Comfort Lift Door Drive
Operating Instructions AT 18
DateofIssue:Rev.07-02/06
Comfort lift Door Drive
AT 18
Sassi Lift Systems Limited
Tel: [phone]

Rev.01 Issue 09/05
2 Operating instructions AT18 SEDM
1 Table of contents
1 Table of contents ............................................................................................................. 2
2 Introduction ...................................................................................................................... 4
3 Safety instructions ........................................................................................................... 5
3.1 General safety notices ............................................................................................. 5
4 Terms .............................................................................................................................. 6
5 Overview of the control elements.................................................................................... 7
6 Functions and equipment responses .............................................................................. 8
6.1 Learn and test run..................................................................................................... 8
6.2 DOOR OPEN command........................................................................................... 8
6.3 DOOR CLOSE command......................................................................................... 8
6.4 Service button .......................................................................................................... 8
6.5 Parameter setting...................................................................................................... 8
6.6 Blockage recognition - “CLOSE” .............................................................................. 9
6.7 Blockage recognition - “OPEN”................................................................................. 9
6.8 Restart after AC power failure ................................................................................. 9
6.9 Closing force ........................................................................................................... 10
6.10 Emergency rescue................................................................................................ 10
6.11 Nudging................................................................................................................. 10
6.12 Light barrier........................................................................................................... 10
6.13 Emergency power supply (option) ....................................................................... 11
6.14 Overload protection .............................................................................................. 11
7 Mechanical assembly and set-up.................................................................................. 12
8 Electrical set-up and initial start-up ............................................................................... 13
9 Relay contacts (option) ................................................................................................. 16
10 The travelling curve .................................................................................................... 17
11 Operating status display ............................................................................................. 18
12 Extension modules (option) ........................................................................................ 20
12.1 Installation of the extension modules .................................................................. 20
12.2 The emergency power module ............................................................................ 24
12.2.1 Connecting the emergency power module to the AT18 ............................... 24
13 Technical data ............................................................................................................. 25
13.1 DC gear motor ..................................................................................................... 25
13.2 Power transformer ............................................................................................... 25
13.3 Controller ............................................................................................................. 25
13.4 Regulations and standards .................................................................................. 25
14 Appendix...................................................................................................................... 26
14.1 Appendix 1: ID numbers of individual components.............................................. 26
14.2 Appendix 2: AT 18 controller dimensioned drawing............................................. 27
14.3 Appendix 3: AT 18 power transformer dimensioned drawing.............................. 28
14.4 Appendix 4: 24 V drive motor, drive pinion left, with rubber-bonded metal and
mounting bracket........................................................................................................... 29
14.5 Appendix 5: Deflection pulley with tightener and mounting bracket .................... 30
14.6 Appendix 6: Door carrier....................................................................................... 31
14.7 Appendix 7: mounting suggestion ....................................................................... 32
14.8 Appendix 8: Control input connection diagram .................................................... 33
Connection with external supply .................................................... 33a
14.9 Appendix 9: Emergency power module dimensional drawing ............................ 34
14.10 Appendix 10: Connection cable for emergency power module ....................... 35

Rev.01 Issue 09/05
3 Operating instructions AT18 SEDM
14.11 Appendix 11: Diagnosis and parameter setting ................................................ 36
14.11.1 Terminal module:.......................................................................................... 36
14.11.2 Handheld terminal HT18 (service tool)........................................................ 36
14.12 FrontEndPC ..................................................................................................... 42
14.12.1 User terminal emulation .............................................................................. 42
14.12.2 The driving parameter editor........................................................................ 42
14.12.3 Oscilloscope function .................................................................................. 43
14.13 Minimal Editor ................................................................................................... 45
14.14 Adjustment log .................................................................................................. 46

