D-Link UpLink Newsletter 1 October 2002
D-Link UpLink Newsletter
October 2002
>>>>>>>>>>NEW D-LINK PRODUCTS<<<<<<<<<<
POWERFUL NEW WIRELESS SOLUTIONS FROM D-LINK SET TO LAUNCH IN OCTOBER
D-Link has expanded our line of wireless solutions with three new wireless products launching in October
including two multimode adapters that serve both 802.11a and 802.11b networks. Plus, we are set to release
two new USB 2.0 adapters and two PC Cameras just in time for the holiday selling season. See below for
details….
DI-714P+ - The DI-714P+ is a wireless broadband router that allows users to share
a cable or DSL connection and create an 802.11b wireless network with data
transfer rates up to 22Mbps! An intelligent, Web-based set up wizard allows users
to quickly connect computers to share high-speed Internet access and other
network resources. Plus, the DI-714P+ includes a built-in 4-port switch for
additional connectivity options, a built-in print server, and offers 256-bit WEP
encryption for a higher level of security compared to standard 802.11b products.
The DI-714P+ also incorporates advanced firewall features and parental controls
that are easy to set up with a Web-based user interface.
DWL-AB520 - The D-Link DWL-AB520 is multimode wireless PCI adapter that
simultaneously serves both 802.11a networks at 54Mbps and 802.11b networks at
11Mbps. The DWL-AB520 also supports Advanced Encryption Security (AES) – a
new security standard much more robust than WEP encryption found in existing
wireless solutions. The DWL-AB520 is an ideal solution for users that want a
flexible yet affordable solution that will protect your investment in your current
wireless networking infrastructure.
DWL-AB650 - - The D-Link DWL-AB650 is multimode wireless cardbus adapter
that simultaneously serves both 802.11a networks at 54Mbps and 802.11b networks
at 11Mbps. This flexible adapter serves the mobile professional that needs to have
wireless network access regardless of the standard (802.11a or 802.11b). The
DWL-AB650 also includes security features and robust management capabilities
that make it an excellent solution for users looking to upgrade to a future proof
wireless networking solution.
DUB-C2 – For laptop users that want a quick and easy way to upgrade to the new,
faster USB 2.0 standard, D-Link presents the DUB-C2 – a 2-Port USB 2.0 Cardbus
adapter. The DUB-C2 offers transfer rates up to 480Mbps (40x faster than USB 1.1
solutions) and is backward compatible with existing USB 1.1 solutions.
DFB-A5 – The DFB-A5 is a combination USB 2.0 and Firewire Adapter that offers
users a flexible way to attach peripherals to a PC. The DFB-A5 includes two (2)
USB 2.0 ports that offer transfer rates up to 480Mbps and is backward compatible
with existing USB 1.1 products. In addition, this adapter also includes 3 Firewire
ports (1 internal, 2 external) offering transfer rates up to 400Mbps.
DSB-C110 - The D-Link DSB-C110 PC Camera is a 100K Pixel Resolution USB
Video Camera. The DSB-C110 features 352 x 288 resolution and includes software
to facilitate video conferencing, chat and video e-mail. This unit simply attaches to a
PC via a standard USB connection.

D-Link UpLink Newsletter 2 October 2002
DSB-C310 – D-Link’s DSB-C310 is a 300K Pixel Resolution PC Camera that
includes several robust features at a very affordable price. These features include:
640 x 480 resolution, built-in microphone to add sound to video, snapshot button for
easy still image capture, and software to make the DSC-C310 a complete
audio/video solution.
>>>>>>>>>>PRICING UPDATES<<<<<<<<<<
NEW PRODUCTS, NEW PRICING
Pricing on the new D-Link products shipping in October is as follows:
D-Link
Part # Description MSRP
DI-714P+ Enhanced 2.4GHz Wireless Router with Print Server $189.99
DWL-AB520 Multimode 2.4/5GHz Wireless PCI Adapter $189.99
DWL-AB650 Multimode 2.4/5GHz Wireless Cardbus Adapter $149.99
DUB-C2 2-Port USB 2.0 Cardbus Adapter $49.99
DFB-A5 3-Port Firewire 1394 + 2-Port USB 2.0 PCI Combo Adapter Card $89.99
DCS-C110 100K Pixel PC Camera $29.99
DCS-C310 300K Pixel PC Camera $39.99
D-LINK DELIVERS THE SAVINGS WITH SEVERAL PRICE REDUCTIONS FOR OCTOBER
In an effort to maintain our position as the price leader in networking equipment, D-Link has lowered the price
on several key products including selections from our AirPlus line and our popular 10/100 switches. See
below for details on all of our October price moves.
D-Link
Part # Description
Approx.
