Dacor DTT48 960 Series User manual

User Manual
Rangetop
DTT48*960**/DTT36*960**
DG68-01474A-01
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 1FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 1 2023-04-25 오후 6:03:352023-04-25 오후 6:03:35

English2
WARNING
Never Operate the Top Surface Cooking Section of this Appliance
Unattended
• Failure to follow this warning statement could result in fire,
explosion, or burn hazard that could cause property damage,
personal injury, or death.
• If a fire should occur, keep away from the appliance and
immediately call your fire department.
DO NOT ATTEMPT TO EXTINGUISH AN OIL / GREASE FIRE WITH
WATER.
WARNING : If the information in this manual is not followed
exactly, a fire or explosion may result causing property damage,
personal injury or death.
• DO NOT store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
• WHAT TO DO IF YOU SMELL GAS
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch.
- DO NOT use any phone in your building.
- Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
- If you cannot reach your gas supplier, call the fire department.
• Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 2FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 2 2023-04-25 오후 6:03:352023-04-25 오후 6:03:35

English 3
Regulatory Notice
1. Radio Apparatus Notice
CAUTION
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
The remote enable equipment installed on this product complies
with Part 15 of FCC Rules and Innovation, Science and Economic
Development Canada’s license-exempt RSS(s). Operation is Subject to
following two conditions:
1) This equipment may not cause harmful interference, and
2) This equipment must accept any interference received including
interference that cause undesired operation.
For products available in the US/Canadian markets, only channels
1~11 are available. You cannot select any other channels.
1. Radio Apparatus STATEMENT:
This equipment has been tested and found to comply within the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules and Canadian ICES-003. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 3FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 3 2023-04-25 오후 6:03:352023-04-25 오후 6:03:35

English4
• Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment and receiver
• Connecting the equipment to an outlet that is on a different circuit
than the radio or TV
• Consulting the dealer or an experienced radio/TV technician for
help.
RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC and IC RSS-102 radiation exposure
limits set forth for an uncontrolled environment. This equipment
should be installed and operated so there is at least 8 inches (20 cm)
between the radiator and your body. This device and its antenna(s)
must not be co-located or operated in conjunction with any other
antenna or transmitter.
Regulatory Notice
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 4FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 4 2023-04-25 오후 6:03:352023-04-25 오후 6:03:35

English 5
To Our Valued Customer:
Congratulations on your purchase of the very latest in Dacor products! Our unique
combination of features, style and performance make us a great addition to your home.
In order to familiarize yourself with the controls, functions and full potential of your new
Dacor Appliance, read this use and care manual thoroughly, beginning with the Before you
begin section.
All Dacor appliances are designed and manufactured with quality and pride, while working
within the framework of our company value. Should you ever experience a problem with
your product, please first check the Troubleshooting section of this manual for guidance. It
provides useful suggestions and remedies prior to calling for service.
Valuable customer input helps us to continuously improve our products and services, so
please feel free to contact our Customer Service Team for assistance with any of your
product support needs.
Dacor Customer Assurance
• USA
Samsung Electronics America, Inc.
85 Challenger Road
Ridgefield Park, NJ 07660
• Canada
Samsung Electronics Canada Inc.
2050 Derry Road West, Mississauga,
Ontario L5N 0B9 Canada
Telephone: [phone](USA), 844-509-4659(Canada)
Hours of Operation: Mon – Fri, 8:00 a.m. to 8:00 p.m. Pacific Time
Website: www.dacor.com
Thank you for choosing Dacor for your home. We are a company built by families for
families, and we are dedicated to serving yours. We are confident that your new Dacor
product will deliver a high level of performance and enjoyment for many years to come.
Sincerely,
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 5FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 5 2023-04-25 오후 6:03:362023-04-25 오후 6:03:36

Contents
English6
Contents
Contents
Before you begin 8
Important 8
About this manual 8
Important note to the installer 8
Important note to the consumer 9
Important note to the servicer 9
Important safety instructions 10
Read all instructions before using this appliance 10
Symbols used in this manual 10
California Proposition 65 Warning 10
Commonwealth of Massachusetts 10
General safety 11
Fire safety 12
Gas safety 13
Electrical and grounding safety 14
Installation safety 15
Location safety 16
Rangetop safety 17
Usage in high altitude area 18
Overview 19
Layout 19
What’s included 20
Using the Rangetop 21
Burners 21
Special rangetop features 22
Ignition 23
Cookware 25
Grates 27
Griddle (Additional purchase Accessories) 28
Wok Ring 29
Using the Smart Connect feature 30
Using the hood control feature 32
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 6FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 6 2023-04-25 오후 6:03:362023-04-25 오후 6:03:36