Rev.01 Issue 09/05
4 Operating instructions AT18 SEDM
2 Introduction
The AT18 comfort lift door drive is an “intelligent” door drive, with which cabin doors and
landing gates can be operated with adjustable speed and acceleration. The
maintenance-free drive unit consists of a direct current motor with a non self locking gear
box that is driven by a controlled rotational speed motor. The power transmission takes
place over a toothed belt. The toothed belt is led across a deflection pulley and can be
equipped with two door pushers. This allows both one-sided as well as central opening
doors to be operated.
The AT18 is currently delivered with the following motor:
- 24V motor, 4.9A for maximum 180 kg total door leaf mass
The door drive can be ordered with various drive pinion mounting positions (on the left or
right, see the diagram in the Appendix).
The door drive does not require a limit switch.
The door width as well as the “OPEN” and “CLOSE” positions are determined
automatically.
A display of the current operating condition is shown via a 7 segment display (H5000) in
the controller.
In the Appendix are all important dimensional drawings, a mounting suggestion and the
ID numbers for ordering the individual drive components.
Note
For reasons of clarity these operating instructions do not contain detailed information
about all product models and can also not cover every conceivable installation, operation
or the maintenance question.
If you require further information, or if special problems should arise which are not
explained in enough detail in this manual, you can get the necessary information from
the AT Service Hotline Tel: [phone].
In addition we wish to point out that the content of this manual is not part of an earlier or
existing agreement, declaration of intent or legal relationship or a revision of such. All
obligations of Siemens result from the respective sales contract, which also contains the
complete and only valid guarantee regulations. The contractual guarantee provisions are
neither extended nor limited by the actions taken as a result of using this manual.

Rev.01 Issue 09/05
5 Operating instructions AT18 SEDM
3 Safety instructions
Observe the following before start-up
Read the manual carefully. It contains important information for the installation, use and
safety of the equipment.
Special references
Three kinds of special references are used in the manual in order to emphasize
important information:
WARNING
In the sense of this manual it means that death, serious bodily injury or substantial
damage to property can occur if the appropriate precautionary measures are not taken.
CAUTION
In the sense of this manual it means that minor bodily injury or property damage can
occur if the appropriate precautionary measures are not taken.
NOTE
In the sense of this manual this indicates important information about the product or the
respective part of the manual to which particular attention is to be paid.
3.1 General safety notices
WARNING
Only qualified personnel are allowed to work on or near this equipment. The personnel
must be thoroughly familiar with all warnings and maintenance procedures in accordance
with these operating instructions.
Qualified personnel in the sense of these operating instructions or warnings are persons
who are familiar with the installation, assembly, initial start-up and operation of the
product and have the corresponding qualifications as a result of their occupation, e.g.:
- training, instruction and/or authorization to switch on and off electric circuits and
equipment / systems in accordance with the standards of safety engineering.
– training or instruction in the care and use of appropriate safety equipment, in
accordance with the standards of safety engineering
– training in first aid.
The failure free and safe operation of this equipment assumes appropriate transport,
professional storage, installation and assembly as well as careful operation and
maintenance.
All electrical connections are to be checked for secure contact prior to start-up.
Before working on the door drive, power is to be removed by removing the power supply
plug from the mains.

Rev.01 Issue 09/05
6 Operating instructions AT18 SEDM
4 Terms
Initial speed = decreased speed used in closing and opening operations after power is
turned on until normal operation is recognized.
Creep speed = decreased speed in the proximity of the “Open” position of the lift door
(creep distance). The driving parameter names are “slow start speed open” and “slow
end speed open”.
Cam speed = decreased speed in the proximity of the “Close” position of the lift door
(cam distance). The driving parameter names are “slow start speed close” and “slow end
speed close”.
Creep distance = door operating area in the proximity of the “Open” position. The
driving parameter names are “slow start distance open” and “slow end distance open”.
Cam distance = door operating area in the proximity of the “Close” position. The driving
parameter names are “slow start distance close” and “slow end distance close”.

