D-Link DIR-612 User manual

WIRELESS N 300 ROUTER
DIR - 612
QUICK
INSTALLATION
GUIDE
PETUNJUK PEMASANGAN CEPAT

DIR - 612
2
ENGLISH
CONTENTS OF
PACKAGING
CONTENTS
WIRELESS N 300 ROUTER
DIR-612
POWER ADAPTER
9V 0.6A
If any of these items are missing from your packaging, contact
your reseller.
ETHERNET CABLE (CAT5 UTP)
CONNECT THE ROUTER TO YOUR PC DURING SETUP

DIR - 612 3
ENGLISH
PRODUCT SETUP
WEB-BASED SETUP
Step 1
Position your DIR-612 near your Internet-connected modem and
PC. Keep the router in an open area for better wireless coverage.
Step 4
Open a browser on the connected computer. If you are not
automatically directed to the D-Link Setup Wizard, go to
‘http://192.168.0.1’ and follow the onscreen instructions to congure
your DIR-612. Use ‘admin’ as your username and password.
Step 2
Unplug the modem Ethernet cable connected to your computer and
plug it into the port labeled ‘INTERNET’ on the router.
Connect the supplied power adapter to the router and a power
outlet, then verify that the power LED is on.
Step 3
Plug one end of the supplied Ethernet cable into the port labeled ‘1’
on the back of the router, and the other end into the Ethernet port on
your computer.
Modem
Router
PC
Modem
PC Modem
Internet
Save
Router
Router

DIR - 612
4
ENGLISH
TROUBLESHOOTING
SETUP AND CONFIGURATION PROBLEMS
1. HOW DO I CONFIGURE MY DIR-612 ROUTER MANUALLY?
- Connect your PC to the router using an Ethernet cable.
- Open a web browser and enter the address ‘http://192.168.0.1’ .
- The default username and password is ‘admin’.
- If you have changed the password and can not remember it, you will need to reset the router to
return to an empty password eld.
2. HOW DO I RESET MY DIR-612 ROUTER TO FACTORY DEFAULT SETTINGS?
- Ensure the router is powered on.
- Press and hold the reset button at the bottom of the device for 10 seconds.
Note: Resetting the router to factory default will erase the current conguration settings.
To re-congure your settings, log into the router as outlined in question 1, then run the Setup Wizard.
3. HOW DO I ADD A NEW WIRELESS CLIENT OR PC IF I HAVE FORGOTTEN MY
WI-FI NAME (SSID) OR WI-FI PASSWORD?
- For every PC that needs to connect to the router wirelessly, you will need to ensure you use the
correct Wi-Fi Name (SSID) and Wi-Fi password.
- Use the web-based user interface (as described in question 1 above) to check or choose your
wireless settings.
- Make sure you write down these settings so that you can enter them for each wirelessly
connected PC. The back of this document features an area to record this important information.
4. WHY CAN'T I GET AN INTERNET CONNECTION?
- For ADSL users, please contact your ISP to make sure the service has been enabled/connected
by your ISP and that your ISP username and password is correct.

DIR - 612 5
ENGLISH
TECHNICAL SUPPORT
Australia:
Tel: [phone]
24/7 Technical Support
Web: http://www.dlink.com.au
E-mail: [email protected]
India:
Tel: [phone] or 1860-233-3999
Web: www.dlink.co.in
E-Mail: [email protected]
Singapore, Thailand, Indonesia,
Malaysia, Philippines, Vietnam:
Singapore - www.dlink.com.sg
Thailand - www.dlink.co.th
Indonesia - www.dlink.co.id
Malaysia - www.dlink.com.my
Philippines - www.dlink.com.ph
Vietnam - www.dlink.com.vn
Korea:
Tel : [phone]
Monday to Friday 9:30am to 6:30pm
Web : http://d-link.co.kr
E-mail : [e-mail]
New Zealand:
Tel: [phone]
24/7 Technical Support
Web: http://www.dlink.co.nz
E-mail: [email protected]
South Africa and Sub Sahara
Region:
Tel: [phone]
08600 DLINK (for South Africa only)
Monday to Friday 8:30am to 9:00pm South
Africa Time
Web: http://www.d-link.co.za
E-mail: [email protected]
D-Link Middle East
Dubai, U.A.E.
Tel: [phone]
Fax: [phone]
Technical Support: [phone]
General Inquiries: [email protected]
Tech Support: [email protected]
Egypt:
Technical Support Call Center: [phone]
General Inquiries: [email protected]
Tech Support : [email protected]
Kingdom of Saudi Arabia:
Technical Support:
[phone]
General Inquiries: [email protected]
Tech Support: [email protected]
Pakistan:
Technical Support: [phone], 34305069
General Inquiries: [email protected]
Tech Support: [email protected]
Morocco:
Phone ofce: [phone]
Email: [email protected]
Bahrain:
Technical Support: [phone]
Tech Support: [email protected]
Kuwait:
Tech Support: [email protected]
You can nd software updates and user documentation on the D-Link website.
Tech Support for customers in