English 7
ContentsContents
Care and maintenance 34
Cleaning the rangetop surface 34
Stainless steel surfaces 35
Control knobs 36
Burner grates and components 37
Burner caps and heads 38
Burner bases 39
Electrodes 39
Grates and Wok Ring 40
Burner head and cap replacement 40
Troubleshooting 43
Checkpoints 43
Warranty and Service 45
Warranty 45
Appendix 48
Model name & serial number 48
Open Source Announcement 49
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 7FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 7 2023-04-25 오후 6:03:362023-04-25 오후 6:03:36

English8
Before you begin
Before you begin
Important
• The overall design and/or accessories
may differ with the model.
Installer
• To promote safety and minimize
problems, read this manual thoroughly
before starting the installation. Leave
this manual with the user.
• Write the appliance’s model/serial
numbers in this manual for service/
maintenance reference.
User
• Keep this manual for personal reference
and for that of inspectors, service
personnel, etc.
About this manual
READ THESE INSTRUCTIONS COMPLETELY AND CAREFULLY.
Important note to the installer
• Read all instructions contained in these installation instructions before installing the
appliance.
• Remove all packing materials from the appliance compartments before connecting the
electric and gas supply to the appliance.
• Observe all governing codes and ordinances.
• Be sure to leave these instructions with the consumer.
• Installation of this appliance requires basic mechanical skills.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not covered under the Warranty.
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 8FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 8 2023-04-25 오후 6:03:362023-04-25 오후 6:03:36

English 9
Before you begin
Important note to the consumer
Keep these instructions with your user manual for future reference.
• As when using any appliance generating heat, there are certain safety precautions you
should follow.
• Be sure your appliance is installed and grounded properly by a qualified installer or
service technician.
• Make sure the wall coverings around the rangetop can withstand the heat generated
by the appliance.
• Cabinet storage space above the rangetop burners should be a minimum of 30 in
(76.2 cm).
Important note to the servicer
The electrical diagram is attached inside the burner box.
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 9FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 9 2023-04-25 오후 6:03:362023-04-25 오후 6:03:36

English10
Important safety instructions
Important safety instructions
Read all instructions before using this appliance
• All electrical and gas equipment with moving parts can be dangerous. Be sure to read
the Important Safety Information in this manual. The instructions must be followed to
minimize the risk of property damage, injury, or death.
• Keep this manual in a handy place so you can refer to it as needed.
Symbols used in this manual
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in electric shock, personal injury, or property
damage.
NOTE
Useful tips and instructions
These warning icons and symbols are intended to prevent property damage and personal
injury. Follow them explicitly.
California Proposition 65 Warning
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Commonwealth of Massachusetts
This product must be installed by a licensed plumber or gas fitter qualified or licensed by
the State of Massachusetts. When using ball-type gas shut-off valves, you must use the
T-handle type. Multiple flexible gas lines must not be connected in series.
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 10FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 10 2023-04-25 오후 6:03:362023-04-25 오후 6:03:36

English 11
Important safety instructions
General safety
WARNING
To reduce the risk of fire, electric shock, personal injuries, and/or death, observe the
following precautions.
• Do not touch any surface, component, or mechanism of the appliance during or
immediately after cooking.
• Learn where and how to shut off the valve that feeds gas to the appliance.
• Do not let children near the appliance. Do not let children play with the appliance or
any part(s) of the appliance. Do not leave children unattended in the kitchen when
the appliance is in use. For children’s safety, we recommend utilizing the control/door
lockout feature.
• Remove all packaging before operating the appliance to keep this material from
catching fire. Keep all packaging away from children. Properly dispose of packaging as
soon as the rangetop is unpacked.
• Do not keep objects of interest to children on or around the appliance.
• Do not operate the rangetop if it is damaged in any way, if it malfunctions, or is
missing parts.
• Do not use the rangetop as a space heater. Use the rangetop for cooking only.
• Use only dry pot holders.
• Do not use the appliance to heat sealed food containers. Do not use the appliance to
heat sealed food containers.
• When disposing of the appliance, cut off the power cord to prevent children and
animals from getting trapped.
• Unplug the appliance before service/maintenance.
• Make sure all meat and poultry is cooked thoroughly. Meat should always be cooked
to an internal temperature of 160 °F (71 °C). Poultry should always be cooked to an
internal temperature of 180 °F (82 °C).
• Keep the appliance area clear and free of combustible materials, gasoline, and other
flammable vapors and liquids.
• Teach children not to touch or play with the controls or any part of the appliance.
• An air curtain or other overhead range hood, which operates by blowing a downward
airflow onto a range, shall not be used in conjunction with a gas range unless the
hood and range have been designed and tested in accordance with the Standard
for Domestic Gas Ranges, ANSI Z21.1 • CSA1.1, and listed by an independent testing
laboratory for combination use.
WARNING
NEVER use this appliance as a space heater to heat or warm the room. Doing so may
result in carbon monoxide poisoning and overheating of the oven.
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 11FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 11 2023-04-25 오후 6:03:362023-04-25 오후 6:03:36