Rev.01 Issue 09/05
7 Operating instructions AT18 SEDM
5 Overview of the control elements
Figure
Flachband-
kabel
module
connection
X14X1X15
H5000
AT18
Komfort-Türsteuerung
Comfortliftdoorcontroller
Auf
open
1
2
3
1
2
3
4
5
6
7
8
EingangImpulsgeber
Inputincremental
encoder
Motorerkennung
Motoridentification
Ausgang
Motorspannung
Outputmotorsupply
1
2
Signal
Akkubetrieb
Accumulator
mode
X5
X7
PE
X11Relaismodul(Option)
Relaymodule(option)
Reversiert
Reverse
X12
1
2
3
1
2
3
X13
Zu
close
Eingang
Spannungsversorgung
vomTrafo
Inputpowersupply
fromtransformer
1
2
3
+
PE
-
X3
SNr.:
-
+
-
Lichtschranke
lightbarrier
6
5
4
3
2
1
Return
Ausgang/
Output
DC-24V/0,4A
MadeinGermany
Terminalmodul(Option)
Terminalmodule(option)
H1
Anschluss
Handterminal
Connectorfor
userterminal
X8
Verdrahtung
ohne
Lichtschranke
Wiringwithout
lightbarrier
2
1
-
+
X4
X6
S5001
Auf
open
S1S2S3S4
ESC
TürParam.
doorparam.
S5000
Zu
close
S5002
GND
Drängeln/
nudging
Zu/close
Auf/open
Basic AT18 module:
X1: Auxiliary modules flat cable connection
X3: Input transformer connection
X4: Output voltage 24V / 0.4A
X5: Emergency power module input signal
X6: Input signal connection:
- Light barrier
- Nudge
- Close
- Open
X7: Motor plug
X8: Connection for user terminal and USB
adapter (FrontEndPC)
H5000: 7 segment display for door condition
and error codes
S5000: Door parameter button
S5001: Service button “OPEN”
S5002: Service button “CLOSE”
Relay module (option):
X11: Relay output “CLOSE”
X12: Relay output “reverse”
X13: Relay output “OPEN”
X14: Flat cable connection to the controller
Terminal module (option):
X15: Flat cable connection to the controller
H1: LCD-Display
S1 – S4: Control keys of the terminal module

Rev.01 Issue 09/05
8 Operating instructions AT18 SEDM
6 Functions and equipment responses
6.1 Learn and test run
Pushing the Door Parameter button (S5000) causes automatic parameter sensing to
start:
1. Recognition of the motor type
2. Recognition of the door motion direction and the “CLOSE” position
3. Determination of the door system friction values and the door mass.
4. Determination of the door width and the “OPEN” position.Close the door until the
determined door width is travelled and the “CLOSE” position is reached.
At this point the parameters are saved, this takes approximately 3 seconds.
6.2 Door Open command
With the door open command the door opens according to the set travelling curve, as
long as the command is active.
The transitions of the travelling curve (e.g. of acceleration in inertia) are smoothed in
order to avoid noise which would develop due to the play between the cabin and shaft
door. The door reaches the “OPEN” position at creep speed. Afterwards with a queued
up Door Open command the door is kept open by reduced torque.
−The Door Open command must be active during the entire opening travel.
−The Door Open command must be constantly active if in the OPEN position a
continuous toque is to be applied.
−The Door Open command has priority over all other control commands.
6.3 Door CLOSE command
To close the door the Door Close command must be continuously active. After closing,
the door is held closed by reduced torque as long as the Door Close command is active.
6.4 Service button
The door can be opened and closed from the controller with the OPEN (S5001) and
CLOSE (S5002) service buttons. By the operation of these buttons the controller
receives the Door Open or Door Close command respectively in addition to the input
signals on X6.
6.5 Parameter setting
The AT18 terminal module (option), the HT18 user terminal or the FrontEndPC offer
additional adjustment and diagnostic possibilities.
The terminal module is integrated in the housing of the AT18 controller and can be
ordered as an option or added later.
The HT18 user terminal is available separately as an option.
It is attached to X8 of the controller.
It is also possible to use an existing type HT25 user terminal.
The FrontEndPC offers the most comfortable diagnostic possibilities.
A PC can be attached over an USB adapter (option for the FrontEndPC) to X8 of the
controller.

