D-Link DSB-650TX User manual

-1-
This Installation Guide includes instructions for:
§Windows XP
§Windows 2000
§Windows Me
§Windows 98/98se
Installation Guide Contents:
Section 1:Minimum System Requirements
Section 2:Installing the DSB-650TX
Section 3:Windows XP Driver Installation
Section 4:Windows 2000 Driver Installation
Section 5:Windows Me Driver Installation
Section 6:Windows 98/98SEDriver Installation
Section 7:Features & LED Description
Section 8:Tips & Technical Support
Review Package Contents:
Make sure that the package contains the following items. If any items are
missing, please contact your reseller.
§D-Link DSB-650TX
§Drivers on Floppy Disk
§This Installation Guide
Minimum System Requirements:
The following hardware must be available to use this product correctly…
§Pentium Class 166 MHz or Equivalent or Faster
§16 MB of RAM
§Floppy Disk Drive
§One Available USB Port
§Windows XP, Windows 2000, Windows Me, Windows 98 SE
D-Link DSB-650TX
USB 1.1 Fast Ethernet Adapter
Installation Guide

-2-
Installing the DSB-650TX
§Plug the “A” connector of the
USB cable provided into an
available USB slot on your
computer. This is the narrow
end of the cable.
§Plug the “B” connector of the
USB cable into the
DSB-650TX. This is the larger
end of the cable.
§Connect one end of a
straight-through Ethernet
cable to the RJ-45 port of the
DSB-650TX.
§Connect the other end of the
Ethernet cable to a switch or
broadband modem.
§Windows will detect the
DSB-650TX and ask you for
the drivers. Refer to the
following sectionbelowthat
corresponds to your operating system.
TypeA
Type B
RJ45
RJ45

-3-
Windows XP Driver Installation
§Insert the DSB-650TX Driver Disk into your Floppy Drive.
§The “Found New Hardware”
window will appear.
§Click “Next”.
§Click “Install from a list
or specific location
(Advanced)”, then click
“Next.”

-4-
§Insert the driver disk.
Select “Search
removable media
(floppy, CD-ROM…)”
and thenclick “Next.”
§Click “Finish”
§The installation is
complete.

-5-
Windows 2000 Driver Installation
§Insert the DSB-650TX Driver Disk into your Floppy Drive.
§The “Found New
Hardware Wizard” will
appear
§Click “Next”.
§Select “Search for a
suitable driver for my
device
(recommended)”. Insert
the driver disk into the
floppy disk drive and
click “Next”.

-6-
§Select “Floppy disk
drives” and thenclick
“Next”.
§Click “Next” to install
the driver.
§Click “Finish” to
complete the
installation.

-7-
Windows Me Driver Installation
§Insert the DSB-650TX Driver Disk into your Floppy Drive.
§The “Found New Hardware
Wizard” will appear.
§Insert the driver disk
into the floppy disk
drive. Select
“Automatic search
for a better driver
(Recommended)” and
then click “Next”.
§Click “Finish”.
§The “System Setting
Change” window will
appear.Select “Yes” to
restart your computer and
complete the installation.

-8-
Windows 98/98SE Driver Installation
§Insert the DSB-650TX Driver Disk into your Floppy Drive.
§The “FoundNew
Hardware Wizard”
will appear.
§Insert the driver disk
into your floppy disk
drive. Click “Next”.
§Select “Search for the
best driver for your
device
(Recommended)”.
Click “Next”.

-9-
§Select “Floppy disk
drives”. Click “Next”.
§Click “Next” to
continue.

-10-
§Click “Finish”.
§Click “Yes” to restart
your computer and
complete the
installation.

-11 -
Features & LED Description
Features
USB Plug and Play capability, install the drivers and be networked in
minutes.
§Based on the IEEE 802.3u standard at 100BaseTX and the IEEE
802.3 standard at 10BaseT, the DSB-650TX is compatible with
common networking standards.
§Automatically detects 10/100 Mbps data transfer rates.
§Automatically senses full duplex or half duplex modes. Data transfer
rate doubles at full duplex.
LED Description
The DSB-650TX has two LED indicators. The Link LED indicates that
there is an active connection between the DSB-650TX and the network.
§The Link LED is green when the DSB-650TX is operating at
100Mbps.
§The Link LED is amber when the DSB-650TX is operating at
10Mbps.
§The Tx/Rx (transmitting and receiving) LED flashes green when the
DSB-650TX is transmitting or receiving information.

-12-
Tips & Technical Support
Tips
§When inserting the DSB-650TX into the USB port of your computer,
make sure that you insert it securely.
§For best performance, use certified CAT5 Fast Ethernet cable.
§Remember that you must connect a CAT5 Fast Ethernet cable from
the DSB-650TX to a switch or broadband gateway to connect to your
network.
§When setting IP addresses, make sure that you are on the same IP
address scheme as the other computers in the network. For example,
if the rest of your network uses an IP address of 192.168.0.XXX, then
you must set your IP address to the same scheme, such as 192.168.0.5.
If your network uses a DHCP server, then you don’t have to worry
about it as the server will assign the correct IP address automatically.
Also, make sure that you have the same workgroup name.
Technical Support
D-Link provides free technical support for customers within the United
States during the warranty period. U.S. customers can contact D-Link
Technical Support through our web site, e-mail or by phone.
D-Link Technical Support over Telephone:
§1-800-758-5489
§24 Hours a Day, 7 Days a Week
D-Link Technical Support over the Internet:
§support.dlink.com
§[email protected]