English12
Important safety instructions
Important safety instructions
Fire safety
WARNING
To reduce the risk of fire, electric shock, personal injury, or death, observe these
precautions:
• Do not store/place/use combustible materials (e.g., paper, plastic, pot holders, linens,
gasoline, alcohol) near the appliance.
• Do not wear loose fitting or hanging garments while using the appliance.
• To avoid grease buildup, regularly clean the vents.
• Do not let pot holders or other flammable materials touch a heating element. Do not
use a towel or other bulky cloth in place of a pot holder.
• Do not douse a grease fire with water. Instead, turn off the heat source, and smother
the fire with a tight-fitting lid, or use a multi-purpose, dry-chemical or foam
extinguisher.
• Do not heat unopened food containers. The buildup of pressure may cause the
containers to burst and result in injury.
• Do not leave items such as paper, cooking utensils or food on the appliance when not
in use. Items on the appliance can ignite.
• Do not put any combustible material or items around the appliance.
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 12FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 12 2023-04-25 오후 6:03:362023-04-25 오후 6:03:36

English 13
Important safety instructions
Gas safety
WARNING
To reduce the risk of fire, electric shock, personal injury, or death, observe these
precautions:
If you smell gas:
• Close the valve and do not use the appliance.
• Do not light a match, candle, or cigarette.
• Do not turn on any gas or electric appliances.
• Do not touch any electrical switches or plug in a power cord.
• Do not use any phone in your building.
• Evacuate everyone from the building.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the fire department.
Checking for gas leaks
• Leak-testing the appliance must be done according to the manufacturer’s instructions.
Do not use a flame to check for gas leaks. Use a brush to spread a soap-and-water
solution around the area you are checking. If there is a gas leak, small bubbles will
appear in the solution.
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 13FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 13 2023-04-25 오후 6:03:362023-04-25 오후 6:03:36

English14
Important safety instructions
Important safety instructions
Electrical and grounding safety
WARNING
To reduce the risk of fire, electric shock, personal injury, or death, observe these
precautions:
• Plug the appliance into a grounded 3-prong outlet.
• Do not remove the ground prong.
• Do not use an adapter or an extension cord.
• Do not use a damaged power plug, power cord, or loose power outlet.
• Do not modify the power plug, cord, or outlet.
• Do not put a fuse in a neutral or ground circuit.
• Use a dedicated 120-volt, 60-Hz, 20-amp, AC, fused electrical circuit for this appliance.
A time-delay fuse or circuit breaker is recommended. Do not plug more than one
appliance into this circuit.
• Do not connect the ground wire to plastic plumbing lines, gas lines, or hot water pipes.
• This appliance must be Earth grounded. If the appliance malfunctions or breaks down,
grounding reduces the risk of electric shock by providing a safe path for the current.
This appliance’s power cord has a grounding plug, which must be firmly plugged into
an outlet that is properly installed and grounded according to local regulations. If you
are not sure your electrical outlet is properly grounded, have it checked by a licensed
electrician.
• The appliance is supplied with a 3-pronged grounded plug. This cord must be plugged
into a mating, grounded 3-prong outlet that meets all local codes and ordinances.
If codes permit the use of a separate ground wire, we recommend that a qualified
electrician determine the proper path for this ground wire.
• Electrical service to the rangetop must conform to local codes. Barring local codes,
it should meet the latest ANSI/NFPA No. 70 – Latest Revision (for the U.S.) or the
Canadian Electrical Code CSA C22.1 – Latest Revisions.
• The appliance owner shall ensure that the proper electrical service is provided for the
appliance.
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 14FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 14 2023-04-25 오후 6:03:362023-04-25 오후 6:03:36