Rev.01 Issue 09/05
9 Operating instructions AT18 SEDM
NOTE
If the door parameter button (S5000) is pressed while applying the mains voltage, the
current parameters are overwritten at the end of the training run by the factory settings.
If the door parameter button is pressed during normal operation, then only a door width
and a mass determination is performed. The run time curve parameters, force limits and
continuous torque values remain unchanged. Dependent upon the mass determination,
the maximum closing speed as well as the nudge speed is limited.
6.6 Blockage recognition - “CLOSE”
If the door is blocked during a Door CLOSE command while moving in the “CLOSE”
direction, the door then stops and reverses direction.
After reaching the open position the door closes again at normal speed up to approx.
2cm before the obstacle. Subsequently, it moves at decreased speed (initial speed)
against the obstacle and again reverses itself.
This function is continuously performed as long as the obstacle is present.
After the obstacle is removed the door moves at decreased speed to approx. 2cm
beyond the stored position of the obstacle and then continues at normal closing speed
for the remainder of the travel.
6.7 Blockage recognition - “OPEN”
If the door is blocked during a Door OPEN command while moving in the “OPEN”
direction; the door stops.
After approximately 2 seconds the door tries again to reach the open position.
This function is performed a maximum of 3 times.
The door then stops in this position.
If the Door OPEN command is removed, and in the meantime the close command is
activated and the Door OPEN command is re-activated, the door moves at normal
velocity to approx. 2cm before the stored position of the obstacle and then moves with
decreased speed against the obstacle.
Here the door drive stops and repeats the opening sequence 3 times.
If the obstacle was eliminated beforehand, then the door moves with decreased speed to
approx. 2cm beyond the stored blockage position and is driven at normal speed until the
open position is reached.
6.8 Restart after AC power failure
After a mains voltage failure the controller must re-determine the door end positions.
For this the door is driven at decreased speed (initial speed) until the two end positions,
“Open” and “Close”, are recognized by the controller.
Subsequently, the door is again driven at normal speed.

Rev.01 Issue 09/05
10 Operating instructions AT18 SEDM
6.9 Closing force
The closing force can be adjusted between 70 and 230N. When 150N is exceeded a
warning appears on the LCD display of the terminal module (option).
The values mentioned refer to a door that opens to one side; a load cell will only indicate
the half value with central opening doors.
WARNING
During the setting of the closing force the possible effective closing weight must be
considered.
For 1kg of counterweight the desired closing force must be reduced by 10N.
This relates to: - Closing force “CLOSE”
- Closing force “cam distance CLOSE”
- Nudge force “CLOSE”
Example: Closing weight = 4 kg
Desired static force limit “CLOSE” = 150N
The counterweight of 4kg corresponds to a force of 40N. The force limit set must then
amount to 150N - 40N = 110N.
The factory setting is calculated in such a way as to take into account a counterweight of
6kg.
That means it that the resulting static closing force is limited to 90N.
6.10 Emergency rescue
WARNING
An emergency rescue can only be performed if:
– neither a DOOR OPEN nor a DOOR CLOSE command is active,
– the service buttons are not pressed,
– the user terminal or FrontEndPC is not in the menu option high-speed adjustment
or total adjustment (inclusive submenus) position,
– the door has stopped.
Only in these cases is the door drive free of torque. The force necessary to open the
door is below 300 N in accordance with TRA and EN81 requirements.
6.11 Nudging
No reverse is performed during a nudging operation. The DOOR CLOSE and NUDGE
command must be active at the same time. In the case of the recognition of an obstacle
the torque is reduced after 1 second to the limit retaining torque of the motor.
6.12 Light barrier
The input for the light barrier signal has the same function as the DOOR OPEN command.
Exception: The light barrier signal is ignored if the door is opened for less than 1 cm.
If no voltage is present at the light barrier input, this is interpreted as a light barrier
interruption.
The door cannot close.
An interrupted light barrier causes the door to open.
If at the same time a DOOR CLOSE command is active, the door moves toward “OPEN”
until the position of light ray interruption is reached.