Price Drop
DWL-520+ Enhanced 2.4Ghz Wireless PCI Adapter $10.00
DWL-900AP+ Enhanced 2.4Ghz Wireless Access Point $10.00
DCF-660W Wireless CompactFlash Card, Type I/Type II $10.00
DFE-690TXD 10/100 32-Bit CardBus Adapter w/Direct Port $5.00
DSS-8+ 8-Port 10/100 Switch $8.00
DES-1026G 24-Port 10/100 Switch w/2-Gigabit Ports $75.00
DES-3226SM 24-Port 10/100 Managed Stackable Switch w/1-Port GBIC $50.00
>>>>>>>>>>DISCONTINUED PRODUCTS<<<<<<<<<<
KEEP UP-TO-DATE ON CURRENT D-LINK PRODUCTS
In an ongoing effort to provide our partners and customers with the most current networking solutions, D-Link
has discontinued the following products (includes recommended replacement products):
D-Link
Part # Description
Recommended
Replacement
DSB-C100 100K Pixel PC Camera DSB-C110
DSB-C300 300K Pixel PC Camera DSB-C310
>>>>>>>>>>PROMOTIONS<<<<<<<<<<
D-LINK’S TOP SELLING DSS-24+ IS AN EVEN BETTER DEAL AFTER INSTANT REBATE
D-Link continues to provide margin-enhancing incentives through our Distribution Partners. Check out the
following instant rebates valid through October on our popular 24-Port 10/100 Switch – the DSS-24+ and our
20-Port Managed Gigabit Switch with 4 GBIC ports – the DGS-3224TG.

D-Link UpLink Newsletter 3 October 2002
D-Link
Part # Description
Instant
Rebate
DSS-24+ 24-Port 10/100 Rack Mount Switch $20.00
DGS-3224TG 20-Port 10/100/1000 Managed Gigabit Switch w/4-Port GBIC $100.00
NEW TECHNOLOGY, GREAT OFFERS FROM D-LINK FOR THE FALL SEASON
The seasons may be changing but D-Link’s commitment to offering
affordable networking solutions is not. D-Link’s Fall Promotion includes special
mail-in rebate offers on our very best selling products. See below for the rebate
deals that are good from October 1 through November 23, 2002.
Part # Description Rebate
DI-614+/DWL-650+ Enhanced Wireless Cable/DSL Router +
Wireless PC Card, 802.11b (Bundle) $30
DI-614+/DWL-520+ Enhanced Wireless Cable/DSL Router +
Wireless PCI Adapter, 802.11b (Bundle) $30
DI-604 4-Port Broadband Ethernet Router $10
DSS-5+ 5-Port 10/100 Switch $5
DSS-8+ 8-Port 10/100 Switch $8
DSS-16+ 16-Port 10/100 Switch $16
D-LINK EXTENDS SPECIAL DEMO PRICING THROUGH THE END OF 2002!
For a limited time, resellers can purchase select D-Link
products with special demo pricing that offers savings of up to
30% off current distribution pricing! This tremendous offer
gives resellers the perfect opportunity to sample D-Link’s
brand new AirPlus Wireless Networking Solutions that offer
data transfer rates up to 22Mpbs and our high-end switching
solutions. Discover why top trade publications like PC
Magazine have awarded D-Link products their highest honors
and save with demo pricing through the end of 2002.Contact
your Distribution Sales Representative for more information.
Special demo pricing is available on the following products:
D-Link Part # Description Approx.
Discount
DCS-1000W Wireless Internet Camera 802.11b 20%
DWL-6000AP 2.4HGz/5Ghz Dual Band Wireless Access Point 20%
DWL-5000AP 5GHz Wireless Access Point 802.11a 54Mbps 20%
DWL-A650 5GHz Wireless PC Card 802.11a 54Mbps 20%
DWL-A520 5GHz Wireless PCI Card 802.11a 54Mbps 20%
DI-764* Multimode Wireless Cable/DSL Router, 802.11a/802.11b 20%
DI-614+ Enhanced 2.4GHz Wireless Cable/DSL Router 802.11b up to 22Mbps 30%
DWL-900AP+ Enhanced 2.4GHz Wireless Access Point 802.11b up to 22Mbps 30%
DWL-650+ Enhanced 2.4GHz Wireless PC Card, 802.11b, up to 22Mbps 30%
DWL-520+ Enhanced 2.4GHz Wireless PCI Adapter, 802.11b, up to 22Mbps 30%
DWL-120* Wireless USB Adapter, 802.11b 20%
DSS-24+ 10/100 24-Port Rack-mount Switch w/Slot for Fiber Module 20%
DGS-3308FG 6 Port 1000BaseT Managed Layer 3 Switch w/2 Port GBIC 20%
DGS-3308TG 6 Port 10/100/1000BaseT Managed Layer 3 Switch w/2 Port GBIC 20%
DES-3226 24 Port 10/100 Managed Switch, SNMP, 2 Port Optional Gigabit Module 20%
DES-3226SM* 24-Port 10/100 Managed Stackable Switch w/1 Port GBIC 20%
DES-3326 24 Port 10/100 Managed Layer 3 Switch, 2 Port Optional Gigabit Module 20%

D-Link UpLink Newsletter 4 October 2002
DES-6000 10/100/1000 8 Open Slot Chassis Switch SNMP Managed-Chassis, CPU, 1
power supply 20%
DGS-1016T 10/100/1000 16-Port Gigabit Switch Rack-mount 20%
DGS-1024T 10/100/1000 24-Port Gigabit Switch Rack-mount 20%
DI-604* Cable/DSL Router with 4-Port Switch 20%
DI-804V* Cable/DSL VPN Router w/4-Port Switch and UPnP 20%
DFL-300* SOHO VPN Firewall w/Free Unlimited Clients 20%
*New Demo SKU Added in Q4 2002.