English 15
Important safety instructions
Installation safety
WARNING
To reduce the risk of fire, electric shock, personal injury, or death, observe these
precautions:
• The appliance should be installed and properly grounded by a qualified installer, as
specified in the Installation Instructions. Adjustments and service should be performed
only by qualified installer or service technician.
• Do not try to service/modify/replace the appliance or any part of it unless specifically
recommended in this manual. All other service should be performed by a qualified
technician.
• Use only new, flexible connectors when installing the appliance.
• Due to the size and weight of the appliance, have two or more people move the
appliance.
• Remove all tape and packaging materials.
• After unpacking the appliance, remove all accessories from inside and around it.
(Cautiously handle the heavy grates and griddles.)
• Make sure no parts came loose during shipping.
• Make sure your rangetop is correctly installed / adjusted by a qualified service
technician or installer for the type of gas (natural or LP) you will use.
• Installation of this appliance must conform with local codes or, in the absence of
local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA.54, latest edition. In
Canada, installation must conform with the current Natural Gas Installation Code, CAN/
CGA-B149.1, or the current Propane Installation Code, CAN/CGA-B149.2, and with local
codes where applicable. This rangetop has been design-certified by ETL according to
ANSI Z21.1, latest edition, and Canadian Gas Association according to CAN/CGA-1.1,
latest edition.
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 15FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 15 2023-04-25 오후 6:03:362023-04-25 오후 6:03:36

English16
Important safety instructions
Important safety instructions
Location safety
WARNING
To reduce the risk of fire, electric shock, personal injuries, and/or death, observe the
following precautions.
• This appliance is for indoor, household use only. Do not install the appliance outdoors
or anywhere that it will be exposed to weather/water or wind/strong drafts.
• Do not install the appliance in a place which is exposed to a strong draft.
• Select a level, well-constructed floor that can support the appliance’s weight. Synthetic
flooring, such as linoleum, must withstand 180 °F (82 °C) temperatures without
shrinking, warping, or discoloring. Do not install the appliance directly over interior
kitchen carpeting unless a sheet of ¼ inch plywood or a similar insulator is placed
between the appliance and carpeting.
• Select a location where a grounded, 3-prong outlet is easily accessible.
• If the appliance is located near a window, do not hang long curtains or paper blinds on
that window.
• For the appliance to ventilate properly, make sure the appliance’s vents are not
blocked, and that there is enough clearance at the top, back, sides, and underneath the
appliance. The vents allow the necessary exhaust for the appliance to operate properly
with correct combustion.
• Make sure the wall coverings around the appliance can withstand heat up to 200 °F
(93 °C) generated by the appliance.
• Cabinet storage above the surface of the appliance should be avoided. If cabinet
storage above the appliance is necessary, allow a minimum clearance of 30 inches
(76.2 cm) between the cooking surface and the bottom of the cabinets or install a range
hood that projects horizontally a minimum of 5 inches (12.7 cm) beyond the bottom of
the cabinets.
• Locate the appliance out of kitchen traffic paths and drafty locations to prevent poor
air circulation.
• If the appliance is located near a window, NEVER hang long curtains or paper blinds
on that window. They could blow over the surface burners and ignite, causing a fire
hazard.
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 16FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 16 2023-04-25 오후 6:03:362023-04-25 오후 6:03:36

