Dacor DTT48M976L Series User manual

User Manual
Modernist Rangetop
DTT48M976L*/DTT36M974L*
Dacor Part No. 112139 Rev A

Contents
English2
Contents
Contents
Before you begin 5
Important 5
About this manual 5
Important note to the installer 5
Important note to the consumer 6
Important note to the servicer 6
Regulatory Notice 7
Important safety instructions 10
Overview 20
Layout 20
What’s included 21
Using the rangetop 23
Burners 23
Special cooktop features 24
Ignition 25
Cookware 27
Grates 29
Griddle 30
Wok grate 32
Using the iQ Connect feature 33
Using the hood control feature 35
Care and maintenance 37
Cleaning the cooktop surface 37
Stainless steel surfaces 38
Control knobs 39
Burner grates and components 40
Burner caps and heads 41
Burner bases 42
Electrodes 42
Grates and wok grate 43
Burner head and cap replacement 43

English 3
Contents
Troubleshooting 47
Checkpoints 47
Warranty and Service 49
Warranty 49
Appendix 52
Model name & serial number 52
Open Source Announcement 53

English4
To Our Valued Customer:
Congratulations on your purchase of the very latest in Dacor® products! Our unique
combination of features, style and performance make us The Life of the Kitchen™, and a
great addition to your home.
In order to familiarize yourself with the controls, functions and full potential of your new
Dacor Appliance, read this use and care manual thoroughly, beginning with the Before you
begin section.
All Dacor appliances are designed and manufactured with quality and pride, while working
within the framework of our company value. Should you ever experience a problem with
your product, please first check the Troubleshooting section of this manual for guidance. It
provides useful suggestions and remedies prior to calling for service.
Valuable customer input helps us to continuously improve our products and services, so
please feel free to contact our Customer Service Team for assistance with any of your
product support needs.
Dacor Customer Service Team
14425 Clark Avenue
City of Industry, CA 91745
Telephone: [phone]
Fax: [phone]
Hours of Operation: Monday through Friday 6:00 A.M. to 5:00 P.M. Pacific Time
Website: www.Dacor.com
Thank you for choosing Dacor for your home. We are a company built by families for
families, and we are dedicated to serving yours. We are confident that your new Dacor
product will deliver a high level of performance and enjoyment for many years to come.
Sincerely,

English 5
Before you begin
Before you begin
Important
Overall design/accessories may differ
with the model.
Installer
•For safety and to minimize problems,
read this manual thoroughly before
installation.
•Write the rangetop model/serial
numbers in this manual, and leave it
with the owner.
User
Keep this manual for personal reference
and for that of inspectors, service
personnel, etc.
About this manual
READ THESE INSTRUCTIONS COMPLETELY AND CAREFULLY.
Important note to the installer
•Read this manual thoroughly before installing the appliance.
•Remove all packing material from the rangetop before connecting the electric and
gas supply.
•Observe all governing codes and ordinances.
•Leave this manual with the consumer.
•Installation of this appliance requires basic mechanical skills.
•The installer shall ensure proper installation.
•The warranty does not cover appliance failure due to improper installation.

English6
Before you begin
Before you begin
Important note to the consumer
Keep this manual with your installation manual for future reference.
•All heat-generating appliances require you to follow certain safety precautions.
•Ensure the rangetop is properly installed/grounded by a qualified installer or service
technician.
•Ensure the surrounding wall coverings can withstand the heat from the rangetop.
•Allow at least 30 in. (76.2 cm) from the rangetop to the base of the cabinets above.
Important note to the servicer
The electrical diagram is attached inside the burner box.

English 7
Regulatory Notice
Regulatory Notice
1. FCC Notice
CAUTION
FCC CAUTION: Any changes or modifications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of FCC Rules. Operation is Subject
to following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received including
interference that cause undesired operation.
For products available in the US/Canadian markets, only channels
1–11 are available. You cannot select any other channels.
FCC STATEMENT:
This equipment has been tested and found to comply within the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
•Reorienting or relocating the receiving antenna
•Increasing the separation between the equipment and receiver

English8
Regulatory Notice
Regulatory Notice
•Connecting the equipment to an outlet that is on a different circuit
than the radio or TV
•Consulting the dealer or an experienced radio/TV technician for
help.
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna or
transmitter.
2. IC Notice
The term “IC” before the radio certification number only signifies
that Industry Canada technical specifications were met. Operation
is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the
device.
This Class B digital apparatus complies with Canadian ICES-003.
For products available in the US/Canadian markets, only channels
1–11 are available. You cannot select any other channels.