Rev.01 Issue 09/05
11 Operating instructions AT18 SEDM
6.13 Emergency power supply (option)
In case of a failure of the mains voltage a battery or a rechargeable battery (e.g. lead gel
rechargeable battery) can be attached to the external emergency power module (option)
and thus makes possible emergency operation.
The door can be opened and closed in this condition; the light barrier input is interpreted.
The movement is thereby limited to a reduced speed (slowendspeedcls or
slowstartspeedop).
When the mains voltage is again present, the controller switches back automatically at
the door end position (OPEN or CLOSE) into normal operation.
CAUTION
The fuse for the emergency power supply, which is installed by the customer, must be a
6 A slow acting fuse.
6.14 Overload protection
If the drive motor is heavily loaded by frequent short DOOR OPEN and DOOR CLOSE
commands quickly following one another, then an automatic extension of the door open
time occurs. The next closing cycle is delayed despite a possible DOOR CLOSE
command; the 7 segment display (H5000) shows “4”.
This function prevents the motor from going into thermal overload.

Rev.01 Issue 09/05
12 Operating instructions AT18 SEDM
6.13 Emergency power supply (option)
In case of a failure of the mains voltage a battery or a rechargeable battery (e.g. lead gel
rechargeable battery) can be attached to the external emergency power module (option)
and thus makes possible emergency operation.
The door can be opened and closed in this condition; the light barrier input is interpreted.
The movement is thereby limited to a reduced speed (slowendspeedcls or
slowstartspeedop).
When the mains voltage is again present, the controller switches back automatically at
the door end position (OPEN or CLOSE) into normal operation.
CAUTION
The fuse for the emergency power supply, which is installed by the customer, must be a
6 A slow acting fuse.
6.14 Overload protection
If the drive motor is heavily loaded by frequent short DOOR OPEN and DOOR CLOSE
commands quickly following one another, then an automatic extension of the door open
time occurs. The next closing cycle is delayed despite a possible DOOR CLOSE
command; the 7 segment display (H5000) shows “4”.
This function prevents the motor from going into thermal overload.

Rev.01 Issue 09/05
13 Operating instructions AT18 SEDM
7 Mechanical assembly and set-up
CAUTION
The safe operation of the lift door drive requires that it is correctly installed and put into
operation by qualified personnel under consideration of the warning references in these
operating instructions.
Before working on the door drive you must ensure that voltage has been removed from
the controller. Only then can you be sure the door is unable to move.
The mechanical assembly and set-up of the lift door drive take place in six steps:
1. Mount the motor onto the motor mount (rubber-bonded metal).
Then, if necessary, mount the motor onto the mounting bracket.
2. If necessary, install the guide roller with mounting bracket.
Pay attention to the adjustment of drive pinion and guide roller; these should align with
each other as exactly as possible (aligning).
3. Bolt the toothed belt together with the door latch and mount.
CAUTION
Only use as door catch (toothed belt lock) the door catch described in the Appendix!
Unsuitable mounting can cause a notch effect on the toothed belts, which can lead to
damage of the toothed belt!
The door catch (toothed belt lock) may not run over the drive pinion or the guide roller!
4. Adjust the toothed belt with the help of the tightener. The correct belt tension is
reached when the toothed belt can be pushed down in the centre approx. 3 cm for each
meter distance between the drive pinion and guide roller.
5. Install the controller in the proximity of the drive motor (consider the cable length).
6. Install the power transformer in the proximity of the controller (consider the cable
length).
CAUTION
If there is a short circuit on the secondary side of the power transformer (defect of the
controller), the temperature of the transformer housing will increase up to over 105°C.
For this reason, the power transformer must be mounted on non-flammable materials.
It must also be prevented that unauthorised people are able to contact the housing.
The service staff is to be instructed.

