Dabtastic THE BULLET User manual

THE BULLET

1
INTRODUCTION
Thank you for purchasing this vaporizer, this is the advanced complete
baking vaporizer making the vaporization process very fast and pure,
no combustion, which instantly destroy the key elements found in
various herb and release a multitude of new chemical compounds.
Complete 3in1 baking vaporizer, adjustable voltage when connect with
the wax tank to 3 voltage option mold. 5 temperature to choose when
use the herb heating device. To ensure optimal performance and safety
of your herb vaporizer, please read this entire manual for instructions.

FEATURES
2
Silicone
Cover
Heating Chamber
Base
Mouthpiece
Battery
Bottom LED
light Power Button

3
TURNING ON/OFF
USB Cable Silicon Cover Battery Chamber Mouthpiece
Base Manual Cleaning brush Dab tool Wax Tank
(Sell Separately)

4
PACKING CONTENTS
1 X Battery
1 X Heating Chamber
1 XMouthpiece
1 XSilicone Cover
1 X USB Cable
1 X Base
1 X Manual
1 X Dab Tool
1 X Cleaning Brush
1 XGift Box

5
SPECIFICATIONS
Device Size
Capacity & Output
Resistance
Lock/Unlock
Heating Up Time
Safety Power Time
Charging Time
Low Power
Safeguard
122*22*22mm
2200mAh Li-polymer battery, 5V, 1A
0.5～0.7 ohms
Press power button 5 times in
rapid succession
Within 20 seconds
5 Minutes auto-shut off
Around 3 hours
Bottom red LED light alternating
flash 5 times
Dual PCB/IC protection

6
INTRUCTIONS
Loading the device:
For Dry herb
Screw out the mouthpiece from
the heating chamber
Fill the chamber full with dry herb(always make sure to finely grind
your materials before vaporizing).But don't over-pack because proper
airflow is needed for best results.
Re-attach the mouthpiece back once your device has been applied.
(Put the silicone cover on the mouthpiece if you need to use bubbler)
Click the power button 5 times to turn on, press the power button one
times to switch the temperature.
Note: Vaporization may vary depending on type of material and temperature
setting.
A.
•
•
•
•

7
Fox Wax
The battery can be matched with different kinds of wax tank.
We recommend you use our special Tallva to test it’s better vapor.
For Oil
The battery can support various oil tank in the market, please follow
the oil tank manual.
B.
•
C.
•

8
Turning on/off the device
Turn on :
Once loading the device, press the battery button 5 times continuous
and slowly within 3 seconds to turn on it.
Turn off:
Press the button 5 times again to turn off the device.
Auto shutdown:
the device has a safety power duration function, the unit will auto
shutdown after 5 minutes of use. Simply press the button 5 times
rapidly to re-activate the device.
•

8
Turning on/off the device
Turn on :
Once loading the device, press the battery button 5 times continuous
and slowly within 3 seconds to turn on it.
Turn off:
Press the button 5 times again to turn off the device.
Auto shutdown:
the device has a safety power duration function, the unit will auto
shutdown after 5 minutes of use. Simply press the button 5 times
rapidly to re-activate the device.
•

9
Battery Capacity Indication & Charging
Battery Capacity Indication:
This device has a LED light on battery bottom, it will light on for 10
seconds then off. Different color indicate different battery power, as
below:
•
Red LED light
10%～30%
Blue LED light
30%～70%
Green LED light
70%～90% Power

10
Charging:
During operation, a low battery power will
be indicated by alternate red light flashing
5 times on battery button and bottom LED
light, then the device shutdown. That means
the battery power less than 10%, you have to
recharging the device. To charge, plug provided
USB cable into the micro USB port. A slowly flashing red LED light
indicates charging in process. The bottom LED green light flashing
10 times, then off means full charge. A full charge is recommended
before first use and a full charge from empty to full may take
around three hours.
•

11
Note:
The device contains lithium-ion battery, please be sure to discard
of them in proper receptacle. Don't overcharge it and short circuit it.
Imcompatiable chargers maycarr a different voltage, which may be
a fire hazard. For this reason,we atrongly request to sue supplied
charger along with the package. The use of any charging unit with
a different voltage will void the limited warranty offered on the
device.
In order to prevent overheating, pls don't leave the charger
plugged in overnight.
•
•
•

12
This device has five temperate settings:
375F/390F/405F/ 420F/435F. When the device turn
on, your temperature will be set at 375F, the blue
light will appear on the side of battery (the first
position). In the meantime, a flashing blue LED light
will appear on battery button to indicating that your
device start heating up process. When the indicator light become solid
blue ,the desired temperature is reached.(we recommend you wait 3 or 4
seconds before inhaling through the mouthpiece).
To charge your setting temperature, pls press the power button once, the
battery side LED light will change position to indicate the heating selection.
Keep pressing power button to cycle through the heating setting.
•
•
Temperature Setting For Dry Herb

13
Voltage Setting For Wax & Oil
This device has three voltage options for wax/oil(3.7V/3.9V/4.2V). When
connect the wax or oil tank(You can buy it from local market), it turns
to voltage setting mold automatically. Click the battery button five
times to turn on/off. Click the battery button four times change to your
desired voltage. Press and hold the battery button for vapor.
•
Adjustable Voltage

13
Voltage Setting For Wax & Oil
This device has three voltage options for wax/oil(3.7V/3.9V/4.2V). When
connect the wax or oil tank(You can buy it from local market), it turns
to voltage setting mold automatically. Click the battery button five
times to turn on/off. Click the battery button four times change to your
desired voltage. Press and hold the battery button for vapor.
•
Adjustable Voltage

14
CLEANING AND
MAINTAINING THE HERB TANK
Lock the device before cleaning.
Remove the mouthpiece and empty the
chamber completely.
To cleaning the heating chamber,
please use the cleaning brush to gently
remove any excess particles inside
and around the chamber.
Note:
1. While using the device, portions of the device may reach high temperatures. Don't
clean or disassemble the device until all portions of the device has cooled completely.
2. Don't immerse the herb tank in liquid of any kinds, it will damage the heating element.
•
•

15
IMPORTANT SAFETY INFORMATION
•
•
•
•
•
Warning
Internal parts of the device reach high temperatures. Use caution when
accessing the chamber.
Keep out of reach of children.
Do not dismantle the device for the cleaning and maintenance
instructions, which is beyond of warranty service.
Do not touch the heating cup for at least 10 minutes after use as it will
be very hot.
Use only provided power supply to charge battery, use of any other
power supply is dangerous and which can't call for warranty.
This vaporizer is designed for legal dry herb as an aroma therapy
device, not for Tobacco use. Refrain from using this product if you are
under the legal smoking age in your state, pregnant or nursing. This
product is not an aid for smoking cessation.

16
WARRANTY INFORMATION
The device has 6 moths limited warranty which covers your vaporizer
against defects in manufacturing, parts and labor. If any quality issue
is during the warranty coverage, we will fix or replace it. The unit must
be returned in its original packaging along with receipt of purchase.