English 9
Regulatory Notice
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure limits
set forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna or
transmitter.
General safety instructions
This unit has been tested and found to comply with the limits for
a class B digital device, pursuant to Part 18 of the FCC rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This unit generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this unit does cause harmful interference to
radio or television reception, which can be determined by turning
the unit off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorienting or relocating the receiving antennae.
•Increasing the distance between the unit and receiver.
•Connecting the equipment to an outlet that is on a different circuit
than the radio or TV.

English10
Important safety instructions
Important safety instructions
WARNING: Failure to follow the instructions in this manual exactly
may cause a fire or explosion, and, consequently, property damage,
personal injury, or death.
•DO NOT keep or use gasoline or other flammable products near
this appliance.
•IF YOU SMELL GAS:
-DO NOT light any appliances.
-DO NOT touch any electrical switches.
-DO NOT use any phone in your building.
-Immediately call your gas supplier from a neighbor’s phone,
and follow the supplier’s instructions. (If you cannot reach
your gas supplier, call the fire department.)
•Installation and service must be performed by a qualified
installer, service agency, or the gas supplier.
Read all instructions before using this appliance
•All electrical and gas equipment with moving parts can be dangerous. Be sure to read
the Important Safety Information in this manual. The instructions must be followed to
minimize the risk of property damage, injury, or death.
•Keep this manual in a handy place so you can refer to it as needed.
Symbols used in this manual
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in electric shock, personal injury, or property
damage.
NOTE
Useful tips and instructions

English 11
Important safety instructions
These warning icons and symbols are intended to prevent property damage and personal
injury. Follow them explicitly.
State of California Proposition 65 warning (US only)
This product contains chemicals known to the State of California to cause cancer and
birth defects or other reproductive harm.
Gas appliances can cause low-level exposure to Proposition 65-listed substances
(e.g., benzene, carbon monoxide, formaldehyde, soot) cause by the incomplete
combustion of LP or natural gas.
Commonwealth of Massachusetts
This product must be installed by a licensed plumber or gas fitter qualified or licensed
by the State of Massachusetts. When using ball-type gas shut-off valves, you must use
the T-handle type. Multiple flexible gas lines must not be connected in series.
General safety
WARNING
To reduce risk of fire, electric shock, personal injury, and death:
•Do not touch any part of the appliance during or immediately after cooking.
•Learn the location of and how to shut off the rangetop's gas-intake valve.
•Do not let children near the rangetop or leave them unattended in the kitchen when
the rangetop is in use. Dacor recommends activating the control/door lockout feature.
•Remove and dispose of packaging as soon as the rangetop is unpacked. Do not let
children play with the packaging.
•Do not keep objects of interest to children on or around the rangetop.
•Do not operate the rangetop if it is damaged, if it malfunctions, or if parts are missing.

English12
Important safety instructions
Important safety instructions
•Use only dry pot holders.
•Do not heat sealed food containers on the rangetop.
•When disposing of the rangetop, cut off the power cord.
•Unplug the rangetop before service/maintenance.
•Ensure all meat and poultry is cooked thoroughly. Meat should always be cooked to
an internal temperature of 160 °F (71 °C), and poultry to 180 °F (82 °C).
•Do not leave/store combustible material and liquids on/near the rangetop.
•Teach children not to touch or play with the controls or any part of the appliance.
•Air curtains or range hoods that blow air downward shall not be used with a gas
range unless the hood and range are designed and tested according to the Standard
for Domestic Gas Ranges, ANSI Z21.1 • CSA1.1, and listed by an independent testing
laboratory for combination use.
WARNING
NEVER use this appliance as a space heater to heat or warm the room. Doing so may
result in carbon monoxide poisoning and overheating of the oven.