DIR - 612
6
BAHASA INDONESIA
ISI
KEMASAN
ISI
WIRELESS ROUTER N 300
DIR-612
ADAPTOR DAYA
9V / 0.6A
KABEL ETHERNET (CAT5 UTP)
MENGHUBUNGKAN ROUTER DENGAN PC SELAMA
PROSES INSTALASI
Bila salah satu dari item tidak terdapat dalam kemasan, segera
hubungi penjual.

DIR - 612 7
BAHASA INDONESIA
Modem
Router
PC
Modem
PC Modem
Internet
Save
Router
Router
PENGATURAN PRODUK
INSTALASI BERDASARKAN WEB BROWSER
Langkah 1
Posisikan DIR-612 Anda dekat dengan modem Internet dan PC.
Letakkan router di area terbuka agar jangkauan nirkabel menjadi
lebih baik.
Langkah 4
Buka browser pada komputer yang terhubung. Jika Anda tidak secara
otomatis diarahkan ke Setup Wizard D-Link, buka halaman
'http://192.168.0.1' dan ikuti petunjuk pada layar untuk
mengkongurasi DIR-612. Masukkan admin untuk username dan
admin untuk katasandi.
Langkah 2
Cabut kabel modem Ethernet yang terhubung ke komputer Anda
dan hubungkan ke port berlabel 'INTERNET' pada router.
Sambungkan adaptor daya yang termasuk dalam kemasan ke
router dan stopkontak listrik, kemudian pastikan bahwa LED daya
menyala.
Langkah 3
Pasang salah satu ujung kabel Ethernet yang telah disediakan ke port
berlabel '1 'di belakang router, dan ujung lainnya ke port Ethernet pada
komputer Anda.

DIR - 612
8
BAHASA INDONESIA
PENANGANAN MASALAH
MASALAH PADA PENGATURAN DAN KONFIGURASI
1. BAGAIMANA CARA MENGATUR DIR-612 ROUTER SAYA SECARA MANUAL?
- Hubungkan PC Anda ke router menggunakan kabel Ethernet.
- Buka web browser dan masukkan alamat ‘http://192.168.0.1’.
- Default username admin; password default adalah admin.
- Jika Anda telah mengubah password dan tidak dapat mengingatnya, Anda perlu me-reset router
supaya kata sandi kembali kosong.
2. BAGAIMANA CARA ME-RESET DIR-612 SAYA KE PENGATURAN DEFAULT PABRIK?
- Pastikan router dinyalakan.
- Tekan dan tahan tombol reset di bagian bawah perangkat selama 10 detik.
Catatan: reset router ke bawaan pabrik akan menghapus kongurasi yang ada. Kongurasi
ulang pengaturan Anda, login ke router seperti pada pertanyaan 1, kemudian jalankan Setup
Wizard.
3. BAGAIMANA CARA MENAMBAH KLIEN NIRKABEL BARU ATAU PC JIKA SAYA TIDAK
INGAT NAMA WI-FI (SSID) ATAU WI-FI PASSWORD SAYA?
- Untuk setiap PC yang terhubung ke router nirkabel, Anda perlu menggunakan Nama Wi-Fi (SSID)
dan Wi-Fi password yang benar.
- Gunakan antarmuka pengguna berbasis web (seperti yang dijelaskan dalam pertanyaan 1 di
atas) untuk memeriksa atau memilih pengaturan nirkabel Anda.
- Pastikan Anda menuliskan pengaturan ini sehingga Anda dapat memasukkan informasi ini ke
setiap PC yang terhubung secara nirkabel. Bagian belakang dokumen ini memiliki area untuk
mencatat informasi penting ini.
4. MENGAPA SAYA TIDAK DAPAT MENGAKSES INTERNET?
- Untuk pengguna ADSL, silahkan hubungi ISP Anda untuk memastikan bahwa layanan telah
diaktifkan / terhubung oleh ISP dan bahwa username dan password sudah benar.

DIR - 612 9
BAHASA INDONESIA
DUKUNGAN TEKNIS
Update perangkat lunak dan dokumentasi pengguna dapat diperoleh pada situs web D-Link.
Dukungan Teknis untuk pelanggan:
Dukungan Teknis D-Link melalui telepon:
Tel: [phone] (Layanan Bebas Pulsa)
Dukungan Teknis D-Link melalui Internet:
Pertanyaan Umum: [email protected]
Bantuan Teknis: [email protected]
Website : http://www.dlink.co.id