Rev.01 Issue 09/05
14 Operating instructions AT18 SEDM
8 Electrical set-up and initial start-up
WARNING
With the operation of electrical equipment inevitably some parts of the equipment contain
dangerous voltage.
Neglecting the operating instructions can therefore lead to severe bodily injuries or
property damage.
Therefore the warnings must be absolutely followed.
During the start-up of the controller (in particular during automatic parameter
determination) the door movements cannot always be externally influenced.
The light barrier is not active during the training run.
An authorized person is therefore required, who is stationed at the door, to guarantee
that during start-up no other person can come into the proximity of the lift door.
The permissible forces and energies are to be checked by the service staff after start-up
on the heaviest door of the overall system (lift).
NOTE
During the parameter training run the motor temperature may not be under 0°C, since
this could cause the value of the door mass to be incorrectly determined and the closing
speed and nudge speed set to a prohibited value.
1. Push the door into the “CLOSE” position.
2. Open the housing cover.
3. Connect motor plug X7.
NOTE
So that no uncontrolled movement occurs during start-up, plug X6 (control inputs) must
not be installed.
4. Connect the input transformer to the mains (230 V AC).
5. Press and hold the red “DOOR PARAM” button (S5000).
6. Connect the output of the mains transformer to X3.
7. Hold the red “DOOR PARAM” button (S5000) until the 7 segment display (H5000)
indicates “_.”.
8. After pushing the brown “OPEN” (S5001) or “CLOSE” button (S5002) the training run
starts. The 7 segment display (H5000) indicates “H.”.
The training run consists of 1 or 2 approximately 10cm opening and closing cycles at
creep speed.
This is followed by a 25cm opening and closing cycle at creep speed that is used to
determine the friction of the door system.
Afterwards the door opens and closes at reduced speed (complete travel). During the
opening cycle, after approximately 10cm of travel, a short acceleration ramp is performed
to determine the mass of the door.
In the “CLOSED” position the door parameters and the calculated door width are saved.
The 7 segment display (H5000) indicates “u”.
9. The door can now be opened with the “OPEN” button S5001.
The 7 segment display (H5000) indicates “o” while the door is opening.
10. Switch off the controller by pulling the input power plug X3.

Rev.01 Issue 09/05
15 Operating instructions AT18 SEDM
The following settings can be made:
Function Adjustment range
Factory setting
Slow end open distance 0...100 mm 30 mm
Slow start open distance 0...100 mm 30 mm
Slow start close distance 0...100 mm 20 mm
Slow end close distance 0...100 mm 40 mm
Maximum speed open 100...800 mm/s 700 mm/s
Slow end speed open 30...90 mm/s 40 mm/s
Slow start speed open 30...90 mm/s 60 mm/s
Slow speed open initial 30...90 mm/s 90 mm/s
Maximum speed close 100...500 mm/s 319 mm/s
Slow start speed close 30...90 mm/s 60 mm/s
Slow end speed close 30...90 mm/s 40 mm/s
Slow speed close initial 30...90 mm/s 90 mm/s
Nudging speed 50...250 mm/s 150 mm/s
Acceleration ramp open 300...1400 mm/s² 1300 mm/s²
Deceleration ramp open 300...1400 mm/s² 600 mm/s²
Reversal ramp open/close 300...1400 mm/s² 1200 mm/s²
Acceleration ramp open 300...1400 mm/s² 500 mm/s²
Deceleration ramp close 300...1400 mm/s² 500 mm/s²
Reversal ramp close/open 300...1400 mm/s² 850 mm/s²
Idle torque open (current) 0...3,5A 0,7 A
Idle torque close (current) 0...2,5A 0,7 A
Peak torque close (current) 0...10,0A 3,0 A
Limit force open 70...300 N 300 N
Limit force close 70...230 N 90 N
Limit force end close 70...230 N 90 N
Limit force nudging 70...230 N 90 N
Changes to the parameters should always be performed in normal operation with the
door in the “CLOSE” position since then the values are then taken over immediately by
the controller.
CAUTION
The maximum static closing force may not exceed 150N including the consideration of
the counterweights!
WARNING
The energies and forces are to be checked by the service
staff after start-up on the heaviest
lift door and to be reduced to the limit values if necessary
.
NOTE
The acquired, optimal parameter settings can be recorded in the adjustment log (see
Appendix adjustment log). This log should also be available when addressing questions
to the Hotline.