English 13
Important safety instructions
Fire safety
WARNING
To reduce risk of fire, electric shock, personal injury, and death:
•Do not wear loose-fitting or hanging garments while using the rangetop.
•To avoid grease buildup, regularly clean the vents.
•Do not let pot holders or other flammable materials touch a heating element. Do
not use a towel or other bulky cloth in place of a pot holder.
•In case of a grease fire, turn off the burner, and smother the fire with a tight-fitting
lid, or use a multi-purpose, dry-chemical or foam extinguisher. (Do not use water.)
•Remove paper, utensils, food, and other items from the rangetop when not in use.

English14
Important safety instructions
Important safety instructions
Gas safety
WARNING
To reduce risk of fire, electric shock, personal injury, and death:
If you smell gas:
•Close the valve and do not use the appliance.
•Do not light a match, candle, or cigarette.
•Do not turn on any gas or electric appliances.
•Do not touch any electrical switches or plug in a power cord.
•Do not use any phone in your building.
•Evacuate everyone from the building.
•Immediately call your gas supplier from a neighbor’s phone. Follow the supplier’s
directions.
• If you cannot reach your gas supplier, call the fire department.
Checking for gas leaks
Leak-testing the appliance must be done as the manufacturer directs. Do not use a
flame to check for gas leaks. With a brush, spread a soap-and-water solution around
the area in question. If there is a gas leak, small bubbles will appear in the solution.

English 15
Important safety instructions
Electrical and grounding safety
WARNING
To reduce risk of fire, electric shock, personal injury, and death:
•Plug the appliance in to a grounded, 3-prong outlet.
•Do not remove the ground prong.
•Do not use an adapter or an extension cord.
•Do not use a damaged power plug/cord, or loose power outlet.
•Do not modify the power plug, cord, or outlet.
•Do not put a fuse in a neutral or ground circuit.
•Use a dedicated 120-volt, 60-Hz, 20-amp, AC, fused electrical circuit. A time-delay
fuse or circuit breaker is recommended. Plug only the rangetop into this circuit.
•Do not connect the ground wire to plastic plumbing, gas, or hot-water lines.
•The rangetop must be grounded. If it malfunctions, grounding provides a safe path for
the current. The rangetop’s grounding plug must be firmly plugged into an outlet that
is properly installed and grounded per local regulations. If you are unsure your outlet
is properly grounded, have it checked by a licensed electrician.
•If codes allow a separate ground wire, a qualified electrician should determine the
proper path for this ground wire.
•Electrical service to the rangetop must conform to local codes, in the absence of
which, it should meet the latest ANSI/NFPA No. 70 – Latest Revision (for the U.S.) or
the Canadian Electrical Code CSA C22.1 – Latest Revisions.
•The rangetop owner shall ensure that proper electrical service is provided.

English16
Important safety instructions
Important safety instructions
Installation safety
WARNING
To reduce risk of fire, electric shock, personal injury, and death:
•The rangetop should be installed and grounded by a qualified installer, per the
Installation Instructions. Adjustments and service should be performed only by a
qualified installer or service technician.
•Do not service/modify/replace the rangetop or any part of it except as recommended
in this manual. All other service should be performed by a qualified technician.
•Use only new, flexible connectors when installing the rangetop.
•Due to the its size and weight, at least two people should move the rangetop.
•After removing all packing material, remove all accessories inside and out.
(Cautiously handle the heavy grates and griddles.)
•Verify that no parts came loose during shipping.
•Verify that the rangetop is installed/adjusted by a qualified service technician or
installer for the type of gas (natural or LP) you will use.
•Installation must conform with local codes or, in their absence, with the National Fuel
Gas Code, ANSI Z223.1/NFPA.54, latest edition. In Canada, installation must conform
with the current Natural Gas Installation Code, CAN/CGA-B149.1, or the current
Propane Installation Code, CAN/CGA-B149.2, and with applicable local codes. This
rangetop is design-certified by ETL according to ANSI Z21.1, latest edition, and
Canadian Gas Association according to CAN/CGA-1.1, latest edition.