ANNOUNCING SPECIAL VALUE ADDED OFFERS ON D-LINK’S ENTIRE LINE OF GIGABIT SWITCHES
Buy a D-Link Unmanaged Gigabit Switch, Get a Free DGE-500T Gigabit Ethernet Adapter
D-Link offers a full line of high performance unmanaged Gigabit Switches that are
available in 4, 8, 16, and 24 port versions and are capable of auto sensing speeds
at 10/100/1000Mbps. Designed as a seamless migration of Ethernet and Fast
Ethernet networks, this line of switches provides Gigabit speeds at an affordable
price. Now these switches are an even better deal because for a limited-time, D-
Link is pleased to offer the DGE-500T Gigabit Ethernet Adapter Free with the
purchase of an unmanaged Gigabit Switch.
D-Link Part # Description Free Product
DGS-1004T 4-Port 10/100/1000 Gigabit Switch DGE-500T
DGS-1008T 8-Port 10/100/1000 Gigabit Switch DGE-500T
DGS-1016T 16-Port 10/100/1000 Gigabit Switch DGE-500T
DGS-1024T 24-Port 10/100/1000 Gigabit Switch DGE-500T
Buy a D-Link Managed Gigabit Switch, Get a Free Managed Gigabit Ethernet Adapter
For networks that require more sophisticated management features along with data
transfer rates at Gigabit speeds, D-Link offers the DGS-3224TG – a 2-Port
10/100/1000 Managed Gigabit Switch with four (4) GBIC slots and the DGS-
3308TG – a 6-Port 10/100/1000 Managed Layer 3 Gigabit Switch with two (2) GBIC
slots. For a limited time these switches also ship with a free adapter – the DGE-
550T, a 32/64 Bit Managed Gigabit Adapter. For networks applications that require
the use of fiber, D-Link offers the DGS-3308FG – a 6-Port 1000 Base-T Managed
Layer 3 Gigabit Switch with two (2) GBIC slots. A free adapter is included with this
switch as well – the DGE-550SX Fiber Gigabit Network Adapter.
D-Link Part # Description Free Product
DGS-3224TG 20-Port 10/100/1000 Managed Gigabit Switch w/ 4 GBIC slots DGE-550T
DGS-3308TG 6-Port 10/100/1000 Managed Layer 3 Gigabit Switch w/ 2 GBIC slots DGE-550T
DGS-3308FG 6-Port 1000Base-T Managed Layer 3 Gigabit Switch w/ 2 GBIC slots DGE-500SX
>>>>>>>>>>RECENT PRESS AND AWARDS<<<<<<<<<<
MICROSOFT WINDOWS XP EXPERT ZONES RECOGNIZES HIGH-SPEED AIRPLUS SOLUTIONS
A recent article from the Microsoft Windows XP Expert Zone talked about the faster data transfer rates
available in the new AirPlus products versus standard 802.11b products. Quotes from the review include:
"For home and small office users who regularly transfer large files between computers, 802.11b throughput is
not fast enough. The 802.11b+ technology offered by vendors such as D-Link in their AirPlus line, provides an
additional 2-3 Mbps speed."
This article is available online at:
http://www.microsoft.com/windowsxp/expertzone/columns/bowman/02september03.asp

D-Link UpLink Newsletter 5 October 2002
802.11 PLANET.COM PRAISES THE D-LINK DCS-1000W WIRELESS INTERNET CAMERA
The D-Link DCS-1000W Wireless Internet Camera was recently reviewed by 802.11 Planet.com and received
praise from the reviewer that included:
"The New DCS-1000W doesn't look anything like a Web cam, and that's good, since that is not what the unit
is supposed to be."
"Excellent IP View software lets you view and administer multiple cameras."
"Thankfully, the DCS-1000W supports e-mail alerts."
This review is available online at:
http://www.80211planet.com/reviews/ST/article/0,4000,10722_1448141,00.html
That’s all for October! For more information on D-Link products visit our Web site at www.dlink.com
or contact your D-Link representative at 800-326-1688.
