Dacor DMT2420 Technical manual

PLANNING
GUIDE
12.2
Specications subject to change without notice. Phone: [phone]www.Dacor.com
Microwave Oven (Black Glass)
and Built-In Trim Kits
DMT2420BK, AMTK, AOMTK
23 15/16”
(60.8 cm)
19 1/4”
(48.9 cm)
13 7/16”
(34.1 cm)
A
B
18 1/8”
(46.0 cm)
1”
(2.5 cm)
AMTK TRIM KIT DIMENSIONS
(USED WITH DISTINCTIVE AND RENAISSANCE SERIES
WALL OVENS)
Trim Kit
Model #
(A) Overall
Width
(B) Opening
Width
Trim Kit
Overlays
Approximate
Shipping Weight
AMTK27 27” (68.6 cm)
24”
(61.0 cm)
Top: 5/8”
(1.6 cm)
Bottom:
3/4”
(1.9 cm)
12 lbs.
AMTK30 30” (76.2 cm) 12 lbs.
AMTK36 36” (91.4 cm) 16 lbs.
AOMTK27 27” (68.6 cm) 17 lbs.
AOMTK30 30” (76.2 cm) 18 lbs.
NOTE:
1. Microwave is supplied with 42” (106.7 cm) power cord
with a three prong grounding plug.
2. 3/4” (1.9 cm) platform (flush with cutout) required.
3. 20” (50.8 cm) minimum interior cabinet depth required
for AMTK and AOMTK built-in trim kits.
4. See the Combination Installation (CI) section if installing
with a wall oven or warming oven.
A
B
18 1/8”
(46.0 cm)
1 1/4”
(3.2 cm)
All tolerances: +1/16”, -0, (+1.6 mm, -0) unless otherwise stated
WARNING
• Observe all governing codes and ordinances during planning
and installation. Contact your local building department for
further information.
• This appliance must be installed in accordance with the
accompanying installation instructions.
Document # PG12-004 Revised 01/24/11 Page 1/1
16 3/4"
(425 cm)
24 3/8" (61.9 cm) 1” Min.*
(2.5 cm)
7/8” Min.*
(2.2 cm)
18” **
(45.7 cm)
4” **
(10.2 cm)
4” **
(10.2 cm)
MICROWAVE INSTALLATION WITH BUILT-IN TRIM KIT
DMT2420 MICROWAVE SPECIFICATIONS
Shipping weight: 46 lbs.
Circuit required: 120 Vac, 15 Amp. dedicated, grounded, 3-prong electrical outlet
Total connected load: 12.5 Amp. @ 120 Vac, 60 Hz.
Interior dimensions: 10 1/4" H x 16 5/8" W x 17 3/4" D, interior walls are recessed
* Minimum spacing: Includes additional space to avoid scraping/vibration.
** 120 Vac 15 Amp. 3-prong electrical outlet must be located in one of the
shaded areas shown unless interior cabinet depth is more than 21"
(53.3 cm).
AOMTK TRIM KIT DIMENSIONS
(USED WITH DISCOVERY SERIES WALL OVENS)