English 17
Important safety instructions
Rangetop safety
WARNING
To reduce the risk of fire, electric shock, personal injury, or death, observe these
precautions:
• Make sure all burners are off when not in use.
• Do not use aluminium foil to line the grates or any part of the rangetop. This can cause
carbon monoxide poisoning. Aluminum foil linings may also trap heat, causing a fire
hazard. Do not leave burners unattended on medium or high heat settings.
• Before igniting, make sure all burner caps are properly in place and all burners are
level.
• Always use the LITE position when igniting the burners and make sure the burners
have ignited. If ignition fails, turn the knob to Off and wait until the gas has dissipated.
• When you set a burner to simmer, do not turn the knob quickly. Make sure the flame
stays on.
• This appliance is designed for use with a wok or wok ring attachment.
• To flame food, you must have a ventilation hood. When you flame food, the hood must
be on.
• Before removing or changing cookware, turn off the burners.
• Remove food and cookware immediately after cooking.
• Before removing any parts of the burner for cleaning, make sure the rangetop is off
and completely cool.
• After cleaning the burner spreader, make sure it is completely dry before re-
assembling.
• Make sure the spark mark on the dual burner spreader is placed beside the electrode
when it is assembled.
• To avoid carbon monoxide poisoning, do not pour water into the rangetop well while
cleaning.
• Select cookware that is designed for rangetop cooking. Use cookware that is large
enough to cover the burner grates. Adjust the burner flames so that the flames do not
extend beyond the bottom of the cookware.
• To avoid cookware discoloration, deformity, and/or carbon monoxide poisoning, do not
use cookware that is substantially larger than the grate.
• Make sure cookware handles are turned to the side or rear of the rangetop, but not
over other surface burners.
• Stand away from the rangetop while frying.
• Always heat frying oils slowly, and watch as they heat. If you are frying foods at high
heat, carefully watch during the cooking process. If you are going to use a combination
of fats or oils when frying, mix them together before heating.
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 17FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 17 2023-04-25 오후 6:03:362023-04-25 오후 6:03:36

English18
Important safety instructions
Important safety instructions
• Use a deep-fryer thermometer whenever possible. This prevents overheating the fryer
beyond the smoking point.
• Use a minimum amount of oil when shallow pan-frying or deep-frying. Avoid cooking
unthawed food or food with excessive amounts of ice.
• Before moving cookware full of fats or oils, make sure it has completely cooled.
• To prevent delayed eruptive boiling, always allow heated liquids to stand at least 20
seconds after you have turned off the burner so that the temperature in the liquid can
stabilize. In the event of scalding, follow these first aid instructions:
1. Immerse the scalded area in cool or lukewarm water for at least 10 minutes.
2. Do not apply any creams, oils, or lotions.
3. Cover with a clean, dry cloth.
• Do not wear loose or hanging garments when using the appliance. They could ignite
and burn you if they touch a surface burner.
• Never leave plastic items on the appliance. Hot air from the vent can melt or ignite
plastic items or cause a build up of dangerous pressure in closed plastic containers.
• Do not place portable appliances, or any other object other than cookware on the
appliance. Damage or fire could occur if the appliance is hot.
• Always make sure foods being fried are thawed and dry. Moisture of any kind can
cause hot fat to bubble up and over the sides of the pan.
• Always make sure the controls are Off and the grates are cool before you remove them
to prevent any possibility of being burned.
• Do not put any combustible material or items around the appliance.
• Take care that your hands do not touch the burners when they are on. Turn off the
burners when you change a pan or pot.
• To warm liquid such as sauces, stir it while warming.
Usage in high altitude area
• This appliance has been tested for operation up to an altitude of 7,800 ft elevation
above sea level.
• If desired, for altitudes above 2,000 ft elevation above sea level, adjustments can
be made to the cooktop burners for low flame settings. If flame performance is
satisfactory, adjustment will not be required.
• See the LP conversion instruction for information about adjustment for low flame
settings.
* However, 36" Models (Rangetop and Pro-Range) should not be used in high altitude
environments.
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 18FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 18 2023-04-25 오후 6:03:362023-04-25 오후 6:03:36

English 19
Overview
Overview
Layout
36" Model: DTT36*960**
01
02
03
04
01 Grate 02 Surface burners
03 Knob (Shower lighting) 04 Surface burner knobs (6 pcs)
48" Model: DTT48*960**
01
02
03
04
01 Grate 02 Surface burners
03 Knob (Shower lighting) 04 Surface burner knobs (6 pcs)
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 19FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 19 2023-04-25 오후 6:03:372023-04-25 오후 6:03:37

Overview
English20
Overview
What’s included
Parts list - DTT36*960**
Grate (3) Burner heads (6) and
Burner caps* (8)
Wok Ring
Parts list - DTT48*960**
Grate (3) Burner heads (6) and
Burner caps* (8)
Wok Ring
The rangetop is supplied with two different types of burner caps (brass and porcelain) to
suit the customer’s preference.
FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 20FULL_RANGE TOP_DTT48T960GS_DG68-01474A-01_EN+MES+CFR.indb 20 2023-04-25 오후 6:03:372023-04-25 오후 6:03:37