English 17
Important safety instructions
Location safety
WARNING
To reduce risk of fire, electric shock, personal injury, and death:
•Only install the rangetop indoors away from weather, water, wind, and strong drafts.
•Select a location where a grounded, 3-prong outlet is easily accessible.
•If the rangetop is near a window, do not hang long curtains or paper blinds that may
blow over/onto the rangetop.
•For the rangetop to ventilate properly, its vents must not be blocked, and that there is
enough clearance all around. The vents allow the necessary exhaust for the appliance
to operate properly with correct combustion.
•Ensure the wall coverings near the appliance can withstand heat up to 200 °F (93 °C).
•Avoid cabinet storage above the rangetop. If such storage is unavoidable, leave at
least 30 in. (76.2 cm) from cooking surface to cabinet bottom, or install a hood that
projects at least 5 in. (12.7 cm) beyond the cabinet bottom.

English18
Important safety instructions
Important safety instructions
Rangetop safety
WARNING
To reduce risk of fire, electric shock, personal injury, and death:
•Ensure all burners are off when not in use.
•Do not use aluminium foil to line the grates or any part of the rangetop.
•Do not leave burners unattended on medium or high heat settings.
•Before igniting, ensure all burner caps are properly in place and all burners are level.
•Always use the LITE position to ignite the burners, then ensure the burners ignite. If
ignition fails, turn the knob to OFF, wait until the gas dissipates, then try again.
•When setting a burner to simmer, turn the knob slowly. Ensure the flame stays on.
•Place only cookware on the rangetop.
•Flame food only under an active ventilation hood.
•Turn off burners before removing cookware from the burners.
•Remove food and cookware immediately after cooking.
•Before disassembling a burner for cleaning, ensure all burners are off and the
rangetop is completely cool.
•After cleaning the burner spreader, ensure it is completely dry before re-assembling.
•When assembling a burner, ensure the spark mark on the dual burner spreader is be
the electrode.
•Do not pour water into the rangetop drip basin.
•Use cookware that is designed for rangetop cooking and is large enough to cover the
burner grates. Adjust burner flames so they remain under the cookware.
•To avoid cookware discoloration, deformity, and/or carbon monoxide poisoning, do
not use cookware that is substantially larger than the grate.
•Turn cookware handles away from surface burners and the rangetop front edge.
•Stand back from the range while frying.
•Heat frying oils slowly, and watch as they heat. If frying at high heat, closely watch
the cooking process. If combining fats or oils when frying, mix them before heating.

English 19
Important safety instructions
•Use a deep-fryer thermometer if possible to monitor the oil temperature.
•Use minimal oil when frying.
•Do not fry frozen food or partially thawed food that it clumped with ice.
•Before moving fat-/oil-filled cookware, make sure it has completely cooled.
•To prevent delayed eruptive boiling, let hot liquids stand at least 20 seconds after
turning off the burner so the liquid temperature can stabilize. In case of scalding:
1. Immerse the burn in cool water for at least 10 minutes.
2. Do not apply creams, oils, or lotions.
3. Cover with a clean, dry cloth.
•Center pots on the grates. Do not put a pot larger than 9” in diameter on a rear
burner. Oversized pots may impede airflow, making the flame sputter and burn
inefficiently.
•Do not wear loose or hanging clothing when using the rangetop.
•Never leave plastic on the rangetop. Vented hot air can melt or ignite plastic or
cause a buildup of dangerous pressure in closed plastic containers.
•Put only cookware on the rangetop.
•Thaw and pad food dry before frying. Moisture can cause oil to erupt and overflow.
•Always make sure the controls are OFF and the grates are cool before you remove
them to prevent any possibility of being burned.
•Keep combustible material away from the rangetop.
•Do not touch an active burner. Turn off the burners before moving the cookware.
•Stir sauces and other liquid food while warming.

English20
Overview
Overview
Layout
36" Model: DTT36M974L*
02
04
05
03
01
01 Spill tray 02 Surface burners
03 Knob (Shower lighting) 04 Surface burner knobs (4 pcs)
05 Griddle knob
48" Model: DTT48M976L*
01
02
04
05
03
01 Spill tray 02 Surface burners
03 Knob (Shower lighting) 04 Surface burner knobs (6 pcs)
05 Griddle knob