Rev.01 Issue 09/05
16 Operating instructions AT18 SEDM
9 Relay contacts (option)
The relay contacts are part of the relay module (option) and can be used in order to
report the following door conditions to the main lift controller:
– X11
The door has reached the “CLOSE” position
The relay switches on, when the controller recognizes the “CLOSE” position and no more
impulses are spent by the pulse generator, i.e., the door has stopped. Pin 3 is connected
with pin 1 until the Door OPEN command is activated. The relay then immediately drops
and Pin 3 is again connected with pin 2.
– X12
The door reverses.
The relay switches on, if the door reverses e.g. due to a blockage, a light barrier
interruption or an open command.
Pin 1 is then connected with pin 3 until the “OPEN” position is reached
– X13
The door has reached the “OPEN” position
The relay switches on, if the current distance of the door to the “OPEN” position falls
below 2 cm. Pin 1 and pin 3 are then connected.
When the distance of 2 cm is again exceeded, the relay immediately drops and pin 3 is
again connected with pin 2.
In the “Overview of the control elements” the contacts are represented in a power-off
(inactive) condition.
The active condition is also indicated by an LED on the switched relay.
WARNING
The door controller is not a safety device. Therefore the relay contacts may not be used
for the lift's safety circuit.
With an opened housing cover only low voltage (voltage less than 42V) may be applied
to the controller!
When connecting higher voltages (max. 230V AC) to the relay module, these voltages
may only be turned on if the protective cap is closed and tightened with the mounting
screw.
In this case, the attached wiring must have double or reinforced insulation and only be
stripped directly at the terminal connectors.
The components of the controller and connection cables, as well as the motor plug and
its wiring, may only come into contact with the double or reinforced insulation of the live
wires.
Strain relief is provided by cable ties inside of the protective cap and at the attachment
locations of the housing.

Rev.01 Issue 09/05
17 Operating instructions AT18 SEDM
10 The travelling curve
Figure 2
Reversing ramp OPEN_CLOSE = reverse of the direction of travel from the OPEN
direction towards the CLOSE direction.
Reversing ramp CLOSE_OPEN = reverse of the direction of travel from the CLOSE
direction towards the OPEN direction.
When reversing from the opening to the closing direction the door is braked with the
reversing ramp OPEN_CLOSE and starts the closing movement with the acceleration
ramp CLOSE.
SPEED

Rev.01 Issue 09/05
18 Operating instructions AT18 SEDM
11 Operating status display
The 7 segment display H5000 shows the following operating conditions:
Display Meaning
0 Signal light barrier active (light barrier interrupted)
1 RAM -, EEPROM or CPU error (system error)
2 EEPROM error
3 Error in the second power-off sequence
4 Increase of the open time with increased motor duty cycle
5 Motor undefined
6 Motor blockage in closing direction
7 Pulse generator error
8 Minimum editor is started (service button OPEN and CLOSE operated at the
same time)
9 Motor over current
A Minimum editor (force adjustment) active
B Reserved
C Blockage when opening
C Minimum editor (profile setting) active
D Door remains standing during initialization run (no OPEN or CLOSE signal)
E Motor over voltage
F Motor under voltage
h Reserved
H Parameter determination (training run)
n Friction values of the door too high
L Current measurement error
o Function O. K.
P Parameter error (error during the training run)
u Door is closed
U Max. door mass exceeded
- Controller waiting for training run

Rev.01 Issue 09/05
19 Operating instructions AT18 SEDM
Speed limit curve
The speed limit curve is the characteristic used for the determination of the maximum
permissible door speed V
max
as a function of the total door leaf mass.
In accordance with EN 81 the maximum kinetic energy of the door moving in the closing
direction may not exceed 10 joules. WKIN = 1/2 m ·v ² = 10 J.
Example from following speed limit curve:
Total door leaf mass m = 180 kg = > Vmax = 0.33 m/s.
Figure 3
NOTE
The speed can be adjusted between 0 (corresponds to 0.10 m/s) and 100 %
(corresponds to 0.80 m/s).

Rev.01 Issue 09/05
20 Operating instructions AT18 SEDM
12 Extension modules (option)
12.1 Installation of the extension modules
Components
1
 Basic AT18 module:
2  Terminal module:
3  Relay module:
4
 Flat cable with the plugs A, B and C
5
 Mounting screws for the terminal module
6
 Mounting screws for the relay module
Photo 1
Flat cable pin assignment (Pos.4):
A = basic unit AT18 (Pos. 1)
B = terminal module (Pos. 2)
C = relay module (Pos. 3)
3 2
1
4
6 5
CB
A
