ban signal attenuation aroun
50 Hz, which raises the lower frequency limit of the C4-SUB to
aroun 60 Hz. The +B2 setting increases the hea room on the
C4-SUBs while the combine system response will not change
significantly.
Operation with E-PAC (Version 3 with display only)
Selecting C4-SUB mo e in the E-PAC enables one C4-SUB cabinet
to be riven at an output power of 300 Watts. We o not
recommen that two C4-SUB cabinets are riven in LO IMP mo e as
the 6 B re uction in input level to the lou speakers results in no
gain in acoustical output.
Operation with P1200A
C4-SUB
GRISP
MUTE
OVL
-12 dB
-6 +6
0
Controls on C4-SUB
controller module
Up to two C4-SUB cabinets can be riven by each P1200A power
amplifier channel fitte with a C4-SUB controller mo ule. Fitting
one C4-SUB an one TOP controller mo ule allows a single
mainframe to rive two C4-SUB an two TOP cabinets. All cabinets
can be linke together locally an fe by a single 4-wire cable
from either mainframe output connector.

C4-SUB Manual (3.0E) Page 6 of 8
Technical specifications
C4-SUB system data
Frequency response (–5 B)......................................................................50 Hz - 150 Hz
Max. soun pressure (1 m, free fiel ) with D12 ................................................ 135 B
Max. soun pressure (1 m, free fiel ) with E-PAC ............................................ 131 B
Max. soun pressure (1 m, free fiel ) with P1200A ......................................... 133 B
(SPLmax peak, pink noise test signal with crest factor of 4)
Input level (100 B SPL / 1 m)...............................................................................–13 Bu
Polarity to controller INPUT (XLR pin 2: + / 3: –) .................................................. LF: +
C4-SUB subwoofer
Nominal impe ance................................................................................................... 8 ohms
Power han ling capacity (RMS / peak 10 ms)........................................200 / 800 W
Connections ..................................................................................................................2 x EP5
Pin assignments ......................................................3/4 an 5 (Pin 5: SenseDrive - D12)
optional.........................................................................................................................2 x NL4
Pin assignments .......................................................................................................... 2+ / 2–
Weight ...............................................................................................................48 kg (106 lb)
-5
0
5
10
-10
-15
-20
-25
-30
20 100 1k 10k
20k
C4-SUB frequency response
C4-SUB cabinet dimensions in mm [inch]

C4-SUB Manual (3.0E) Page 7 of 8
EU declaration of conformity (CE symbol)
EU conformity of loudspeakers
This eclaration applies to lou speakers manufacture by &b
au iotechnik AG an inclu es the types liste in the table below:
− C4-SUB Z2255
All pro uction versions of these types are inclu e , provi e they
correspon to the original technical version an have not been
subject to any later esign or electromechanical mo ifications.
e herewith declare that said products are in
conformity with the provisions of the following EC
directives including all applicable amendments:
− 89/336 Electromagnetic Compatibility
The following standards have been applied:
− DIN EN 55013:08-1991
− DIN EN 55020:05-1995
− DIN EN 50082-1:03-1993

C4-SUB Manual (3.0E) Page 8 of 8
